IMI NORGREN F64G Installation and operating instructions

F64G Filter
Installation & Maintenance Instructions
6/15
I&M/en 8.240.100.01
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. (1999 - I&M8074d) © 2015 IMI International s.r.o.
Fluid: Compressed air
Maximum pressure:
Guarded transparent bowl: 10 bar (150 psig)
Metal bowl: 17 bar (250 psig)
Operating temperature*:
Transparent bowl: –20° ... +50°C (0° ... +125°F)
Metal bowl: –20° ... +80°C (0° ... +175°F)
* Air supply must be dry enough to avoid ice
formation at temperatures below +2°C (+35°F).
Particle removal: 5 µm, 25 µm or 40 µm filter
element
Air quality: Within ISO 8573-1, Class 3 and
Class 5 (particulates)
Typical flow with 40 µm element, 6,3 bar (90
psig) inlet pressure and 0,5 bar (7 psig) droop
from set: 70 dm3/s (148 scfm)
Automatic drain connection: 1/8”
Automatic drain operating conditions:
Pressure: 0,7 bar (10 psig). Drain opens when
bowl pressure drops below 0,2 bar (3 psig).
Minimum air flow: 1 dm3/s (2 scfm) required to
close drain
Nominal bowl size:0,2 litre (7 fluid oz)
Materials:
Body: Zinc
Bowl:
Metal: Aluminium
Transparent, optional: Polycarbonate
Metal bowl liquid level indicator lens, standard:
Grilamid
Metal bowl sight glass, optional:Pyrex
Element: Sintered plastic
Elastomers: Synthetic rubber
Replacement Items
Service kit, contains required items circled:
4380-200
Prismatic sight glass 4380-040
Pyrex sight glass 4380-041
Filter element, 5 µm 4338-01
Filter element, 40 µm 4338-02
Manual drain 684-84
Automatic drain 3000-97
Mechanical service Indicator (1) 5797-50
Installation
1. Install unit vertically in air line -
• vertically (bowl down),
• with air ow in direction of arrow on body,
• upstream of regulators, lubricators, and cycling
valves,
• as close as possible to the air supply when
used as a main line filter,
• as close as possible to the device being
serviced when used as a final filter.
2. Before assembling the basic unit into the yoke
the port seal o-rings should be lightly
smeared with o-ring grease.
3. Locate clamp ring under lugs on top of yoke,
oer basic unit into yoke with directional
arrows correctly aligned (an interference fit
prevents assembly if misaligned) before
engaging and fully tightening the clamp ring.
4. Turn bowl or bowl guard fully clockwise into
body before pressurizing. Lock symbols on
body and bowl guards must align.
5. Auto-drain units may be fitted with a short
drain pipe and connector, minimum 5 mm
bore, to the G1⁄8 bottom outlet.
A B
C
Servicing
1. Open manual drain to expel accumulated
liquids. Keep liquids below bae (53).
2. To operate automatic drain manually, lift
operating pin in bottom outlet with a blunt
rod.
3. Clean or replace filter element when dirty.
Disassembly
1. Shut o inlet pressure. Reduce pressure in
inlet and outlet lines to zero.
2. For ease of maintenance the unit can be re
moved from the yoke by unscrewing the
clamp ring, which will jack the unit out
downwards.
3. Lift and turn the filter bow counterclockwise
and remove with bowl o-ring.
4. Disassemble in general accordance with
the item numbers on exploded view. Do not
remove the drains or the service indicator
unless replacement is necessary. Remove
and replace only if they malfunction.
Cleaning
1. Partial cleaning of the filter element is possible
by washing the element in soapy water and
blowing out thoroughly with compressed air.
Replacement by a clean element is
recommended. Clean plastic bowl and lens
(45) with warm water only. Clean other parts
with warm water and soap.
2. Rinse and dry parts. Blow out internal
passages in body with clean, dry compressed
air.
3. Inspect parts. Replace those found to be
damaged. Replace plastic bowl with a metal
bowl if plastic bowl shows signs of cracking
or cloudiness.
Assembly
1. Lubricate o-rings with o-ring grease.
2. Assemble the unit as shown on the exploded
view.
3. Torque Table
Torque in
Item N-m (Inch-Pounds)
55 (Filter guide) 2,0 ... 2,7 max (18 ... 25)
4. Assemble bae (53), contact + 1/4 turn.
5. Turn bowl or bowl with guard fully clockwise
into body.
Caution
Water vapor will pass through these units and
could condense into liquid form downstream as
air temperature drops. Install an air dryer if water
condensation could have a detrimental eect on
the application.
Technical features
Option selector
Port
2 1/4”
3 3/8“
4 1/2“
6 3/4
Option
D Service indicator
N None
Bowl
D Metal
P Transparent with guard
R Metal with Pyrex sight glass
Element
1 5 µm
2 25 µm
3 40 µm
Thread
A PTF (1/8 PTF gauge ports)
B ISO Rc taper (1/8 ISO Rc gauge ports)
G ISO G parallel (1/8 ISO Rc gauge ports)
N No thread (basic unit)
F64G – ˙˙˙ – ˙˙˙
Drain
A Automatic
M Manual
Q Manual 1/4 turn
55
56 8
7
62
4
3
5
1
48
32
47
18
31
30
29
43
44
46
45
40
36
38
37
41
42
39
33
35
34
26
22
24
23
27
28
25
19
21
20
54
53

F64G Filter
Installation & Maintenance Instructions
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. (1999 - I&M8074d) © 2015 IMI International s.r.o.
I&M/en 8.240.100.02
6/15
WARNING
These products are intended for use in industrial
compressed air systems only. Do not use these
products where pressures and temperatures can
exceed those listed under Technical Data.
Polycarbonate plastic bowls can be damaged
and possibly burst if exposed to such
substances as certain solvents, strong
alkalies, compressor oils containing ester-based
additives or synthetic oils. Fumes of these
substances in contact with the polycarbonate
bowl, externally or internally, can also result in
damage. Clean with warm water only.
Use metal bowl in applications where a plastic
bowl might be exposed to substances that are
incompatible with polycarbonate.
Before using these products with fluids other
than air, for non industrial applications, or for
life-support systems consult Norgren.
Use in potentially explosive atmospheres
Code of device according EC
directive 94/9/EC Ex II 2 GD c TX
• Only non-ammable gasese to be used as a
medium.
• Surface temperature dependant on process
fluid temperature and ambient temperature
must be below the ignition temperature of the
flammable gas or dust.
• Earth unit and/or pipework to avoid
electrostatic discharge.
• Precautions should be taken to prevent hazard
from adiabatic compression.
• Use wet cloth for cleaning.
• Protect the unit from object falling onto it.
• Avoid contact with corrosive environment.
• For servicing the unit it is recommended to
carry out this work outside of the danger
zone.
• For details of ignition hazard assessment
contact Norgren.
