Impecca Portable Air Conditioner
Users Manual
IPAC-08K—8000 BTU PORTABLE AC
IPAC-10K—10000 BTU PORTABLE AC

Table of Contents:
– Introduction ..................................................................................... p.1
– Safety Precautions................................................................................ p.1
– What’s In The Box................................................................................. p.2
– Installation Accessory Kit Items ................................................................... p.2
– Specications & Warnings ........................................................................ p.3
– Environmental Operating Conditions ............................................................. p.3
– Device parts identication........................................................................ p.4
– Installation Instructions........................................................................... p.5
– Energy Conservation Tips......................................................................... p.6
– Operating Panel Overview........................................................................ p.8
– Operating Instructions ........................................................................... p.9
– Additional Features..............................................................................p.10
– Basic Error Codes & Solutions ....................................................................p.10
– Troubleshooting ................................................................................p.11
– Contact Support ................................................................................p.11
– Care instructions ................................................................................p.12
Regulatory Warnings:
DISPOSAL:
Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special
treatment is necessary.
It is prohibited to dispose of this appliance in domestic household waste.
For disposal, there are several possibilities:
A) The municipality has established collection systems, where electronic waste can be disposed of at
least free of charge to the user.
B) When buying a new product, the retailer will take back the old product at least free of charge.
C) The manufacturer will take back the old appliance for disposal at least free of charge to the user.
D) As old products contain valuable resources, they can be sold to scrap metal dealers.
Wild disposal of waste in forests and landscapes endangers your health when hazardous substances leak
into ground-water and nd their way into the food chain.
CAUTION:
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.

1
INTRODUCTION:
Congratulations on your purchase of an IMPECCA™ Electronic Controlled Portable Air Conditioner. Before
using this product, it is recommended that you familiarize yourself with the features, functions, and opera-
ting procedures described in this manual. Inside you will nd many helpful hints on how to use and maintain
your air conditioner properly. Just a little preventive care on your part can save you a great deal of time and
money over the lifespan of your air conditioner. You will nd many answers to common problems in the
chart of troubleshooting tips.
FEATURES AT A GLANCE:
• Quiet Operation • Ion Filter (select models)
• Energy Saver Function • Sleep mode
• Remote Control with LED • Eco-Friendly Refrigerant
• Remote Personal Temperature Sensor (select models)
SAFETY PRECAUTIONS:
To prevent injury and/or property damage, please familiarize yourself with the following instructions
and safety precautions. Failure to comply with the instructions and cautions mentioned in this manual may
cause harm or damage. The seriousness is classied by the following indications:
IMPORTANT:
• Always contact an authorized service technician for repair or maintenance of this unit.
• This air conditioner is not intended for use by young children or elderly persons without supervision.
• Young children should be advised not to operate the air conditioner.
• If the power cord is to be replaced, replacement work should only be performed by certied or autho-
rized technicians.
• All electrical work must be performed in accordance with the national wiring standards and should only
be performed by authorized personnel.
NOTE: Due to slight modications in production, the instructions, features, and/or descriptions found in this
manual might vary slightly from your product.
SAVE TIME AND MONEY!
If you review our chart of Troubleshooting Tips rst, you may not need to call for service at all.
⚠ WARNING This symbol indicates the possibility of serious injury or death.
⚠ CAUTION This symbol indicates the possibility of injury and/or damage to property.
⊘Never do this.
⍟Always do this.

2
WHAT’S IN THE BOX:
Please verify your box for the following items. Note that some models may not include all items.
1. Air Conditioning Unit
2. Remote control (may dier from photo)
3. User’s Guide
4. Remote control user’s guide
5. Installation kit (see details below)
❶
❸&❹
❷
INSTALLATION ACCESSORY KIT ITEMS:
Your model may not include some optional mounting accessories, as noted by the symbol *. Illustrations
may vary slightly from actual appearance of product.
PART (for illustration only, may not be identical) PART DESCRIPTION: QUANTITY INCLUDED:
Exhaust hose and adapter A
–OR– adapter B 1 set
Wall Exhaust Adapter A* 1 piece (optional)
Round Mouth Adapter B* 1 piece (optional)
Expansion Plug & Wooden Screw* 4 pieces (optional)
Foam Seal 3 pieces
Remote Controller
& Battery 1 piece
Drain hose and adapter* 1 piece (optional)
Avoid damaging your new appliance! If required accessories are missing, please contact technical support.

3
SPECIFICATIONS & WARNINGS:
Carefully review all of these specications and warnings BEFORE operating your air conditioner unit. Failure
to do so may cause damage, injury, or bodily harm including permanent disability and/or death.
WARNING FOR YOUR SAFETY
• Do not store or use gasoline or other ammable vapors/liquids in the vicinity of this or any other appliance.
• Avoid re hazard or electric shock. Do not use an extension cord or an adaptor plug.
Do not remove any prong from the power cord.
WARNING ELECTRICAL INFORMATION
• Be sure your electrical wiring is adequate for the model you have chosen. This information can be found
on the serial plate, which is located on the side of the cabinet and behind the grille.
• Be sure the air conditioner is properly grounded. To minimize shock and re hazards, proper grounding
is important. The power cord is equipped with a three-prong grounding plug for protection against
shock hazards.
• Your air conditioner must be connected to a properly grounded wall receptacle. If the wall receptacle
you intend to use is not adequately grounded or protected by a time delay fuse or circuit breaker, have a
qualied electrician install the proper receptacle.
• Ensure the receptacle is accessible after the unit installation.
ENVIRONMENTAL OPERATING CONDITIONS:
The air conditioner must be operated within the temperature ranges indicated below:
MODE ROOM TEMPERATURE
COOLING F: 62° to 95° | C: 17° to 35°
FAN OR DEHUMIDIFYING F: 55° to 95° | C: 13° to 35°
HEATING (heat pump models) F: 62° to 88° | C: 5° to 30°
HEATING (electrical heating models) F: under 88° | C: under 30°
⍟ ALWAYS DO THIS! ⍟
• Your air conditioner should be used in such a way that it
is protected from moisture. e.g. condensation, splashed
water, etc. Do not place or store your air conditioner where
it can fall or be pulled into water or any other liquid. If unit
is in contact with liquid, unplug immediately.
• Always transport your air conditioner in a vertical position
and stand on a stable, level surface during use.
• Turn o the product when not in use.
• Always contact a qualied person to carry out repairs. If
the supply cord is damaged, it must be repaired by a qual-
ied repairer.
• Keep an air path of at least 12”(30cm) all around the unit
from walls, furniture and curtains.
• If the air conditioner is knocked over during use, turn o
the unit and unplug immediately.
⊘ NEVER DO THIS! ⊘
• Do not operate your air conditioner in a wet room such as
a bathroom or laundry room.
• Do not touch the unit with wet or damp hands or when
barefoot.
• Do not press the buttons on the control panel with any-
thing other than your ngers.
• Do not remove any xed covers. Never use this appliance
if it is not working properly, or if it has been dropped or
damaged.
• Never use the plug to start and stop the unit. Always use
the switch on the control panel.
• Do not cover or obstruct the inlet or outlet grille.
• Do not use hazardous chemicals to clean or come into
contact with the unit. Do not use the unit in the presence
of ammable substances or vapors such as alcohol, insecti-
cides, petrol, etc.
• Do not allow children to operate the unit unsupervised.
• Do not use this product for functions other than those
described in this instruction manual.

4
DEVICE PARTS IDENTIFICATION:
FRONT PANEL MODEL A:
FRONT PANEL MODEL B:
REAR PANEL:
1) Operation panel
2) Air direction blade (automatic)
3) Rolling casters
4) Carrying handles (both sides)
6) Upper air lter (behind the grille)
7) Air outlet
8) Power cord outlet
9) Air intake
10) Drain outlet
11) Air intake
12) Lower Air Filter (behind the grille)
13) Bottom tray drain outlet
1) Operation panel
2) Air direction blade (manual)
3) Remote signal receptor
4) Rolling casters
5) Carrying handles (both sides)

5
INSTALLATION INSTRUCTIONS:
Carefully review all of these instructions BEFORE proceeding to install and operate your air conditioner unit.
Failure to do so may cause damage, injury, or bodily harm including permanent disability and/or death.
LOCATION:
• The air conditioner should be placed on a rm foundation to minimize noise and virbration. For safe and
secure positioning, place the unit on a smooth, level oor strong enough to support the unit.
• The unit has casters to aid placement, but it should only be rolled on smooth, at surfaces. Use caution
when rolling on carpet surfaces. Do not attempt to roll the unit over objects.
• The unit must be placed within reach of a properly rated grounded socket.
• Never place any obstacles around the air inlet or outlet of the unit.
• Allow 1 to 3 feet (30cm to 100cm) of space from the wall with for ecient air-conditioning and prevent
overheating.
EXHAUST HOSE INSTALLATION:
The exhaust hose and adaptor must be installed or removed in accordance with the usage mode.
INSTALLED—Cooling, heat pump, or auto mode
REMOVED—Heating (electric), fan or dehumidify mode
1. Install the window Exhaust adapter B onto the exhaust hose as shown
in Fig. A or Fig. B. Refer to the previous pages for window kit installation.
2. Place the Exhaust hose over against the air outlet opening hook and
at the other end (Figure C) for quick installation.
The exhaust hose can be installed into the wall (ot applicable to the units
without adapter A, expansion plugs and wooden screws of accessories).
1. Prepare a hole in the wall. Install the wall Exhaust adapter A onto the
wall (outside) by using 4 expansion plugs and wooden screws, be sure to
x thoroughly. (see Figure D)
2. Attach the Exhaust hose to wall Exhaust adaptor A.
NOTE: Cover the hole using the adaptor cap when not in use.
The duct can be compressed or extended moderately according to the
installation requirement, but it is desirable to keep the duct length to a
minimum.
IMPORTANT: DO NOT OVERBEND OR KINK THE EXHAUST HOSE (see Fig. E)
CAUTION EXHAUST PORT
Make sure that there are no obstacles within 18”or 50cm around the exhaust
outlet in order for the exhaust system to work properly.

6
INSTALLATION INSTRUCTIONS CONTINUED:
WATER DRAINAGE:
Certain functions of your air conditioning unit create condensation and must evacuate accumulated water.
Please carefully follow these instructions according to your operating and usage conditions.
DEHUMIDIFYING MODE: Remove the drain plug from the back of the
unit, install the drain connector(5/8”universal female mender) with 3/4”
hose (available in a local hardware store). For the models without drain
connector, just attach the drain hose to the hole. Place the open end
of the hose directly over the drain area in your basement oor. Refer to
gures F & G.
When the water level of the bottom tray reaches a predetermined level,
the unit beeps 8 times, the digital display area shows P1. At this time
the air conditioning/dehumidication process will immediately stop.
The fan motor will continue to operate—this is normal.
Carefully move the unit to a draining location, remove the bottom
drain plug and let the water evacuate (see Figure H). Restart the ma-
chine until the P1 symbol disappears. If the error repeats, call for ser-
vice.
NOTE: Be sure to reinstall the bottom drain plug before using the
unit.
$$$ SAVE & CONSERVE ENERGY
• Use the unit in the recommended room size.
• Locate the unit where furniture cannot obstruct the air ow.
• Keep blinds/curtains closed during the sunniest part of the day.
• Keep the lters clean.
• Keep doors and windows closed to keep cool air in and warm air out

7
INSTALLATION INSTRUCTIONS:
WINDOW SLIDER KIT INSTALLATION OPTIONAL:
Your window slider kit has been designed to t most standard vertical
and horizontal window applications, However, it may be necessary for
you to improvise/modify some aspects of the installation procedures for
certain types of windows. Please refer to Figure K & Figure L for minimum
and maximum window openings. Window slider kit can be xed with a
bolt (see Figure M).
WINDOW SLIDER SIZING CHART
Use the following chart to determine minimum and maximum gap sizes
for exhaust installation within windows. If the window opening is shorter
than the noted minimum length of the window slider kit, cut the slider
kit to the appropriate length. NEVER cut the kit shorter than the hole.
A a B b
Type I 67.5 cm 2.22 ft. 123 cm 4.04 ft
Type II 56.2 cm 1.84 ft. 98.2 cm 3.22 ft
• A columns correpsond to minimum size
• B columns correspond to maximum size
INSTALLATION IN A DOUBLEHUNG SASH WINDOW:
1. Cut the foam seal (adhesive type) to the proper length and attach it to the window
stool. (see Figure N)
2. Attach the window slider kit to the window stool. Adjust the length of the window
slider kit according to the width of window, shorten the adjustable window kit
if the width of window is less than 26.5 (Type I) or 22.1 (Type II) inches Open the
window sash and place the window slider kit on the window stool. (see Figure O)
3. Cut the foam seal(adhesive type) to the proper length
and attach it on the top of the window. (see Figure P)
4. Close the window sash securely against the window.
5. Cut the foam seal to an appropriate length and seal the open gap between the
top window sash and outer window sash. (see Figure Q)

8
INSTALLATION IN A SLIDING SASH WINDOW:
1. Cut the foam seal(adhesive type) to the proper length and attach it to the window frame. (see Figure R)
2. Attach the window slider kit to the window stool. Adjust the length of the window slider kit according to
the width of window, shorten the adjustable window kit if the width of window is less than 26.5 (Type I)
or 22.1 (Type II) inches. Open the window sash and place the window slider kit on the window stool.
(see Figure S)
3. Cut the foam seal (adhesive type) to the proper length
and attach it on the top of the window. (see Figure T)
4. Close the sliding sash securely against the window.
5. Cut the foam seal to an appropriate length and sea the open gap between the top window sash and
outer window sash. (see Figure U)
FRONT PANEL OVERVIEW:
The following diagram and legend shows the functions of the front operating panel. Some functions are
only available on select models.
1) Mode selector Button
Alternate between Auto, Cool, Dry, Fan & Heat modes
2) Timer Button
Activate the unit for a set period of time, increased and
decreased using the + and – buttons
3) Power Button
4) Sleep Button
Initiate the sleep functionality of the unit.
5) Fan/Ion* Button
Control fan speed between low, medium, high and auto.
6) Up and Down Buttons
Use to increase or decrease temperature.To change between
degree display in F or C, press and hold both buttons simul-
taneously for 3 seconds.
7) LED display
Displays the set temp., in fan/dry mode displays actual temp.
8) Ion Button*
Press to enable/disable the ion air purication feature and
remove pollens and allergens from the air passing through the
air conditioning unit.
9) Swing button
Only on units with an automatic air direction blade, push to
start the automatic movement of the blade. Push again to lock
the blade position.

9
OPERATING INSTRUCTIONS:
COOLING operation
• Press the“MODE” button until the “COOL”indica-
tor light comes on.
• Press the ADJUST buttons“+” or “ -“ to select your
desired room temperature. The temperature can
be set within a range of 17°C-30°C/62°F-88°F.
• Press the“FAN SPEED”button to choose fan speed.
HEATING operation
• Press the“MODE” button until the “HEAT”indica-
tor light comes on.
• Press the ADJUST buttons“+” or “ -“ to select your
desired room temperature. The temperature can
be set within a range of 17°C-30°C/62°F-88°F.
• Press the“FAN SPEED”button to choose the fan
speed. For some models, the fan speed can not
be adjusted under HEAT mode.
• Press the“MODE” button until the “DRY”indicator
light comes on.
• Under this mode, you cannot select a fan speed
or adjust the temperature. The fan motor oper-
ates at LOW speed.
• Keep windows and doors closed for the best
dehumidifying eect.
• Do not connect the duct to window.
AUTO operation
• When you set the air conditioner in AUTO mode,
it will automatically select cooling, heating(cool-
ing only models without), or fan only operation
depending on what temperature you have select-
ed and the room temperature.
• The air conditioner will control room temperature
automatically round the temperature point set by
you.
• Under AUTO mode, you can not select the fan speed.
FAN operation
• Press the“MODE” button until the “FAN “ indicator
light comes on.
• Press the“FAN SPEED”button to choose the fan
speed. The temperature cannot be adjusted.
• Do not connect the duct to window.
TIMER operation
• When the unit is on, press the
• Timer button will initiate the Auto-o stop pro-
gram, the TIMER OFF indicator light illuminates.
Press the UP or down button to select the de-
sired time. Press the TIMER button again within 5
seconds, the Auto-on start program is initiated.
And the TIMER ON indicator light illuminates.
Press the up or down button to select the desired
Auto-on start time.
• When the unit is o, press the Timer button to
initiate the Auto-on start program,press it again
within ve seconds will initiate the Auto-o stop
program.
• Press or hold the UP or DOWN button to change
the Auto time by 0.5 hour increments, up to 10
hours, then at 1 hour increments up to 24 hours.
Thecontrol willcountdown the time remaining
until start.
• The system will automatically revert back to dis-
play the previous temperature setting if there is
no operation in a ve seconds period.
• Turning the unit ON or OFF at any time or adjust-
ing the timer setting to 0.0 will cancel the Auto
Start/ Stop timer program.
• When the malfunction (E1,E2,E3 or E4) occurs,
the Auto Start/Stop timed program will also be
cancelled.
SLEEP operation
• Press this button, the selected temperature
will increase (cooling) or decrease (heating) by
1°C/2°F after 30 minutes. The temperature will
then increase (cooling) or decrease (heating) by
another 1°C/2°F after an additional 30 minutes.
• The new temperature will be maintained for 7
hours before it returns to the originally select-
ed temperature. This ends Sleep mode and the
unit will continue to operate as originally pro-
grammed.
• NOTE: This feature is unavailabe under FAN or
DRY mode.

10
ADDITIONAL FEATURES:
FOLLOW ME Feature:
• NOTE:This feature can be activated from the
remote control ONLY. The remote control acts
as a remote thermostat allowing for the precise
temperature control at its location.
• To activate the Follow Me/Temp Sensing feature,
point the remote control towards the unit and
press the Follow Me/Temp Sensing button. The
remote display is actual temperature at its loca-
tion. The remote control will send this signal to
the air conditioner every 3 minutes interval until
press the Follow Me/Temp Sensing button again.
• If the unit does not receive the Follow Me/Temp
Sensing signal during any 7 minutes interval, the
unit will beep to indicate the Follow Me/Temp
Sensing mode has ended.
Auto Restart
• If the unit breaks ounexpectedly due to the
power cut, it will restart with the previous func-
tion setting automatically when the power
resumes.
Self Protection
• After the unit has stopped, it can not restart oper-
ation for 3 minutes following shut down. This is
to protect the unit. Operation will automatically
resume after 3 minutes has elapsed.
Air ow direction adjustment
• The directional blade can be adjusted automati-
cally.
• Adjust the air ow direction automatically
• When the Power is ON, the blade opens fully.
• Press the SWING button on the panel or remote
controller to initiate the Auto swing feature.
• The blade willl swing up and down automatically.
• Press the SWING button again to block the blade
in a xed direction.
• NOTE: Please do not adjust the blade manually.
BASIC ERROR CODES:
Use the following guidelines to understand and troubleshoot common error codes.
E1: Room temperature sensor error.
• Unplug the unit and plug it back in.
• If error repeats, call for service.
E2: Evaporator temperature sensor error
• Unplug the unit and plug it back in.
• If error repeats, call for service.
E4: Display panel communication error
• Unplug the unit and plug it back in.
• If error repeats, call for service.
P1: Bottom condensation tray is full
• Connect the drain hose and drain the collected water away.
• Note that frequent draining may be required, especially in humid climates
and during seasonal weather changes.
• If protection repeats after draining, call for service.

11
TROUBLESHOOTING TIPS:
Problem Possible Causes Remedies
Unit does not start when
pressing on/o button
P1 appears in the display window Drain the water in the bottom tray
Room temperature is lower than
the set temperature (cool mode) Reset the temperature
Room not cool enough
The windows or doors in the room
are not closed
Make sure all the windows and
doors are closed
There are heat sources inside the
room
Remove the heat sources
if possible
Exhaust air duct is not connected or
blocked
Connect the duct and make sure
it can function properly
Temperature setting is too high Decrease the set temperature
Air lter is blocked by dust Clean the air lter
Machine noisy or vibrates The ground is not level or not at
enough
Place the unit on a at, level
surface if possible
Gurgling noises
The sound comes from the owing
of the refrigerant inside the air
conditioner unit
This noise is normal
Power shuts o in heating mode
The automatic overheat protection
function kicks in. When the tem-
perature at the aur outlet exceeds
158°F/70°C, the device will automa-
tically shut o.
Switch on again after the unit has
cooled o.
Impecca customer support can be contacted in the following methods:
• Online 24/7: www.impeccausa.com
• By e-mail: ser[email protected]
• By phone: [phone]
CONTACT SUPPORT:

12
CARE & MAINTENANCE:
IMPORTANT:
1) Be sure to unplug the unit before cleaning or servicing.
2) Do not use gasoline, thinner or other chemicals to clean
the unit.
3) Do not wash the unit directly under a tap or using a hose.
It may cause electrical danger.
4) If the power cord is damaged, it should be repaired by
manufacture or its agency.
AIR FILTER CLEANING:
Clean the air lter at least once every two weeks to prevent
inferior fan operation because of dust.
REMOVAL: This unit has two lters. Take the upper lter out
and pull upward (Figure 1). Remove the lower lter by loose-
ning the screw, taking out the lter as shown in (Figure 2).
CLEANING: Wash the air lter by immersing it gently in warm
water (about 40°C/104°F) with a neutral detergent. Rinse the
lter and dry it in a shady place.
MOUNTING: Install the upper air lter after cleaning , and
install the lower lter by using the screw (see Figure 2).
UNIT ENCLOSURE:
Use a lint-free cloth soaked with neutral detergent to clean
the unit enclosure. Finish by wiping with a dry clean cloth.
BEFORE STORING OR NOT USING A UNIT
FOR LONG PERIODS OF TIME:
• Remove the rubber plug at the back of the unit and attach a
hose to drain outlet. Place the open end of the hose directly
over the drain area in your basement oor. (Fig. F & G, page 6)
• Remove the plug from the bottom drain outlet, all the water
in the bottom tray would drain out (Fig. H, page 6)
• Keep the appliance running on FAN mode for half a day in
a warm room to dry the appliance inside and prevent mold
forming.
• Stop the appliance and unplug it, wrapped the cord and
bundle it with the tape (Figure 4). Remove the batteries from
the remote controller.
• Clean the air lter and reinstall it. (Instructions above)
• Unscrew the exhaust hose to the right or left and pull to re-
move (Figure 5). Store it safely and close the window (or wall)
vent port with the adapter cap.

13
Aire Acondiconado Portátil Impecca
Manual de Usuario
IPAC-08K—8000 BTU Aire Acondicionado Portátil
IPAC-10K—10000 BTU Aire Acondicionado Portátil

Tabla de Materias:
–Introducción.....................................................................................p.15
–Medidas De Seguridad ...........................................................................p.15
– ¿Qué Hay En La Caja? ...........................................................................p.16
– Instalación Del Kit De Accesorios.................................................................p.16
– Especicaciones Y Advertencias..................................................................p.17
– Condiciones Ambientales para el Funcionamiento................................................p.17
– Identicación de las Partes del Dispositivo .......................................................p.18
– Instrucciones de Instalación .....................................................................p.19
– Consejos para Ahorro de Energía ................................................................p.20
– Descripción General del Panel de Operación .....................................................p.22
– Instrucciones de Funcionamiento ...............................................................p.23
– Características Adicionales ......................................................................p.24
– Códigos de Error y Soluciones Básicas ...........................................................p.24
– Resolución de Problemas .......................................................................p.25
– Contactar al Soporte ............................................................................p.25
Avisos de Regulación:
ELIMINACIÓN:
No se deshaga de este producto como basura local común. Es necesaria la recolección de esta basura para
un tratamiento especial.
Está prohibido desechar este aparato entre la basura doméstica.
Para su eliminación, existen varias posibilidades:
A) El municipio tiene establecido sistemas de recolección, donde la basura electrónica se puede de-
sechar sin cargo alguno para el usuario.
B) Cuando se compra de un producto nuevo, el minorista puede retirar el producto viejo incluso de
forma gratuita.
C) El fabricante tomará de nuevo el aparato viejo para su eliminación incluso sin cargo alguno para el
usuario.
D) Dado que los productos viejos contienen recursos valiosos, se pueden vender a los recicladores de
metal.
La disposición de los residuos en los bosques y áreas naturales pone en peligro su salud cuando las sustan-
cias peligrosas se ltran en las aguas subterráneas, y llegan a la cadena alimenticia.
PRECAUCIÓN:
• Este aparato no está destinado para ser utilizado por personas (incluidos niños) con disminución en sus
capacidades físicas, sensoriales o mentales; o con falta de experiencia y conocimiento, a menos de que
hayan recibido supervisión o instrucciones relativas al uso del aparato por una persona responsable de su
seguridad.
• Los niños deben ser supervisados para asegurarse de que no jueguen con el aparato.

15
INTRODUCCIÓN:
Felicitaciones por su compra de un Aire Acondicionado Portátil Controlado Electrónicamente Impecca™.
Antes de utilizar este producto, se recomienda que se familiarice con las características, funciones y procedi-
mientos operativos descritos en este manual. En su interior encontrará muchos consejos útiles sobre cómo
utilizar y conservar su aire acondicionado. Un poco de cuidado preventivo de su parte puede ahorrarle mu-
cho tiempo y dinero durante la vida útil de su aire acondicionado. Encontrará muchas respuestas a proble-
mas comunes en la tabla de consejos para la solución de problemas.
AHORRE TIEMPO Y DINERO!
Si primero revisa nuestro cuadro de consejos para solución de problemas, es posible que no necesite
llamar al servicio técnico.
VISTAZO A LAS CARACTERÍSTICAS:
• Funcionamiento silencioso • Filtro de Iones (modelos elegidos)
• Función de Ahorro de Energía • Modo de suspensión
• Control Remoto con LED • Refrigerante Amigable con el Medio Ambiente
• Sensor Remoto de Temperatura Personal (en algunos modelos)
MEDIDAS DE SEGURIDAD:
Para evitar lesiones y / o daños a la propiedad, por favor familiarícese con las siguientes instrucciones
y precauciones de seguridad. El incumplimiento de las instrucciones y precauciones mencionadas en este
manual puede causar lesiones o daños. Su gravedad se clasica mediante las siguientes indicaciones:
⚠
ADVERTENCIA Este símbolo indica la posibilidad de lesiones graves o la muerte.
⚠
PRECAUCIÓN Este símbolo indica la posibilidad de lesiones y / o daños a la propiedad.
⊘Nunca haga esto.
⍟Siempre haga esto.
IMPORTANTE:
• Siempre contacte a un técnico de servicio autorizado para la reparación o mantenimiento de esta uni-
dad.
• Este aire acondicionado no está diseñado para ser utilizado por niños o adultos mayores sin supervisión.
• Se debe advertir a los niños pequeños sobre no utilizar el aire acondicionado.
• Si el cable de alimentación debe ser sustituido, el trabajo de sustitución sólo debe ser realizado por técni-
cos certicados o autorizados.
• Todos los trabajos eléctricos deben ser realizados de acuerdo con las normas nacionales de cableado y
sólo debe ser realizado por personal autorizado.
NOTA: Debido a ligeras modicaciones en la producción, las instrucciones, características y / o descripciones
que se encuentran en este manual pueden variar ligeramente a las de su producto.

16
QUÉ HAY EN LA CAJA?:
Por favor revise en su caja los siguientes elementos. Tenga en cuenta que algunos modelos pueden no in-
cluir todos los elementos.
1. Unidad de Aire Acondicionado
2. Control remoto
(puede diferir al de la fotografía)
3. Manual de Usuario
4. Manual de Usuario del Control Remoto
5. Kit de instalación (ver detalles más abajo)
❶
❸&❹
❷
ARTÍCULOS DEL KIT DE INSTALACIÓN DE ACCESORIOS:
Su modelo puede no incluir algunos de los accesorios de montaje opcionales, como se indica por el símbo-
lo*. Las ilustraciones pueden variar ligeramente de la apariencia real del producto.
PARTE
(Sólo como ejemplo, puede no ser idéntica) DESCRIPCIÓN DE LA PARTE : CANTIDAD INCLUIDA :
Manguera de escape y adaptador
A –O– adaptador B 1 conjunto
Adaptador de Escape de Pared A* 1 unidad (opcional)
Adaptador de boca redonda B* 1 unidad (opcional)
Hoyo de Expansión
& Tornillo de Madera* 4 unidads (opcional)
Sellante Sintético 3 unidads
Control Remoto Y Pila 1 unidad
Manguera de drenaje
y Adaptador* 1 unidad (opcional)
¡Evite dañar su aparato nuevo! Si los accesorios necesarios no están incluidos, por favor póngase en contacto
con soporte técnico.

17
ESPECIFICACIONES Y ADVERTENCIAS:
Revise cuidadosamente todas estas especicaciones y advertencias ANTES de usar su unidad de aire acondi-
cionado. El no hacerlo puede causar daños, lesiones o daños corporales incluyendo discapacidad perma-
nente y / o muerte.
ADVERTENCIA POR SU SEGURIDAD
• No guarde ni use gasolina u otros líquidos o vapores / líquidos en las proximidades de este o cualquier otro electrodoméstico.
• Evite el riesgo de incendio o descarga eléctrica. No utilice un cable de extensión ni un adaptador.
• No retire ninguna clavija del cable de alimentación.
ADVERTENCIA INFORMACIÓN ELÉCTRICA
• Asegúrese de que el cableado eléctrico sea adecuado para el modelo que usted ha elegido. Esta información se puede encon-
trar en la placa de serie, que se encuentra al lado de la carcasa y detrás de la rejilla.
• Asegúrese de que el aire acondicionado esté correctamente conectado a tierra. Para minimizar los riesgos de choque eléctri-
co e incendio, es importante una conexión a tierra adecuada. El cable de alimentación está equipado con un enchufe de tres
clavijas para protección contra posibles descargas eléctricas.
• El aire acondicionado debe estar conectado a un enchufe de pared con polo a tierra adecuado. Si el tomacorriente que pre-
tende utilizar no está conectado adecuadamente a tierra o protegido por un fusible de retardo o un interruptor de circuito,
haga que un electricista calicado instale el tomacorriente adecuado.
• Asegúrese de que el receptáculo sea accesible después de la instalación de la unidad.
CONDICIONES AMBIENTALES DE FUNCIONAMIENTO:
El aire acondicionado debe ser operado dentro de los rangos de temperatura indicados a continuación:
MODO TEMPERATURA DE LA HABITACIÓN
REFRESCAR F: 62° a 95° | C: 17° a 35°
VENTILADOR O DESHUMIDIFICADOR F: 55° a 95° | C: 13° a 35°
CALEFACCIÓN (modelos con bomba de calor) F: 62° a 88° | C: 5° a 30°
CALEFACCIÓN (modelos con calefacción eléctrica) F: bajo 88° | C: menos de 30°
⍟ SIEMPREHAGAESTO! ⍟
• El aire acondicionado debe usarse de tal manera que esté
protegido de la humedad, por ejemplo, condensación,
salpicaduras de agua, etc. No ponga ni almacene el aire
acondicionado donde se pueda caer o ser empujado al
agua o cualquier otro líquido. Si la unidad se pone en con-
tacto con el líquido, desenchufe inmediatamente.
• Siempre transporte el aire acondicionado en posición
vertical y apoyado sobre una supercie estable y nivelada
durante su uso.
• Apague el aparato cuando no esté en uso.
• Siempre contacte una persona calicada para llevar a cabo
las reparaciones. Si el cable de alimentación está dañado,
debe ser reparado por un taller de reparación calicado.
• Conserve un espacio de ventilación de por lo menos 12”
(30 cm) alrededor de la unidad respecto a paredes, mueb-
les y cortinas.
• Si el aire acondicionado es derribado durante el uso, apa-
gue la unidad y desenchufe inmediatamente.
⊘ NUNCA HAGA ESTO! ⊘
• No utilice su aire acondicionado en una habitación húme-
da como un baño o lavadero.
• No toque la unidad con las manos húmedas o mojadas, o
con los pies descalzos.
• No presione los botones del panel de control con algo
diferente a los sean los dedos.
• No retire ninguna cubierta ja. Nunca use este aparato si
no funciona correctamente, o si se ha caído o dañado.
• Nunca utilice el enchufe para encender y apagar la unidad.
Siempre utilice el interruptor en el panel de control.
• No cubra ni obstruya la rejilla de entrada o de salida.
• No utilice productos químicos peligrosos para limpiar o
entrar en contacto con la unidad. No utilice el aparato en
presencia de sustancias o vapores inamables como alco-
hol, insecticidas, gasolina, etcétera.
• No permita que los niños usen la unidad sin supervisión.
• No utilice este aparato para funciones distintas a las descri-
tas en este manual de instrucciones.

18
IDENTIFICACIÓN DE LAS PARTES DEL DISPOSITIVO :
PANEL FRONTAL MODELO A :
PANEL FRONTAL MODELO B :
PANEL TRASERO :
1. Panel de funciones
2. Rejilla de dirección de aire (automático)
3. Rueditas para mover
4. Asideras para mover (ambos lados)
6. Filtro de aire superior (detrás de la rejilla)
7. Salida de aire
8. Salida del cable de alimentación
9. Entrada de aire
10. Desagüe
11. Entrada de aire
12. Filtro de aire inferior (detrás de la rejilla)
13. Desagüe de la bandeja inferior
1. Panel de funciones
2. Rejilla de dirección de aire (manual)
3. Receptor de señal del control remoto
4. Rueditas para mover
5. Asideras para mover (ambos lados)
