Impecca IPAC08-CR User manual

Portable Air Conditioner—User Manual
Aire acondicionado—Manual de usuario
Models: IPAC08-CR, IPAC-10CR
www.impecca.com

Read the following notices and information carefully to ensure proper operation of your air
conditioner unit.
This manual is solely provided for informational purposes and in no way constitutes a legally
binding document between the manufacturer, distributor, and end consumer.
Lea las siguientes indicaciones cuidadosamente para asegurar el correcto funcionamiento
de su unidad de aire acondicionado.
Este manual se proporciona únicamente con fines informativos y de ninguna manera
constituye un documento jurídicamente vinculante entre el fabricante, distribuidor y
consumidor final.
Warning: To avoid permanent damage to
unit:
Ensure it is in the upright position for at least 24 hours
before powering on the first time.
Advertencia: Para evitar daños
permanentes a la unidad:
Asegúrese de que está en la posición vertical durante al
menos 24 horas antes de encender la primera vez.

ENGLISHESPAÑOL
–1–
INTRODUCTION
Thank you for purchasing this quality Impecca portable air conditioner unit. To ensure the
longest life and highest energy eiciency of your unit, please carefully follow these operating
instructions. Keep these instructions in a safe place and consult them as needed. Please note
that constant enhancement and improvements to our air conditioning units may mean that
your model will slightly dier in appearance from the model pictured in this manual, but the
actual operation and installation of the unit remains unchanged. This manual is solely provid-
ed for informational purposes and does not constitue a binding, legal contract.
SAFETY NOTICE:
This appliance should not be used by children or mentally/physically disabled persons with-
out strict, direct supervision by a responsible adult. Never play with or around the appliance.
SAFETY INFORMATION
• Before operation, ensure your electrical installation (outlets and circuits) complies
with the power specifications found on the unit.
• Before cleaning or maintaining the air conditioner, please turn o air conditioner
and unplug the unit.
• Make sure the power cord isn’t kinked, bent, or under the weight of sharp or heavy
objects.
• Do not pull or yank the power cord to unplug the unit or move the air conditioner.
• Do not insert or unplug the power plug with wet hands.
• Only use a grounded power outlet. Make sure the grounding is functional.
• If the power cord is damaged, it must be replaced by the manufacturer or a quali-
fied technician in order to avoid fire and electrical hazards.
• Should abnormal operation occur (such as a burning smell), please disconnect
power cord immediately and contact your local dealer.
• If nobody is present to monitor the operation of the unit, please turn it o and
disconnect the power cord.
• Do not splash or pour water on air conditioner to avoid causing a short circuit or
damage to the unit.
• Do not put or hang dripping objects above the air conditioner.
• If using a drainage hose, ensure the ambient temperature remails well above
freezing (32°F or 0°C) to avoid cracking or damaging the unit.
• Keep heat sources away from the air conditioner.
• Ensure the unit is far away from fire, inflammable, or explosive objects.
• Never allow children or persons with reduced physical, sensory, or mental capabil-
ities to operate or play around the air conditioner without direct adult supervision.
• Never allow children to perform cleaning or other user-maintenance operations
without direct adult supervision.
• Never attempt to repair or disassemble the air conditioner by yourself.
• Never insert objects into the air conditioner.

ENGLISH ESPAÑOL
–2–
OPERATING CONDITIONS
• The air conditioner must be operated within the temperature range of 62°F to 95°F
(16°C to 35°C).
• The appliance is for indoor use only.
• The appliance must be positioned so that the plug is accessible.
• A perimiter of 12′′(30cm) around the air conditioner should be free of all objets.
• Do not operate the air conditioner in a humid environment.
• Please keep air inlet and air outlet clean and free of obstacles.
• During operation, close doors and windows to improve cooling eect.
• Please put the air conditioner on smooth and flat ground for operation to avoid
noise and vibration.
• This air conditioner is equipped with castors that roll on smooth, flat surfaces.
• Do not tilt or turn over the air conditioner. If there’s problem, please disconnect
the power supply immediately and contact your local dealer or technical support.
• Avoid exposing the unit to direct sunlight.
GETTING TO KNOW YOUR AIR CONDITIONER
1
2
3
4
5
1213 11 10
9
6
7
8
1. Control panel
2. Horizontal directional blades
3. Vertical directional blades
4. Castors
5. Remote control storage compartment
6. Power cord
7. Filter
8. Upper air intake grille
9. Lower air intake grille
10. Connector A
11. Heat exhaust pipe
12. Connector B
13. Connector C
Note: do not discard the exhaust pipe or other acces-
sories; you may need them later should you need to
change the location of your air conditioner unit.

ENGLISHESPAÑOL
–3–
USING YOUR AIR CONDITIONER
CONTROL PANEL OVERVIEW
1 2 3 4 5 6
987
1. IR receiver
2. Water condensation build-up (when illuminated)
3. Cooling A/C mode operation (when illuminated)
4. Temperature LED: Displays the desired room temperature during cooling mode. In
other modes, the display will be blank.
5. Dehumidifier mode operation (when illuminated)
6. Fan mode operation (when illuminated)
7. Mode button: Cycle between cooling mode, dehumidifier mode, and fan mode.
8. Temperature +/- buttons: Set the desired room temperature by pressing the ap-
propriate button. Temperature changes are displayed in 1° increments in the
range of 61°F (16°C) and 86°F (30°C) Note: Temperature cannot be set when using
the fan or dehumidifier modes
9. Power ON/OFF button: Use this button to turn the unit on or o.

ENGLISH ESPAÑOL
–4–
REMOTE CONTROL
21
3
4 5
6 7
1. ON/OFF button
2. Mode button
3. Temperature +/- buttons
4. Fan button
5. Swing button
6. Sleep button
7. Timer button
REMOTE CONTROL DISPLAY OVERVIEW
13 14
7 6
1
2
3
4
5
10
12
11
8
9
1. Signal transmission
2. Swingoperation(notapplicabletothisunit)
3. Sleep mode operation
4. Remote control lock
5. Fan speed
6. Set timer
7. Desired temperature
8. Heat mode (not applicable to this unit)
9. Fan mode
10. Dehumidifier mode
11. Cooling mode
12. Automatic operation
13. Start up timer activated
14. Shut down timer activated

ENGLISHESPAÑOL
–5–
USING THE REMOTE CONTROL
ON/OFF BUTTON
Press the ON/OFF button to turn the unit on or o.
MODE BUTTON
Cycle between cooling mode, dehumidifier mode, and fan mode.
TEMPERATURE +/- BUTTONS
Set the desired room temperature by pressing the appropriate button. Temperature
changes are displayed in 1° increments in the range of 61°F (16°C) and 86°F (30°C)
Note: Temperature cannot be set when using the fan or dehumidifier modes
FAN BUTTON
Cycle through dierent fan speeds between Auto, Low, Medium, and High speed. Auto
speed selects an appropriate fan speed based on ambient temperature and most ei-
cient unit operation.
SWING BUTTON
Not applicable for this model.
SLEEP BUTTON
During cooling mode, the sleep button will allow the room temperature to slightly in-
crease for more energy eicient operation.
TIMER BUTTON
• When the unit is running, press this button to program a time when the unit will
automatically turn o. While the T-OFF and H icons are flashing on the remote
control display, use the +/- buttons to determine the time the unit will shut down
in 30 minute (.5h) increments. Press the Timer button again to confirm the shut
down command.
• When the unit is powered on but not running, press this button to program a time
when the unit will automatically turn on. While the T-ON and H icons are flashing
on the remote control display, use the +/- buttons to determine the time the unit
will start up in 30 minute (.5h) increments. Press the Timer button again to confirm
the power on command.
• To cancel a timer, press the timer button to see remaining time before the timer
activates. Press the timer button again to cancel the timer.
Note: Timers can be set between the range of 30 minutes (.5h) and 24 hours. The unit must
remain plugged in for the timer to function properly.

ENGLISH ESPAÑOL
–6–
REMOTE CONTROL LOCK
1. Press and hold the + and - buttons simultaneously to activate the remote control
child lock and prevent inadvertent changes to unit settings.
2. Press the + and - buttons simultaneously to deactivate the remote control lock.
CHANGE TEMPERATURE UNITS (C° OR F°)
While the unit is o, press the - and MODE button simultaneously on the remote
control to toggle the unit readout temperature between Celsius (C°) and Fahren-
heit (F°).
REPLACING THE REMOTE CONTROL UNIT BATTERIES
1. Press gently on the tab located on the back side of the remote control unit. Li out
the battery compartment cover.
2. Replace the batteries with two AAA 1.5v batteries. Insert batteries while respecting
the polarity of the batteries (+ and - sides). Replace both batteries at the same
time; never insert an old battery with a fresh battery to avoid a battery leak.
3. Gently reinsert the battery compartment cover.
REMOTE CONTROL OPERATION NOTES
• When using the remote control, aim the controller directly at the air conditioning
units IR receiver located on the control panel.
• The remote control must have a clear line of sight to the control panel.
• Interference to remote control operation may occur in areas with fluorescent light-
ing or wireless telephones.
• When the remote control will remain unused for long periods of time, please re-
move the batteries.
• If the display appears faint or does not appear, please replace the batteries.
PRE-INSTALLATION INSTRUCTIONS
TOOLS & ACCESSORIES FOR INSTALLATION
Gather the following tools and unit accessories before beginning your installation:
UNIT & ACCESSORIES
• Air conditioning unit
• Connectors A, B, C
• Window frame (3 pieces)
• Heat exhaust duct
• Screws (x5)
• Pipe clip
• Rubber stopper
• Drainage pipe
• Pipe hoop
• Remote control batteries (2x AAA)
• Remote control
• Users manual
Note: Never use an underrated electrical cord or outlet!

ENGLISHESPAÑOL
–7–
INSTALLING YOUR UNIT
STEP 1: IDENTIFY INSTALLATION LOCATION
1. Following the steps in the pre-installation section, identify a proper installation location.
STEP 2: INSTALLATION OF THE AIR EXHAUST DUCT
1. Remove the exhaust hose and all connectors.
STEP 3: WINDOW KIT INSTALLATION
The window kit is designed for installation in most vertical or horizontal sash windows.
You may be required to slightly modify your specific installation to ensure safe and proper
use of your air conditioner unit.
Horizontal window:
Minimum width: 27.5” (70cm)
Maximum width: 48” (122cm)
Vertical window:
Minimum height: 27.5” (70cm)
Maximum height: 48” (122cm)
1. Adapt window frame size
Insert the window exhaust port fitting (#1) into your window and extend the width or
height to fill your window entirely using the adjustment plate (#2).
If the inner width of the window is less than 28”, you may need to cut the frame to adjust
the width. Cut on the OPPOSITE side (#3) side of the opening, as indicated below.
1
2
3
2. Insert connector C (#2) into the window frame (#1)
2
1

ENGLISH ESPAÑOL
–8–
3. Fasten the window frame
Fasten the frame (#1) to the windowsill (#2) with screws (#3) based on the dimensions be-
low corresponding to the width (horizontal window sash) (#4) or height (vertical window
sash) (#5) of the installation.
1
1
2
3
3
4
2
5
Width or height less than 28”: 2 screws
Width or height between 28” and 36.5” : 3 screws
Width or height between 36.5” and 64” : 4 screws
4. Close the window to finish installation

ENGLISHESPAÑOL
–9–
AIR EXHAUST PORT MOUNTING
If you have an existing air exhaust port, you can directly connect your portable air condi-
tioning unit to the port. For the best energy eiciency and to preserve the longest life of
your unit, avoid bending the hose and keep the exhaust hose length as short as possible.
The hose bending point should be at least 24” away from the unit for optimal perfor-
mance. Avoid any kinks or sharp bends.
CONNECTING THE AIR EXHAUST DUCT
2
1
3
Step 1: First completely expand about 5 inch-
es of hose on both ends of the exhaust pipe.
Insert and fasten connector A (#1) to the ex-
haust pipe (#2) by turning the connector
clockwise at one end of the hose. Repeat the
process at the opposite end of the hose with
connector B (#3).
Step 2: Ensure the side marked TOP on connector A is facing upwards. Slide connector A
into the rails (#1) found at the rear of the air conditioner unit and press firmly until you
hear a slight click from the clasp (#2).
2
1

ENGLISH ESPAÑOL
–10–
2
1
OK
Step 3: Insert connector B (#1)
into connector C (#2) by the win-
dow by locating the slot in con-
nector C, and inserting and
slightly twisting connector B for
a snug fit.
Note: For optimal performance, avoid any kinks or bends in the air exhaust duct.
OK OK
OK
DRAINAGE PIPE SETUP
Condensation buildup in humid environments will severely impact the eiciency and
normal operation of your unit. If you have a drain near the installation, you can have a
continuous drainage setup.
Step 1: Remove the rubber plug (#1) found at the rear base of the unit.
1

ENGLISHESPAÑOL
–11–
Step 2: Using the provided screw (#1), attach the drainage pipe clip (#2) near the drainage port.
1
2
Step 3: Place the drainage pipe (#1) onto the drainage port (#2) and fasten with the drain-
age pipe hoop (#3). Place the rubber stopper (#4) at the top of the pipe, clip the hose to
the unit (#5), and drain the unit in a suitable location as needed.
1
2
3
4
5
TESTING UNIT OPERATION
Turn the unit on by plugging in the power cord and pressing the ON/OFF button. Press the
mode button to cycle through the various operation modes.
Note: if the ambient temperature is below 61°F, the cooling mode will not function.

ENGLISH ESPAÑOL
–12–
CLEANING & MAINTENANCE
SAFETY WARNING
To avoid electric shock, fire, damage, or injury while performing maintenance on your unit:
• Always turn o and disconnect the air conditioner from electric power.
• Never submerge the unit in water or spray liquids directly on the unit.
• Never use solvents or other flammable or volatile liquids (examples: paint thinner,
acetone, gasoline, etc.) to clean the air conditioner.
PRE-COOLING SEASON UNIT CHECK
Before using your air conditioner in the warm summer months, always perform the fol-
lowing verifications to ensure reliable, eicient operation.
• Check the air inlets and outlets for any foreign objects (example: leaves, sticks,
small toys, etc.)
• Check that the electrical cord and socket are not damaged, bent, or fraying.
• Check the filter and clean if necessary.
• Check the batteries in the remote control and insert or replace them if needed.
• Check whether the connectors, heat exhaust duct, and window brackets are firmly
in place.
• Check the heat exhaust duct for any cracks, damage, or other signs of weakness.
POST-COOLING SEASON UNIT CHECK
Aer using your air conditioner in the warm summer months, always perform the follow-
ing verifications.
• Disconnect the unit electrical power.
• Clean the filter and unit casing.
• Remove dust and other objects on the unit.
• Discard any accumulated water inside the unit (see section about drainage)
• Check whether the connectors, heat exhaust duct, & window brackets are firmly in place.
LONG-TERM STORAGE
Should you place your unit in long-term storage, perform all of the post-season checks
listed above and perform the following additional steps:
• Disassemble the heat exhaust duct and connectors
• Wrap the electrical cord loosely around the unit.
• Cover the unit with a sheet or cloth to prevent dust buildup inside during storage.
DISPOSAL INFORMATION
• Most unit packaging materials are recyclable. Please dispose of them according to
local recycling guidelines.
• If you wish to discard the unit, contact your local authorities for specific appliance
disposal instructions. If the unit is functional and in good repair, but you wish to
dispose of it, consider donating it to a local charity.

ENGLISHESPAÑOL
–13–
DRAINING CONDENSATION BUILDUP
If the unit emits 8 beeps and displays H8 on the control panel, unplug the unit and wheel
it outdoors or in another area suitable for water drainage. Remove the rubber plug from
the drainage hose and allow the water to drain; replace the plug and reinstall the unit.
Note: the unit will restart aer the compressor has been stopped for at least 3 minutes.
CLEANING THE OUTER HOUSING AND INTAKE GRILLE
If dust has accumulated on the unit, use a so, dry dusting towel to wipe it o. If grease or
other harder to remove substances is on the unit, use a wrung-out cloth dampened with
warm, soapy water. Use a so brush to clean o the grille.
CLEANING THE FILTER 1 2
For energy eicient operation, your filter
should be cleaned every three months.
Units in dusty environments may require
more frequent cleaning.
• The front filter cover rests on a bot-
tom hinge and swings down. Open by using pulls on either side of the cover.
• Remove the filter by gently tugging on it.
• Use a vacuum cleaner or run cold water onto the filter to clean it. If the filter is
particularly dirty (such as grease buildup), wash and gently scrub the filter in a
bath of warm soapy water. Let the filter completely dry in a shady place; exposing
the filter to direct sunlight can cause deformation.
• Aer the filter is clean and completely dry, re-insert the filter by pressing firmly
without forcing.
Note: To avoid deformation and fire risk, never dry the filter with a heat source, such as a
hair dryer, fireplace, or heater.
CLEANING THE HEAT EXHAUST DUCT
Disconnect the heat exhaust duct from the unit. Clean using warm, soapy water. Com-
pletely dry the parts and reconnect the duct.
TROUBLESHOOTING
PROBLEM / POSSIBLE CAUSES
The air conditioner does not function at all
• Is the power cable properly inserted into a functioning, grounded outlet?
• Is there a power failure such as a blown fuse or tripped circuit breaker?
• Is the timer set to “TIMER ON” mode? Disable the timer to immediately start operations.
• Is the internal collection tank or partition drain full/blocked and the FULL light
illuminated? Empty the tank.
• Is the ambient temperature lower than 61°F (16°C)? A safety device prevents the
unit from cooling the room to even lower temperatures.

ENGLISH ESPAÑOL
–14–
Heating or cooling is insuicient
• Is the room temperature set properly?
• Is the air filter dirty?
• Are doors or windows open?
• Is the room directly exposed to sunlight or are other heat sources in the room?
• Are there a large number of people in the room?
The air conditioner does not restart immediately aer turning it o.
• The unit can not be restarted for 3 minutes to allow the condenser to cool and
avoid risk of fire. Wait a few minutes before restarting the unit.
The air conditioner unit starts and stops frequently.
• Verify the rating of your electrical system and outlets. You may need a qualified
electrician to troubleshoot and upgrade your electrical circuits if your air condi-
tioner unit exceeds the rated capacity.
• Ensure the exhaust system is properly connected and not bent or kinked. Keep
the hose as short as possible and cut excess length as needed.
Fog is blown out during cooling
• In warm, high humidity environments this may naturally occur. Continued cool-
ing will remove excess humidity from the room and the fog will disappear.
The unit emits a strange smell
• This may be caused by cigarette smoke or other residues from cooking and other
living activities that remain in the air conditioning unit. Clean the filter.
The unit makes loud or unusual noises and vibrations
• Place the unit on a level surface.
There is a “squeezing” noise
• The cycling of the refrigerant inside the unit can temporarily cause this noise.
There is a “patting” noise
• This is oen caused by heat expansion in the plastic parts.
The remote control doesn’t work
• Ensure the remote control has a clear line-of-sight to the operating panel on the
unit and ensure the sensors are not obstructed by curtains or other objects. Ensure
the remote control has fresh, working batteries.
There is moisture at the air output
• High humidity environments may cause condensation at the air flow output.
Wipe the condensation o with a sponge.

ENGLISHESPAÑOL
–15–
Water spills while moving the unit
• The internal water collection tank is nearly full. Empty the water tank by placing
the unit near a drain or outdoors and remove the base plug. Aer draining has
completed, replace the base plug and reinstall your unit in the desired location.
IF ANY OF THE FOLLOWING PHENOMENA OCCUR DESPITE THE ABOVE TROUBLESHOOT-
ING TECHNIQUES, PLEASE TURN OFF THE UNIT AND DISCONNECT THE POWER CORD
IMMEDIATELY AND CONTACT TECHNICAL SUPPORT OR A QUALIFIED TECHNICIAN:
• The fuse blows or circuit breaker
trips frequently.
• The power cable is abnormally hot.
• The insulation of the power cable is
ripped, shred or torn.
• The unit controls do not work.
• The unit produces abnormal noises.
UNIT ERROR CODES
When the air conditioner status is abnormal, the indicator display on the indoor unit will dis-
play an appropriate error code. Refer to the below table for specific and immediate action.
E5: OVER-CURRENT PROTECTION
Unplug and restart your unit to clear the error. If the error persists, contact a qualified
service technician.
E6: Unplug and restart your unit to clear the error. If the error persists, contact a qualified
service technician.
F1: Unit failure. Contact a qualified service technician.
F2: Unit failure. Contact a qualified service technician.
H1: Defrosting status; a natural phenomenon. The error will automatically clear aer suf-
ficiently defrosting the cooling coils.
H6: Unplug and restart your unit to clear the error. If the error persists, contact a qualified
service technician.
OTHER ERROR CODES: Contact a qualified service technician.
TECHNICAL SUPPORT
For additional assistance, please visit our website or contact technical support.
Web: www.impecca.com
Phone: [phone]
Email: [e-mail]

ENGLISH ESPAÑOL
–16–
INTRODUCCIÓN
Gracias por comprar esta unidad portátil de aire acondicionado de calidad Impecca. Para ase-
gurar una larga vida útil y la más alta eficiencia de energía de su unidad, siga cuidadosamente
estas instrucciones. Mantenga estas instrucciones en un lugar seguro y consúltelas cuando
lo requiera. Tome en cuenta que las mejoras constantes a nuestras unidades de aire acondi-
cionado significan que su modelo puede variar ligeramente en apariencia al compararlo con
el modelo en imagen, pero la operación actual y el proceso de instalación permanecen sin
cambios. Este manual se proporciona únicamente con fines informativos y de ninguna mane-
ra constituye un documento legal vinculante.
AVISO DE SEGURIDAD:
Este electrodoméstico no debe ser utilizado por niños o por personas que tienen una disca-
pacidad mental o física sin la supervisión estricta y directa de un adulto responsable. Nunca
juegue con o cerca de la unidad.
INFORMACIÓN DE SEGURIDAD
• Antes de la operación, asegúrese
que su instalación eléctrica (toma-
corrientes y circuitos) cumplan con
las especificaciones de energía y po-
tencia señaladas en la unidad
• Antes de limpiar o darle manteni-
miento a la unidad de aire acondi-
cionado, apague el aire acondicio-
nado y desconéctelo
• Asegúrese que el cable de suminis-
tro de energía no esté torcido, do-
blado, u oprimido bajo objetos pe-
sados o filosos.
• Para desconectar la unidad o mover-
la de lugar no jale el cable de sumi-
nistro de energía.
• No conecte o desconecte la unidad
con las manos mojadas.
• Utilice solamente un tomacorrientes
aterrizado. Asegúrese que la conexión
a tierra es la adecuada y funciona.
• Si el cable de suministro de energía
está dañado, debe ser reemplazado
por el fabricante o por un técnico ca-
lificado para evitar incendios y peli-
gros eléctricos
• En caso de que ocurra una opera-
ción anormal (como puede ser olor
a quemado) desconecte de inme-
diato la unidad y entre en contacto
con su distribuidor local.
• Si nadie se encuentra presente para
supervisar la operación de la unidad,
por favor apáguela y desconéctela.
• No salpique o vierta agua en la uni-
dad de aire acondicionado para
evitar daños a la unidad o un corto
circuito.
• No coloque o cuelgue objetos que
puedan gotear encima de la unidad
de aire acondicionado.
• Si utiliza una manguera de drenado,
asegúrese que la temperatura am-
biente permanezca por encima del
punto de congelación (32°F o 0°C)
para evitar que la unidad se agriete
o se dañe.
• Mantenga las fuentes de calor lejos
de la unidad de aire acondicionado.
• Asegúrese que la unidad se encuen-
tra lejos del fuego y objetos inflama-
bles o explosivos.

ENGLISHESPAÑOL
–17–
• No permita que niños o personas
con capacidades físicas, sensoriales
o mentales disminuidas operen o
estén cerca de la unidad sin la su-
pervisión directa de un adulto.
• No permita que los niños realicen
la limpieza u otras operaciones de
mantenimiento sin la supervisión
directa de un adulto.
• No intente reparar o desarmar usted
mismola unidadde aireacondicionado.
• Nunca inserte objetos en la unidad
de aire acondicionado.
CONDICIONES DE OPERACIÓN
• La unidad de aire acondicionado debe ser operada dentro de un rango de tempe-
ratura de 62°F a 95°F (16°C a 35°C).
• Este electrodoméstico es para uso en interiores únicamente.
• El electrodoméstico debe colocarse de modo tal que el tomacorrientes esté a la mano.
• Se debe dejar un perímetro libre de objetos alrededor del aire acondicionado de
12′′ (30 cm).
• No opere el aire acondicionado en climas húmedos.
• Mantenga la entrada y salida de aire limpias y libres de obstáculos.
• Durante la operación, cierre las puertas y ventanas para mejorar el efecto de en-
friamiento.
• Coloque el aire acondicionado sobre una superficie plana y suave para evitar el
ruido y la vibración al estar operando.
• Este aire acondicionado esta equipado con ruedas giratorias que permiten desli-
zarlo sobre superficies planas y suaves.
• No incline o ponga de cabeza la unidad de aire acondicionado. Si hay algún pro-
blema desconecte de inmediato y entre en contacto con su distribuidor local o
soporte técnico.
• Evite exponer la unidad directamente a la luz del sol.

ENGLISH ESPAÑOL
–18–
CONOCIENDO SU UNIDAD DE AIRE ACONDICIONADO
1
2
3
4
5
1213 11 10
9
6
7
8
1. Panel de control
2. Cuchillas direccionales horizontales
3. Cuchillas direccionales verticales
4. Ruedas giratorias
5. Compartimento del control remoto (mando
a distancia)
6. Cable de suministro de energía
7. Filtros
8. Rejilla superior de entrada de aire
9. Rejilla inferior de entrada de aire
10. Conector A
11. Tubo de escape de calor
12. Conector B
13. Conector C
Nota: No descarte el tubo de escape de calor u otros
accesorios; los necesitará más adelante en caso de
cambiar la unidad de aire acondicionado de lugar.
