Impecca Through-the-Wall
Air Conditioner
Users Manual
ITAC-08KS • ITAC-10KSA20 (115V) • ITAC-12KSA20 (115V)
ITAC-14KS • ITAH-08KR • ITAH-10KR • ITAH-12KR • ITAH-14KR

Table of Contents:
– Introduction ..................................................................................... p.1
– Safety Notices.................................................................................. p.2-3
– What’s In The Box................................................................................. p.4
– Operating Your Air Conditioner ................................................................. p.5-7
– Installation Instructions........................................................................p.8-20
– Care Instructions ................................................................................p.21
– Troubleshooting .............................................................................p.22-23
– Various Machine Sounds/Noises .................................................................p.23
Operating Conditions .............................................................................p.23
– Contact Support ................................................................................p.23
Regulatory Warnings:
DISPOSAL:
Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special
treatment is necessary.
It is prohibited to dispose of this appliance in domestic household waste.
For disposal, there are several possibilities:
A) The municipality has established collection systems, where electronic waste can be disposed of at
least free of charge to the user.
B) When buying a new product, the retailer will take back the old product at least free of charge.
C) The manufacturer will take back the old appliance for disposal at least free of charge to the user.
D) As old products contain valuable resources, they can be sold to scrap metal dealers.
Wild disposal of waste in forests and landscapes endangers your health when hazardous substances leak
into ground-water and nd their way into the food chain.
CAUTION:
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.

1
INTRODUCTION:
Congratulations on your purchase of an IMPECCA™ Electronic Controlled Portable Air Conditioner. Before
using this product, it is recommended that you familiarize yourself with the features, functions, and operat-
ing procedures described in this manual. Inside you will nd many helpful hints on how to use and maintain
your air conditioner properly. Just a little preventive care on your part can save you a great deal of time and
money over the lifespan of your air conditioner. You will nd many answers to common problems in the
chart of troubleshooting tips.
FEATURES AT A GLANCE:
• Quiet Operation • Ion Filter (select models)
• Energy Saver Function • Sleep mode
• Remote Control with LED • Eco-Friendly Refrigerant
• Remote Personal Temperature Sensor (select models)
SAFETY PRECAUTIONS:
To prevent injury and/or property damage, please familiarize yourself with the following instructions
and safety precautions. Failure to comply with the instructions and cautions mentioned in this manual may
cause harm or damage. The seriousness is classied by the following indications:
CAUTION FOR YOUR SAFETY
• Always contact an authorized service technician for repair or maintenance of this unit.
• Use an authorized and certied technician for installation of this unit.
• This air conditioner is not intended for use by young children or elderly persons without supervision.
• Young children should be supervised to not to operate or play with the air conditioner.
• Power cord replacements should only be performed by certied or authorized technicians.
• All electrical work must be performed in accordance with the national wiring standards and should only
be performed by authorized personnel.
• Before disposing of the device,it is necessary to remove the battery cells and get rid of them safely for
recycling reasons.
• When you need to disposal of the unit consult our dealer. If pipes are removed incorrectly, the refrigerant
may blow out and come into contact with your skin, causing injury. Releasing refrigerant into the atmo-
sphere also damages the environment. Please recycle or dispose of the packaging material for product in
an environmentally responsible manner.
• Never store or ship the air conditioner upside down or sideways to avoid damage to the compressor.
NOTE: Due to slight modications in production, the instructions, features, and/or descriptions found in this
manual might vary slightly from your product.
SAVE TIME AND MONEY!
If you review our chart of Troubleshooting Tips rst, you may not need to call for service at all.
⚠ WARNING This symbol indicates the possibility of serious injury or death.
⚠ CAUTION This symbol indicates the possibility of injury and/or damage to property.
⊘Never do this.
⍟Always do this.

2
⍟ Plug in power plug properly. ⊘ Do not operate or stop the unit by insert-
ing or pulling out the power plug.
⊘ Do not damage or use an unspecied
power cord.
• Otherwise, it may cause electric shock or
re due to excess heat generation.
• It may cause electric shock or re due
to heat generation.
• It may cause electric shock or re.
• If the power cord is damaged, it must
be replaced by the manufacturer or an
authorised service centre or a similarly
qualied person to avoid hazard.
⊘ Do not modify power cord length or
share the outlet with other appliances.
⊘ Do not operate with wet hands or
in damp environment.
⊘ Do not direct airow
at room occupants only.
• It may cause electric shock or re due
to heat generation. • It may cause electric shock. • This could be harmful to your health.
⍟ Always ensure eective
grounding/earthing.
⊘ Do not allow water to run
into electric parts.
⍟ Always install circuit breaker and
a dedicated power circuit.
• Incorrect grounding
may cause electric shock.
• It may cause failure of machine
or electric shock.
• Incorrect installation may cause re
and electric shock.
⍟ Unplug the unit if strange sounds, smells,
or smoke comes from it.
⊘ Do not use the socket if it is loose or
damaged. ⊘ Do not open the unit during operation.
• It may cause re and electric shock. • It may cause re and electric shock. • It may cause electric shock.
⍟ Keep rearms away. ⊘ Do not leave the power cord
near heating appliances.
⊘ Do not use the power cord near am-
mable gas or combustibles, such as
gasoline, benzene, thinner, etc.
• It may cause re. • It may cause re and electric shock. • It may cause an explosion or re.
⍟ Ventilate room before operating
air conditioner if there is a gas leakage
from another appliance.
⊘ Do not disassemble or modify unit.
• It may cause explosion, re and, burns. • It may cause failure and electric shock.
WARNING
READ THESE NOTICES CAREFULLY—THEY ARE IMPORTANT!
⊘ When the air lter is to be removed,
do not touch the metal parts of the unit.
⊘ Do not clean the air conditioner
with water.
⍟ Ventilate the room well when used
together with a stove, etc.
• It may cause an injury. • Water may enter the unit and degrade the
insulation. It may cause an electric shock. • An oxygen shortage may occur.
⍟ When the unit is to be cleaned, switch o,
and turn o the circuit breaker.
⍟ Do not put a pet or house plant where it
will be exposed to direct air ow. ⊘ Do not use for special purposes.
• Do not clean unit when power is on as it
may cause re and electric shock, it may
cause an injury.
• This could injure or be harmful
to your pet or plants.
• Do not use this air conditioner to pre-
serve precision devices, food, pets,
plants, and art objects.
• It may cause deterioration, etc.
CAUTION

3
CAUTION ELECTRICAL INFORMATION
• Be sure your electrical wiring is adequate for the model
you have chosen. This information can be found on the
serial plate, which is located on the side of the cabinet and
behind the grille.
• Be sure the air conditioner is properly grounded. To min-
imize shock and re hazards, proper grounding is important. The
power cord is equipped with a three-prong grounding plug for
protection against shock hazards.
• Your air conditioner must be connected to a properly grounded
wall receptacle. If the wall receptacle you intend to use is not ade-
quately grounded or protected by a time delay fuse or circuit break-
er, have a qualied electrician install the proper receptacle.
• Ensure the receptacle is accessible after the unit installation.
⍟ Stop operation and close the window
in storm or hurricane.
⍟ Hold the plug by the head of the power
plug when unplugging unit.
⍟ Turn o the main power switch when
not using the unit for a long time.
• Operation with windows opened may
cause wetting of indoor and soaking of
household furniture.
• Otherwise, it may cause electric shock
and damage. • It may cause failure of product or re.
⊘ Do not place obstacles around air-inlets
or inside of air-outlet.
⊘ Ensure that the installation bracket of the
outdoor appliance is not damaged due to
prolonged exposure.
⍟ Always insert the lters securely.
Clean lter once every two weeks.
• It may cause failure of appliance
or accident.
• If bracket is damaged, the unit can fall and
cause damage, injury or bodily harm.
• Operation without lters may cause
failure.
⊘ Do not use strong detergent such as
wax or thinner to clean the unit.
Use a soft cloth.
⊘ Do not place heavy object on the
power cord and ensure that the cord
is not compressed.
⊘ Do not drink water drained from
air conditioner.
• Appearance may be deteriorated due to
change of product color or scratching of
its surface.
• There is danger of re or electric shock. • It contains contaminants and could
make you sick.
⍟ Use caution when unpacking and
installing. Sharp edges can cause injury.
⍟ If water enters the unit, turn the unit o at
the power outlet and switch o the circuit
breaker. Isolate supply by taking the pow-
er-plug out and contact a qualied service
technician immediately.
CAUTION
NOTE: The power supply cord with this air conditioner con-
tains a current detection device designed to reduce the risk
of re. In the event that the power supply cord is damaged, it
cannot be repaired-it must be replaced with a cord from the
Product Manufacturer.
The power supply cord contains a current device that senses damage to
the power cord. To test your power supply cord do the following:
1. Plug in the Air Conditioner.
2. The power supply cord will have TWO buttons on the plug head. Press the
TEST button, you will notice a click as the RESET button pops out.
3. Press the RESET button, you will notice a click as the button engages.
4. The power supply cord is now supplying electricity to the unit.
(On some models this it also indicated by a light on the plug head.)
NOTES: • Do not use this device to turn the unit on or o.
• Always make sure the RESET button is pushed in for correct operation.
• The power supply must be replaced if it fails reset when either the TEST button is pushed, or it cannot be reset.
• A new power supply can be obtained from the product manufacturer.
• If power supply cord is damaged, it cannot be repaired. It MUST be replaced by one from the product manufacturer.

4
WHAT’S IN THE BOX:
Please verify your box for the following items. Note that some models may not include all items.
1. Air Conditioning Unit
2. Remote control (may dier from photo)
3. User’s Guide
4. Remote control user’s guide
5. Installation kit (see details below)
❸&❹
❷
INSTALLATION ACCESSORY KIT ITEMS:
TOOLS REQUIRED: large at blade screwdriver, tape measure, adjustable wrench or pliers, pencil, level,
socket wrenches, and Phillips screwdriver.
NOTE: You may not need all listed parts. Discard unused parts.
PART DESCRIPTION QUANTITY PART DESCRIPTION: QUANTITY:
17”Tapered
Spacer Blocks 2Trim Frame (Side Legs) 2
4½”x 3½” x 1½”
Centered/Support Blocks 4Trim Frame (Top & Bottom Legs) 2
⅛”x 4½” x 84”
Plastic Divider 1Ground Wire (green) 1
1”x1½”x25”Seal 3 Toothed Washer
for grounding screw 2
1”x1½”x14”Seal 2 Grounding Screw 1
1”x⅜”x25”Seal 3 Grille (plastic & aluminum) 1
1”x⅜”x14”Seal 2 Nuts (plastic) 4
1”x¾”14”Seal 2 Screw Washer & Screw 4
Avoid damaging your new appliance! If required accessories are missing, please contact technical support.
Illustrations may vary slightly from actual appearance of parts or product.
❶

5
TURNING THE UNIT ON OR OFF:
• Press the On/O Button.
ADJUSTING THE TEMPERATURE:
• Press the up arrow to raise the temperature.
• Press the down arrow to lower the temperature.
• A range of 62°F to 86°F will be maintained.
• To display actual room temperature, use FAN mode.
ADJUSTING THE FAN SPEED:
• Use this button to select fan speed.
• Choose between AUTO, LOW, MED, & HIGH.
• The fan speed in HEAT mode can’t be changed
• The fan speed in DRY mode is set to low.
SET AUTO, COOL, DRY, HEAT OR FAN,MODES:
• Use the mode button to cycle between the modes.
• AUTO mode automatically selects operating mode
based on ambient room temperature.
• Fan speed can’t be adjusted in AUTO mode.
OPERATING YOUR AIR CONDITIONER:
Before you begin, thoroughly familiarize yourself with the control panels as shown below and all its func-
tions, then follow the symbol for the functions you desire. The unit can be controlled by the unit control
alone or with the remote.
NOTE: This illustration is for explanation purposes only. The actual appearance of the control panel on the
air conditioner you bought may be slightly dierent.

6
FAN ONLY MODE:
• Use this mode when you’d like to circulate air or
exhaust stale air but not run the air conditioner.
• Open the vent in fan mode, but for most eciency
keep it closed during cooling mode.
• The display shows the ambient room temperature.
DRY MODE:
• The unit functions as a dehumidier in dry mode.
• Some cooling may occur during this mode.
ENERGY SAVE FEATURE:
• With a press of the Energy Save button, the fan
continues to blow air through the compressor anr
provide cooled air. The fan will run for 2 minutes
every 10 minutes, and cooling will resume once the
room temperature exceeds the set temperature.
SLEEP MODE FEATURE:
• When you push the sleep button, the selected tem-
perature will increase (cooling) or decrease (heat-
ing) by 1°C/2°F after 30 minutes. The temperature
will then increase (cooling) or decrease (heating) by
another 1°C/2°F after an additional 30 minutes.
• The new temperature will be maintained for 7
hours before it returns to the originally selected
temperature. This ends Sleep mode and the unit
will continue to operate as originally programmed.
TIMER & AUTO START/STOP FEATURE:
• The timer indicator lights are for two separate
functions, one to automatically turn the unit on and
another to automatically shut it o. Both programs
can be set at the same time.
Setting the unit to automatically turn o:
• Push the timer button once (if dehumidier is run-
ning) or twice (if dehumidier is not running) until
the‘OFF’indicator illuminates
• Use the + and – pad to select the number of hours
before the unit automatically turns o.
• The time will be programmed after 5 seconds of
inactivity and the display will return to show the
humidity level.
Setting the unit to automatically turn on:
• Push the timer button once (if dehumidier is not
running) or twice (if dehumidier is running) until
the‘ON’indicator illuminates.
• Use the + and – pad to select the number of hours
before the unit automatically turns o.
• The time will be programmed after 5 seconds of
inactivity and the display will return to show the
humidity level.
NOTE: Both‘ON’and ‘OFF’indicators can be illumi-
nated—the unit will automatically turn itself on and
o according to the programmed times.
PERSONAL MAPPING TEMPERATURE SENSOR:
• NOTE: This feature can be activated from the
remote control ONLY and on select models.
The remote control acts as a remote thermostat
allowing for the precise temperature control at its
location.
• To activate the personal mapping temperature
sensor, point the remote control towards the unit
and press the PMTS button. The remote display
is actual temperature at its location. The remote
control will send this signal to the air conditioner
every 3 minutes interval until press the PMTS
button again.
• If the unit does not receive the remote signal
during any 7 minutes interval, the unit will beep
to indicate the personal mapping temperature
sensor mode has ended.

7
CHECK FILTER FEATURE:
• The indicator light illuminiates automatically after
250 hours of operation to help you maintain opti-
mum performance.
• To reset after cleaning the lter, press the Check
Filter button and the light will turn o.
DISPLAYS
• The LCD unit displays the set temperature, or in FAN
mode shows the ambient room temperature.
ION CLEAN AIR FEATURE SELECT MODELS
• The Ion lter will energize to remove allergens and
pollen from the air that passes through the unit.
OTHER USEFUL THINGS
• The COOL function has an automatic 3 minute time
delayed start if the unit is turned o and on quickly.
This prevents overheating of the compressor and
tripping the circuit breaker. The fan will continue to
run during this time.
• The display unit is capable of displaying tempera-
ture in degrees Fahrenheit or degrees Celsius. To
convert from one to the other, press and hold both
the Up and Down Temp/Timer buttons at the same
time, for 3 seconds.
FRESH AIR VENT CONTROL SOME MODELS
The fresh air vent allows the air conditioner to:
1. Recirculate inside air—vent closed (image 1)
2. Draw fresh air in the room—vent open (image 2)
3. Exchange air from the room and draws fresh air
into the room—vent & exhaust open (image 3)
CHOOSING AIR FLOW DIRECTION
• The 4-way air directional blades allow you to direct
the air ow up or bown (on some models) and left
or right throughout the room as needed. To adjust
the directional blades side-to-side. Use the center
handles as you move it side-to-side.
Display
Area
Image 1:
Vent closed
Image 2:
Vent open
Image 3:
Vent & exhaust open
Move blades up/down or left/right to modify
air ow direction.

8
PREINSTALLATION INSTRUCTIONS:
Please read ALL instructions before installing. Two people are recommend to install this product. If a new
electrical outlet is required, have the outlet installed by a qualied electrician before installing unit.
Step 1) Using the following table, nd your wall-sleeve brand of your installation.
Brand
Dimensions
W x H
x D
Page Brand
Dimensions
W x H
x D
Page
White-Westinghouse
Frigidaire
Carrier (52F Series)
25½” x 15¼”x
16”OR 17½”
OR 22”
17 Sears/Kenmore
Carrier(51S Series)
25¾“ x 16⅞“
x 18⅝“14
General Electric
Hotpoint
26”x 15⅝”
x 15⅞14 Fedders Emerson
26¾”’x 15¾”
x 15” 10
Whirlpool 25⅞”x 16½”
x17⅛“15 Fedders, Emerson Friedrich
27 x 16¾”
x 16¾” 12
Whirlpool 25⅞”x 16½”
x23” 16 Fedders Emerson
27”x 16¾”
x19¾” 11
NOTE: All wall sleeves used to mount the new air conditioner must be in
sound structural condition and have a rear grille that securely attaches to
sleeve, or rear ange that serves as a stop for the air conditioner.
CAUTION: When installation is complete, replacement unit MUST have a
rearward slope as shown.
Step 2) Remove old air conditioner from wall sleeve and prepare wall sleeve as follows:
• Clean interior (do not disturb seals).
• Wall sleeve must be securely fastened in wall before installing air conditioner.
• Drive more nails or screws through sleeve, into wall, if needed.
• Repair paint if needed.
Step 3) Remove old air conditioner from wall sleeve and prepare wall sleeve as follows:
If a grounding wire is not already place, drill a 1/8 clearance hole for the grounding screw through left side
of wall sleeve, in a clear area about 3 inches maximum back from front edge of sleeve, using the grounding
screw and toothed washer.
Pull loose end of ground wire out front of sleeve, and temporarily bend it down and around lower edge of
sleeve. This ground wire will later be attached to frame of air conditioner once it is installed.
Step 4) Begin specic wall sleeve preparations based on the instructions referenced in the above table.

9
11
This units increased performance characteristics result from having two rear air intakes.
It is very important that these installation instructions are followed so your unit can operate at
maximum efficiency.
If this is an existing sleeve, and there is an existing rear grille, it needs to be replaced by one that
has been shipped with the unit in the accessory kit.
FOR INCREASED EFFICIENCY,UTILIZE THE PROVIDED LOUVERED REAR PANEL
Installation of new grille provided with unit
1. Remove the existing grille.
2. Place the grille included with the new air conditioner towards the rear of the sleeve.
3. Mark through the hole positions.
4. Drill through the sleeves flanges with a 1/8 drill bit.
5. Attached the new grille with self-threading screws and washers.
6. It is VERY IMPORTANT that the grill e is placed exactly as shown below.
7.Most decorative exterior grilles may be left in place as long as the proper interior air direction grille
is installed.
IMPORTANT
READ CAREFULLY—IMPORTANT

10
12
Wall Sleeve Brands:
#1 Emerson 15 Deep
1. Remove existing rear grille as shown on Page
11 of this manual and replace with provided
louvered rear panel. Install as shown here.
NOTE: You may need to drill holes in flange of
existing sleeve to match new rear grille.
2. Attach(1)1 x3/8 x25 long seal in the center at
the top of the sleeve. Remove the backing paper
and press into position.
3. Attach the (2) 1 x3/8 x14 long seals to the
left and right sides of the sleeve.
4. Cut (2) 1 x3/8 x25 long seals to 14 long,and
attach it to the vertical sections of the rear grille
as shown.
5. Attach (2)4 x3 x1 centering/support blocks
one on each side wall. Place in center of side
wall with the tapered end facing the opening.
6. Gently slide unit into sleeve.
7. Before sliding all-the-way back, remove 2nd
screw from front on left side of unit.
8. Remove the plastic washer from the screw.
9. Screw and attach the other end of the ground
wire to the unit as shown in picture. Make sure
that the toothed washer is against the cabinet.
10.Slide the unit completely to the rear to ensure
a good seal, making sure the ground wire does
not become tangled.
11.Seal & Frame the unit as described on page 22.
12. If you have difficulty with mounting the grill to
the sleeve, follow the instructions for direct
mounting on Page 21.
1
/21 /21
/2
2
4 4
44
383
8
N° 1: EMERSON 15”DEEP WALL SLEEVES
1. Remove existing rear grille as shown on page 9 of this
manual and replace with provided louvered rear panel.
Install as shown here.
11. Seal & frame the unit as described on p.20.
12. If you have diculty with mounting the grill to the
sleeve, follow the instructions for direct mounting on p.19

11
13
Wall Sleeve Brands:
#2 Fedders 19 Deep
1.
34
/
2. Attach(2)4 x3 x1 centering/support blocks
one on each side wall. Place in center of side
wall with the tapered end facing the opening.
3. Cut (2) 17 Tapered Spacer Blocks as shown
below into two pieces.
4. The 4 section is placed in front of the rib on
base with the tapered end facing the back of
the sleeve. The remaining portion will be
placed behind the rib again sloping toward
the rear of the sleeve. This helps induce a
rearward slope on the unit.
5. Attach (1)1 x3/8 x25 long seal in the center
at the top of the sleeve. Remove the backing
paper and press into position.
6. Attach (2) 1 x3/8 x14 seals to the left and
right sides of the sleeve.
7. Cut (2) 1 x3/8 x25 long seals to 14 long
and attach it to the vertical sections of the rear
grille as shown.
8. Gently slide unit into sleeve.
9. Before sliding all-the-way back, remove 2nd
screw from front on left side of unit.
10. Remove the plastic washer from the screw.
11. Screw and attach the other end of the ground
wire to the unit as shown in picture. Make sure
that the toothed washer is against the cabinet.
12.Slide the unit completely to the rear to ensure
a good seal, making sure the ground wire does
not become tangled.
13.Seal & Frame the unit as described on page 22.
14. If you have difficulty with mounting the grill to
the sleeve, follow the instructions for direct
mounting on Page 21.
1
/21
/2 /2
1
/2 /2
Cut Here
3/4
17
Tapered Spacer Block 1
Protection Paper
Backing
5
4
Remove existing rear grille as shown on Page
11 of this manual and replace with provided
louvered rear panel. Install as shown here.
NOTE: You may need to drill holes in flange
of existing sleeve to match new rear grille.
4
4
44
383
8
N° 2: FEDDERS 19¾”DEEP WALL SLEEVES
1. Remove existing rear grille as shown on page 9 of this
manual and replace with provided louvered rear panel.
Install as shown here.
13. Seal & frame the unit as described on p.20.
14. If you have diculty with mounting the grill to the
sleeve, follow the instructions for direct mounting on p.19

12
14
Wall Sleeve Brands:
#3 Fedders or Friedrich 16 Deep
1.Remove existing rear grille as shown on Page
11 of this manual and replace with provided
louvered rear panel. Install as shown here.
NOTE: You may need to drill holes in flange of
existing sleeve to match new rear grille.
34
/
2. Attach(2)4 x3 x1 centering/support blocks
one on each side wall. Place in center of side
wall with the tapered end facing the opening.
3. Cut (2) 17 Tapered Spacer Blocks as shown
below into three pieces.
4. The 2 section is placed in front of the rib on
base with the tapered end facing the back of
the sleeve. Cut the remaining portion to 12
and placed behind the rib again sloping toward
the rear of the sleeve. This helps induce a
rearward slope on the unit.
5. Attach (1)1 x3/8 x25 long seal in the center
at the top of the sleeve. Remove the backing
paper and press into position.
6. Attach (2) 1 x3/8 x14 seals to the left and
right sides of the sleeve.
7. Cut (2) 1 x3/8 x25 long seals to 14 long
and attach it to the vertical sections of the rear
grille as shown.
8. Gently slide unit into sleeve.
9. Before sliding all-the-way back, remove 2nd
screw from front on left side of unit.
10. Remove the plastic washer from the screw.
11. Screw and attach the other end of the ground
wire to the unit as shown in picture. Make sure
that the toothed washer is against the cabinet.
12.Slide the unit completely to the rear to ensure
a good seal, making sure the ground wire does
not become tangled.
13.Seal & Frame the unit as described on page 22.
14. If you have difficulty with mounting the grill to
the sleeve, follow the instructions for direct
mounting on Page 21.
1
/21
/2 /2
1
/2 /2
Cut Here
3/4
17
Tapered Spacer Block 1
Protection Paper
Backing
12-1/2 2-1/2
1
/2
1
/2
5
4 4
44
383
8
N° 3: FEDDERS/FRIEDRICH 16¾” DEEP WALL SLEEVES
1. Remove existing rear grille as shown on page 9 of this
manual and replace with provided louvered rear panel.
Install as shown here.
13. Seal & frame the unit as described on p.20.
14. If you have diculty with mounting the grill to the
sleeve, follow the instructions for direct mounting on p.19

13
15
Wall Sleeve Brands:
#4 General Electra/Hotpoint 16 Deep
1. Remove existing rear grille as shown on Page
11 of this manual and replace with provided
louvered rear panel. Install as shown here.
NOTE: You may need to drill holes in flange of
existing sleeve to match new rear grille.
78
/
2. Cut (2) 17 Tapered Spacer Blocks as shown
below into two pieces.
3. Install 13 section as shown with the tapered end
from the back of the sleeve. This helps induce a
rearward slop on the unit.
4. Attach (1)1 x3/8 x25 long seal in the center
at the top of the sleeve. Remove the backing
paper and press into position.
5. Attach (2) 1 x3/8 x14 seals to the left and
right sides of the sleeve.
6. Cut (2) 1 x3/8 x25 long seals to 14 long
and attach it to the vertical sections of the rear
grille as shown.
7. Center unit and gently slide unit into sleeve.
8. Before sliding all-the-way back, remove 2nd
screw from front on left side of unit.
9. Remove the plastic washer from the screw.
10. Screw and attach the other end of the ground
wire to the unit as shown in picture. Make sure
that the toothed washer is against the cabinet.
11.Slide the unit completely to the rear to ensure
a good seal, making sure the ground wire does
not become tangled.
12.Seal & Frame the unit as described on page 22.
13. If you have difficulty with mounting the grill to
the sleeve, follow the instructions for direct
mounting on Page 21.
1
/2
3/4
17
Tapered Spacer Block 1
Protection Paper
Backing
Cut Here
13
5
4
44
44
383
8
N° 4: GENERAL ELECTRIC/HOTPOINT 16⅞”DEEP WALL SLEEVES
1. Remove existing rear grille as shown on page 9 of this
manual and replace with provided louvered rear panel.
Install as shown here.
12. Seal & frame the unit as described on p.20.
13. If you have diculty with mounting the grill to the
sleeve, follow the instructions for direct mounting on p.19

14
16
Wall Sleeve Brands:
#5 Sears or Carrier 51S Series
( 18 Deep)
1. Remove existing rear grille as shown on Page
11 of this manual and replace with provided
louvered rear panel. Install as shown here.
NOTE: You may need to drill holes in flange of
existing sleeve to match new rear grille.
58
/
2. Install (2) tapered spacer blocks to the floor of
the sleeve as shown. This helps induce a
rearward slop on the unit.
3. Install as shown with the tapered end from
the back of the sleeve. This helps induce a
rearward slop on the unit.
4. Attach (1)1 x3/8 x25 long seal in the center
at the top of the sleeve. Remove the backing
paper and press into position.
5. Attach (2) 1 x3/8 x14 seals to the left and
right sides of the sleeve.
6. Cut (2) 1 x3/8 x25 long seals to 14 long
and attach it to the vertical sections of the rear
grille as shown.
7. Center unit and gently slide unit into sleeve.
8. Before sliding all-the-way back, remove 2nd
screw from front on left side of unit.
9. Remove the plastic washer from the screw.
10. Screw and attach the other end of the ground
wire to the unit as shown in picture. Make sure
that the toothed washer is against the cabinet.
11.Slide the unit completely to the rear to ensure
a good seal, making sure the ground wire does
not become tangled.
12.Seal & Frame the unit as described on page 22.
13. If you have difficulty with mounting the grill to
the sleeve, follow the instructions for direct
mounting on Page 21.
1
/2
5
4
44
44
383
8
N° 5: SEARSKENMORE/CARRIER 51S 18⅝”DEEP WALL SLEEVES
1. Remove existing rear grille as shown on page 9 of this
manual and replace with provided louvered rear panel.
Install as shown here.
12. Seal & frame the unit as described on p.20.
13. If you have diculty with mounting the grill to the
sleeve, follow the instructions for direct mounting on p.19

15
17
Wall Sleeve Brands:
#6 Whirlpool 17 Deep
1. Remove existing rear grille as shown on Page
11 of this manual and replace with provided
louvered rear panel. Install as shown here.
NOTE: You may need to drill holes in flange of
existing sleeve to match new rear grille.
18
/
2. Cut (2) 17 Tapered Spacer Blocks as shown
below into two pieces.
3. Install 13 section to the floor of the sleeve as
shown. This helps induce a rearward slop on the
unit.
4. Attach (1)1 x3/8 x25 long seal in the center
at the top of the sleeve. Remove the backing
paper and press into position.
5. Attach (2) 1 x3/8 x14 seals to the left and
right sides of the sleeve.
6. Cut (2) 1 x3/8 x25 long seals to 14 long
and attach it to the vertical sections of the rear
grille as shown.
7. Center unit and gently slide unit into sleeve.
8. Before sliding all-the-way back, remove 2nd
screw from front on left side of unit.
9. Remove the plastic washer from the screw.
10. Screw and attach the other end of the ground
wire to the unit as shown in picture. Make sure
that the toothed washer is against the cabinet.
11.Slide the unit completely to the rear to ensure
a good seal, making sure the ground wire does
not become tangled.
12.Seal & Frame the unit as described on page 22.
13. If you have difficulty with mounting the grill to
the sleeve, follow the instructions for direct
mounting on Page 21.
3/4
17
Tapered Spacer Block 1
Protection Paper
Backing
Cut Here
13
5
4
44
44
383
8
N° 6: WHIRLPOOL 17⅛”DEEP WALL SLEEVES
1. Remove existing rear grille as shown on page 9 of this
manual and replace with provided louvered rear panel.
Install as shown here.
12. Seal & frame the unit as described on p.20.
13. If you have diculty with mounting the grill to the
sleeve, follow the instructions for direct mounting on p.19

16
18
Wall Sleeve Brands:
#7 Whirlpool ( 23 Deep)
1. Remove existing rear grille as shown on Page
11 of this manual and replace with provided
louvered rear panel. Install as shown here.
NOTE: You may need to drill holes in flange of
existing sleeve to match new rear grille.
2. Place (2) 1 x1 x14 seals against each side.
3. Gently slide unit in and check if amount extend-
ing from the sleeve is sufficient once the trim
frame is attached.
4. If position is Ok, remove unit and proceed to
the next step. If not go to step 9.
5. Attach (1)1 x1 x25 long seal in the center
at the top of the sleeve. Remove the backing
paper and press into position.
6. Attach (2) 1 x1 x14 seals to the left and
right sides of the sleeve.
7. Cut (2) 1 x x25 long seals to 14 long
and attach to the vertical sections of the grille as
shown.
8. Attach the tapered spacer blocks to the floor of
the sleeve. Now go to step 15.
Use these next steps if the unit requires extra
extension into the room.
9. Attach 1 x x14 long seal over the solid
vertical portion of the rear grille.
10. Attach (2) 4 x3 x1 foam blocks with the
slot overlapping the seal above.
11. Install the divider into the slots of the foam
blocks. You may need to trim the length to size.
12. Repeat steps 9-11 for the other vertical shown
portion of the grille as shown in the picture.
13. Attach (2) 1 x1 x14 seals along the sides
of the sleeve again making sure all seals are
flush.
14.Cut the 1 x1 x25 seal to fit the top of the
sleeve. The pieces must be fitted flush to the
edge of the divider.
15. Center unit and gently slide unit into sleeve.
16. Before sliding all-the-way back, remove 1st
screw from front on left side of unit.
17. Remove the plastic washer from the screw.
18. Screw and attach the other end of the ground
wire to the unit as shown in picture. Make sure
that the toothed washer is against the cabinet.
19.Slide the unit completely to the rear to ensure
a good seal, making sure the ground wire does
not become tangled.
20.Seal & Frame the unit as described on page 22.
21. If you have difficulty with mounting the grill to
the sleeve, follow the instructions for direct
mounting on Page 21.
Because of the increased unit depth, first try
dry fitting using the method described below:
1
/2
1
/2
1
/2
3
/8
3
/4
3
/
43
/43
/4
1
/2
6
5
12
9
11
13
10
14
1
/2
7
44
44
383
8
44
7
N° 7: WHIRLPOOL 23”DEEP WALL SLEEVES
1. Remove existing rear grille as shown on page 9 of this
manual and replace with provided louvered rear panel.
Install as shown here.
20. Seal & frame the unit as described on p.20.
21. If you have diculty with mounting the grill to the
sleeve, follow the instructions for direct mounting on p.19

17
N° 8: WESTINGHOUSE/CARRIER 52F 16 & 17”DEEP WALL SLEEVES
19
Wall Sleeve Brands:
#8 White Westinghouse/Frigidaire/
Carrier 52F Series ( 16 +17 Deep)
1.Remove existing rear grille as shown on Page
11 of this manual and replace with provided
louvered rear panel. Install as shown here.
NOTE: You may need to drill holes in flange of
existing sleeve to match new rear grille.
2. Attach (1)1 x3/8 x25 long seal in the center
at the top of the sleeve. Remove the backing
paper and press into position.
3. Attach (2) 1 x3/8 x14 seals to the left and
right sides of the sleeve.
4. Attach (2) 1 x3/4 x14 long seals vertically 4.5
from the left side of the sleeve .Attach the other
1 x3/4 x14 long seal 4 from the right side of the
sleeve.
5. Center unit and gently slide unit into sleeve.
6. Before sliding all-the-way back, remove 2nd
screw from front on left side of unit.
7. Remove the plastic washer from the screw.
8. Screw and attach the other end of the ground
wire to the unit as shown in picture. Make sure
that the toothed washer is against the cabinet.
9. Slide the unit completely to the rear to ensure
a good seal, making sure the ground wire does
not become tangled.
10.Seal & Frame the unit as described on page 22.
11. If you have difficulty with mounting the grill to
the sleeve, follow the instructions for direct
mounting on Page 21.
1
/2
4
23
44
44
383
81. Remove existing rear grille as shown on page 9 of this
manual and replace with provided louvered rear panel.
Install as shown here.
10. Seal & frame the unit as described on p.20.
11. If you have diculty with mounting the grill to the
sleeve, follow the instructions for direct mounting on p.19

18
20
Wall Sleeve Brands: #9 White Westinghouse or Frigidaire
( 22 Deep)
2. Place (2) 1 x1 x14 seals against each side.
3. Gently slide unit in and check if amount extend-
ing from the sleeve is sufficient once the trim
frame is attached.
4. If position is Ok, remove unit and proceed to
the next step. If not go to step 8.
5. Attach (1)1 x1 x15 long seal to the left and
right sides of the sleeve.
6. Cut (1) 1 x1 x25 long seal to 14 long and
attach it vertically to the rear grill 4.5 from
the left side ,repeat and attach 4 from the right
side.
7. Attach(1) 1 x1 x25 long seal in the center at
the top of the sleeve.Remove the backing paper
and press into position.Proceed to step 14.
Use these next steps if the unit requires extra
extension into the room.
8. Attach 1 x x14 long seal over the solid
vertical portion of the rear grille.
9. Attach (2) 4 x3 x1 foam blocks with the
slot overlapping the seal above.
10. Install the divider into the slots of the foam
blocks. You may need to trim the length to size.
11. Repeat steps 8-10 for the other vertical shown
portion of the grille as shown in the picture.
12. Attach (2) 1 x1 x14 seals along the sides
of the sleeve again making sure all seals are
flush.
13.Cut the 1 x1 x25 seal to fit the top of the
sleeve. The pieces must be fitted flush to the
edge of the divider.
14. Center unit and gently slide unit into sleeve.
15. Before sliding all-the-way back, remove 1st
screw from front on left side of unit.
16. Remove the plastic washer from the screw.
17. Screw and attach the other end of the ground
wire to the unit as shown in picture. Make sure
that the toothed washer is against the cabinet.
18.Slide the unit completely to the rear to ensure
a good seal, making sure the ground wire does
not become tangled.
19.Seal & Frame the unit as described on page 22.
20. If you have difficulty with mounting the grill to
the sleeve, follow the instructions for direct
mounting on Page 21.
Because of the increased unit depth, first try
dry fitting using the method described below:
1
/2
1
/2
1
/2
1
/2
3
/4
3
/43
/43
/4
1
/2
1
/2
1.
6
7
11
8
10
12
9
13
Remove existing rear grille as shown on Page
11 of this manual and replace with provided
louvered rear panel. Install as shown here.
NOTE: You may need to drill holes in flange
of existing sleeve to match new rear grille.
5
6
44
44
383
8
44
N° 9: WHITE/WESTINGHOUSE FRIGIDAIRE 22”DEEP WALL SLEEVES
1. Remove existing rear grille as shown on page 9 of this
manual and replace with provided louvered rear panel.
Install as shown here.
19. Seal & frame the unit as described on p.20.
20. If you have diculty with mounting the grill to the
sleeve, follow the instructions for direct mounting on p.19
