Impex CLUB REVOLUTION CYCLE Installation and operating instructions

NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Pack
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
H2502C
Retain This
Manual for
Reference
110624
ASSEMBLY &
OWNER'S
MANUAL
CLUB REVOLUTION
CYCLE
H2502C
IMPEX®INC.
2801 S. Towne Ave, Pomona, CA 91766
Tel: [phone] Fax: [phone]
www.impex-fitness.com
[email protected]

TABLE OF CONTENTS
BEFORE YOU BEGIN...................................................................................….. 1
IMPORTANT SAFETY NOTICES..................................................................…. 2
WARNING LABEL PLACEMENT…………………………………………………. 3
HARDWARE PACK……….....…....................................................................…. 4
ASSEMBLY INSTRUCTIONS........................................................................…. 6
EXPLODED DIAGRAM……………………………………………………………... 8
PARTS LIST...................................................................................................….. 9
CARE, MAINTENANCE, AND STORAGE………………………………………… 10
OPERATING NOTES………………………………………………………………… 11
EXERCISE GUIDELINES……………………………………………………………. 12
WARRANTY.................................................................................................……. 13
ORDERING PARTS.....................................................................................……. 13
BEFORE YOU BEGIN
Thank you for selecting the MARCY Club Revolution Cycle H2502C by IMPEX®INC.
For your safety and benefit, read this manual carefully before using the bike. As a
manufacturer, we are committed to provide you complete customer satisfaction. If you
have any questions, or find there are missing or damaged parts, we guarantee you
complete satisfaction through direct assistance from our factory. To avoid
unnecessary delays, please call our TOLL-FREE customer service number. Our
Customer Service Agents will provide immediate assistance to you.
Toll-Free Customer Service Number
1-800-999-8899
Mon. - Fri. 9 a.m. - 5 p.m. PST
www.impex-fitness.com
[email protected]
© IMPEX INC. 1

© IMPEX INC. 2
IMPORTANT SAFETY NOTICE
PRECAUTIONS
This exercise bike is built for optimum safety. However, certain precautions apply
whenever you operate a piece of exercise equipment. Be sure to read the entire manual
before you assemble or operate your bike. In particular, note the following safety
precautions:
1. Keep children and pets away from the exercise bike at all times. DO NOT leave
children unattended in the same room with the bike.
2. Only one person at a time should use the bike.
3. If the user experiences dizziness, nausea, chest pain, or any other abnormal symptoms,
STOP the workout at once. CONSULT A PHYSICIAN IMMEDIATELY.
4. Position the bike on a clear, leveled surface. DO NOT use the bike near water or
outdoors.
5. Keep hands away from all moving parts.
6. Always wear appropriate workout clothing when exercising. DO NOT wear robes or
other clothing that could become caught in the bike. Running or aerobic shoes are also
required when using the bike.
7. Use the bike only for its intended use as described in this manual. DO NOT use
attachments not recommended by the manufacturer.
8. Do not place any sharp object around the bike.
9. Disabled person should not use the bike without a qualified person or physician in
attendance.
10. Before using the bike to exercise, always do stretching exercises to properly warm up.
11. Never operate the bike if it is not functioning properly.
12. Read all warnings posted on the exercise bike.
13. Inspect the exercise bike for worn or loose component prior to use. Tighten/replace any
loose or wore components prior to use.
14. Care should be taken in mounting or dismounting the exercise bike.
15. This exercise bike is for consumer and home use only.
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE
OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL
INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES
NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE
SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.
SAVE THESE INSTRUCTIONS.

WARNING LABEL PLACEMENT
The Warning Labels and Caution Label shown here have been placed on the Rear Stabilizer, Main Frame.
If the labels are missing or illegible, please call customer service at 1-800-999-8899 for replacement. Apply the
labels in location shown.
© IMPEX INC. 3

HARDWARE PACK
NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
No. Description Identifier Q’ty
8 Lever Knob
4
9 M8 x 5/8” Allen Bolt
4
16 M8 x 2 7/8” Carriage Bolt 4
17 Ø 7/8” Curved Washer 4
18 M8 Acorn Nut
4
19 Ø 5/8” x Ø 3/8” Flat Washer
4
20 Ø ½” x Ø 3/8” Lock Washer
4
#6 Allen Wrench
1
Crossing Wrench
1
© IMPEX INC. 4

COMPONENTS FOR ASSEMBLY
© IMPEX INC. 5

ASSEMBLY INSTRUCTION
Tools Required For Assembling the Bike: One Crossing Wrench and Allen Wrench,
provided by manufacturer.
NOTE: It is strongly recommended that two or more people assemble this bike to
avoid possible injury.
STEP-1
A.) Do not tighten Bolts until instructed to do so.
B.) Thread two Level Adjustment Knobs (#8) each onto the Front & Rear Stabilizer (#2 & #3).
C.) Attach the Front Stabilizer (#2) to the Main Frame (#1). Secure it with two M8 x 2 ¾” Carriage Bolts
(#16), two Ø 5/8” Curved Washers (#17), and two M8 Acorn Nuts (#18).
D.) Attach the Rear Stabilizer (#3) to the Main Frame (#1). Secure it with two M8 x 2 ¾” Carriage Bolts
(#16), two Ø 5/8” Curved Washers (#17), and two M8 Acorn Nuts (#18).
E.) Securely tighten all Bolts.
F.) Adjust the Level Adjustment Knob to stabilize the Bike on floor.
G.) Thread the Right Pedal (#15) clockwise onto the right Crank (#38).
H.) Thread the Left Pedal (#14) counterclockwise onto the left Crank (#38)
© IMPEX INC. 6

STEP 2
A.) Insert the Handle Post (#6) into the front opening on Main Frame (#1). Use the Lock Knob (#11) to
hold the Handle Post at selected height.
B.) Attach the Handle (#7) to the Handle. Secure them together with four M8 x 5/8” Allen Bolts (#9),
four Ø 5/8” Lock Washers (#20), and four Ø 5/8” Flat Washers (#19).
C.) Insert the Seat Post (#4) into the opening on Main Frame. Use the Lock Knob (#11) to hold the
Seat Post at selected height.
D.) Flip over the Seat Pad (#12). Insert the tube of the Seat Support into the open slot and securely
fasten the two nuts to secure the Seat Pad to the tube.
E.) Insert the Seat Support (#5) through the open slot on Seat Post. Use the Lock Knob (#11) to hold
the Seat at selected position.
© IMPEX INC. 7

EXPLODED DIAGRAM
© IMPEX INC. 8

© IMPEX INC. 9
PARTS LIST
PART
NO. DESCRIPTION SPEC. QUANTITY
1 Main Frame 1
2 Front Stabilizer 1
3 Rear Stabilizer 1
4 Vertical Seat Post 1
5 Seat Support 1
6 Handle Post 1
7 Handle 1
8 Level Adjustment Knob 4
9 Allen Bolt M8 x 5/8” 4
10 Tension Adjustment Knob 1
11 Lock Knob 3
12 Seat Pad 1
13 Brake Handle 1
14 Left Pedal 1
15 Right Pedal 1
16 Carriage Bolt M8 x 2 7/8” 4
17 Curved Washer Ø 7/8” 4
18 Acorn Nut M8 4
19 Flat Washer Ø 5/8” x Ø 3/8” 4
20 Lock Washer Ø ½” x Ø 3/8” 4
21 Handle Grip 2
22 Round End Cap Ø 1” 2
23 Rectangle End Cap 7/8” x 2” 4
24 Sleeve 4
25 Bottle Rack 1
26 Philips Screw M4 x ¾” 2
27 Brake Bracket 1
28 Brake Pad 1
29 Flywheel 1
30 Flywheel Axle 1
31 Flywheel Ball Bearing 6001 2
32 Stabilizer End Cap 4
33 Aircraft Nut M8 2
34 Roller Wheel 2
35 Allen Bolt M8 x 1 5/8” 2
36 Shroud 1
37 Chain Belt 1
38 Crank 1
39 Crank Axle 1
40 Crank Ball Bearing 6203 2
