Impex MARCY ME-709 User manual

NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Pack
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
ME-709
Retain This
Manual for
Reference
06-15-09
OWNER'S
MANUAL
MARCY®
Magnetic-Resistance
Recumbent Bike
ME-709
IMPEX®INC.
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: [phone] Fax: [phone]
www.impex-fitness.com
[email protected]

TABLE OF CONTENTS
BEFORE YOU BEGIN...................................................................................…. 1
IMPORTANT SAFETY NOTICES..................................................................…. 2
HARDWARE PACK……….....…....................................................................…. 4
ASSEMBLY INSTRUCTIONS........................................................................…. 5
EXPLODED DIAGRAM………………………………………………………………. 10
PARTS LIST...................................................................................................… 11
COMPUTER................................................................................................…… 12
WARRANTY.................................................................................................…. 16
ORDERING PARTS.....................................................................................….. 16
BEFORE YOU BEGIN
Thank you for selecting the MARCY®Magnetic Recumbent Bike ME-709 by
IMPEX®INC. For your safety and benefit, read this manual carefully before
using the machine. As a manufacturer, we are committed to provide you
complete customer satisfaction. If you have any questions, or find there are
missing or damaged parts, we guarantee you complete satisfaction through
direct assistance from our factory. To avoid unnecessary delays, please call
our TOLL-FREE customer service number. Our Customer Service Agents
will provide immediate assistance to you.
1
Toll-Free Customer Service Number
1-800-999-8899
Mon. - Fri. 9 a.m. - 5 p.m. PST
www.impex-fitness.com
[email protected]m

IMPORTANT SAFETY NOTICE
PRECAUTIONS
This exercise machine is built for optimum safety. However, certain
precautions apply whenever you operate a piece of exercise equipment. Be
sure to read the entire manual before you assemble or operate your machine.
In particular, note the following safety precautions:
1. Keep children and pets away from the machine at all times. DO NOT
leave children unattended in the same room with the machine.
2. Only one person at a time should use the machine.
3. If the user experiences dizziness, nausea, chest pain, or any other
abnormal symptoms, STOP the workout at once. CONSULT A PHYSICIAN
IMMEDIATELY.
4. Position the machine on a clear, leveled surface. DO NOT use the machine
near water or outdoors.
5. Keep hands away from all moving parts.
6. Always wear appropriate workout clothing when exercising. DO NOT wear
robes or other clothing that could become caught in the machine. Running
or aerobic shoes are also required when using the machine.
7. Use the machine only for its intended use as described in this manual. DO
NOT use attachments not recommended by the manufacturer.
8. Do not place any sharp object around the machine.
9. Disabled person should not use the machine without a qualified person or
physician in attendance.
10. Before using the machine to exercise, always do stretching exercises to
properly warm up.
11. Never operate the machine if the machine is not functioning properly.
12. The Maximum Weight Capacity is 300 lbs.
13. Read all warnings posted on the exercise bike.
14. Inspect the exercise bike for worn or loose component prior to use.
Tighten/replace any loose or wore components prior to use.
15. Care should be taken in mounting or dismounting the exercise bike.
16. This exercise bike is for consumer and home use only.
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT
YOUR PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS
OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH
PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS
EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR
PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR
THROUGH THE USE OF THIS PRODUCT.
SAVE THESE INSTRUCTIONS. 2

WARNING LABEL REPLACEMENT
The Warning Label shown here has been placed on the Rear Stabilizer. If the label is missing or
illegible, please call customer service at 1-800-999-8899 for replacement. Apply the label in
location shown.
3

HARDWARE PACK
Part# Description Identifier
#8 M8 x 5/8” Allen Bolt (Qty 12)
#9 Ø 7/8” Curved Washer (Qty 8)
#13 M8 x 2 ½” Carriage Bolt (Qty 4)
#19 Acorn Nut (Qty 4)
#20 M8 Leverage Knob (Qty 1)
#27 Ø 5/8” Washer (Qty 12)
#31 M8 x 3” Hex Bolt (Qty 4)
#33 M8 Aircraft Nut (Qty 4)
Tools:
Allen Wrench (Qty 1)
Crossing Wrench (Qty 1)
4

PRE-ASSEMBLY CHECK LIST
PART NO. DESCRIPTION Q’TY
1 Main frame 1
25 Seat support tube 1
26 Sliding frame 1
14 Front Stabilizer w/Transportation Wheel 1
30 Rear Stabilizer w/Leveling End Cap 1
4 Front post 1
35 Back Cushion 1
28 Seat Cushion 1
32 Seat support tube 1
2 Computer 1
17 Pedal 2
5

ASSEMBLY INSTRUCTION
NOTE: It is strongly recommended that two or more people assemble this machine to
avoid possible injury.
STEP 1 (See Diagram1)
A.) Do not tighten Nuts and Bolts until instructed to do so.
B.) Insert the Sliding Frame (#26) into the Main Frame (#1). Thread the Quick Release Knob
(#24) through selected hole on Main Frame into Sliding Frame to lock the Frame in position.
Thread a M8 Leverage Knob (#20) into the Sliding Frame from bottom.
C.) Attach the Front Stabilizer (#14) to the Main Frame (#1). Secure it with two M8 x 2 ½”
Carriage Bolts (#13), two ∅7/8” Curved Washers (#9), and two M8 Acorn Nuts (#19).
D.) Attach the Sliding Frame to the Rear Stabilizer (#30). Secure it with two M8 x 2 ½” Carriage
Bolts (#13), two Ø 7/8” Curved Washers (#9), and two M8 Acorn Nuts (#19).
E.) Securely tighten all Nuts and Bolts.
F.) Rotate the two Rear Stabilizer End Caps (#29), and attach the M8 Leverage Knob on floor
completely to stabilize the Bike before exercising. DIAGRAM 1
6

STEP 2 (See Diagram 2)
A.) Note: In order to hold the Front Post (#4) while connecting the cables and wires,
extra help may be needed.
B.) Attach the Front Post (#4) to the Main Frame (#1). Connect the Upper Computer Wire
(#10) from the bottom of Front Post to the Lower Computer Wire (#12) from the main
Fame.
C.) Pull the tension connector from the Upper Tension Cable (#7) and slide in between the
opening on the connector holder on the Lower Tension Cable (#11). Pull the Upper
Tension Cable upward and slide the wire through the slot on the bracket.
D.) Drop down the Upper Tension Cable so the fitting sits firmly on top of the bracket.
E.) Secure the Front Post to the Main Frame with four M8 x 5/8” Allen Bolts (#8) and four
Ø 7/8” Curved Washers (#9).
DIAGRAM 2
7

STEP 3 (See Diagram 3)
A.) Attach the Seat Support (#25) to bracket on the Sliding Frame (#26). Secure it with
two M8 x 2 ¾” Hex Bolts (#31), two Ø 5/8” Washers (#27), and two M8 Aircraft Nuts
(#33).
B.) Attach the Backrest Board (#28) to the Seat Support. Secure it with four M8 x 5/8”
Allen Bolts (#8) and four Ø 5/8” Washers (#27).
C.) Attach the Seat Pad (#32) to the Seat Support. Secure it with four M8 x 5/8” Allen
Bolts (#8) and four Ø 5/8” Washers (#27).
D.) Pull up the Quick Release Knob (#24), slide the Sliding Frame to desired position,
and release the Knob to lock the Seat in position. DIAGRAM 3
8

STEP 4 (See Diagram 4)
A.) Attach the Handle (#22) to the Seat Support (#25). Secure it with two M8 x
2 ¾” Hex Bolts (#31), two Ø 5/8 Washers (#27), and two M8 Aircraft Nuts
(#33).
B.) Connect Upper Computer Wire (#10) to the wire on the Computer.
Remove the two M5 x 3/8” Philips Screws (#3) from Computer. Slide the
Computer onto the bracket on Front Post. Secure it with the two Screws.
C.)Thread the left Pedal (#17L) Counterclockwise into the left Crank #21).
Thread the right Pedal (#17R) Clockwise into the Crank on the other side.
DIAGRAM 4
9
