Impex APEX PT-36 User manual

NOTE:
Please read all instructions
carefully before using this
product
Safety Notice
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
PT-36
Retain This
Manual for
Reference
100510
OWNER'S
MANUAL
APEX
PLATE TREE PT-36
IMPEX INC.
2801 S. Towne Ave., Pomona, CA 91766
Tel: [phone] Fax: [phone]
www.impex-fitness.com
[email protected]

TABLE OF CONTENTS
BEFORE YOU BEGIN...................................................................................... 1
IMPORTANT SAFETY NOTICES..................................................................... 2
ASSEMBLY INSTRUCTIONS........................................................................... 5
PARTS LIST...................................................................................................... 6
WARRANTY.................................................................................................…. 7
ORDERING PARTS.......................................................................................… 7
BEFORE YOU BEGIN
Thank you for selecting the APEX PT-36 Plate Tree by IMPEX INC. For
your safety and benefit, read this manual carefully before using the
machine. As a manufacturer, we are committed to provide you complete
customer satisfaction. If you have any questions, or find there are missing
or damaged parts, we guarantee you complete satisfaction through direct
assistance fro our factory. To avoid unnecessary delays, please call our
TOLL-FREE customer service number. Our Customer Service Agents will
provide immediate assistance to you.
Toll-Free Customer Service Number
1-800-999-8899
Mon. – Fri. 9 a.m. – 5 p.m. PST
www.impex-fitness.com
[email protected]
1

IMPORTANT SAFETY NOTICE
PRECAUTIONS
This exercise machine is built for optimum safety. However, certain precautions apply
whenever you operate a piece of exercise equipment. Be sure to read the entire
manual before you assemble or operate your machine. In particular, note the following
safety precautions:
1. Keep children and pets away from the machine at all times. DO NOT
leave children unattended in the same room with the machine.
2. Only one person at a time should use the machine.
3. If the user experiences dizziness, nausea, chest pain, or any other abnormal
symptoms, STOP the workout at once. CONSULT A PHYSICIAN IMMEDIATELY.
4. Position the machine on a clear, leveled surface. DO NOT use the machine
near water or outdoors.
5. Keep hands away from all moving parts.
6. Always wear appropriate workout clothing when exercising. DO NOT wear
robes or other clothing that could become caught in the machine. Running
or aerobic shoes are also required when using the machine.
7. Use the machine only for its intended use as described in this manual. DO
NOT use attachments not recommended by the manufacturer.
8. Do not place any sharp object around the machine.
9. Disabled person should not use the machine without a qualified person or
physician in attendance.
10. Before using the machine to exercise, always do stretching exercises to
properly warm up.
11. Never operate the machine if the machine is not functioning properly.
12. Maximum weight capacity: 300 lbs.
13. Assembled Dimension: 28” x 28”x 32”
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE
AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL
INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC.
ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY
DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.
SAVE THESE INSTRUCTIONS.
2

WARNING LABEL PLACEMENT
The Warning Label shown here has been placed on the Base Frame. If the label is missing or illegible, please
call customer service at 1-800-999-8899 for replacement. Apply the label in location shown.
3

HARDWARE PACK
4

ASSEMBLY INSTRUCTION
Tools Required to Assemble the Machine: One Adjustable Wrench
STEP 1 (See Exploded Diagram)
A.) Attach three Base Frames (#2) to the Post Frames (#3 & #4). Secure each with one M10 x ¾”
Carriage Bolt (#6), 3/4” Washer (#7), and M10 Aircraft Nut (#8). Do not tighten the Nuts and
Bolts yet.
B.) Connect the three Base Frames (#2) together with a Bracket (#5). Secure them with three M10
x ¾” Carriage Bolts (#6), Ø ¾” Washers (#7), and M10 Aircraft Nuts (#8).
C.) Place the Cup Holder (#1) onto the top of the three Post Frames. Secure them together with
three M10 x ¾” Carriage Bolts (#6), Ø ¾” Washers (#7), and M10 Aircraft Nuts (#8).
D.) Securely tighten all Nuts and Bolts. Place the Cup (#11) on the top.
E.) Attach eight Spring Clips (#9) to the posts.
EXPLODED DIAGRAM
5

Parts list
KEY NO. DESCRIPTION Q’ty
1 Cup Holder 1
2 Base Frame 3
3 Three-Post Frame 2
4 Two-Post Frame 1
5 Bracket 1
6 M10 x ¾” Carriage Bolt 9
7 ¾” Washer 9
8 M10 Aircraft Nut 9
9 Spring Clip 8
10 1” Cone Shaped End Cap 8
11 Cup 1
6

IMPEX INC.
LIMITED WARRANTY
IMPEX Inc. ("IMPEX") warrants this product to be free from defects in workmanship and material,
under normal use and service conditions, for a period of two years on the Frame from the date of
purchase. This warranty extends only to the original purchaser. IMPEX's obligation under this
Warranty is limited to replacing or repairing, at IMPEX's option.
All returns must be pre-authorized by IMPEX. Pre-authorization may be obtained by calling
IMPEX Customer Service Department at 1-800-999-8899. All freights on products returned to
IMPEX must be prepaid by the customer. This warranty does not extend to any product or
damage to a product caused by or attributable to freight damage, abuse, misuse, improper or
abnormal usage or repairs not provided by an IMPEX authorized service center or for products
used for commercial or rental purposes. No other warranty beyond that specifically set forth
above is authorized by IMPEX.
IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or
in connection with the use or performance of the product or other damages with respect to any
economic loss, loss of property, loss of revenues or profits, loss of enjoyments or use, costs of
removal, installation or other consequential damages or whatsoever natures. Some states do
not allow the exclusion or limitation of incidental or consequential damages. Accordingly, the
above limitation may not apply to you.
The warranty extended hereunder is in lieu of any and all other warranties and any implied
warranties of merchantability or fitness for a particular purpose is limited in its scope and duration
to the terms set forth herein. Some states do not allow limitations on how long an implied
warranty lasts. Accordingly, the above limitation may not apply to you.
This warranty gives you specific legal right. You may also have other rights which vary from
state to state.
IMPEX INC.
2801 S. Towne Ave.
Pomona, CA 91766
ORDERING REPLACEMENT PARTS
Replacement parts can be ordered by calling our Customer Service Department toll-free at 1-
800-999-8899 during our regular business hours: Monday through Friday, 9 am until 5 pm
Pacific standard time.
www.impex-fitness.com
[email protected]
When ordering replacement parts, always give the following information.
1. Model
2. Description of Parts
3. Part Number
4. Date of Purchase

7
