IMRELAX IM-MH90S User manual

IM-MH90S
90W LED SPOT MOVING HEAD
USERMANUAL
Ver1.0

Table of contents
1. Preface 2
1.1 Packing list 2
1.2 Unpacking instructions 2
1.3 AC Power 2
1.4 Safety instructions 2
2. Introduction 3
2.1 Features 3
2.2 DMX channel 3
3. Setup 4
3.1 Fuse replacement 4
3.2 Fixture linking 4
3.3 3-Pin to 5-Pin conversion chart 4
3.4 Setting up a DMX serial data link 4
3.5 Master/Slave fixture linking 5
3.6 orientation 5
4. Operating instructions 5
4.1 Description of operation panel 5
4.2 Menu map 5
4.3 DMX channel values 7
5. Technical specifications 10

Pleaseread theseinstructions, it includes importantinformation aboutthe
installation, usage and maintenance of this product.
Warning! Verify that the voltage select switch on yourunit matches theline
voltageapplied. Damagetoyour fixture may result if the linevoltageapplied
does not match the voltageindicatedon the voltageselector switch. All fixtures
must be connected to circuits with a suitableEarth ground.
1. Preface
1.1 Packing list
Product name quantity
moving head light 1 pcs
Power -line 1 base
User manual 1pcs
1.2 Unpacking instructions
On receiving afixture, carefully unpack thecarton, check the contentsto
ensurethat all partsare presented, and have been received in agood
condition.Notify the shipper immediately and retainpackingmaterial for
inspectionif any partsappear damagedfrom shippingor the cartonitself
shows, sign of mishandling. Save thecartonandallpackingmaterials. In the
event that afixture must be returned to thefactory,it is important that the
fixture should be returned in originalfactory box and packing.
1.3 AC Power
Todetermine thepower requirementsfor aparticularfixture, see the label
affixed to the back plate of the fixture or referred to the fixtures specification
chart. Afixture listed current ratingis itsaveragecurrent drawunder normal
conditions. All fixtures must be directly poweredoffaswitched circuit and
cannot berun offarheostat (variable resistor) or dimmer circuit, evenif the
rheostat or dimmer sourcevoltage matchesthe fixtures requirement. Check
the fixture or device carefully to make sure that if avoltageselectionswitch
exists that it is set to the correct line voltage you will use.
1.4 Safety instructions
Pleasekeep this user guide for future consultation. If you sell theunit to
another user, be sure that they alsoreceive this instruction booklet.
Always make surethat youare connectingto the proper voltage, andthat the

linevoltage youareconnecting to is not higherthan thatstated on the decal or
rear panel of the fixture.
Before thefirst time to use it, Pleasecheck whether the damagein transit, if
happendamagesin transit, pleasedo not use this lamp, andpleaseasap
contact distributors or manufacturers.
Pleasedon't install the lamp in theordinary combustible materialonthe
surface. Lamp shouldbe installedinthe well ventilatedplace, and thedistance
of the wall to keepit over 10 cm, at the same time, please checkthe fan hole
was clear.
Do not use lamp direct project in flammableobjects, lamp andthe radiation
of the distance between theobjects please keep it over 12 m.
Do not use direct lamp project light source , toavoid damage the eyes.
Before installation,please make sure your use power supplyvoltageand
marked voltage
Note: beforeany install, maintain and clean lamp, please confirm cut off the
power supply.
2. Introduction
2.1 Features
*Light source:1pcs 90W white LED
*Electronic dimmer 0~100%
*Fan Cooling /Forced convection
*Pan movement:540
*Tilt movement:270
*Pan/Tilt resolution:8-16bit
*Prism rotating 3-facet prism
*Focus:linear focus from close to far
*1 fixed gobo wheel: 8gobos plus blank
*1 rotated gobo wheel: 6gobos plus blank,gobo rotating 360
*1 color wheel:7colors plus white
*Strobe:0-16Hz, from slow to fast, adjusting
*Control mode:Auto, soundactive , DMX512
*DMX channel:15CH
* LCD display
2.2 DMX channel
3. Setup
Disconnect the power cord beforereplacingafuse andalways replacewiththe
same type fuse.
3.1 Fuse replacement
With aflat head screwdriver wedge the fuseholdout of itshousing. Remove

the damaged fuse from itsholder andreplacewith exactsame type fuse. Insert
the fuse holder back in its place and reconnect power.
3.2 Fixture linking
You willneed aserial datalink to run light showof one or more fixtures using a
DMX-512 controlleror to run synchronized ontwo or more fixtures set to a
master/slave operating mode. The combinednumberof channels required by
all the fixtures on aserial datalink determinesthe number of fixtures the data
link can support.
3.3 3-Pin to 5-Pin conversion chart
Note! If you useacontrollerwith a5pin DMX output connector.You will need
to use a 5pin to 3 pin as apter
CHAUVETModel No: DMX5M. Or DMX 5F
The chartbelow details a proper cable conversion:
3.4 Setting up a DMX serial data link
At first link the first light and DMX control through XLR-connectionsignal cable,
then connect the light in series, as the follow：
3.5 Master/Slave fixture linking
1. Connect the (male) 3pinconnector side of the DMX cableto the output
(female) 3pin connector of the first fixture.
2. Connect the endof thecablecoming fromthe first fixture which will have a
(female) 3pin connector to the input connectorof the next fixture consisting of
a(male) 3pinconnector.Then, proceed to connect fromthe output as stated
above to the input of the following fixture and so on.
3.6 orientations
This fixture may be mountedin any position providedthere is adequateroom
for ventilation.

4. Operating instructions
4.1 Description of operation panel
4.2 Menu map
Setting
running mode
Controller
sound
performance 1
performance 2
performance 3
performance 4
random
Address 1-512
DMX 15CH
sound sensitivity 1-99
Pan Reverse ON/OFF
Tilt Reverse ON/OFF
Pan/Tilt exchange swap
ON/OFF
coding mask ON/OFF
Signal timeout Blackout /keep
Screen saveON/OFF
color liner ON/OFF
reset Confirm
Manual mode
dimmer 0-255
strobe 0-255
pan 0-255
pan fine 0-255
up
menu enter menu
down
DMX
ERR

tilt 0-255
tilt fine 0-255
pan/tilt speed 0-255
color 0-255
gobo 0-255
gobo2 0-255
gobo2 rotate 0-255
focus 0-255
prism rotate 0-255
auto 0-255
reset >
offset value
offset value
pan offset -128）- +127）
tilt offset -128）- +127）
color wheeloffset -128）- +127）
gobo wheeloffset -128）- +127）
gobo wheel2 offset -128）- +127）
focusoffset -128）- +127）
Advance setting
language switch Confirm
The screen upside
down Confirm
Time to reset Confirm
Protect the
temperature 0-120
Hardware
information
color wheelHoare X
gobo wheelHoare X
gobo wheel2Hoare X
focus Hoare X
pan codingmask XX
pan route XXXXX
tilt coding mask XX
tilt route XXXXX
System information
Version XXXXXXXXXX
Use time offixture XXXXX
Turn on time XXXXX
temperature XXX
When the Temperatureresistance has problem, the screenwill
have the followingtips:
Thermistor Open
Thermistor Short
Thermistor Hot

4.3DMXchannels
15CH
15
channel
Function channel
value description
1 dimmer 0-255 from dark to bright
2 strobe 0-10 no strobe
11-255
from slow to fast strobe
3 pan 0-255 pan
4 pan fine 0-255 pan 16 bit
5 tilt 0-255 tilt
6 tilt fine 0-255 tilt 16 bit
7 pan tilt speed 0-255 pan tilt speed slow
8 color
0-9 white
10-19 white+color 1
20-29 color 1
30-39 color 1+color 2
40-49 color 2
50-59 color 2+color 3
60-69 color 3
70-79 color 3+color 4
80-89 color 4
90-99 color 4+color 5
100-109
color 5
110-119
color 5+color 6
120-129
color 6
130-139
color 6+color 7
140-149
color 7
150-159
color 7+white
160-255
color anticlockwise from slow tofast
water
9 fix gobo wheel
0-9 white
10-19 gobo 1
20-29 gobo 2
30-39 gobo 3
40-49 gobo 4
50-59 gobo 5
60-69 gobo 6
70-79 gobo 7
80-89 gobo 8
90-99 white

9 fix gobo wheel
100-109
gobo 1 shake
110-119
gobo 2 shake
120-129
gobo 3 shake
130-139
gobo 4 shake
140-149
gobo 5 shake
150-159
gobo 6 shake
160-169
gobo 7 shake
170-179
gobo 8 shake
180-214
gobo clockwise from fast to slow
215-219
stop
220-255
gobo anticlockwise from slow tofast
10 gobo 2
0-9 white
10-19 rotated gobo 1
20-29 rotated gobo 2
30-39 rotated gobo 3
40-49 rotated gobo 4
50-59 rotated gobo 5
60-69 rotated gobo 6
70-79 white shake
80-89 rotated gobo 1 shake
90-99 rotated gobo 2 shake
100-109
rotated gobo 3 shake
110-119
rotated gobo 4 shake
120-129
rotated gobo 5 shake
130-139
rotated gobo 6 shake
140-194
rotated gobo clockwise from
195-199
stop
200-255
rotated gobo anticlockwise from
11 gobo 2 rotated
0-127 gobo degree
128-190
gobo clockwise from fast to slow
191-192
stop
193-255
gobo anticlockwise from slow tofast
12 focus 0-255 focus
13 prism rotated
0-127 invalid
128-136
valid
137-255
prism from slow tofastrotated
14 Macro Function
0-255 from dark to bright
0-5 invalid
6-55 Perform 1
56-105
Perform 2

106-155
Perform 3
156-205
Perform 4
206-255
random model
15 reset
0-25 invalid
26-76 Motor reset
77-127
XY reset
128-255
Whole reset
5.Technical specifications
Voltage AC100-240v 50/60Hz
LED 90W LED
Color wheel 7 colors+open
Gobo wheel 1 fixed gobo wheel: 8gobos plus blank
1rotated gobowheel: 6gobos plus blank,gobo
rotating 360
Max temperature 104 F(40 C)
Data input/output 3pin XLR-connection、anode socket
Outside size 270*190*390mm
N.W 9kg
