IQL® Albireo Floodlight 2 Version 5.1 201302
Contents
1. Safety..................................................................................................................................... 3
2. Warranty................................................................................................................................ 3
2.1 General.................................................................................................................................... 3
2.2 Life span .................................................................................................................................. 3
3. Type plate .............................................................................................................................. 4
4. Product Description................................................................................................................ 6
5. Specifications......................................................................................................................... 6
5.1 General.................................................................................................................................... 6
5.2 Dimensions .............................................................................................................................. 7
6. Installation ............................................................................................................................ 8
6.1 Preparation .............................................................................................................................. 8
6.2 Assembly ................................................................................................................................. 8
6.3 Connections ............................................................................................................................. 9
7. Use......................................................................................................................................... 9
7.1 Commissioning ......................................................................................................................... 9
7.2 Insulation test .......................................................................................................................... 9
8. Maintenance........................................................................................................................... 9
9. Recycling.............................................................................................................................. 10
10. Contact details ..................................................................................................................... 10
11. EC Declaration of Conformity ............................................................................................... 11
Copyright © IMT B.V.
All rights reserved.
No part of this User Manual may be copied, redistributed, published or changed without the prior written
permission of IMT B.V.

User Manual
IQL® Albireo Floodlight
User Manual
IQL® Albireo Floodlight 3 Version 5.1 201302
1. Safety
In order to use the product safely and optimise the life of the product, the following instructions must be
observed.
Only qualified personnel may install the product.
Work in accordance with locally applicable safety standards and regulations.
Ensure that there is no mechanical load applied to the light fitting during installation.
If excessive tension is applied to the mounting feet during installation, such as when mounting on an
uneven surface, the spot welds on the mounting feet can be torn free from the light fitting.
Use all the mounting holes when installing the light fitting.
Ensure that the cable gland is suitable for the dimensions of the type of cable that will be connected.
This is necessary to ensure the IP protection.
Ensure that the cable gland used has an IP level of IP66, IP67 or IP68 in conformance with EN 60529,
and in case of an explosion proof lighting fixture, is Ex-e certified according to IEC 60079-7.
When using metal glands, use an earthing plate and locknut on the inside of the junction box.
Ensure there is a reliable connection to the earthing system, both with the external earthing point and
with the connection in the light fitting junction box.
Never open the light fitting housing.
Do not clean the light fitting with a high pressure steam or water jet. This will avoid damage that falls
outside the guarantee terms.
2. Warranty
2.1 General
The guarantee on the IQL®-FL series is only applicable when the light fitting is used within the operational
limits.
Operational limits are:
The minimum and maximum ambient temperature for the IQL®-FL is -40°C to +40°C.
The light fitting must be installed by a qualified person and in compliance with the installation
instructions.
Damage caused by incorrect installation, accidents or external influences such as lighting strike and
harmonic distortion in accordance with EN 50055 are not covered by the guarantee.
The lighting level of the light fitting depends on the temperature and is therefore not covered by the
guarantee.
If an IQL®-FL fitting fails within the warranty period, IMT B.V. will supply a new fitting with a comparable
specification free of charge. Before the guarantee can be confirmed, a defective light fitting must be sent to
IMT B.V. at the user’s expense for inspection. After this inspection the user will be informed of the result(s).
See invoice for individual guarantee agreements.
2.2 Life span
Switching the light fitting with a semiconductor photoelectric cell or a semiconductor relay has no known effect
on the life span of the light fitting.
It is expected that more than 70% of the original illumination power will be retained after 80,000 operating
hours

User Manual
IQL® Albireo Floodlight
User Manual
IQL® Albireo Floodlight 4 Version 5.1 201302
3. Type plate
3.1 Standard model
The standard model light fitting has a type plate attached:
This contains the following information:
1. Type : Low temperature range IQL55-FL-LT IQL85-FL-LT IQL165-FL-LT
: Normal temperature range IQL55-FL IQL85-FL IQL165-FL
2. Ambient temp. : Low temperature range -40°C up to 40°C
: Normal temperature range -20°C up to 40°C
3. Serial number
4. Year of Manufacture
5. Frequency : AC 50/60
: DC none
6. Voltage : 200-277Vac/dc or 100-120Vac/dc
7. Current : 100-120Vac/dc 200-277 Vac/dc
: 55W 460mA 260mA
: 85W 730mA 400mA
: 165W 1420mA 740mA
9. Ingress Protection : IP66

User Manual
IQL® Albireo Floodlight
User Manual
IQL® Albireo Floodlight 5 Version 5.1 201302
3.2 Explosion proof model
The explosion proof model light fitting has a type plate attached:
This contains the following information:
1. Type : Low temperature range IQL55-FL-LT IQL85-FL-LT IQL165-FL-LT
: Normal temperature range IQL55-FL IQL85-FL IQL165-FL
2. Ambient temp. : Low temperature range -40°C up to 40°C
: Normal temperature range -20°C up to 40°C
3. Serial number
4. Year of Manufacture
5. Frequency : AC 50/60
: DC none
6. Voltage : 200-277Vac/dc or 100-120Vac/dc
7. Current : 100-120 Vac/dc 200-277 Vac/dc
: 55W 460mA 260mA
: 85W 730mA 400mA
:165W 1420mA 740mA
8. Labeling : 55W FL II 2 GD Ex e mb II T4 T135°C
: 85W FL II 2 GD Ex e mb II T4 T135°C
: 165W FL II 2 GD Ex e mb II T3 T160°C
9. Ingress Protection : IP66

User Manual
IQL® Albireo Floodlight
User Manual
IQL® Albireo Floodlight 6 Version 5.1 201302
4. Product Description
The IQL®-FL fittings have been designed for use in demanding conditions.
The characteristics of the IQL®-FL fittings are:
Maximum of 10 year guarantee on correct operation1
100,000 hours maintenance-free operation expected 2
sealed for life
vibration proof
based on the principle of induction
explosion-safe model ATEX category 23suitable for use in Zone 1 & 21
The IQL®-FL fittings are suitable for use in the following:
terrain lighting
tunnel lighting
safety lighting
general industry
power stations
offshore industry
(petro)chemical industry
infrastructure
voedingsmiddelenindustriefood industry
5. Specifications
5.1 General
Housing : corrosion resistant aluminium with a polyurethane varnish RAL7032 (gray)
Lens : toughened glass
Colour recognition : Ra>80
Ingress protection : IP66
Voltage : AC-100-120V..±6% or 200-277V..±6%
: DC-100-120V..±6% or 200-277V..±6%
Burning position : Universal
(Re)ignition : Immediate
Power factor : >0,92
Connection : Standard –Ex-e junction box with 1 x M25 input, terminals for max.
4mm2
Other : compact lightweight construction
: including adjustable stainless steel mounting bracket
1For the ALBIREO IQL®165 a different maximum guarantee period of 6 years applies. See invoice for individual guarantee
agreements.
2For the ALBIREO 165W version 60.000 hrs of maintenance free operation expected
3Risk of the presence of an explosive gas mixture or dust mixture during normal operation is high (10 to 1,000 hours per year)

User Manual
IQL® Albireo Floodlight
User Manual
IQL® Albireo Floodlight 7 Version 5.1 201302
5.2 Dimensions
5.2.1 IQL® 55-FL and IQL® 85-FL
5.2.2 IQL®165 FL

User Manual
IQL® Albireo Floodlight
User Manual
IQL® Albireo Floodlight 8 Version 5.1 201302
6. Installation
6.1 Preparation
1. Check that the light fitting will be installed in an environment that matches the ambient
temperatures, gas group and temperature class. This data is shown on the light fitting type plate.
WARNING
The installation of the light fitting in an environment that does not match the specified
conditions can result in a dangerous situation.
WARNING
The installation of the light fitting in an environment that does not match the specified
ambient temperatures can have a strong negative effect on the life span of the light
fitting.
2. Choose the correct type of protection for the light fitting. The protection device needs to
be a fuse or a circuit breaker of at least 4 kA with a C characteristic.
3. Determine the number of light fittings that can be installed in each group. Consult the following table for
this.
Installation
protection
55 W
85 W
165 W
100-120
VAC/DC
200-277
VAC/DC
100-120
VAC/DC
200-277
VAC/DC
200-277
VAC/DC
B Type, 10 A
15
20
15
20
10
C type, 10 A
15
20
15
20
10
B Type, 16 A
22
30
22
30
16
C type, 16 A
26
35
26
35
16
55 W
85 W
165 W
100-120
VAC/DC
200-277
VAC/DC
100-120
VAC/DC
200-277
VAC/DC
200-277
VAC/DC
Inrush currents
16
12
16
12
24
Peak duration
170 μs
170 μs
170 μs
170 μs
140 μs
When using 30 mA earth leakage switches, provision must be made for a maximum of 30 light fittings on one
switch.
6.2 Assembly
1. Take the light fitting out of the packaging.
2. Inspect the light fitting for mechanical damage.
WARNING
The installation of the light fitting in an environment that does not match the specified
conditions can result in a dangerous situation.
WARNING
The installation of the light fitting in an environment that does not match the specified
ambient temperatures can have a strong negative effect on the life span of the light
fitting.
3. Mount the light fitting.
Ensure there is a reliable connection to the earthing system, both with the external earthing point and
with the connection in the light fitting junction box.
Ensure that the cable gland is suitable for the dimensions of the type of cable that will be connected
and has an IP level of IP66, IP67 or IP68 in conformance with EN 60529, and in case of an explosion
proof lighting fixture, is Ex-e certified according to IEC 60079-7. This is necessary to ensure the IP
protection, and to be suitable for a hazardous environment.
WARNING
Ensure that there is no mechanical load applied to the light fitting during installation.

User Manual
IQL® Albireo Floodlight
User Manual
IQL® Albireo Floodlight 9 Version 5.1 201302
4. Route the connecting cable correctly through the cable gland. Make especially certain that the cable gland
is suitable for the dimensions of the type of cable that will be connected. This is necessary to ensure the IP
protection.
5. Cut the cable to length.
6. Connect the cable to the terminals. The standard terminals in the junction box are suitable as standard for
a core diameter of 0-4 mm².
7. Check the connections that have been made.
8. Close the junction box.
WARNING
The installation must be carried out in accordance with (NEN-EN) IEC 60079-14.
6.3 Connections
In the light fitting junction box there is a terminal block as shown in the illustration.
The following connection can be made:
L-N : Permanent connection for the power supply.
In case of a flying lead, the free end of the permanently connected unterminated power cable shall be
connected by using a suitable certified junction box. For use in the presence of combustible dust, the junction
box shall have a degree of protection IP6X according to EN 60529.
The neutral (code N –blue), the phase (code L –brown) and earth (code PE, yellow-green) need to be
connected.
7. Use
7.1 Commissioning
The light fitting can be switched on immediately after installation.
7.2 Insulation test
Installations in which IQL®-FL light fittings are installed can be checked with an insulation test. For this test,
apply a maximum of 500 VDC between earth and a phase or neutral connection.
WARNING
Never apply more than 500 VDC between a phase and a neutral connection.
During production, all light fittings have been subjected to a dielectric test (1500 VAC for 60 seconds). In
addition, the light fittings have also been subjected to an endurance test.
8. Maintenance
The light fitting is ‘sealed for life’ and cannot be opened. Consequently maintenance as laid down in the IEC
60079-17 standard is not applicable; a visual inspection for correct operation will suffice.

User Manual
IQL® Albireo Floodlight
User Manual
IQL® Albireo Floodlight 10 Version 5.1 201302
WARNING
Opening the light fitting voids the guarantee.
9. Recycling
For recycling the light fitting, agreements have been made with local bodies within the context of the WEEE
directive.
Contact your local partner (see the chapter ‘Contact details’). The local partner will be responsible for further
processing.
10. Contact details
IMT B.V.
Pascalweg 10a, 4104 BG Culemborg
P.O. Box 88, 4100 AB Culemborg
THE NETHERLANDS
Phone : [phone]
Fax : [phone]
E-mail : [email protected]
For an up-to-date overview of all national and international contacts, visit our website: www.imt.eu.

User Manual
IQL® Albireo Floodlight
User Manual
IQL® Albireo Floodlight 11 Version 5.1 201302
11. EC Declaration of Conformity
The undersigned, representing the company
IMT B.V.
Pascalweg 10a
4104 BG Culemborg
The Netherlands
Phone :+31 (0) 88 - 12 69 100
hereby declares that the product: Albireo Floodlight type IQL®-FL labelled as II 2 GD Ex e mb II T4 T135°C,
IP66 55W 85W and II 2 GD Ex e mb II T3 T160°C, IP66 165W complies with the terms of the EC directive(s)
including all applicable supplements.
94/9/EC
Equipment and protective systems intended for use in potentially explosive atmospheres
2004/108/EC
Electromagnetic Compatibility
and that all of the following standards and/or technically related specifications are met.
Standard
Issue
Title
EN 60079-0
2009
Electrical apparatus for potentially explosive atmospheres
General requirements
EN 60079-7
2006
Explosive atmospheres –Part 7: Equipment protection by increased safety “e”
EN 60079-18
2009
Explosive atmospheres –Part 18: Equipment protection by encapsulation “m”
EN 60079-31
2009
Explosive atmospheres –Part 31: Equipment dust ignition protection by enclosure
“t”
EN 61547
2009
Equipment for general lighting purposes. EMC immunity requirements
EN 61000-3-2
2006
Limits for harmonic current emissions (equipment input current up to and including
16A per phase),
EC type certificate number KEMA 02 ATEX 1257 X issued by
Kema B.V.
Utrechtseweg 310
6812 AR ARNHEM
Nederland
Identificatienummer: 0344
Culemborg, 1-12-2010
IMT B.V.
R.L.L.M.G. Mignot, Managing director

IMT B.V.
Pascalweg 10a, 4104 BG Culemborg
P.O. Box 88, 4100 AB Culemborg
Tel: [phone], Fax [phone]
www.imt.eu, [e-mail]
