DIMON TECHNOLOGY LED Neon flex User manual

LED Neon flex
User Manual
DIMON
TECHN OLO GY

Contents
1) Introduction..................................................................................... 1
2) Product Overview.................................................................. 2
3) Installation Guide........................................................................ 4
4) Mounting Product...................................................................... 5
5) DIY screw connector kit assembly instruction................ 8
6) DIY snap connector kit assembly instruction................. 11
7) Electrial Connection.................................................................. 15
8) Connection Examples................................................................. 17
DIMON
TECHN OLO GY

1.Introduction
LED Neon Flex are bendable and highly durable linear LED solutions – suitable for
both indoor and outdoor applications. To achieve a uniform and diffused light output,
The LED Neon Flex range encapsulates LED strips with high-quality Epistar chips
inside a flexible 4OZ FPC. The protective casing prevents UV damage, is waterproof,
as well as flame and solvent-resistant. We offer a range of dimensions and colour
temperatures; depending on the environment our Neon LEDs can be mounted,
recessed and semi-recessed.
LED neon flex can be divided with different bending direction between horizontal
and vertical, also the shape and emitting beam angle are not the same.
This user manual is intended to cover as
much detail as possible for this product,
and great care has been taken to ensure
this and the accuracy of the information
contained within, however should
additional information or clarification be
required that is not covered within this
manual or associated data sheets, or if
there are any uncertainties regarding the
installation and operation of this product,
Distributor MUST be contacted before
any work is carried out on the fixture or
associated products.
Horizontal Bending (Sideview emmiting series)
Vertical Bending
Construction
Sideview Emitting
Topview Emitting
(Topview emmiting series)
8*17mm 11.5*21mm 17*16.5mm 11.5*29mm
13.5*13.5mm 16.5*16.5mm
W*H
FPCB
PVC/silicone
PVC/silicone
FPCB
PVC/silicone
FPCB
FPCB
PVC/silicone
LM-80
68
One
Bin
CE
Certificate
UL
Certificate
RoHS
Certificate LM-80 IK08
UV
Protected
Class 2
Electrical
Dirt
Resistant
Saltwater
Resistant
Corrosion
Resistant
Ingress
Protection One Bin
outdoor use indoor use
1
DIMON
TECHN OLO GY

2. Product Overview
Side flat shape Neon Flex (8*17mm)
-Flat retangular emission surface with 120-degree beam angle.
-The mini bend diameter of 8cm, suitable for led neon sign application.
-Available in static color including white in CCT ranging from 2200K-6500K.
(Please refer to our datesheets specification for the exact color range)
-Color opitions include green, blue, red, pink, amber, orange.
-Dimmable with DALI, 0-10V, DMX/RDM, Triac control options.
8mm
0.31 inch
17mm
0.67 inch
Side flat shape Neon Flex (11.5*21mm)
-Flat retangular emission surface with 120-degree beam angle.
-8 cm bend diame ependant on variant
-Available in static color including white in CCT ranging from 2200K-6500K.
(Please refer to our datesheets specification for the exact color range)
-Color opitions include RGB, RGBW, DW and Pixel.
-DALI, 0-10V, Triac DMX/RDM control options.
11.5mm
0.45 inch
21mm
0.82 inch
Side flat shape Neon Flex (16.5*16.5mm)
-Flat retangular emission surface with 120-degree beam angle.
-The bend diameter of 12cm
-Available in static color including white in CCT ranging from 2200K-6500K.
(Please refer to our datesheets specification for the exact color range)
-Color opitions include green, blue, red, pink, amber, orange.
-Dimmable with DALI, 0-10V, DMX, Triac.
16.5mm
0.64 inch
16.5mm 0.64 inch
2
DIMON
TECHN OLO GY

11.5mm
0.45 inch
29mm
1.14 inch
-Dome retangular emission surface with 270-degree beam angle.
-The bend diameter of 8/12cm
-Available in static color including white in CCT ranging from 2200K-6500K.
(Please refer to our datesheets specification for the exact color range)
-Color opitions include green, blue, red, pink, amber, orange.
-Dimmable with DALI, 0-10V, DMX, Triac.
Side flat shape Neon Flex (16.5*16.5mm)
-Flat retangular emission surface with 120-degree beam angle.
-12cm bend diameter
-Available in static color including white in CCT ranging from 2200K-6500K.
(Please refer to our datesheets specification for the exact color range)
-Color opitions include RGB, RGBW, DW and Pixel
-DALI, 0-10V, DMX, Triac controller options
16.5mm
0.64 inch
16.5mm 0.64 inch
-Color opitions include RGB, RGBW, DW and Pixel
Top flat mini shape Neon Flex (13.5*13.5mm)
-Flat retangular emission surface with 120-degree beam angle.
-8cm bend diameter
-Available in static color including white in CCT ranging from 2200K-6500K.
(Please refer to our datesheets specification for the exact color range)
-DALI, 0-10V, DMX, Triac controller options
13.5mm
0.53 inch
13.5mm
0.53 inch
Side Dome shape Neon Flex (11.5*29mm)
3
DIMON
TECHN OLO GY

3. Installation Guide
This product left the place of manufacture in perfect condition.
In order to maintain this condition and for safe operation, the user must always follow
the instructions and safety warnings described in this user manual.
Safety Warning!
General
- This product must be installed by a qualified and competent professional.
- When working on the fixture, heat resistant gloves should be worn to provide
adequate user protection.
- Do not work on the product with wet hands.
- Always disconnect the power supply before attempting to maintain or service
the equipment.
- Always operate the equipment as described in this user manual.
- Do not stand close to the equipment and stare directly into the LED light source.
- Make sure that all parts of the equipment are kept clean and free of dust which
should be carried out as part of a maintenance cycle that’s appropriate for the
installation location of the product.
- When transferring the product, it is advisable to use the original packaging in
which the product left the factory.
- Shields, lenses, ultraviolet screens and pressure release valves should be
changed if they have become damaged to such an extent that their
effectiveness is impaired.
- The lamp (LED) should be changed if it has become damaged or thermally
deformed.
- The power supply (PSU), DMX/RDM driver and LED drivers should be changed if
they fail to operate.
Installation
- A minimum distance of 0.5m must be maintained between the equipment and
any combustible surface. The mounting surface must not be combustible.
- Always ensure the supporting structure is a flat and solid surface and can
support the weight of the product and any additional wind or shear force.
The supporting structure must be capable for the installation of luminaires,
and advice must be taken from an appropriately qualified and competent person
to verify proposed mounting positions and surfaces.
- Always make sure that the equipment is installed securely and ensure all safety
anchors are installed.
- The product must be installed within well-ventilated areas.
- The Earth wire MUST ALWAYS be connected.
- Local electrical and building regulations must be followed. If in doubt, please
contact support distributor
- Avoid shaking or strong impacts to any part of the equipment.
- Always make sure that the power and data connections are connected correctly
and securely. If there is any malfunction of the equipment, contact your local
distributor immediately.
- This fixture should not be buried.
Specific Installation
- Although this product does not generate a great amount
of heat, it is recommended that you do not cover or conceal it.
- Do not route the product through walls, doors, windows,
or building structures.
- Do not roll out the product onto rough surfaces or over
sharp corners. This will scratch the PVC /silicone optics
and damage the finish of the product.
- Do not use the product if :
The outer PVC jacket is damaged
There are loose electrical connections
The wires are visible without insulation.
- Do not secure the product with staples, nails, or alike that might
damage the insulation or PVC/silicone material.
- Do not install the product on/in places where it is subject
to continuous flexing.
- Do not operate/run the product in temperatures
exceeding 55C.
- Do not operate the product over the specified voltage
or LED life degradation will be greatly increased.
- Do not leave any part of the product unsecured.
- Constant movement over time from weather can
cause damage.
- Do not reverse polarity when connecting from both ends.
This will damage the internal PCB. Always test connections
with a multi-meter before applying power.
- Do not energise the product whilst in packaging.
- The product can be cut only where marked. Look for
the “Dotted Line” or“Cutting Mark”. A cut section must have
the appropriate IP rated cap flex accessory to maintain
IP ratings.
- Cutting outside of the specified mark will damage the light.
- Do not cut while the LED flex neon is connected to power.
-- Do not install in human inhabited pools.
- During installation, violent pulling and bending are prohibited.
- Must always be used with an electrical isolation
transformer providing SELV (safety extra low voltage).
- Do not cut off the cable wire between the waterproof metal
ferrule and connector.
Waterproof metal ferrule
The light source and other electronic components
contained in this luminaire shall only be replaced by
your distributor service agent.
Caution, risk of electric shock
FAILURE TO COMPLY WITH THIS MANUAL AND LOCAL ELECTRICAL AND
CONSTRUCTION REGULATIONS MAY RESULT IN SERIOUS INJURY
OR EVEN DEATH - ALWAYS ISOLATE POWER BEFORE WORKING ON
ELECTRICAL PRODUCTS AND ENSURE ADEQUATE MEASURES ARE TAKEN
TO MECHANICALLY SUPPORT FIXTURES AT ALL TIMES.
This user manual is intended to cover as much detail as possible
for this product,and great care has been taken to ensure this and
the accuracy of the information contained within, however should
additional information or clarification be required that is not covered
within this manual or associated data sheets, or ifthere are any
uncertainties regarding the installation and operation of this product,
Distributor MUST be contacted before any work is carried out on the
fixture or associated products.
R
L
24V
+
BUSI
L
24V
Cutting mark
R
+
R
L
24V
+
4
DIMON
TECHN OLO GY

4. Mounting Product
Led neon flex is a highly durable product but must be installed in accordance to the pictures
shown below, which indicate the minimum bending parameters as well as the correctly
bending direction for each specific variant of models
Side flat and side round shape neon flex
LED neon flex must be installed by at least 2 people,
who can support the product in various locations as shown.
During installation, care should be taken to ensure the bending
radius of is not exceeded.
8mm
17mm
80mm
3.14 inch
11.5mm
21mm
80mm
3.14 inch
16.5mm
16.5mm
150mm
5.9 inch
11.5mm
29mm
120mm
4.72 inch
Light profile Bending direction Min. bending diameter
The maximum horizontal force
5-10kg
5
DIMON
TECHN OLO GY

LED neon flex must be installed by at least 2 people,
who can support the product in various locations as shown.
During installation, care should be taken to ensure the bending
radius of is not exceeded.
Led neon flex is a highly durable product but must be installed in accordance to the pictures
shown below, which indicate the minimum bending parameters as well as the correctly
bending direction for each specific variant of models
Top flat shape neon flex
13.5mm
13.5mm
Light profile Bending direction Min. bending diameter
80mm
3.14 inch
16.5mm
16.5mm
120mm
4.72 inch
×××
General DO NOTS
The images give indication as
to what is not acceptable as
an intended installation or during
installation of other fixing methods
6
DIMON
TECHN OLO GY

Gerneral mounting
LED neon flex can be fastened to surfaces using appropriate accessories available from
distributor. Please refer to data sheets or contact technical support for a copy. The
use of glues and resins as fixing agents should be avoided. Use of glues and resins
may invalidate the warranty of the product, unless it’s use is agreed in writing by
distributor as part of a detailed project specification.
The images indicate one type of fixing available in the accessories range. The different
fixings serve obvious purposes, however when in doubt technical support should be
contacted.
Quantities of accessories and fixings are dependent on the type and its effect on the
variant it’s being used with. Care should be taken to ensure drooping is avoided,
and to ensure that is fastened adequately to avoid stresses on itself.
The aluminum mounting piece of IP67 front connector and end cap should keep
at least 10mm space apart from aluminum channel when making installation. Installation surface
Screw
(Wood or concrete wall)
Aluminum profile
Installation direction
Installation direction Installation direction
Incorrect installation like below picture could lead to light failure.
>10mm
>10mm
Ensure the feeding cable not bear force, keep the head10mm in natural loose.
Press the flex light into mounted aluminum channel in one direction.
Mount the cable junction in hermetic enclosure
like waterproof junction box in outdoor application.
Waterproof
connector or
junction box
Power Supply
>100mm
Do not bend against light terminals;
otherwise it will lead to failure of
connector waterproof.
<100mm
Pull
>10mm
7
DIMON
TECHN OLO GY

Screw
[x4]
[x1]
Anti-skidding clip Aluminum mounting piece
[x1]
Blank end
[x1]
Rubber gasket
[x1]
RTV SILICONE
MEETS REQUIREMENT TO RoHS
MEETS REQUIREMENT TO CERTIFIFED
NEUTRAL NO POISON TO ENVIRONMENT
BE ABLE TO ENDUCE CLIMATE,AGING AND THE CHEMICAL
BE ABLE TO ENDURE VIBRATION,SEALING AND HIGH/LOW TEMPERATURE
FILENO:E343836L
RoHS
Screw
[x4]
[x1]
Anti-skidding clip Aluminum mounting piece
[x1]
Front feed connector
[x1]
Rubber gasket
[x1]
RTV SILICONE
MEETS REQUIREMENT TO RoHS
MEETS REQUIREMENT TO CERTIFIFED
NEUTRAL NO POISON TO ENVIRONMENT
BE ABLE TO ENDUCE CLIMATE,AGING AND THE CHEMICAL
BE ABLE TO ENDURE VIBRATION,SEALING AND HIGH/LOW TEMPERATURE
FILENO:E343836L
RoHS
Step 1
Place the anti-skidding clip on the very end
of the tubing with the 2 tiny tabs that are
pointing inwards still touching the end of
the material and crimp in place.
Step 2
Line up the alumimum mounting piece so
the screw hole face the plug and slide on
over the anti-skidding clip.
Step 3
Insert the rubber gasket along with slit
into the pin of the front feed connector, put
100% clear silicone on the surface of
the rubber gasket.
Step 4
Carefully insert thhe pins of the front feed
connector into the gap created behind
the FPCB.
Step 5
Srew the front feed connector to the aluminum
mounting piece
Step 1
Place the anti-skidding clip on the very end
of the tubing with the 2 tiny tabs that are
pointing inwards still touching the end of
the material and crimp in place.
Step 2
Line up the alumimum mounting piece so
the screw hole face the plug and slide on
over the anti-skidding clip.
Step 3
Apply 100% clear silicone onto the end face
of led neon flex
Step 4
Place the rubber gasket squarely onto the
end face of led neon flex.
Step 5
Srew the blank end to the aluminum
mounting piece.
5. DIY Screw Connector Kit Assembly Instruction
Step 1 Step 2
Step 3 Step 4 Step 5
DIY Screw End Cap kit Assembly instruction
DIY Screw Front connector kit Assembly instruction
Step 1 Step 2
Step 3 Step 4 Step 5
The kit can be installed and link up with power supply to light up the neon flex after
you have measured the exact length in your project, this can help you easily do it by yourself
below the detailed assembly instruction。With the capability of IP67, the neon flex also can
be used both outdoor and indoor.
finished assembly view
finished assembly view
8
DIMON
TECHN OLO GY

9
Screw
[x4]
[x1]
Anti-skidding clip Aluminum mounting piece
[x1]
Front feed connector
[x1]
Rubber gasket
[x1]
Step 1 Step 2
Step 3 Step 4 Step 5
RTV SILICONE
MEETS REQUIREMENT TO RoHS
MEETS REQUIREMENT TOCERTIFIFED
NEUTRAL NO POISON TO ENVIRONMENT
BE ABLE TOENDUCE CLIMATE, AGING AND THE CHEMICAL
BE ABLE TOENDURE VIBRATION, SEALING AND HIGH/LOW TEMPERATURE
FILENO:E343836L
RoHS
Screw
[x4]
[x1]
Anti-skidding clip Aluminum mounting piece
[x1]
Front feed connector
[x1]
Rubber gasket
[x1]
RTV SILICONE
MEETS REQUIREMENT TO RoHS
MEETS REQUIREMENT TOCERTIFIFED
NEUTRAL NO POISON TO ENVIRONMENT
BE ABLE TOENDUCE CLIMATE, AGING AND THE CHEMICAL
BE ABLE TOENDURE VIBRATION, SEALING AND HIGH/LOW TEMPERATURE
FILENO:E343836L
RoHS
Step 1
Place the anti-skidding clip on the very end
of the tubing with the 2 tiny tabs that are
pointing inwards still touching the end of
the material and crimp in place.
Step 2
Line up the alumimum mounting piece so
the screw hole face the plug and slide on
over the anti-skidding clip.
Step 3
Insert the rubber gasket along with slit
into the pin of the front feed connector,
put 100% clear silicone on the surface of
the rubber gasket.
Step 4
Carefully insert thhe pins of the front feed
connector into the gap created behind
the FPCB.
Step 5
Srew the front feed connector to the
aluminum mounting piece
Step 1
Place the anti-skidding clip on the very end
of the tubing with the 2 tiny tabs that are
pointing inwards still touching the end of
the material and crimp in place.
Step 2
Line up the alumimum mounting piece so
the screw hole face the plug and slide on
over the anti-skidding clip.
Step 3
Insert the rubber gasket along with slit
into the pin of the front feed connector,
put 100% clear silicone on the surface of
the rubber gasket.
Step 4
Carefully insert thhe pins of the front feed
connector into the gap created behind
the FPCB.
Step 5
Srew the front feed connector to the
aluminum mounting piece
Step 1 Step 2
Step 3 Step 4 Step 5
finished assembly view
finished assembly view
DIMON
TECHN OLO GY

RTV SILICONE
MEETS REQUIREMENT TORoHS
MEETS REQUIREMENT TOCERTIFIFED
NEUTRAL NO POISON TOENVIRONMENT
BE ABLE TOENDUCE CLIMATE, AGING AND THE CHEMICAL
BE ABLE TOENDURE VIBRATION, SEALING AND HIGH/LOW TEMPERATURE
FILENO:E343836L
RoHS
Screw
[x4]
[x1]
Anti-skidding clip Aluminum mounting piece
[x1]
Blank End
[x1]
Rubber gasket
[x1]
Step 1
Place the anti-skidding clip on the very end
of the tubing with the 2 tiny tabs that are
pointing inwards still touching the end of
the material and crimp in place.
Step 2
Line up the alumimum mounting piece so
the screw hole face the plug and slide on
over the anti-skidding clip.
Step 3
Apply 100% clear silicone onto the end face
of led neon flex
Step 4
Place the rubber gasket squarely onto the
end face of led neon flex.
Step 5
Srew the blank end to the aluminum
mounting piece.
Step 1 Step 2
Step 3 Step 4 Step 5
Screw
[x4]
[x1]
Anti-skidding clip Aluminum mounting piece
[x1]
Front feed connector
[x1]
Rubber gasket
[x1]
RTV SILICONE
MEETS REQUIREMENT TORoHS
MEETS REQUIREMENT TOCERTIFIFED
NEUTRAL NO POISON TOENVIRONMENT
BE ABLE TOENDUCE CLIMATE, AGING AND THE CHEMICAL
BE ABLE TOENDURE VIBRATION, SEALING AND HIGH/LOW TEMPERATURE
FILENO:E343836L
RoHS
Step 1
Place the anti-skidding clip on the very end
of the tubing with the 2 tiny tabs that are
pointing inwards still touching the end of
the material and crimp in place.
Step 2
Line up the alumimum mounting piece so
the screw hole face the plug and slide on
over the anti-skidding clip.
Step 3
Insert the rubber gasket along with slit
into the pin of the front feed connector, put
100% clear silicone on the surface of
the rubber gasket.
Step 4
Carefully insert thhe pins of the front feed
connector into the gap created behind
the FPCB.
Step 5
Srew the front feed connector to the aluminum
mounting piece
Step 1 Step 2
Step 3 Step 4 Step 5
finished assembly view
finished assembly view
10
DIMON
TECHN OLO GY

Polycarbonate
outer sleeve
[x1]
[x1]
Anti-skidding clip
[x1]
Front feed connector
[x1]
Rubber gasket
[x1]
Joiner bracket
6. DIY Snap Connector Kit Assembly Instruction
R
R
R
R
R
R
Polycarbonate
outer sleeve
[x1]
[x1]
Anti-skidding clip
[x1]
End Cap
[x1]
Rubber gasket
[x1]
Joiner bracket
R
R
R
R
R
R
TOP
RTV SILICONE
MEETS REQUIREMENT TORoHS
MEETS REQUIREMENT TOCERTIFIFED
NEUTRAL NO POISON TOENVIRONMENT
BE ABLE TOENDUCE CLIMATE, AGING AND THE CHEMICAL
BE ABLE TOENDURE VIBRATION, SEALING AND HIGH/LOW TEMPERATURE
FILENO:E343836L
RoHS
The snap kit can be easily installed than screw kit without any tool, it also has the same waterproof fuction of IP67.
Linked up with power supply to light up the neon flex after you have measured the exact length in your project,
this can help you easily do it by yourself below the detailed assembly instruction。
Step 1
Let neon flex goes through polycarbonate outer
sleeve, printed instruction aligns with the ‘Snap End’
arrow points in the direction of the front feed connector.
Step 2
Place the anti-skidding clip on the very end of the
neon with the 2 tiny tabs that are pointing inwards
still touching the end of material and crimp in place.
Step 3
Place the tip of the assistant tool against the outer
side of the internal circuit board within the neon flex.
Carefully push the tool into the neon flex (max. depth of
12.5mm) and creates a small cavity in the flexible
material on the outer side of the circuit board.
Step 4
Insert rubber gasket into the pins and apply 100%
clear silicone on the surface of it. Align the front
feed connector with the cut end part and carefully
push its pins into the gaps.
Step 5
Gently yet firmly push the joiner bracket onto the
front feed connector assembly. The two parts close
together and eventually lock them into place.
Step 6
Slide the polycarbonate outer sleeve and butts up to
the flange of the front connector.
Step 1
Let neon flex goes through polycarbonate outer
sleeve, printed instruction aligns with the ‘Snap End’
arrow points in the direction of end cap.
Step 2
Place the anti-skidding clip on the very end of the
neon with the 2 tiny tabs that are pointing inwards
still touching the end of material and crimp in place.
Step 3
Place the tip of the assistant tool against the outer
side of the internal circuit board within the neon flex.
Carefully push the tool into the neon flex (max. depth of
12.5mm) so that it creates a small cavity in the flexible
material on the outer side of the circuit board.
Step 4
Insert rubber gasket into the pins and apply 100%
clear silicone on the surface of it. Align end cap with
the cut end part and carefully push its pins into the gaps.
Step 5
Gently yet firmly push the joiner bracket onto the
end cap assembly. The two parts close together
and eventually lock them into place.
-Step 6
Slide the polycarbonate outer sleeve and butts up to
the flange of end cap
TOP
RTV SILICONE
MEETS REQUIREMENT TORoHS
MEETS REQUIREMENT TOCERTIFIFED
NEUTRAL NO POISON TOENVIRONMENT
BE ABLE TOENDUCE CLIMATE, AGING AND THE CHEMICAL
BE ABLE TOENDURE VIBRATION, SEALING AND HIGH/LOW TEMPERATURE
FILENO:E343836L
RoHS
Step 1 Step 2 Step 3
Step 4 Step 5 Step 6
Step 1 Step 2 Step 3
Step 4 Step 5 Step 6
finished assembly view
finished assembly view
11
DIMON
TECHN OLO GY

Polycarbonate
outer sleeve
[x1]
[x1]
Anti-skidding clip
[x1]
Front feed connector
[x1]
Rubber gasket
[x1]
Joiner bracket
Bottom
Snap End
Polycarbonate
outer sleeve
[x1]
[x1]
Anti-skidding clip
[x1]
End cap
[x1]
Rubber gasket
[x1]
Joiner bracket
Bottom
Snap End
R
R
R
TOP
RTV SILICONE
MEETS REQUIREMENT TORoHS
MEETS REQUIREMENT TOCERTIFIFED
NEUTRAL NO POISON TOENVIRONMENT
BE ABLE TOENDUCE CLIMATE, AGING AND THE CHEMICAL
BE ABLE TOENDURE VIBRATION, SEALING AND HIGH/LOW TEMPERATURE
FILENO:E343836L
RoHS
R
R
R
R
R
R
R
TOP
RTV SILICONE
MEETS REQUIREMENT TORoHS
MEETS REQUIREMENT TOCERTIFIFED
NEUTRAL NO POISON TOENVIRONMENT
BE ABLE TOENDUCE CLIMATE, AGING AND THE CHEMICAL
BE ABLE TOENDURE VIBRATION, SEALING AND HIGH/LOW TEMPERATURE
FILENO:E343836L
RoHS
Step 1
Let neon flex goes through polycarbonate outer
sleeve, printed instruction aligns with the ‘Snap End’
arrow points in the direction of end cap.
Step 2
Place the anti-skidding clip on the very end of the
neon with the 2 tiny tabs that are pointing inwards
still touching the end of material and crimp in place.
Step 3
Place the tip of the assistant tool against the outer
side of the internal circuit board within the neon flex.
Carefully push the tool into the neon flex (max. depth of
12.5mm) so that it creates a small cavity in the flexible
material on the outer side of the circuit board.
Step 4
Insert rubber gasket into the pins and apply 100%
clear silicone on the surface of it. Align end cap with
the cut end part and carefully push its pins into the gaps.
Step 5
Gently yet firmly push the joiner bracket onto the
end cap assembly. The two parts close together
and eventually lock them into place.
-Step 6
Slide the polycarbonate outer sleeve and butts up to
the flange of end cap.
Step 1
Let neon flex goes through polycarbonate outer
sleeve, printed instruction aligns with the ‘Snap End’
arrow points in the direction of the front feed connector.
Step 2
Place the anti-skidding clip on the very end of the
neon with the 2 tiny tabs that are pointing inwards
still touching the end of material and crimp in place.
Step 3
Place the tip of the assistant tool against the outer
side of the internal circuit board within the neon flex.
Carefully push the tool into the neon flex (max. depth of
12.5mm) and creates a small cavity in the flexible
material on the outer side of the circuit board.
Step 4
Insert rubber gasket into the pins and apply 100%
clear silicone on the surface of it. Align the front
feed connector with the cut end part and carefully
push its pins into the gaps.
Step 5
Gently yet firmly push the joiner bracket onto the
front feed connector assembly. The two parts close
together and eventually lock them into place.
Step 6
Slide the polycarbonate outer sleeve and butts up to
the flange of the front connector.
Step 1 Step 2 Step 3
Step 4 Step 5 Step 6
Step 1 Step 2 Step 3
Step 4 Step 5 Step 6
finished assembly view
finished assembly view
12
DIMON
TECHN OLO GY

R
Polycarbonate
outer sleeve
[x1][x1]
Anti-skidding clip
[x1]
Front feed connector
[x1]
Rubber gasket
[x1]
Joiner bracket
Polycarbonate
outer sleeve
[x1]
[x1]
Anti-skidding clip
[x1]
End Cap
[x1]
Rubber gasket
[x1]
Joiner bracket
TOP
RTV SILICONE
MEETS REQUIREMENT TORoHS
MEETS REQUIREMENT TOCERTIFIFED
NEUTRAL NO POISON TOENVIRONMENT
BE ABLE TOENDUCE CLIMATE, AGING AND THE CHEMICAL
BE ABLE TOENDURE VIBRATION, SEALING AND HIGH/LOW TEMPERATURE
FILENO:E343836L
RoHS
R
R
R
R
TOP
RTV SILICONE
MEETS REQUIREMENT TORoHS
MEETS REQUIREMENT TOCERTIFIFED
NEUTRAL NO POISON TOENVIRONMENT
BE ABLE TOENDUCE CLIMATE, AGING AND THE CHEMICAL
BE ABLE TOENDURE VIBRATION, SEALING AND HIGH/LOW TEMPERATURE
FILENO:E343836L
RoHS
Step 1
Let neon flex goes through polycarbonate outer
sleeve, printed instruction aligns with the ‘Snap End’
arrow points in the direction of end cap.
Step 2
Place the anti-skidding clip on the very end of the
neon with the 2 tiny tabs that are pointing inwards
still touching the end of material and crimp in place.
Step 3
Place the tip of the assistant tool against the outer
side of the internal circuit board within the neon flex.
Carefully push the tool into the neon flex (max. depth of
12.5mm) so that it creates a small cavity in the flexible
material on the outer side of the circuit board.
Step 4
Insert rubber gasket into the pins and apply 100%
clear silicone on the surface of it. Align end cap with
the cut end part and carefully push its pins into the gaps.
Step 5
Gently yet firmly push the joiner bracket onto the
end cap assembly. The two parts close together
and eventually lock them into place.
-Step 6
Slide the polycarbonate outer sleeve and butts up to
the flange of end cap.
Step 1
Let neon flex goes through polycarbonate outer
sleeve, printed instruction aligns with the ‘Snap End’
arrow points in the direction of the front feed connector.
Step 2
Place the anti-skidding clip on the very end of the
neon with the 2 tiny tabs that are pointing inwards
still touching the end of material and crimp in place.
Step 3
Place the tip of the assistant tool against the outer
side of the internal circuit board within the neon flex.
Carefully push the tool into the neon flex (max. depth of
12.5mm) and creates a small cavity in the flexible
material on the outer side of the circuit board.
Step 4
Insert rubber gasket into the pins and apply 100%
clear silicone on the surface of it. Align the front
feed connector with the cut end part and carefully
push its pins into the gaps.
Step 5
Gently yet firmly push the joiner bracket onto the
front feed connector assembly. The two parts close
together and eventually lock them into place.
Step 6
Slide the polycarbonate outer sleeve and butts up to
the flange of the front connector.
Step 1 Step 2 Step 3
Step 4 Step 5 Step 6
Step 1 Step 2 Step 3
Step 4 Step 5 Step 6
finished assembly view
finished assembly view
13
DIMON
TECHN OLO GY

[x1]
Anti-skidding clip
[x2]
Interlink board
[x1]
Rubber gasket
[x2]
Steel Joiner bracket finished assembly view
R
[x1]
Anti-skidding clip
[x2]
Interlink board
[x1]
Rubber gasket
[x2]
Steel Joiner bracket finished assembly view
Step 1 Step 2
Step 3 Step 4
Step 1
Step 2
Step 3 Step 4
Step 1
Place anti-skidding clip onto both end of
the neon flex, pay attention to its direction.
Step 2
Put rubber gasket on both side of interlink
board, then insert interlink board into the gap
created behind the FPCB.
Step 3
Align the anti-skidding clip with steel joiner
bracket and press the neon flex downwards
at the same time till bottom,
Step 4
Now push each neon flex in towards the center
of joiner bracket, locking tabs on both grip clips
click into place within their respective openings
in the steel joiner bracket
Step 1
Place anti-skidding clip onto both end of
the neon flex, pay attention to its direction.
Step 2
Put rubber gasket on both side of interlink
board, then insert interlink board into the gap
created behind the FPCB.
Step 3
Align the anti-skidding clip with steel joiner
bracket and press the neon flex downwards
at the same time till bottom,
Step 4
Now push each neon flex in towards the center
of joiner bracket, locking tabs on both grip clips
click into place within their respective openings
in the steel joiner bracket
14
DIMON
TECHN OLO GY

7. Electrial Connections
LED neon flex is manufactured to order, meaning that the appropriate power feeds
are moulded. There are two options available for all versions, these are bare end
cables or plugs.
Bare end cables come with a standard length which can vary pending the
manufacturing process, therefore it is recommended to ensure the feeder cable is
long enough to reach the cable entry point of flex, where connections can be made.-
Plugs are designed for “plug-and-play” type installations, whereas the installer would
ensure female sockets are available at each flex start location, with the male type
connector then plugging into this female type socket. Female sockets are available as
separate items.
Note that custom feed cable lengths are available upon special request.
LED neon flex is a high-powered product, which requires a detailed electrical design to
ensure equal balancing of loads across drivers and power supplies. Reference can be
made to the various data sheets for specific variants, that indicate the operating voltage
and the wattage per metre. Technical support is on hand to assist with control and power
design. Product operates at 24Vdc unless otherwise stated in specific data sheets or
product labels. Care should be taken to ensure the operating voltage is constant
(constant voltage). A maximum volt drop of 5% is allowed (for example at 24Vdc,
the maximum voltage drop would be 1.2V meaning a delivered voltage of 22.8V to the fixture.
Providing with an extensive range of power supplies, LED Drivers, SPI pixel gateways
and various DC-DC transformers which allow installers to overcome volt
drop issues, as well as various control options such as stand-alone DMX interfaces to
multi-universe video matrix type products. We also has an in-house design and
engineering team that can deliver such systems, please contact support for more information.
Below is a guide which indicates the number of cores and the connections they relate to.
Each manufactured length of flex will have a factory fitted label which indicates
the correct cores to use, as well as the colour of each specific core and its associated
connection. The below guide is in black and white for clarity, and reference should always
be made to the label on the product itself as sometimes, the cable colours may vary pending
manufacturing processes or for custom orders. If in doubt, or if the label is missing, contact
support for assistance before connecting to power.
Mono RGB RGBW
Turnable White Pixel SPI Dynamic Pixel DMX -1
Red - 24V+
Black - Gnd
Green - Green
Red - Red
Black - Blue
Yellow - 24V+
Red - 24V+
Yellow - Warm white
Black - Cold white
Red - 24V+
Yellow - Data
Black - Gnd
Red - Red
Green - Green
Black - Blue
White - White
Yellow - 24V+
Red - 24V+
Black - Gnd
Yellow - Data
Green - Address
Dynamic Pixel DMX -2
Red - 24V+
Yellow - DMX +
Green- Address
White - Gnd
Blue - DMX-
Direct entry Connector
Bottom entry Connector
Side entry Connector
Bare wire
Plug
15
DIMON
TECHN OLO GY
