In-Step Mobility U-Step II User manual

Step-by-Step Guide to Using Your
In-Step Mobility Products Corp.
U-Step II alking Stabilizer
4-inch
non-marking
casters
Padded
seat
Tension
contro
Height
adjustab e
Adjustab e
backrest
Spring- oaded
front whee P ace to step for
going up curbs
G ow-in-the-Dark
tabs
Laser
projected
red ine –
optional
Ergonomica y
positioned
hand ebars
Comfort grips
Hand brake
Removab e
basket
Available in Canada:
Special Needs Computers | 1-877-724-4922

— 2 —
CONTENTS:
A. Assembly Instructions
B. Braking
C. Tension Control Ad ustment
D. Sitting Down
E. Walking Over Obstacles
F. Transporting
G. Setup After Transporting
H. Optional Accessories
1. Laser & Sound Cueing Module
Replacing the Cueing Module Batteries
2. Alternative Brake Accessory
3. Weights
I. Maintenance
J. Warranty Information
Guide for Setting Up & Using Your U-Step II

— 3 —
A. Assembly Instructions
1) After opening the box, cut the plastic ties that secured the
U-Step II in transit.
2) Lift up on the tube at
the top near the seat so
that the seat becomes
horizontal with the
ground.
ress the seat down
until it snaps into place.
(Below)
3) Install the left and the right
handlebars.
If you have any doubt which is the
left and right handlebar, look at the
junction box below the seat and
you can see the left handle bar
cable is connected into the left side
and vice versa for the right.
Junction Box
Right Handlebar
Left Handlebar

You will need to push in the height adjustment button to slide
the handle bar into the lower height adjustment tube. (Left)
Also, when you insert the handlebars make sure that the cables
are routed to the inside of the handlebars, rather than the out-
side. (Right)
4) Adjusting the Handlebars to the proper height. Generally, the
handlebars are adjusted so that the handles are 2-3 inches above
your palm when your arm rests at your side.
5) Quick-Release Handle Bar Lock Lever
a. Slide each handle bar in by depressing the
spring-loaded pin at the bottom of the handle bar.
b. Rotate the Quick-Release Locking Lever
clockwise about three to six turns (B1), until the
lever is in the upright position, then flip the
lever straight down to tighten the handle bar
(B2).
c. Check whether the handle bar wiggles left or
right. If the handle bar wiggles, unlock the
lever and rotate it another turn clockwise; fold
the lever to tighten, and check again for any
wiggling. Repeat this procedure until the han-
dle bars are sufficiently tight.
— 4 —
B1 - Un ocked
Rotate
Clockwi e
Flip
traight
down
B2 - Locked

6) Assembling the Backrest
There are three adjustment holes for the
backrest. (Left) Choose the one most com-
fortable for
you when you
sit down.
Insert the two bolts and wing
nuts provided to secure the back-
rest into place. Slide the bolt
through the top side of the tube
and secure with the wing nut
below. (Right)
7) Mounting the Basket
With the seat flipped up
from the rear (the side held
shut by magnets), position
the basket from underneath,
with the curved side toward
the front, so that the four
connecting bolts slide up
through the mating holes in
the seat frame. (7A)
Secure the basket using the four
washers and the wing nuts pro-
vided. (7B)
— 5 —
7A - Before attaching hardware
7B - After attaching hardware (c ose-up)

— 6 —
B. Braking
The U-Step II wheels will not
roll until you release the brakes
in one of the following ways:
1) Squeeze either or both hand
brake levers to release the
brakes.
2) ull up on the release bar of
the alternative brake accessory
discussed in section H.
1) Not everyone needs to adjust the tension control to be safe.
However, if you feel that the U-Step II rolls too easily for you,
use the tension control to add resistance. lace your U-Step II
on the surface where you walk most often. You will need more
tension on a smooth surface such as flooring than you will on
carpet.
2) Using a flat head screwdriver, loosen the locking blot about
two turns.
C. Tension Control Adjustment (Optional)
Ten ion Control Lever - Notched
Set
Hole
Ten ion
Locking
Bolt
Ten ion
Lever
Tenion
Indicator
(ticker)

— 7 —
j
ARNING:
While sitting, DO NOT push
off with your feet to move
the U-Step II. This is unsafe.
D. Sitting Down
To sit down, you can either turn
around while holding the han-
dlebar, or pivot the U-Step II
around so that it is positioned
behind you and then sit down
on the seat.
When you are sitting on the
U-Step II you are facing back-
wards relative to the moving
direction of the U-Step II.
3) The Tension Control Lever is initially set to Low (L). ush the
Tension Control Lever forward (toward the H) to increase the
tension. Re-tighten the tension locking bolt making sure the
lever settles into one of the set holes. Note: If you do not posi-
tion the lever in a set hole, the tension lever might rub against
the side of the gray wheel.
4) Remember to
squeeze one of the
hand brakes while test-
ing the walker. Test the
rolling speed of the
walker; if you need
more or less resistance
adjust accordingly.
Ten ion Locking Bolt
Ten ion Lever
Ten ion Indicator ( ticker)

— 8 —
E. alking Over Obstacles
The U-Step II has a patented
spring-loaded front caster that
enables it to roll over obsta-
cles, such as door molding
strips and cracks in the side-
walk. It will help you ride over
obstacles as high as one half-
inch.
By removing the safety pins
that stop the rear wheels from
springing up, you can navigate
up larger obstacles such as
curbs without lifting the walker.
You can go up a curb or small
step by either stepping down
on the back of the base, or just
by pulling back on the handle-
bars, you can raise the front of
the walker to go up a curb or
small step.
After raising the front
end, release the
brake and roll up the
obstacle. This feature
requires reasonable
balance and is not
appropriate for every
one. If you feel
unsafe using this fea-
ture, keep the lock-
ing pins in place.
Locking Pin

— 9 —
F. Transporting Your U-Step II
Re ease Lever
2) Reach down and pull
up on the horizontal bar
that has a sticker on it
reading “Lift Here to
Fold” until the U-Step II
folds up.
1) With the U-Step II
in front of you, raise
the release lever in
front of the seat and
tilt the seat upward.
3) Secure the Velcro strap to
stop the walker from folding.
The orange tab on the end of
the Velcro is to help you see
the side of the Velcro with
hooks for securing the strap.

— 10 —
4) Hold the U-Step II
by the side to place
it into your vehicle.
G. Setup After Transporting
j
SAFETY NOTE: It is very important to press the
seat down until the Release Lever fully snaps into place.
1) Release the Velcro strap hold-
ing the U-Step II in the folded
position.
2) Allow the U-Step II to open –
with the base on the ground.
3) ress the seat down in the
middle until the Release Lever
snaps into place.
4) You can put the Velcro strap inside the basket so that it is
not hanging down.

— 11 —
H. Optional Accessories
1) Laser and Sound Cueing Module — Operating the Unit
The module primarily helps those with arkinson’s freezing but
also helps anyone with an irregular gait pattern. The Laser and
Sound Cueing Module can help you get started, normalize your
walking, and increase your stride.
To activate the Laser Cueing function, press the red button on
the unit attached to the right handlebar. You should hear a
series of clicks and see the red power indicator light blinking. A
bright red laser line will appear on the floor to guide your steps.
In this mode, without Sound Cueing activated, the upper black
button adjusts the time period before automatic laser shutoff to
conserve battery power, and the lower black button adjusts the
clicking volume. ressing the upper button extends the shutoff
period from 4 to 28 minutes in increments of 4 minutes; each
click that sounds after pressing the button indicates 4 minutes
of operating time in effect (from 1 to 7 clicks). ressing the
lower button lowers the click volume in steps to the softest set-
ting, then recycling to the loudest setting.
To activate Sound Cueing, press and hold the top black button
in for a few seconds until you hear a steady clicking. In this

— 12 —
mode, the two black buttons increase or decrease the cadence
(speed) with each brief press. The cadence varies from 59 to
130 beats per minute over 15 increments.
The Sound Cueing only operates while the Laser Cueing is on.
When Sound Cueing is activated, both the sound and laser
remain on indefinitely. Turning the Sound Cueing off requires
shutting the entire module off, by pressing the red button.
Use either alkaline or lithium
“AA” batteries. Remove the
small screw holding the bat-
tery cover on (Figure 1) and
slide the cover to the left to
remove it. Note the posi-
tion of the two batteries
(Figure 2), ensuring that the
the “+” and “–” sides are
installed in opposite direc-
tions. The unit will click
either three or five times
when the batteries are
installed correctly. If the
unit clicks three times, it is
shutting off. If the unit clicks
five times, it is turning on
and the power indicator will
blink.
Installing and Replacing the Cueing Module Batteries —
2) Alternati e Brake Accessory – ( rovided Upon Request)
This allows a person to operate the brakes from a Horizontal bar
that attaches at the handles. This feature is rarely used which is
why it is not included. However, if you would like one sent to
you, please call In-Step and we will be happy to send it to you.
Figure 1
Figure 2

— 13 —
3) Weights —
Although the U-Step II is very stable, we do offer weights as an
accessory to increase the
stability of the walker.
These weights easily
secure to the base of the
U-Step II using Velcro
straps
.
Alternati e Brake Accessory Installation instructions below:
a. Loosen the height adjustment bolts on the left and right
side with the 13-millimeter wrench supplied.
b. Carefully insert
the ends of the brake
accessory into the rear
of each handlebar until
the push pin engages
in the holes on the
walker.
c. Adjust the height of the handlebars so that the horizontal
bar is at a comfortable height for you.
d. Re-tighten the height adjustment bolts.
e. The pull-up rod below should be positioned below the
hand brakes so that when the rod is pulled up the hand brakes
are squeezed.
f. If you use this Alternative Brake setup, you may want to
remove the backrest in front so that you can sit down on your
U-Step II from the front.

I. Maintenance
J. arranty
j
NOTE: DO NOT pull on the cabling. ulling on a
cable can cause it to become kinked or stretched out
of shape, which could prevent the braking system
from functioning properly. A damaged cable should
be replaced. lease have your U-Step II serviced if
the cabling becomes damaged.
Your U-Step II Walking Stabilizer is warranted for a full year to
work properly and be free from any defects in materials and
workmanship. Additionally, the frame is warranted for three
years from the date of purchase.
In the event of a defect covered by this warranty, we will, at our
option, repair or replace the device. In the event of a problem,
you will need to return the walker for repair at your cost. We will
fix the product or replace it and send it back to you at our cost.
This warranty does not cover device failure due to owner's mis-
use or negligence.
In the event of a minor problem, In-Step Mobility roducts will
attempt to resolve the issue by sending replacement parts.
If you have a question about your U-Step II or this warranty,
please contact In-Step Mobility roducts at 1-800-558-7837.
— 14 —
Clean your U-Step II with a clean, damp cloth when necessary.
eriodically check some of the moving components for wear.
On a daily basis, check over the U-Step II by trying the brakes.
lease call your U-Step II representative or call 1-800-558-7837
if you experience any problems with the tension of the wheels
or with braking.

My Notes –
— 15 —

U-Step II alking Stabilizer
Medica e
Reimbu sable!
In-Step Mobility P oducts Co p.
8027 Montice o Ave., Skokie, IL 60076
wa [email protected] www.ustep.com
1.800.558.7837
— 16 —
Passive Cont ol Specifications
(Model US-PC2)
Model number ....................................US-PC2
Medi are ode (HCPC) ........................#E0147
Weight apa ity ..................................375 lbs
Height adjustment range..................................
..................a ommodates users 4’10” to 6’2”
Height ustomization ..........................available
Size of Padded Seat............................19” x 8”
Height from floor to seat ............................22”
Overall width ............................................23”
Length ......................................................25”
Folded dimensions...... approx. 42” x 23” x 10”
Turning ir le ............................................29”
Weight ..................................................20 lbs
Material of frame ............................................
............................Tubular Steel and Aluminum
— Patent Pending —
Available in Canada:
Special Needs Computers | 1-877-724-4922
