5-in-1 Mobility &
Bathroom Aid
56120
Instruction Manual
12.11.18
GET MORE FROM YOUR
MOBILITY AID
56120_IB_TH5862_BL_V2.indd 1 2018-12-17 4:01 PM

2
Introduction
Thank you for purchasing the BIOS Living 5-in-1 Mobility and Bathroom Aid.
1. Folding Walker 3. Raised Toilet Seat 4. Toilet Seat Frame 5. Shower Seat
2. Commode
Features:
• Lightweight aluminum “Your walker walks with you” frame
• 2 sets of comfortable hand grips
• Rubber feet to prevent slipping
• Adjustable height: 30” – 38” / 76 – 96.3 cm
• Frame width: 21” / 53 cm
• Weight capacity: 300 lbs / 136 kg
Contents:
• Lightweight aluminum frame
• Commode pail
• Non-slip foam cushion
• Plastic seat with commode cut out
• Black tote bag
Caution:
• Do not assemble or use this equipment without first reading and understanding this instruction manual. Failure to
apply the cautions below could result in injury.
• Do not exceed the maximum weight capacity of 300 lbs / 136 kg. Doing so may result in injury.
• Consult with your healthcare provider in determining the suitability of the device for the particular user.
56120_IB_TH5862_BL_V2.indd 2 2018-12-17 4:02 PM

3
1. Folding Walker
•Do not use on stairs or escalators.
• When turning around, bring the walker around you without twisting your back – you should always be facing the
front of the walker.
• Always be aware of your surroundings and obstacles i.e. electrical cords, throw rugs, toys, etc.
• Stay upright when you move, this will help walking behind it.
• Be careful not to push the walker too far ahead of you.
• Avoid hurrying and taking large steps when you turn. Change directions slowly.
• Do not overload your walker.
• Consult your doctor or therapist for help selecting and maintaining your walker.
1A. About the aluminum frame:
4 x Hand grips
4 x Adjustable legs
Folding button
Frame lock
Back rest
1B. How to use the folding walker:
The aluminum folding walker comes fully assembled; you will only have to adjust the legs to the appropriate position
and height.
1. To open or close the frame press the button located in the middle of the frame.
Important: The frame should be completely open before use.
56120_IB_TH5862_BL_V2.indd 3 2018-12-17 4:02 PM

4
“Your walker walks with you” feature:
Unlike traditional walkers, which are designed to be pushed in front of you,
the BIOS Living 5-in-1 Mobility & Bathroom Aid is designed with a frame
that features the “Your walker walks with you” function. The frame can be
locked, like a traditional walker or when the frame is unlocked the walker
walks with you as you move. The frame shifts on its hinges following your
hand movements. As you lift the walker to step you slightly push the frame
forward with your hand and the frame follows your hand movement sliding
to the left or right to walk with you.
2. To disable the “Your walker walks with you” feature and lock your frame;
start by pressing the folding button in the center on the top frame bar.
3. Fold both arms of the walker in slightly, adjust the frame lock located on the outside of the black back rest. Move
the metal pins from the down position to up on both sides of the back rest ensuring the metal pins “CLICK”
completely into place. The frame will now be locked. (Fig 1-3.)
Fig 2.
Fig 3.
Fig 1.
56120_IB_TH5862_BL_V2.indd 4 2018-12-17 4:02 PM

5
4. To fit your walker, start with your arms resting at your sides. Adjust all 4 legs by moving them UP or DOWN and
line up the metal pins with the corresponding holes; ensure the metal pins “CLICK” completely into place. Adjust
the legs so that the handles are at the height of your wrists. Make sure the height of each leg is the same.
5. With your hands placed on the upper hand grips, your elbow should be flexed 15° – 20°.
6. If you find that you have to stoop down or bring your arms up to reach the walker, adjust the legs to find the best
and comfortable height.
7. Always make sure to place your hands equally on either upper hand grips. This will distribute your weight evenly
across the walker and make it safe to support you while you move.
2. Commode
IMPORTANT: Always make sure all 4 legs are the same height before using.
2A. About the Commode:
Commode pail
Plastic seat
Non-slip foam padding
Commode cut out
4 x Hand grips
4 x Adjustable legs
Folding button
2 x Seat buckles
Back rest
2B. How to use the commode:
1. Stand with the aluminum frame open in front of you, the frame needs to be in the locked position for this
application for safety.
NOTE: If you want to use the non-slip foam padding, place it on the plastic seat before securing the
plastic seat to the aluminum frame.
Frame lock
