Indesit WIDL 146 - ANNEXE 943 User manual

1
GB
English,1
Contents
Installation, 2-3-4-5
Unpacking and levelling, 2
Electric and water connections, 2-3
The first wash cycle, 4
Technical details, 5
Washer-dryer description, 6-7
Control panel, 6
eds, 7
tarting and Programmes, 8
Briefly: how to start a programme, 8
Programme table, 8
Personalisations, 9
Setting the temperature, 9
Setting the drying cycle, 9
Functions, 9
Detergents and laundry, 10
Detergent dispenser, 10
Preparing your laundry, 10
Special items, 10
Precautions and advice, 11
General safety, 11
Disposal, 11
Saving energy and respecting the environment, 11
Care and maintenance, 12
Cutting off the water or electricity supply, 12
Cleaning your appliance, 12
Cleaning the detergent dispenser, 12
Caring for your appliance door and drum, 12
Cleaning the pump, 12
Checking the water inlet hose, 12
Troubleshooting, 13
ervice, 14
Before calling for Assistance, 14
WA HER-DRYER
WIDL 146
Instructions for use
GB

2
GB
Installation
Keep this instruction manual in a safe place for
future reference. Should the appliance be sold,
transferred or moved, make sure the instruction
manual accompanies the washer-dryer to inform the
new owner as to its operation and features.
Read these instructions carefully: they contain vital
information on installation, use and safety.
Unpacking and levelling
Unpacking
1. Unpack the washer-dryer.
2. Check whether the washer-dryer has been
damaged during transport. If this is the case, do not
install it and contact your retailer.
3. Remove the four
protective screws and
the rubber bush with the
respective spacer,
situated on the rear of
the appliance (see also
the installation leaflet).
NB:The plastic spacers
may fall down inside the
machine once the bolt
has been removed, and will not interfere with the
operation of the machine.
4. Seal the gaps using the plastic plugs provided.
5. Keep all the parts: you will need them again if the
washing machine needs to be moved to another
location.
Packaging materials are not children's toys.
Levelling
Your machine may make a considerable amount of noise
if the two front feet have not been adjusted correctly.
1. Install the washer-dryer on a flat sturdy floor,
without resting it up against walls, furniture cabinets
or other.
2. If the floor is not
perfectly level, compen-
sate for any unevenness
by tightening or
loosening the adjustable
front feet (see figure);
the angle of inclination,
measured according to
the worktop, must not
exceed 2°.
evelling your appliance correctly will provide it with
stability and avoid any vibrations, noise and shifting
during operation. If it is placed on a fitted or loose
carpet, adjust the feet in such a way as to allow
enough room for ventilation beneath the washer-
dryer.
Electric and water connections
Connecting the water inlet hose
1. Insert seal A into the
end of the inlet hose
and screw the latter
onto a cold water tap
with a 3/4 gas threaded
mouth (see figure).
Before making the
connection, allow the
water to run freely until
it is perfectly clear.
2. Connect the other end
of the water inlet hose to
the washer-dryer,
screwing it onto the
appliance's cold water
inlet, situated on the top
right-hand side on the
rear of the appliance
(see figure).
3. Make sure there are no kinks or bends in the hose.
The water pressure at the tap must be within the
values indicated in the Technical details table
(on the next page).
If the water inlet hose is not long enough, contact
a specialist store or an authorised serviceman.
Ensure that the supply taps are allowing water
through. Old taps may seize in the closed position
and thus prevent water reaching the machine.
A

3
GB
erviceTroubleshootingPrecautions CareProgrammes DetergentsInstallation Description
Connecting the drain hose
Connect the drain hose,
without bending it, to a
draining duct or a wall
drain situated between
65 and 100 cm from
the floor;
The drain hose may be
connected to an
under-sink trap. Before
connecting the drain
hose from the machine
ensure that any blanks
or removable ends
have been taken off
the spigot.
If it is place over the
edge of a basin or sink
be sure the free end of
the hose should not be
underwater.
 We advise against the use of hose extensions; in
case of absolute need, the extension must have the
same diameter as the original hose and must not
exceed 150 cm in length.
Ensure that if the drain hose is pushed into a
standpipe, that the end does not go down more
than 15cms (6 inches). If the hose is pushed down
too far, this may cause the machine to self -syphon
ie. continuously empty as it is filling.
Electric connection
Before plugging the appliance into the mains
socket, make sure that:
 the socket is earthed and in compliance with the
applicable law;
 the socket is able to sustain the appliance's
maximum power load indicated in the Technical
details table (see page 5);
 the supply voltage is included within the values
indicated on the Technical details table
(see page 5);
 the socket is compatible with the washer-dryer's
plug. If this is not the case, replace
the socket or the plug.
Your appliance is now supplied with a 13 amp fused
plug it can be plugged into a 13 amp socket for
immediate use. Before using the appliance please
read the instructions below.
WARNING - THIS APP IANCE MUST BE EARTHED.
THE FO OWING OPERATIONS SHOU D BE
CARRIED OUT BY A QUA IFIED E ECTRICIAN.
Replacing the fuse:
When replacing a faulty fuse, a 13 amp ASTA
approved fuse to BS 1362 should always be used,
and the fuse cover re-fitted. If the fuse cover is lost,
the plug must not be used until a replacement is
obtained.
Replacement fuse covers:
If a replacement fuse cover is fitted, it must be of
the correct colour as indicated by the coloured
marking or the colour that is embossed in words on
the base of the plug. Replacements can be obtained
directly from your nearest Service Depot.
Removing the plug:
If your appliance has a non-rewireable moulded plug
and you should wish to re-route the mains cable
through partitions, units etc., please ensure that
either:
the plug is replaced by a fused 13 ampere re-
wearable plug bearing the BSI mark of approval.
or:
the mains cable is wired directly into a 13 amp cable
outlet, controlled by a switch, (in compliance with
BS 5733) which is accessible without moving the
appliance.
Disposing of the plug:
Ensure that before disposing of the plug itself, you
make the pins unusable so that it cannot be
accidentally inserted into a socket.
Instructions for connecting cable to an alternative plug:
Important: the wires in the mains lead are coloured
in accordance with the following code:
Green & Yellow Earth
Blue Neutral
Brown Live
65 - 100 cm
Where it connects
to the waste water
pipe cut end off
spigot or remove the
blanking cap

4
GB
GREEN &
YELLOW
BROWN
BLUE
13 ampere fuse
CROSS-BAR
CORD GRIP
As the colours of the wires in the lead may not
correspond with the coloured markings identifyng
the terminals in your plug, proceed as follows:
Connect Green & Yellow wire to terminal marked E
or or coloured Green or Green & Yellow.
Connect Brown wire to terminal marked L or
coloured Red.
Connect Blue wire to terminal marked N or coloured
Black.
If a 13 amp plug (BS 1363) is used it must be fitted
with a
13 amp fuse, either in the plug or adaptor or at the
distribution board.
If you are in any doubt the electrical supply to your
machine, consult a qualified electrician before use.
How to connect an alternative plug:
The wires in this mains lead are coloured in
accordance with the following code:
BLUE NEUTRAL (N)
BROWN LIVE (L)
GREEN & YELLOW EARTH (E)
Disposing of the appliance:
When disposing of the appliance please remove the
plug by cutting the mains cable as close as possible
to the plug body and dispose of it as described
above.
 The washing machine should not be installed in an
outdoor environment, not even when the area is
sheltered, because it may be very dangerous to
leave it exposed to rain and thunderstorms.
 When the washing machine is installed, the mains
socket must be within easy reach.
 Do not use extensions or multiple sockets.
 The power supply cable must never be bent or
dangerously compressed.
 The power supply cable must only be replaced by
an authorised serviceman.
Warning! The company denies all liability if and when
these norms are not respected.
The first wash cycle
Once the appliance has been installed, and before
you use it for the first time, run a wash cycle with
detergent and no laundry, setting the 90°C
programme without a pre-wash cycle.

5
GB
erviceTroubleshootingPrecautions CareProgrammes DetergentsDescriptionInstallation
Technical details
Model WID 146
Dimensions
59.5 cm wide
85 cm high
53.5 cm deep
Capacity from 1 to 5 kg for the wash programme;
from 1 to 4 kg for the drying programme
Electric
connections
voltage 230/240 Volts 50 Hz
maximum absorbed power 2050 W
Wat e r
connections
maximum pressure 1 MPa (10 bar)
minimum pressure 0.05 MPa (0.5 bar)
drum capacity 46 litres
pin speed up to 1400 rpm
Control
programmes
according to
IEC456 directive
Wash: programme 2; temperature 60°C;
run with a load of 5 kg.
Drying: first drying cycle performed with
a 1 kg load, by selecting a drying time
of 40 min;
Second drying cycle performed with a 4
kg load and the DRYING knob on the
setting.
This appliance is compliant with the
following European Community
Directives:
- 73/23/CEE of 19/02/73 ( ow
Voltage) and subsequent amendments
- 89/336/CEE of 03/05/89
(Electromagnetic Compatibility) and
subsequent amendments
- 2002/96/CE

6
GB
Washer-dryer description
Control panel
Detergent dispenser
ON-OFF
Button
TART/RE ET
Button
TEMPERATURE
Knob
PROGRAMME
Knob
Leds
FUNCTION
Buttons
ON-OFF/
DOOR
LOCK
ed
Detergent dispenser: to add detergent and fabric
softener (see page 10).
LED : to find out the wash cycle progress.
If the Delay Timer function has been set, the time
left until the programme starts will be indicated (see
page 7).
DRYING knob: to set the desired drying cycle
(see page 9).
FUNCTION buttons: to select the functions
available. The button corresponding to the function
selected will remain on.
TEMPERATURE knob: to set the temperature or
the cold wash cycle (see page 9).
TART/RE ET button: to start the programmes or
cancel any incorrect settings.
ON-OFF/DOOR LOCK ed: to find out whether the
Washer-dryer is on and if the appliance door can be
opened (see page 7).
ON/OFF button: to turn the Washer-dryer on and off.
PROGRAMME knob: to select the wash
programmes. The knob stays still during the cycle.
DRYING
Knob

7
GB
erviceTroubleshootingPrecautions CareProgrammes DetergentsInstallation Description
ON-OFF/DOOR LOCK led:
If this ED is on, the appliance door is locked to prevent it from being opened accidentally; to avoid any
damages, wait for the ED to flash before you open the appliance door.
 The rapid flashing of the ON-OFF/DOOR OCK ed together with the flashing of at least one other ED
indicates there is an abnormality. Call for Technical Assistance (see page 13).
Cycle progress:
During the wash cycle, the EDs gradually illumina-
te on to indicate the cycle progress:
Prewash / Wash
Rinse
Spin cycle
Drying
Note:
- during draining, the ED corresponding to the
Spin cycle phase will be turned on.
- when the drying cycle is complete, the indicator
light relative to phase will flash, to indicate that
the DRYING knob needs to be set back to the 0
setting.
Function buttons
The FUNCTION BUTTONS also act like EDS.
When a function is selected, the corresponding
button is illuminated.
If the function selected is incompatible with the
programme set, the button will flash and the
function will not be enabled.
If you set a function that is incompatible with
another function you selected previously, only the
last one selected will be enabled.
Leds
The EDS provide important information.
This is what they can tell you:
Delay set:
If the Delay Timer function has been enabled (see
page. 9), once you have started the programme,
the ED corresponding to the delay set will begin to
flash:
As time passes, the remaining delay will be
displayed, and the corresponding ED will flash:
Once the set delay is complete, the flashing ED will
turn off and the programme set will start.

8
GB
Type of fabric and
degree of soil Progr. Te m p e -
rature
Detergent Fabric
softener
ycle
length
(minutes)
Max.
Spin
Speeds
(r.p.m .)
Description of wash cycle
pre-
wash wash
tandard
Extremely soiled whites
(sheets, tablecloths, etc.) 190°C    135 Max. Pre-wash, wash cycle, rinse cycles, intermediate and final spin cycles
Extremely soiled whites
(sheets, tablecloths, etc.) 290°C   125 Max. Wash cycle, rinse cycles,
intermediate and final spin cycles
Heavily soiled w hites and fast
colours 260°C   110 Max. Wash cycle, rinse cycles,
intermediate and final spin cycles
Heavily soiled w hites and delicate
colours 240°C   105 Max. Wash cycle, rinse cycles,
intermediate and final spin cycles
Slightly soiled w hites and delicate
colours (shirts, jumpers, etc.) 340°C   70 Max. Wash cycle, rinse cycles,
intermediate and final spin cycles
Heavily soiled fast colours
(baby linen, etc.) 450°C  75 800 Wash cycle, rinse cycles, anti-crease
or delicate spin cycle
Heavily soiled fast colours
(baby linen, etc.) 440°C   60 800 Wash cycle, rinse cycles, anti-crease
or delicate spin cycle
Wool 540°C   50 600 Wash cycle, rinse cycles anti-crease
or delicate spin cycle
Very delicate fabrics
(curtains, silk, viscose, etc.) 630°C   45 no Wash cycle, rinse cycles, anti-crease
or draining cycle
Drying cotton 7Max.
Drying delicates 8no
Time 4 you
Heavily soiled w hites and fast
colours 960°C   65 Max. Wash cycle, rinse cycles, intermediate and final spin cycles
Delicate colours
(all types of slightly soiled garments) 10 40°C  45 800 Wash cycle, rinse cycles, delicate
spin cycle
Delicate colours
(all types of slightly soiled garments) 11 30°C   30 800 Wash cycle, rinse cycles and delicate
spin cycle
port
Sports shoes (MAX. 2 pairs) 12 30°C  50800 Cold wash (without detergents), wash
cycle, rinse cycles, and delicate spin cycle
Fabrics for sportswear
(Tracksuits, shorts, etc.) 13 30°C   60 600 Wash cycle, rinse cycles, intermediate and final spin cycles
PARTIAL PROGRAMME
Rinse 800 Rinse cycles and spin cycle
Spin cycle 800 Draining and spin cycle
Drain no Drain
tarting and Programmes
Programme table
Notes
-For programme 9, we advise against exceeding a wash load of 3.5 kg.
-For programme 13 we advise against exceeding a wash load of 2 kg.
-For the anti-crease function: see Easy iron, opposite page. The information contained in the table is purely indicative.
pecial programme
Dail (programme 11 for Synthetics) is designed to wash lightly soiled garments in a short amount of time: it only lasts
30 minutes and allows you to save on both time and energy. By setting this programme (11 at 30°C), you can wash
different fabrics together (except for woollen and silk items), with a maximum load of 3 kg.
We recommend the use of liquid detergent.
Briefly: starting a programme
1. Switch the Washer-dryer on by pressing button .
All the EDS will light up for a few seconds and
the ON-OFF/DOOR OCK ed will begin to flash.
2. oad your laundry into the washing machine and
shut the appliance door.
3. Set the PROGRAMME knob to the programme
required.
4. Set the wash temperature (see page 9).
5. Set the drying cycle if necessary (see page 9).
6. Add the detergent and any fabric softener (see page 10).
7. Start the programme by pressing the START/RESET
button for one second. Once the programme has
been accepted all of the option and status ED's
will illuminate momentarily, the Door ock ED
will be lit and the relevant wash cycle progress
ED will also be lit.
To cancel it, keep the START/RESET button pressed
for at least 2 seconds.
8. When the programme is finished, the ON-OFF/
DOOR OCK ed will flash to indicate that the
appliance door can be opened. Take out your
laundry and leave the appliance door ajar to allow
the drum to dry thoroughly. Turn the Washer-dryer
off by pressing button .

9
GB
erviceTroubleshootingPrecautions CareProgrammes DetergentsInstallation Description
Personalisations
C
etting the temperature
Turn the TEMPERATURE knob to set the wash temperature (see Programme table on page 8).
The temperature can be lowered, or even set to a cold wash ( ).
et the drying cycle
Turn the DRYING knob to set the desired drying type.
Two options are available:
A - Based on time: From 40 minutes to 150.
B - Based on the damp level of the dry clothes:
Iron : slightly damp clothes, easy to iron.
Hanger : dry clothes to put away.
Cupboard : very dry clothes, recommended for towelling
and bathrobes.
A cooling stage is foreseen at the end of the drying cycle.
If your laundry load to wash and dry is exceptionally in excess
of the maximum load foreseen (see table opposite), perform
the wash cycle, and when the programme is complete, divide up the garments and put part of them back in the
drum. Now follow the instructions provided for a dry only cycle. Repeat this procedure for the remainder of the load.
Dry only
Turn the PROGRAMME knob to one of the drying settings (7-8) depending on the type of fabric, then select the
desired drying type using the DRYING knob.
Important: - A spin cycle is carried out during the drying if you have set a cotton programme and a level of
dryness (Cupboard , Hanger , Iron ).
- For cotton loads of less than 1 Kg, use the dr ing programme designed for delicate fabrics.
Functions
To enable a function:
1. press the button corresponding to the desired function, according to the table below;
2. the function is enabled when the corresponding button is illuminated.
Note: The rapid flashing of the button indicates that the corresponding function cannot be selected for the
programme set.
Function Effect omments Enabled with
programmes:
D e lay Tim er
Delays the start
of the wash by
up to 9 hours.
Press the button repeatedly until the ED corresponding to the
desired delay is turned on.
The fifth time the button is pressed, the function will be disabled.
N.B.: Once you have pressed the Start/Reset button, the delay
can only be decreased if you wish to modify it.
All
Ea s y i ro n
This option
reduces the
amount of
creasing on
fabrics, making
them easier to
iron.
When this function is set, programmes 4, 5, 6 will end with the
laundry left to soak (Anti-crease) and the Rinse cycle phase
ED will flash.
- to conclude the cycle, press the START/RESET button;
- to run the draining cycle alone, set the knob to the relative
symbol and press the START/RESET button.
3, 4, 5, 6,
9, 10,
Rinse cycle.
Ex t ra R in s e
Increases the
efficiency of the
rinse.
Recommended when the appliance has a full load or with large
quantities of detergent.
1, 2, 3, 4, 9,
10, 12, 13,
Rinse cycle.
1400- 600
Reduces the
spin speed.
All
programmes
except for 6
and draining.
Fabric
type
Load type Max.
load
(kg) Cup-
board
Hanger Iron
Cotton,
inen
Clothing of different sizes 4 130 120 110
Cotton Terry towels 4 130 120 110
Terit al,
Cotton
Sheets, Shirts 2,5 90 80 70
Acrylics Pyjamas, socks, etc. 165 6060
Nylon Slips, tights, stockings, etc. 165 6060
Table of drying times
The data contained in the
table are purel indicative.
 The machine has an intelligent built in check for out of balance loads. To let protect your machine it may reduce the final spin
speed if an unbalanced load is detected.

10
GB
Detergent dispenser
Good washing results also depend on the correct
dose of detergent: adding too much detergent won't
necessarily make for a more efficient wash, and may
in fact cause build up on the interior of your
appliance and even pollute the environment.
Open up the detergent
dispenser and pour in
the detergent and fabric
softener, as follows.
compartment 1: Detergent for pre-wash
(powder)
compartment 2: Detergent for the wash cycle
(powder or liquid)
iquid detergent should only be poured in
immediately prior to the wash cycle start.
compartment 3: Additives (fabric softeners, etc.)
The fabric softener should not overflow from the grid.
 Do not use hand wash detergent because it may
form too much foam.
Preparing your laundry
 Divide your laundry according to:
- the type of fabric/the symbol on the label.
- the colours: separate coloured garments from
whites.
 Empty all pockets and check for loose buttons.
 Do not exceed the weight limits stated below,
which refer to the weight when dry:
Sturdy fabrics: max 5 kg
Synthetic fabrics: max 2.5 kg
Delicate fabrics: max 2 kg
Wool: max 1 kg
How much does your laundry weigh?
1 sheet 400-500 g
1 pillow case 150-200 g
1 tablecloth 400-500 g
1 bathrobe 900-1,200 g
1 towel 150-250 g
pecial items
Curtains: fold curtains and place them in a pillow
case or mesh bag. Wash them separately without
exceeding half the appliance load. Use programme 6
which excludes the spin cycle automatically.
Quilted coats and windbreakers: if they are
padded with goose or duck down, they can be
machine-washed. Turn the garments inside out and
load a maximum of 2-3 kg, repeating the rinse cycle
once or twice and using the delicate spin cycle.
Wool: for best results, use a specific detergent,
taking care not to exceed a load of 1 kg.
Detergents and laundry
123
