Indmar 5.7L MPI User manual

Operator’s Manual
Part No. OME0502-15 Printed in U.S.A.
The first production inboard equipped with catalytic converters.
Ken Cook Co.
5400 Old Millington Road Millington, TN 38053
www.indmar.com
OME0502-15 Cover.qxp_OM0502-05 Cover.qxd 4/28/14 10:27 AM Page 1

PROPOSITION 65
The engine exhaust from this product
contains chemicals known to the
State of California to cause cancer, birth
defects or other reproductive harm.
WARNING
Date of Purchase: ______________________ Owner Name: _____________________________________________
Address: __________________________________________________ City: ________________________________
State/Province: ___________________________ Zip/Postal Code:____________ Country: ____________________
Engine Serial Number: _____________________________ Transmission Serial Number: _______________________
10-20 Hour Service
Date:___________ Hours:____________
By:_______________________________
Every 50 (25) Hour Service
Date:___________ Hours:____________
By:_______________________________
Date:___________ Hours:____________
By:_______________________________
Date:___________ Hours:____________
By:_______________________________
Date:___________ Hours:____________
By:_______________________________
Date:___________ Hours:____________
By:_______________________________
Date:___________ Hours:____________
By:_______________________________
Date:___________ Hours:____________
By:_______________________________
Date:___________ Hours:____________
By:_______________________________
Every 100 Hour Service
Date:___________ Hours:____________
By:_______________________________
Date:___________ Hours:____________
By:_______________________________
Date:___________ Hours:____________
By:_______________________________
Date:___________ Hours:____________
By:_______________________________
Date:___________ Hours:____________
By:_______________________________
Date:___________ Hours:____________
By:_______________________________
Date:___________ Hours:____________
By:_______________________________
Date:___________ Hours:____________
By:_______________________________
Date:___________ Hours:____________
By:_______________________________
Every 300 Hour/Annual Service
Date:___________ Hours:____________
By:_______________________________
Date:___________ Hours:____________
By:_______________________________
Date:___________ Hours:____________
By:_______________________________
Date:___________ Hours:____________
By:_______________________________
Date:___________ Hours:____________
By:_______________________________
Date:___________ Hours:____________
By:_______________________________
Every 2 Year Service
Date:___________ Hours:____________
By:_______________________________
Date:___________ Hours:____________
By:_______________________________
Date:___________ Hours:____________
By:_______________________________
OME0502-15 Cover.qxp_OM0502-05 Cover.qxd 4/28/14 10:27 AM Page 2

Indmar Marine Engines
i
Throughout this manual, specific precautions and sym-
bols identify safety related information.
The Safety Alert Symbol means ATTENTION!
BECOME ALERT! YOUR SAFETY IS INVOLVED!
Indicates the presence of a hazard which
WILL cause SEVERE injury, death or sub-
stantial property damage.
Indicates the presence of a hazard which
CAN cause SEVERE injury, death or substan-
tial property damage.
Indicates the presence of a hazard which
WILL or CAN cause MINOR or MODERATE
personal injury or property damage.
NOTICE
Indicates installation, operation or maintenance infor-
mation which is important but not hazard-related.
The precautions listed in this manual and on the engine
or boat are not all-inclusive. If a procedure, method, tool
or part is not specifically recommended, you must satisfy
yourself that it is safe for you and others, and that the
engine or boat will not be damaged or made unsafe as a
result of your decision.
! !
IMPORTANT SAFETY INFORMATION
!
OME0502-15 Body.qxp_OM0502-05 Body.qxd 5/20/14 12:45 PM Page i

ii
Indmar Marine Engines
Axis
MB Sports
Malibu
Moomba
Sanger
Supra
Svfara
Tigé
The above list is subject to change as new customers become members of the Indmar family.
Engine Families:
5.7L Electronic Fuel Injected
6.0L Electronic Fuel Injected – L96
6.2L Electronic Fuel Injected – LS3, LSA
ENGINES COVERED
The information in this manual applies to the following Indmar-branded GM-based engines, as well as the
GM-based engines built specifically for our OEM Boat Builder Customers listed below:
OME0502-15 Body.qxp_OM0502-05 Body.qxd 5/20/14 12:45 PM Page ii

Indmar Marine Engines
iii
Dear Indmar Marine Engine Owner,
Thank you for selecting a boat powered by an Indmar Marine Engine. Indmar is proud to provide the power
to the best boat companies in the business and we hope that pride shows in the quality of our products. In
the unlikely event that you have a defect related problem with your boat’s engine / drive train, you can
rest assured knowing it is backed by our industry leading Factory 3 standard 3-year warranty coverage.
This is another exciting year for Indmar and for the marine industry. Indmar has expanded its line of
marine inboard engines equipped with catalytic converters. Indmar’s ETX/CAT system reduces exhaust emis-
sions, including carbon monoxide (CO), to provide a cleaner and safer boating experience for you and your
family. ETX/CAT is standard on all 5.7L, 6.0L and 6.2L naturally aspirated Electronic Fuel Injected (EFI)
engines built for sale in the U.S. and Canada.
If you have any questions concerning your engine that are not covered in this manual, please feel welcome
to contact Indmar Customer Service at [phone] or visit our website, www.indmar.com, and submit
your question.
Thanks again for choosing an Indmar powered boat. We wish you safe, trouble-free boating.
Sincerely,
Team Indmar
WELCOME
OME0502-15 Body.qxp_OM0502-05 Body.qxd 5/20/14 12:45 PM Page iii

iv
Indmar Marine Engines
INDMAR MARINE ENGINES COMPANY MISSION
To produce the world’s finest, most advanced and most dependable
gasoline inboard marine engines at the best possible price,
while respecting the needs of our employees, customers, vendors
and the precious environment we share.
OME0502-15 Body.qxp_OM0502-05 Body.qxd 5/20/14 12:45 PM Page iv

Indmar Marine Engines
v
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Chapter 1: First Time Operation and Break-In . . . . . . . . . . . . . . . 1-1
First Time Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
Chapter 2: General Operations and Warnings . . . . . . . . . . . . . . . 2-1
Chapter 3: Engine Starting Procedures . . . . . . . . . . . . . . . . . . . . . 3-1
How to Start Your Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
If Engine Does Not Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3
How to Clear the Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3
Engine Restart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4
Chapter 4: Normal Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Sensible Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1
Daily Routine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1
Operating the Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3
Unusual Vibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-4
Fuel System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-4
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-4
“Service Required” or “Check Engine” Indicator
(EFI Engines Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5
Check Transmission Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6
Engine Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6
Exhaust Hoses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-8
TABLE OF CONTENTS
OME0502-15 Body.qxp_OM0502-05 Body.qxd 5/20/14 12:45 PM Page v

vi
Indmar Marine Engines
Selecting a Propeller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-8
Chapter 5: Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
What Type of Gasoline to Use . . . . . . . . . . . . . . . . . . . . . . . . . .5-1
Using Oxygenated Fuels or Fuels with Alcohol . . . . . . . . . . . .5-2
Fuels in Other Countries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Chapter 6: Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
General Service Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1
Engine Oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-4
Engine Flame Arrestor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-8
Engine Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-8
Internal (Cooling System) Care . . . . . . . . . . . . . . . . . . . . . . . .6-12
Fuel System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-14
Transmissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-14
Electrical System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-19
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-20
Chapter 7: Storage and Winter Lay-up . . . . . . . . . . . . . . . . . . . . . 7-1
General Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-2
Reactivating Engine After Extended Storage . . . . . . . . . . . . .7-10
Extended Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-12
Chapter 8: Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
Appendix A – Maintenance Components and Fluids . . . . . . . . . .A-1
Appendix B – Engine Specifications . . . . . . . . . . . . . . . . . . . . . . . B-1
Appendix C – Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . C-1
OME0502-15 Body.qxp_OM0502-05 Body.qxd 5/20/14 12:45 PM Page vi

This manual will acquaint you with basic information
needed to safely operate and maintain your Indmar
engine. We suggest you and all other operators read the
entire manual before using your boat.
We recommend you contact your Indmar dealer for all
engine service. Certified Indmar Technicians are trained.
They have current specifications, parts and the special
equipment needed to service your Indmar engine and
drive line. To find your nearest Indmar dealer, please call
[phone] or visit our website at www.indmar.com.
To ensure that the proper information is available, note
the six digit engine serial number. Your dealer should
have written the engine serial number on the inside back
cover of this manual. The serial number is stamped on
the engine block; see Figure 1.1 for locations. The serial
number also appears on the emissions label at the rear
of the engine and on several stick-on tags that are
attached to major engine components.
Figure 1.1 – Serial Number Locations
INDM-A001
EMISSIONS
LABEL
INTRODUCTION
Indmar Marine Engines
vii
OME0502-15 Body.qxp_OM0502-05 Body.qxd 5/20/14 12:45 PM Page vii

viii
Indmar Marine Engines
Warranty Registration
The Federal Boat Safety Act of 1971 requires registra-
tions of marine products sold in the United States be
maintained by the manufacturer and dealers of those
products. Your dealer should have completed your
warranty registration to comply with federal regulations.
This registration enables us to contact you, if it should
become necessary, to change or improve your product.
The engine serial number is stamped into the block
and should also be written on the inside of the back
cover of this manual. Always retain a copy of the serial
number for your personal records.
OME0502-15 Body.qxp_OM0502-05 Body.qxd 5/20/14 12:45 PM Page viii

Indmar Marine Engines
ix
Warranty Registration Transfer
The remainder of the engine warranty is transferable to a
second or subsequent owner. Warranty transfers must
be completed within 10 days of the transfer of owner-
ship.
If the trade-in and resale is handled by an authorized
Indmar dealer, the dealer must fill out the warranty regis-
tration transfer form and send it and other paperwork
specified along with the warranty transfer fee (currently
$200.00) and the transfer will be processed on approval
by Indmar.
If the sale of the boat is from a private owner to another
individual, the engine package must be inspected, at the
seller or purchaser’s expense, and the Inspection Form,
Warranty Transfer Form, specified paperwork and trans-
fer fee (currently $200.00) and the transfer will be
processed on approval by Indmar.
The new boat owner will be notified within 10 days of
Indmar’s receipt of the transfer paperwork whether the
transfer has been accepted or not. If the transfer has
been accepted, the warranty expiration date will also be
provided for the new owner.
To obtain enjoyment from your boat, follow recommenda-
tions described in this manual. The knowledge you gain
through careful review will help you experience lasting
satisfaction.
Further information regarding the care, operation,
required equipment or specifications for your boat can be
obtained from your local US Coast Guard Auxiliary, US
Power Squadron, state boating authorities, or the
American Red Cross. Know the law and your responsi-
bilities as a boat owner.
Any alteration, change, improper maintenance or abnor-
mal use by you which renders the engine or any of its
components unreasonably dangerous will void all war-
ranties and Indmar will not be liable for the resulting
damages or injuries.
OME0502-15 Body.qxp_OM0502-05 Body.qxd 5/20/14 12:45 PM Page ix

x
Indmar Marine Engines
EMISSION CONTROL WARRANTY INFORMATION
The inboard engine in your
boat includes the Indmar
Emission Control System
identified as MFI. The fuel
and ignition systems on
your engine meet the
stringent requirements set
forth by the U.S.
Environmental Protection
Agency (EPA) and the
California Air Resources
Board (CARB). Indmar
also uses propylene glycol
anti-freeze in the closed
cooling system of your
engine to reduce the
environmental impact in
the event that anti-freeze
is expelled from the
engine.
Your Indmar manufactured engine has a special environ-
mental label required by the California Air Resources
Board (CARB). The label has 1, 2, 3 or 4 stars. A hang-
tag, provided with your inboard engine, describes the
meaning of the star system.
Operating Fuels and Lubricants
In order to keep your engine operating efficiently and to
maintain the Emission Control System the following
requirements must be observed.
Fuel – Your engine was designed and certified to
operate on the unleaded fuels listed below. Fuel rat-
ings must be based on the (R+M)/2 method and meet
the specifications ASTM D4814 in the US. These
fuels need no additives for proper operation.
• LS3 and LSA Engines 91 Octane
• All other Indmar Engines 89 Octane
INDM-A041
INDM-A042
OME0502-15 Body.qxp_OM0502-05 Body.qxd 5/20/14 1:13 PM Page x

Indmar Marine Engines xi
Lubricant – Indmar uses and recommends 15W40
Marine Oil for use in all of its engines except for
the LS series engines which use Mobil 1 5W30 oil.
If marine oil is not available, any appropriate
viscosity motor oil meeting the API ratings of SL,
CI-4 is acceptable. See Chapter 6, Maintenance,
for information regarding the use of synthetic oil.
Additives – The only additive that is recommended by
Indmar for use in your engine is Sta-Bil brand fuel sta-
bilizer. This additive helps preserve the fuel in your
tank and in the engine’s fuel system. We recommend
the use of Marine Formula Sta-Bil during off-season
storage and for the boater that consumes less than a
full tank of fuel every two weeks. See Chapter 5, Fuel,
for more information.
EPA Emission-Related Warranty Requirements
Your new engine is designed, built, and equipped so it
conforms at the time of sale to the ultimate purchaser
with the requirements of CFR 40, part 1045.120. It is free
from defects in materials and workmanship that may
keep it from meeting these requirements.
The minimum emission-related warranty period is
3 years/480 hours, whichever comes first. The emission-
related warranty covers all components whose failure
would increase an engine’s emissions of any regulated
pollutant, including components listed below and compo-
nents from any other system developed to control
emissions.
Emissions Components Warranty
The following components are considered as part of the
emissions control system and are covered under the
Emissions Control Warranty.
1. Fuel Metering System
A. Fuel injectors
B. Fuel pressure regulator
C. Manifold Absolute Pressure Sensor
D. Throttle Position Sensor
E. Idle Air Control Valve
F. Throttle Body – Port Fuel Injection Models
G. Throttle Body Assembly – Throttle Body Fuel
Injection Models
H. Carburetor
I. Coolant Temperature Sensor
J. Intake Valves
K. Oxygen Sensors
2. Air Induction System
A. Intake Manifold
B. Air Filter (Flame Arrestor)
3. Ignition System
A. Spark Plugs
B. Electronic Ignition System
C. Ignition coil and/or control module
D. Ignition Wires
4. Lubrication System
A. Oil pump and internal parts
5. Positive Crankcase Ventilation (PCV) System
A. PCV valve
B. Oil Filler Cap
OME0502-15 Body.qxp_OM0502-05 Body.qxd 5/29/14 1:43 PM Page xi

xii Indmar Marine Engines
6. Exhaust System
A. Exhaust manifold(s)
B. Exhaust riser(s)
C. Exhaust valves
D. Catalytic Converters
7. Miscellaneous Items Used on Above Systems
A. Hoses, clamps, fittings, tubing, sealing gaskets or
devices and mounting hardware
B. Electronic Controls
C. Electronic Control Module
D. Pulleys, belts and idlers
NOTICE
The repair or replacement of any warranted part oth-
erwise eligible for warranty coverage under the
Emission Control Warranty may be excluded from
such warranty coverage if Indmar demonstrates that
the engine has been abused, neglected, or improperly
maintained and that such abuse neglect or improper
maintenance was the direct cause of the need for
repair or replacement of the part.
The emission warranty covers damage to other engine
components that is caused by the failure of a warranted
part.
This manual contains written instructions for the proper
maintenance and use of your inboard engine. All emis-
sion warranty parts are warranted by Indmar for the
entire warranty period of the engine, unless the part is
scheduled for replacement as required maintenance in
the Operator’s Manual.
Emission warranty parts that are scheduled for replace-
ment, as required maintenance, are warranted by Indmar
for the period of time before the first scheduled replace-
ment date for that part. Emission warranted parts that
are scheduled for regular inspection, but not regular
replacement, are warranted by Indmar for the entire
warranty period of the inboard engine.
Any emission warranty part repaired or replaced under
the terms of this warranty statement is warranted by
Indmar for the remainder of the warranty period of the
original part. All parts replaced under this limited warranty
become the property of Indmar.
If the ownership of a product is transferred during
Emission Components Warranty period, this warranty
shall also be transferred and be valid for the remaining
coverage period provided that Indmar is notified in the
following way:
a. The former owner contacts Indmar and provides us
with the required information listed below; or
OME0502-15 Body.qxp_OM0502-05 Body.qxd 5/29/14 1:43 PM Page xii

Indmar Marine Engines xiii
b. Indmar receives a proof that the former owner agreed
to the transfer of ownership and we are provided with
the information listed below.
- Current owner’s name, address, telephone,
engine serial number and date of purchase
- New owner’s name, address, telephone, engine
serial number and date of transfer
Send the above information to:
Indmar Products
5400 Old Millington Rd
Millington, TN 38053
Attn: Emission Warranty Transfer
NOTICE
The above procedure is valid for the transfer of the
Emission Components warranty only. Refer to the
Limited Warranty in Section C of this manual for informa-
tion regarding warranty transfer of the remaining engine
components.
Emission Maintenance Requirements
The following component maintenance is required to
maintain the Emission Control System of your engine.
See Chapter 6, Maintenance, for procedures.
• Engine oil and filter: Change oil and filter after the first
10 hours then every 50 hours or annually, whichever
occurs first.
• Flame Arrestor: Clean every 100 hours. Replace as
necessary.
• Spark Plugs: Replace every 300 hours or annually,
whichever occurs first.
• Fuel Injectors: Clean every 300 hours or annually,
whichever occurs first.
• PCV Valve: Inspect annually. Replace as necessary.
• Spark Plug Wires: Inspect annually. Replace as
necessary.
NOTICE
Ignition timing, engine idle speed and air-fuel mixture
are not adjustable on this engine. NO OTHER
ADJUSTMENTS NEEDED.
OME0502-15 Body.qxp_OM0502-05 Body.qxd 5/29/14 1:43 PM Page xiii

xiv Indmar Marine Engines
Engine Model Engine
Oil
Oil
Filter
Spark
Plugs
PCV
Valve
Oxygen
Sensor
Flame
Arrestor
Plug
Wires Dist Cap Dist Rotor
5.7L Electronic Fuel Injected
Non Catalyst Models
Catalyst Models 871001
15W40
501001
PZ52 556199 505001
556162
521119
525028
525022
525011
756004 Red
751104 Blue 556345 556346
6.0L Electronic Fuel Injected
L96 Models 501018
PZ167 556188 N/A 525021 751203 N/A N/A
6.2L Electronic Fuel Injected 871003
5W30
Mobil 1
LS3 Models
LSA Models N/A 751202
Emission Component Part Numbers
Following are the Indmar Part numbers for the Emission Maintenance Components:
Emission Maintenance Procedures
Engine Oil and Filter: See Chapter 6, Maintenance
Spark Plugs: See Chapter 6, Maintenance
Fuel Injectors: See Chapter 6, Maintenance
PCV Valve: See Chapter 6, Maintenance
Flame Arrestor: See Chapter 6, Maintenance
Spark Plug Wires: See Chapter 6, Maintenance
Breather Hose: See Chapter 6, Maintenance
Ignition Timing: See Chapter 6, Maintenance
Carburetor Adjustment: See Chapter 6, Maintenance
OME0502-15 Body.qxp_OM0502-05 Body.qxd 5/29/14 1:43 PM Page xiv

Indmar Marine Engines
xv
CALIFORNIA EMISSION CONTROL
WARRANTY STATEMENT
YOUR WARRANTY RIGHTS AND OBLIGATIONS
The California Air Resources Board and Indmar Products
are pleased to explain the emission control system
warranty on your inboard engine. In California, new
inboard engines must be designed, built and equipped
to meet the State’s stringent anti-smog standards.
Indmar Products must warrant the emission control
system in your inboard engine for the time listed below
provided there has been no abuse, neglect or improper
maintenance of your inboard engine.
Your emission control system may include parts such as
the carburetor or fuel injection system, the ignition
system, and catalytic converter. Also included may be
hoses, belts, connectors and other emission-related
assemblies.
Where a warrantable condition exists, Indmar Products
will repair your inboard engine at no cost to you,
including diagnosis, parts and labor.
Manufacturer’s Warranty Coverage
Select emission control parts from model year 2009 and
later are warranted for 3 years.
OME0502-15 Body.qxp_OM0502-05 Body.qxd 5/20/14 12:45 PM Page xv

xvi
Indmar Marine Engines
Owner’s Warranty Responsibilities
As the inboard engine owner, you are responsible for the
performance of the required maintenance listed in your
owner’s manual. Indmar Products recommends that you
retain all receipts covering maintenance on your inboard
engine, but Indmar Products cannot deny warranty solely
for the lack of receipts or your failure to ensure the per-
formance of all scheduled maintenance.
As the inboard engine owner, you should be aware that
Indmar Products may deny you warranty coverage if
your inboard engine or part has failed due to abuse, neg-
lect, improper maintenance or unapproved modifications.
The most common failures we see are due to unstable
or old fuel and lack of proper lubrication. Failures that are
attributed to old/unstable fuel or lack of lubrication are
not warrantable.
If your engine is operated in salt or brackish water, spe-
cial precautions, such as flushing the engine internally
and externally, are important. See the “Salt Water
Operation” information in Chapter 6. Failures due to
corrosion are not covered by the Indmar Limited
Warranty.
You are responsible for presenting your inboard engine
to an Indmar Products service center as soon as
a problem exists. The warranty repairs should be
completed in a reasonable amount of time, generally
within 30 days.
If you have any questions regarding your warranty rights
and responsibilities, you should contact Indmar
Customer Service at 1-901-353-9930.
OME0502-15 Body.qxp_OM0502-05 Body.qxd 5/20/14 12:45 PM Page xvi

Indmar Marine Engines
1-1
A new engine may use a more than normal
amount of engine oil before it is broken in.
Check your oil level hourly during the break-in
period. Once the engine is broken in, check
the oil level before each day’s use and more
often during sustained periods of high RPM or
heavily loaded operation. Marine usage is
different from automobile usage and oil
consumption is EXPECTED. Do not be alarmed
if you have to add oil between oil changes.
The following checks assumes your dealer has per-
formed the pre-delivery service and inspection. Complete
the following pre-start check list before starting your
engine for the first time. If you have questions about any
of these procedures, see your Indmar dealer for assis-
tance.
FIRST TIME OPERATION
1. Check the boat hull and/or garboard drain plug. Make
sure they are installed and secure. Check the boat
owner’s manual for additional pre-operation checks.
2. Make sure all engine drain plugs are installed. Refer
to Chapter 7, Storage and Winter Layup. There are
several drain locations:
Block – There are block drain points on both sides of
the engine. Some engines have brass drain plugs on
each side and some engines have knock sensors
installed in the block drain holes (Figure 1.2).
NOTICE
On the 6.0 and 6.2 Liter engines, removing the knock
sensor does NOT drain the block. Remove the caps
from the brass fittings on both sides of the engine to
drain water from the block.
Exhaust – The drain hose must be connected.
Transmission – The transmission oil cooler has one
drain plug. In addition, the Walters V-Drive and ZF
Ski-Vee (if equipped) have two drain plugs. See
Chapter 7 for instructions.
Chapter 1
FIRST TIME OPERATION AND BREAK-IN
OME0502-15 Body.qxp_OM0502-05 Body.qxd 5/20/14 12:45 PM Page 1-1

1-2
Indmar Marine Engines
Fresh Water Cooling System – If equipped, the heat
exchanger has four drain plugs; two for raw water and
two for coolant. Refer to Chapter 7,
Storage and
Winter Lay-up
.
Figure 1.2 – Anti Knock Sensor
3. Make sure your battery is fully charged and the
cables are clean and tight.
4. Check engine oil for correct level. Refer to Chapter 6,
Maintenance .
Figure 1.3 – Engine Dipstick Level
5. Check transmission oil level for correct level. Refer to
Chapter 6,
Maintenance .
6. If your engine is equipped with fresh water cooling,
check the expansion tank for the correct level. Refer
to Chapter 6,
Maintenance .
Do not mix antifreeze types.
7. Inspect engine mounts to make sure they aligned and
tight. Make sure that the propeller shaft coupler bolts
are tight.
Make sure the engine water intake is not
blocked by the trailer bunk. Blocked or
restricted water flow may damage the engine.
IND-A005A
1
ADD OPERATING RANGE SEE OWNERS MANUA
INDM-A003
OME0502-15 Body.qxp_OM0502-05 Body.qxd 5/20/14 12:45 PM Page 1-2
