iMM Server EN
iMM Server Manual

1.Get started
Get started
Commands are given in purple, e.g.: sudo reboot
Notice are given in orange: iMM server allows to set you only one door
intercom.
Tips and tricks are given in green: In list we can add and remove elements
manually
Caption:
Folder / Directory space at disc where files (pictures, films, videos) are saved.
Directory may contain further subdirectories.
iMM
application
aplikace sw application on video zone
Audio zone AZ zone equipped with music player (Squeezebox or other) and speakers
EPG electronic program guide
Ethernet LAN wire (cable) network
Floorplan FP foor plan of house or individual rooms
Full HD High image resolution (1920x1080px); detail and sharp image. Can be
achieved from BlueRay or TV program providers in HD quality.
DB DB see Streamer
Gyro control GO wireless mouse reacting to hand movement; serves to control the
menu on the video zone
iDM iNELS Designer and Manager – sw environment for iNELS
configuration
iMMClient video zones
iMMControl Center iMM CC iMM configuration administrator available via web interface
IP camera camera connected to system which transfer the image on Ethernet or
Wifi
Linux Operational system VZ on which iMM application runs
LT LT list of songs, videos or pictures
NFS NFS (Network File Systems) protocol for sharing files and folders
Playlist list of songs, videos or pictures
PT PT right button of Gyro control
Slideshow SS automatic presentation of pictures
Streamer satellite receiver that streams TV image top video zones
Stream is link (file) to place (on internet, in network, IP player or
Streamer) which provides image or sound
Storage a place on iMM server hard disk drive where files which all iMM system
users share are centrally saved
Video zone VZ zone equipped with iMM Client and TV (or another monitor).
WiFi wireless network
Gateway GW device Miele gateway or KNX gateway
Asterisk PBX software server side for IP calling by technology VOIP

Linux commands are inserted into the terminal to start using the keyboard shortcut. CTRL+ALT+T
Important basic Linux commands:
ifconfig - finding IP address of station/server, similar to IPCONFIG in Windows
mount - command for connection of certain device (CD-ROM, network drive, etc.)
umount - command for disconnection of certain device
man - command is used to format and display the man page for example. man mount
sudo shutdown now - command shut down device iMM Client/Serve from teminal
sudo reboot - command reboot device iMM Client/Serve from teminal
iMM services
Restart webserver iMM CC sudo /etc/init.d/imm-webadmin restart
Restart asterisk VOIP PBX sudo /etc/init.d/asterisk restart
Restart iMM server sudo /etc/init.d/imm_server stop
sudo /etc/init.d/imm_server start

1.1. Putting VZ in operation
1.1. Putting VZ in operation
a) Once you unpack VZ, let the device stabilize at room temperature.
b) Connect the cabling:
• 230V/19V adapter.
•LAN (iMM cannot be triggered without the presence of active network connection).
•Mouse and keyboard (connection via USB).
•Display device: TV or PC monitor by means of HDMI, or DisplayPort.
Audio output: 3.5 mm jack analogue or digital HDMI
c) Switch on by pressing the On/Off button on the front side of VZ.
d) When the system starts up, iMM application starts automatically (blue screen).

1.2. Basic setting
1.2. Basic setting
Setting in this chapter need not be carried out; it serves for potential problem solution and
general assistan e in the Linux system orientation. Majority of these settings is done already in
the production but one should get familiarized with them and go back to them if a problem occurs.
- Terminate Application by holding down the left mouse button (for longer than 5 seconds) on icon .
- You are on the Linux working area now.
- The application can be restarted by icon on the desktop.
1.2.1 Change of password
a) Enter sudo passwd in terminal, and confirm by Enter.
b) You will be asked to enter the original password (default is “imm123“), and confirm by Enter.
c) Then enter a new password, confirm by Enter, repeat the new password and confirm by Enter.
d) Close the terminal with the cross in the left upper corner.
No characters display when writing a password in terminal.
1.2.2 Resolution adaptation:
The application can be run on LCD, plasma TV or PC monitor with lower resolution than
Full_HD. If the resolution does not seem to be correct Application has to be re-installed. During
the installation, Application will recognize correct resolution of the display device, and will adapt
to it. The TV image should be adjusted to „Adapt“. First of all, the client part has to be
reinstalled. If the version is Server/Client, also the server part will have to be reinstalled.
1.2.3 Installation of new version
a) Download the package with new Application version to VZ desktop.
b) Click on the downloaded package with the right mouse button, and selection the
“Extrac Here” option.
c) A new folder named “iMM" will appear on the desktop.
d) Open the folder and by double click select the “install.sh.” file.
e) Select “Run in terminal” option in the dialogue window.
f) A window with terminal will open, requesting a password. As default the password is
“imm123”. If you changed the password, enter the password you chose and confirm by
Enter.
g) Proceed by the installation instructions in the terminal.

h) If the terminal requests installation of additional packages, confirm the “Y” question
and press Enter.
i) During the server part installation unpack the package on the desktop, same as with
` the client version, and install it in the same manner. (file: “install 12.04.sh)
j) When the installation is completed, terminal closes automatically, and then restarts
given VZ.
1.2.4 Restart and turning the system off
Pressing the „F9“ key will display the upper and lower system bar. Click on icon in the top right
corner.
When the menu unpacks, select the desired option: Shut Down... or Shut Down... and in new window
Restart
Pressing the button with symbol on the front VZ panel calls up a menu with options for
switching off and restart of VZ.
1.2.5 Setting static VZ IP address
All VZ are preset to get automatically IP address via DHCP. For stations it is however recommended to set
fixed IP address of adequate range of home network.
a) Call up the system bar using the “F9” key.
b) By the left mouse button click on the network icon in the upper bar.
c) Select the option “Edit Connections”.
d) A window opens in which select the network named "Wire connection 1", and click on the “Adapt” option.
e) In the next window select the bookmark “Setting IPv4”, and in the drop down menu select “Manual”.

f) A table activates where the "Add" option activates the line for address definition.
• enter IP address of relevant home network range in the “Address” column
• in the “network mask” column enter the mask network
• type the address of your router in the “Gate” column, and confirm by Enter
g) Type again your router's address in the “DNS servers” line or ipaddress your ISP.
h) Confirm by “Save..” key, enter the password and close all windows.
i) Press F9, click on the network connection icon by the left mouse button, and select “Disconnect”.
j) After disconnection click on the network connection icon n the upper system bar and, instead
of “Disconnect”, select “Wire connection 1".
Thus the connection restarts.
1.2.6 Setting the font (preset within the factory settings)
a) Call up the system bar using the “F9” key.
• Application#System tools#Preferences#Advanced settings
b) Select Theme#Window theme “use”(tick only) „Dust“

In the “Fonts“ bookmark set the fonts as follows:
• Default font: Myriad Pro 16
• Document font: Myriad Pro 16
• Monospace fonf: Myriad Pro 16
• Window title font: Myriad Pro 16
• “Close” after completion.
1.2.7 Update administration
The system searches own software update resources by means on the internet. To this
purpose there is update administrator which, when update is found, opens itself and alerts users
on the possibility of downloading new updates. It is recommended to maintain the system updated.
a) You can activate update administrator by yourselves and thus check the software
update status. By calling up system bar “F9”select
• Application#System tools#Administration#Update Manager
b) Click on “Install update” in the “Update Manager” window.
c) The system asks you to type your password; confirm by “„Authenticate”.
d) The system will inform you on the course of download and installation of new
updates.
e) After the completion the wizard closes automatically, and the system should be
restarted (see Chapter 1.2.4.).
Automatic update setting
You can set download and installation of update automatically without confirmation and any other
interventions of user...
a) Upload Ubuntu Software center, select Edit →Software sources from the menu… open the
tool for update and software resources setting and go to the Update card.
b) In the Ubuntu update select which updates will be installed (for automatic update we
recommend to enable only Important Securty updates).
c) In the Automatic update part then select how often the system will check the availability of
updates, and for direct installation of updates after the download tick the optionDownload
and install automaticaly.

2. Network File System (“NFS” hereinafter) configuration
2. Network File System configuration
NFS has to be set in case you use multiple VZ. If you use single VZ as iMM server, NFS need not be configured.

2.1 NFS configuration to VZ iMM Server
2.1 NFS configuration to VZ iMM Server
The following setting must take place physically on iMM Server.
a) Press the ”F9“ key to display the system bar, and open the web browser (default Firefox).
b) Type address http://localhost:8080 to open iMM CC.
c) Here, in the “Configuration” bookmark, set the CU unit IP address and the IP address of server
(of this station), of Sqeezebox server, path in Music folder in relevant lines.
d) Confirm the change by pressing “update” and close the browser.
e )Enter the command “sudo gedit /etc/exports“ in the terminal.
f) The terminal will request your password and file export opens in the text editor after confirming by Enter.
g) Add the below line at the end of the line:
/home/imm „IP address“/“mask network“(rw,sync,no_subtree_check)
(*in the quotation marks of the actual address)
example: /home/imm 10.10.3.0/255.255.255.0(rw,sync,no_subtree_check)
for server there is ALWAYS zero at the end of the IP address!
h) Save the changes in the file and close it.
g) Restart VZ.
Note:
The address of the Squeezebox server is the IP address of the device where the server for music
playback is installed. The path to the Music folder is a precisely pre-defined path to the folder in
the system, and must always have the following format: „/home/imm/Music“.The secondary and
licence key is generated in the production, and must not be deleted otherwise imm Client will not work.
Shared folders in Storage are located here:
/home/imm/Pictures : for keeping photographs and pictures
/home/imm/Music : for saving audio files
/home/imm/Video : for saving video files
/home/imm/Television : here links to TV streams are savedfor example VU+ or IP television.
/home/imm/Cameras : here configuration files of cameras connected to iMM system are stored

2.2 NFS configuration on iMM Client
2.1 NFS configuration on iMM Client
You need to do this part physically, separately for each iMM Client.
a) Press the ”F9“ key to display the system bar, and open the Firefox web browser.
b) Type the address http://localhost:8090 to open iMM CC.
c) Here, in the “Configuration” bookmark, type the iMM Server's IP address in the “Address of IMM server““ line
d) Confirm by pressing “update” and close the browser.
e) Enter the command “sudo gedit /etc/fstab“ in the terminal and confirm by Enter.
f) You will be asked to type your password; which you will confirm by Enter.
g) The fikle “fstab” will upload in the text editor. Add the below line to the end of the file:
ip_imm_server:/home/imm /mnt/nfs nfsver=3,bg, _netdev, nolock, hard, rw, user 0 0
h) Save the file by pressing CTRL+S and terminate the application by CTRL+X.
i) Now you need to restart iMM Client; this will map automatically the needed folders from the server.
i) When the system starts up, terminate the iMM Application, and in folder “Storage” delete the following folders
(Video, Music, Television, Cameras, Pictures). Then open the terminal and enter the following commands:
sudo ln -s /mnt/nfs/Music /home/imm/Music (command for connection to Music storage)
sudo ln -s /mnt/nfs/Video /home/imm/Video (command for connection to Video storage)
sudo ln -s /mnt/nfs/Television /home/imm/Television (command for connection to Television storage)
sudo ln -s /mnt/nfs/Cameras /home/imm/Cameras (command for connection to Cameras)
sudo ln -s /mnt/nfs/Pictures /home/imm/Pictures (command for connection to Pictures)
k) One all the above commands are entered, end the terminal and restart the iMM application by
opening the icon on the desktop.

2.3 Connection of external hard disk drives
2.3 Connection of external hard disk drives
Server
Setiings fstab
In terminal: “sudo gedit /etc/fstab “
Add a new line to the end:
“UUID=F474B7AA74B76DCC /media/My\040Passport ntfs-3g
defaults,nosuid,nodev,nobootwait,locale=cs_CZ.UTF-8 0 0“
Hard disk drive identifier is in red; in bold is the name of hard disk drive; you can find it out by the following
command: “sudo blkid“ which is typed behind UUID=XXXXXXXXXXXXXXX in a line which ends with ntfs.
The HDD name can be found behind the legend. LABEL=XXXXXXXXXXXXXXX
Example: In terminal: „sudo blkid“ the following appears:
/dev/sda1: UUID="453a8d4f-d4fb-4c4e-8de5-ef7666e689d1" TYPE="ext4" - (iMM client's hard disk drive)
/dev/sda5: UUID="0a49bd69-20a7-490c-97db-6781bd794837" TYPE="swap - (iMM client's mechanics)
/dev/sdb1: LABEL="My Passport" UUID="F474B7AA74B76DCC" TYPE="ntfs" - External hard disk drive)
Note: Instead of the space in the name of the hard disk drive (if there is any)
you have to add „\040„
Setting exports
Do terminálu: „sudo gedit /etc/exports“
Na konci textu přidáte nový řádek:
“/media/My\040Passport 192.168.88.0/255.255.255.0(rw,fsid=0,no_root_squash,no_subtree_check,sync)“
Rozsah sítě se liší podle toho na jaké síti je iMM server zapojen… (192.168.88.0) Nakonec tohoto rozsahu
píšete nulu.
Client
fstab setting
In terminal: “sudo gedit /etc/fstab “
Add a new line to the end:
IPADDRESS:/media/My\040Passport /media/My\040Passport / nfs nfsvers=3,rw,hard,intr 0 0
Note: “My\040Passport” is the name of device of concrete hard drive disk which has to be precisely
defined in the client's fstab (same as in fstab on the server).

2.4 Sharing external storage – external HDD
2.4 Sharing external storage – external HDD
Server settings:
a) Set fstab in the same manner like fstab settings of Server 2.3.
b) Set Export in the same manner like the Server 2.3 Export settings.
c) Restart server.
d) Now delete system folders via terminal by entering the below commands:
rm -r /home/imm/Video 2>/dev/null
rm -r /home/imm/Pictures 2>/dev/null
rm -r /home/imm/Television 2>/dev/null
rm -r /home/imm/Cameras 2>/dev/null
e) In the terminal, go to Create “iMM" folder on HDD.
Notice!: The name of the hard disk "iMM HDD“ will always differ depending on how you
name your concrete HDD.
Ex.: If the name of your HDD is, for instance: “Verbatim“ the names in the below links
change to: (mkdir /media/Verbatim/iMM)
mkdir /media/iMM-HDD/iMM
mkdir /media/iMM-HDD/iMM/Video 2>/dev/null
mkdir /media/iMM-HDD/iMM/Video/Recording 2>/dev/null
mkdir /media/iMM-HDD/iMM/Video/Cameras 2>/dev/null
mkdir -m 0777 /media/iMM-HDD/iMM/Pictures 2>/dev/null
mkdir /media/iMM-HDD/iMM/Television 2>/dev/null
mkdir /media/iMM-HDD/iMM/Music 2>/dev/null
mkdir /media/iMM-HDD/iMM/Cameras 2>/dev/null
f) Then create the below system folders in the terminal:
ln -s /media/iMM-HDD/iMM/Music/ Music
ln -s /media/iMM-HDD/iMM/Video/ Video
ln -s /media/iMM-HDD/iMM/Pictures/ Pictures
ln -s /media/iMM-HDD/iMM/Television/ Television
ln -s /media/iMM-HDD/iMM/Music/ Music
ln -s /media/iMM-HDD/iMM/Cameras/ Cameras
g) Then you can already upload your data!

Client
a) Set fstab in the same manner like fstab Client 2.3. settings.
b) Then create the below symbolic links in the terminal:
ln -s /media/iMM-HDD/iMM/Music/ Music
ln -s /media/iMM-HDD/iMM/Video/ Video
ln -s /media/iMM-HDD/iMM/Pictures/ Pictures
ln -s /media/iMM-HDD/iMM/Television/ Television
ln -s /media/iMM-HDD/iMM/Cameras/ Cameras
Note: For visibility of HDD in folders type the following command in the terminal:
for path in Music Video Pictures; do [ ! -L ~/"$path/#EXTERNAL" ] && ln -s /media ~/"$path/#EXTERNAL"; done

2.5 Setting shared storage NAS Synology
2.5 Setting shared storage NAS Synology
Connect to NAS web interface by typing the IP address of the NAS device in the web browser.
Enable NFS service:
Open – Control panel > Win/Mac/NFS > NFS service > Win/Mac/NFS > Enable NFS and click on use
Enable SSH service:
Open – Control panel > Terminal > Enable SSH Service
Open “Putty” tool for remote control on your PC, type in NAS IP address you want to share. Log in as
„root“ by typing: root and password. You are remotely connected to NAS now.
Then type:
mkdir /volume1/iMM
mkdir /volume1/iMM/Video
mkdir /volume1/iMM/Video/Recording
mkdir /volume1/iMM/Video/Cameras
mkdir /volume1/iMM/Pictures
mkdir /volume1/iMM/Television
mkdir /volume1/iMM/Music
mkdir /volume1/iMM/Cameras
whilst volume 1 is a work folder (disk) intended for sharing.
You can find out The name of the folder by command cat /etc/fstab If the name differs, you have to change the
names
in the list of commands.
After creation of shared folders change authorisation to these folders by command:
chmod -R 777 /volume1/iMM/
Next command will export shared folders for access from other devices vi /etc/exports
Press enter and add the following line to the last line (if there is no last line, add it on the first one):
/volume1/iMM 192.168.88.0/255.255.255.0(rw,sync,no_subtree_check,no_root_squash)
You will do that by pressing letter “i” which enables typing, and copy the line, or write it manually;
after typing press Esc and write letters “wq”.
In case of any doubts use the below manual: Manual.
Setting of NAS sharing to client
Type the following command in terminal: “sudo nano /etc/fstab“
A window opens, at the end of which type the below line:
192.168.88.200:/volume1/iMM /mnt/nas nfs nfsvers=3, bg, _netdev, nolock, hard, rw, user 0 0
There is NAS device IP at the beginning of the line. (192.168.88.200)

Open the terminal and create symbolic links:
ln -s /mnt/nas/Music/ Music
ln -s /mnt/nas/Video/ Video
ln -s /mnt/nas/Pictures/ Pictures
ln -s /mnt/nas/Television/ Television
ln -s /mnt/nas/Cameras/ Cameras
Then create a symbolic line for sharing by putting the following command in the terminal:
for path in Music Video Pictures do [ ! -L ~/"$path/#EXTERNAL" ] && ln -s /media ~/"$path/#EXTERNAL" done
