iNetVu Tachyon CI1300 User manual

Tachyon and the iNetVu® 7000 Series Controller
1-877-iNetVu6
www.c-comsat.com
Revision 3.0
May 25, 2015
Tachyon CI1300

INETVU® MOBILE SYSTEM QUICK START – TACHYON
C-COM Satellite Systems Inc. Page 2
This page is intentionally left blank.

INETVU® MOBILE SYSTEM QUICK START – TACHYON
C-COM Satellite Systems Inc. Page 3
1.1 Safety and Warning Information
For your safety and protection the following important safety information should be reviewed before
installation, configuration and use of the iNetVu Satellite Platform System and Modem equipment. It is
also recommended to read the manual in its entirety prior to setup and operation.
Warning: The following general safety precautions must be observed during all phases of setup and
operation of this equipment. Failure to comply with these precautions or with specific warnings
elsewhere in this documentation violates safety standards of design, manufacture and intended use of
the equipment. C-COM Satellites Systems Inc. assumes no liability for the customer’s failure to comply
with these requirements.
This situation or practice might result in property or
equipment damage. Ensure Sensor and Motor cables are
connected prior to powering on 7000 Series Controller. Do not
connect or disconnect cables once controller has been
powered on. It is recommended that controller is properly
grounded at all times.

INETVU® MOBILE SYSTEM QUICK START – TACHYON
C-COM Satellite Systems Inc. Page 4
1.2 System Overview
The iNetVu™Mobile Satellite Internet system is an automatic scanner, polarizer and beam positioning
system for a foldable two-way satellite antenna. It has been designed to automatically find and acquire
the satellite beam and the position based on both a GPS position reading as well as other positioning
parameters. It is targeted for mobile users that require high speed Internet access in remote locations
where cable and DSL do not exist. It provides two-way, high-speed data communications over satellite.
iNetVu™ empowers mobile users with the ability to stop anywhere there is Satellite coverage and
access Internet at broadband speeds. The iNetVu™ Mobile application consists of the iNetVu™ Mobile
software 7000 software (for the 7000 Series Controller)
iNetVu™ Mobile Application
Key Features:
•Automatic re-peak on satellite upon signal loss.
•Automatic dish stow if Mobile Platform moves
•If the vehicle is moved before the dish is stowed, the dish will sense movement and will
automatically begin stowing itself.
•The dish will not transmit unless it is pointed adequately to meet cross-polarization
specifications.
•The system will automatically find any satellite from any point on the Earth within its coverage
area.
•Displays comprehensive information about the satellite, dish, motors, GPS, compass, control
box, and modem.
•Finds the satellite, peaks the signal strength and selects the optimal path to perform the selected
satellite, allowing the customer’s computer to be online as soon as possible
•Simple to install, configure and operate.

INETVU® MOBILE SYSTEM QUICK START – TACHYON
C-COM Satellite Systems Inc. Page 5
1.3 Pre-Configuration Check List
Prior to installing IMS and configuring your system, verify that you are using the minimum
requirements listed below.
Note: Please contact C-COM if you require more information about modem compatibility as these
may change without further notice.
Service Type
Modem Firmware
IMS 7000 S/W
IMS F/W
Interface
Tachyon CI1300/ RMG
1.5.3.0f+
7.2.2+
7.2.2.0+
SNMP
Note: Installed Software and Controller Firmware versions MUST be identical for normal operation
IP Address of Satellite Modem (if using SNMP Interface)
Satellite Name and Coordinate
Transmit and Receive Polarization (Horizontal/Vertical)
COM port users must use a standard male to female DB9 cable with the NULL Modem Adapter
attached to the controller end of the cable.
It is highly beneficial to use the DVB search in the controller when auto-acquiring with the
supported tachyon modems. Any DVB-S tuner on the target satellite could be utilized. If the
tachyon modem is setup for a DVB-S frequency, the controller could be configured to auto-
acquire the same frequency, along with the symbol and code rate. Searching using the RF
search mechanism may take more then five (5) minutes due to the extended response time from
the modem.
It is beneficial to have the service provider disable the 1 hour reboot timer in the Tachyon modem
to decrease the chance of having the modem reboot while the system is searching for satellite.

INETVU® MOBILE SYSTEM QUICK START – TACHYON
C-COM Satellite Systems Inc. Page 6
1.4 2.0 System Wiring with Tachyon Service
1.5 2.1 USB Interface Connection – System Wiring
1. USB Interface System Wiring Diagram for Tachyon CI 1300 IDU
RX
GPS
Antenna
TX
Sensor
Cable
USB Cable
SAT OUT
RX IN
SAT IN
RX OUT
Tachyon CI 1300 IDU
Motor
Cable
IP: A.B.C.D
SUB: 255.X.Y.Z
X-OVER
NETWORK
CABLE
90 - 264 VAC
!
Motor Control Cable
Sensor Cable
RG6 Coaxial Cable
USB Cable
Network Cable
Power Cable
With a USB Connection from a PC to the controller, the software application may be used to configure
the controller, as well as to perform automatic satellite acquisition, and stow functions. If the user
wishes not to use a PC, the controller is fully configurable from the front screen.
IP: A.B.C.D+1
SUB: 255.X.Y.Z
GW: A.B.C.D
*Ground
protection
24 VDC
Input
()

INETVU® MOBILE SYSTEM QUICK START – TACHYON
C-COM Satellite Systems Inc. Page 7
1.6 Network Interface Connection – System Wiring
2. Network Interface System Wiring Diagram for Tachyon Service
RX
GPS
Antenna
TX
Sensor
Cable
SAT OUT
RX IN
SAT IN
RX OUT
Tachyon CI 1300 IDU
Motor
Cable
IP: A.B.C.D
SUB: 255.X.Y.Z
X-OVER
NETWORK
CABLE
90 - 264 VAC
!
Motor Control Cable
Sensor Cable
RG6 Coaxial Cable
USB Cable
Network Cable
Power Cable
With a USB Connection from a PC to the controller, the software application must be used to configure
the controller, as well as to perform automatic satellite acquisition, and stow functions. If the user
wishes not to use a PC, the controller is fully configurable from the front screen.
IP: A.B.C.D+1
SUB: 255.X.Y.Z
GW: A.B.C.D
STRAIGHT
NETWORK
CABLE
IP: A.B.C.D+2
SUB: 255.X.Y.Z
GW: A.B.C.D
*Ground
protection
24 VDC
Input

INETVU® MOBILE SYSTEM QUICK START – TACHYON
C-COM Satellite Systems Inc. Page 8
1.7 Initial Controller Configuration and Verification Test with Tachyon
Once the system wiring is complete and the network configuration on your PC is configured, you are
required to configure the system parameters for the following before satellite acquisition:
Communication Method between IMS and iNetVu® Controller.
Satellite Name, Longitude, and Transmit Polarization
Modem/VSAT Communication Parameters
The 7000 Controller may be configured via the Software Application / Web Interface / LCD interface.
Only one is necessary for complete configuration.
iNetVu® Software Application (preferred method)
First time user should use the iNetVu Wizard which is imbedded into the iNetVu software for
guidance in configuring your system.
USB Connection
Ethernet Connection
iNetVu® Web Interface
Ethernet Connection
iNetVu® 7000 Front Panel
USB drivers must be installed for USB connection method. The configuration process is only required to
be done once as long there are no change in satellite, service, modem, or platform parameters.

INETVU® MOBILE SYSTEM QUICK START – TACHYON
C-COM Satellite Systems Inc. Page 9
1.8 Tips and Recommendations
The user has the option to search for satellite using the following methods depending on what is
available to you:
DVB search and or Reference Satellite Using a Known DVB Carrier
RF search
Beacon receiver
The recommended method of satellite search is DVB using DVB-S/S2, followed by DVB
reference satellite search with RF search being the last option of choice. If using RF search, a
valid RF frequency must be entered and is highly recommended; this can be the service
frequency or any other valid RF frequency from a known carrier (preferably taken from Modem
parameters)
Search Method
DVB or RF search are selectable from the drop down window. DVB will search directly on DVB-
S1 or DVB-S2 carrier and lock on it. This is the option of choice to use when searching for
satellite. RF option will allow the user to base satellite searching and peaking strictly on RF
instead of DVB.
This method of searching could be used when the user is having a hard time finding the
transponder data for a specific satellite, or if no transponder data exists. The controller will then
peak on the modem signal when the satellite is found. RF search should be used as a last resort
after DVB and or DVB with reference satellite because search time is much longer.
The Reference Satellite option is useful when the user cannot find a DVB transponder on the
desired target satellite. The user may select a reference satellite with a known DVB
Transponder. The iNetVu®System will lock onto the reference satellite, and then pivot from that
point to the desired target satellite, and peak on the modem signal. Does not work if search
method selected is RF Search.
Beacon Receiver is used to lock onto a satellite without the use of a modem.
Compass Issues?
If you are in an area where there is magnetic interference or the compass readings are incorrect, it is
recommended to select Full Search which will also override the compass.
Full Search
Override Compass
Selecting Full Search will auto select Override Compass and set the AZ Search Window to 180 or
any other value depending on the Platform type. This value can be overridden to a more desirable
range. Override Compass can be selected without selecting Full Search but this does not hold
true for the vice-versa.
Refer to Controller User Manual for more information on using the iNetVu Controller and
options associated with your system.

INETVU® MOBILE SYSTEM QUICK START – TACHYON
C-COM Satellite Systems Inc. Page 10
1.9 Software Setup and Initial Configuration Procedure with Tachyon
Service
1. If you are using the network interface to communicate with the 7000 Controller, set the
PC/Notebook to the same network as the 7000 Controller. (If you are using the USB interface,
you may skip to the Software Installation)
2. Open Network and Sharing Center\Network
Connections, right-click your network card, and select
Properties.
3. Select Internet Protocol Version 4 (TCP/IPv4) and click
Properties.
4. Select Use the following IP address.
Set your PC to the same subnet as the 7000 Controller.
IP Address: A.B.C.D+2
Subnet Mask: 255.255.255.0
Gateway: A.B.C.D (Modem/Router IP)
The Gateway is usually the Router IP address. If no router is used, it
is usually the VSAT Modem IP Address.
Set the DNS IP Addresses if required.

INETVU® MOBILE SYSTEM QUICK START – TACHYON
C-COM Satellite Systems Inc. Page 11
5. Set the 7000 Controller to the same network as the PC and VSAT Modem.
*Note: The controller IP should be set in the controller through the LCD interface prior to entering
it into the software tool for proper PC to Controller Communication through network interface.
(USB Interface users may skip this step)
To Configure the IP address on the controller, you must navigate to the CONF2 menu using the
LCD Interface. (Default password “password”)
a. Navigate to the “IP” menu and press the “ENTER” button.
b. Press the ‘↑’ button to allow for modification on the C_IP field and set the IP address
of the controller. For example, if the Modem/Router IP is 192.168.0.1 then the
controller IP could be set to 192.168.0.2. Press the “ENTER” button once the change
is complete.
c. Press the “Exit” button twice to exit out of the configuration menu. When prompted if
you would like to save configuration, press the ‘↑’ button to select “Y” (yes) and press
“Enter”.
d. Click the “reset” button on the controller.
You may view the 7000 Controller IP from the LCD interface via – MONITOR IP(C_IP)
S2 MB EL AZ PL GP
C1 C2 C3 DS SG IP
SR
C_IP: 192.168.000.002
M_IP: 192.168.000.001

INETVU® MOBILE SYSTEM QUICK START – TACHYON
C-COM Satellite Systems Inc. Page 12
1.10 Software Installation and Configuration
Please Note: Do not connect the Controller via USB until the drivers and software have
been installed
1. If you are installing from the USB flash drive or have downloaded from the C-COM FTP/KB, run
the iNetVu7000Setup.exe file.
2. Install the iNetVu 7000 Software and close when complete.

INETVU® MOBILE SYSTEM QUICK START – TACHYON
C-COM Satellite Systems Inc. Page 13
3. Install the FTDI USB Drivers and iNetVu USB Drivers. Both are required.
Click “Extract”
Click “Next” Click “Finish”
4. Continue through the USB Driver Installation Wizard.
Click “Next” Click “Finish”

INETVU® MOBILE SYSTEM QUICK START – TACHYON
C-COM Satellite Systems Inc. Page 14
5. Now that the drivers and software package has been installed, connect the iNetVu 7000
Controller via USB to your PC.
6. Windows XP users will have to follow the new hardware wizard and let windows automatically
install the drivers.
Select “No, not this time” Select “Install the software automatically”
Click “Continue Anyway” Click “Finish”
7. Windows Vista and 7 users, the drivers should install automatically without any further user
action.
8. You have successfully installed the 7000 iNetVu Drivers and Software.

INETVU® MOBILE SYSTEM QUICK START – TACHYON
C-COM Satellite Systems Inc. Page 15
1.11 iNetVu Setup Wizard
1. The first screen you will see is the new iNetVu Setup Wizard. You can choose to continue using
the wizard or click NO to proceed to the iNetVu Mobile 7000 software.
NOTE: It is recommended that you continue to the iNetVu Setup Wizard and confirm all required
information is correct. Please select “Do not show this message again” so this pop-up will not
appear after you have completed the initial Controller setup.
2. If the controller firmware does not match you will be prompted to update.

INETVU® MOBILE SYSTEM QUICK START – TACHYON
C-COM Satellite Systems Inc. Page 16
3. Follow the on screen instructions to update the controller firmware. Once complete the wizard
will resume.
4. You may wish to continue through the wizard to complete the controller configuration or verify the
settings. You can switch to the iNetVu software at any time by right clicking and selecting
Controls.

INETVU® MOBILE SYSTEM QUICK START – TACHYON
C-COM Satellite Systems Inc. Page 17
5. Configure the Platform Type, Version and Serial No. If no changes are needed press “Next” to
continue.
Platform
Type: Antenna Model
Version: Antenna Version
Serial No: Antenna Serial Number
It is important that this information be correct or will result in undesired antenna behavior.

INETVU® MOBILE SYSTEM QUICK START – TACHYON
C-COM Satellite Systems Inc. Page 18
6. Complete the Service Information section, set to Tachyon as the Service Type. Select the
Interface method you wish to use and configure accordingly. Mouse over each selection for a
detailed description. After changes have been made please click “Next” to continue.
Service Information
Type: Tachyon
Interface: SNMP or COM (how the Controller will communicate with the Modem)
Modem Configuration
IP Address: Enter the Modem IP Address
Controller TCP/IP Settings
IP Address: Controller IP Address
Subnet Mask: Controller Subnet Mask
Default Gateway: Controller Gateway (Modem or Router)

INETVU® MOBILE SYSTEM QUICK START – TACHYON
C-COM Satellite Systems Inc. Page 19
7. Complete the Satellite Parameters, DVB Settings and Search Method. Mouse over each
selection for a detailed description. Click Finish when complete.
Satellite Parameters:
Longitude: Satellite you will be searching on
RX: Receive Polarity (Vertical or Horizontal)
LNB Power: Select when controller will be powering the LNB, otherwise disable
LNB LO: LNB LO Freq. (GHz)
DVB Settings:
Transponder No: Select a Transponder No. to save configuration to
DVB Type: Carrier Type (DVB-S1 or DVB-S2 ACM)
Frequency: L-Band Frequency (KHz)
Symbol Rate: Symbol Rate (Ksps)
FEC: Code Rate
Search Method:
DVB Search: DVB will search directly on DVB-S1 or DVB-S2 carrier and lock on it. For user
wishing to use the DVB Search Method the DVB Settings are required for satellite
acquisition. Please ask your service provider or NOC for a valid DVB Carrier.
RF Search: RF will allow the user to base satellite searching and peaking strictly on RF
instead of DVB. The controller will then peak on the modem signal when the
satellite is found. Use if you have no DVB carrier.
Duplicate the settings for all satellites: Selecting this will duplicate parameters across all Satellite No. 0 ~ 4

INETVU® MOBILE SYSTEM QUICK START – TACHYON
C-COM Satellite Systems Inc. Page 20
8. Once completed you will be able to save changes by selecting Yes, or select No to return to the
previous screen to make additional changes.
9. Congratulations you have configured your iNetVu Controller. You can now find satellite by
pressing the FIND SAT button from the front panel or by launching the iNetvu Software.
*For more detailed information on the iNetVu® 7000 Controller Software, refer to the iNetVu® 7000
Controller Manual
