Operation Manual of Dive Watch Series
Type B
Comparison Table of Function Adjustment
Do NOT operate any button when swimming or diving under water.
In case of existence of water fog or drop on the interior surface of the looking
glass, please contact the authorized maintenance center for maintenance to
avoid corrosion to internal electronic components.
Clean the surface with a soft cloth and clean water instead of chemicals(esp.
soap water); otherwise,the rubberseal inside the case may be damaged.
Long-duration use of cold-light LCD may take much power.
Do avoid strong shock (exc. anti-shock series watches). The electronic watch
can bear common shock. However, it may be damaged if subject to rough use
or dropped to a hard surface.
Do NOT expose the watch to environments which is too hot or cold.
Do NOT expose the watch to strong electric field or environment with high
radio frequency.To avoid degraded service life, do not illuminate the EL lamp
more than five times on each day.
The cold-light LCD is unapparent if the watch is exposed to sunlight.
The monthly error is <｡40 sec. at normal temperature of 5 to 35｡(ranging
within international standard allowance).
Water-resistance depth is up to 10m.
