Demoboard BTT3018EJ
User Manual V1.0
About this document
Scope and purpose
This document describes how to use the Demoboard BTT3018EJ.
Intended audience
Engineers, hobbyists and students who want to switch 24V loads in their Arduino/XMC1100 kit projects.
Table of Contents
About this document......................................................................................................................... 1
Table of Contents.............................................................................................................................. 1
1 Getting Started................................................................................................................ 2
1.1 BTT3018EJ Shield overview....................................................................................................................2
1.2 Key features.............................................................................................................................................2
1.3 Demoboard package contents ...............................................................................................................2
1.4 Typical connection..................................................................................................................................3
With Arduino Shield ...........................................................................................................................3
Without Arduino shield (For Oscilloscope monitoring) ....................................................................3
2 Demoboard configuration ................................................................................................ 4
2.1 Status pin connection .............................................................................................................................4
2.2 Slew Rate pin configuration....................................................................................................................4
3 Software utilisation ......................................................................................................... 4
3.1 Installation...............................................................................................................................................4
3.2 Features ...................................................................................................................................................5
Monitoring Panel................................................................................................................................5
Control Panel......................................................................................................................................5
Demoboard configuration panel .......................................................................................................6
4 Board connectors description ........................................................................................... 7
4.1 Power connectors ...................................................................................................................................7
4.2 ARDUINO/XMC1100 connectors..............................................................................................................7
Connector SV1....................................................................................................................................7
Connector SV2....................................................................................................................................7
Connector SV3....................................................................................................................................8
Connector SV4....................................................................................................................................8
4.3 Test points ...............................................................................................................................................8
5 Schematic ....................................................................................................................... 9
6 B.O.M.............................................................................................................................10
7 Board Layout..................................................................................................................11
7.1 TOP.........................................................................................................................................................11
7.2 BOTTOM.................................................................................................................................................11
7.3 MECHANICAL VIEW ................................................................................................................................12

User Manual 2 <Revision 1.0>
2017-11-
22
Demoboard BTT3018EJ User Manual
1 Getting Started
1.1 BTT3018EJ Shield overview
The 24V low-side switch demoboard with one BTT3018EJ from Infineon Technologies is a flexible evaluation
board dedicated to drive all kinds of loads. This demoboard is compatible with Arduino UNO shield and Infineon
XMC1100.
The demoboard can be controlled either with the general logic I/O-ports of a microcontroller or with a PWM.
It includes typical schematic to control the BTT3018EJ. This shield offers a quick evaluation of the product, the
“Status” latch functionality, the “SRP” functionality, and all protections, e.g. “Over temperature shut down”.
WARNING:Please refer to BTT3018EJ Datasheet for details on functionalities and parameters values. This user
manual does not replace the datasheet and user must be aware of limitations before turning on any supply.
The demoboard can be easily connected to any Arduino UNO board or Infineon XMC1100 via headers.
Code and graphic interface is available for Arduino UNO.
No code/interface is available for XMC1100, but XMC1100 can be easily programmed through Arduino IDE:
please check the following link for details: https://github.com/Infineon/XMC-for-Arduino
1.2 Key features
o Demoboard is able to provide continuous current load (36V- 20A) between V_OUT and GND.
o A green LED will turn ON when logic supply voltage is connected and ON.
o Output voltage, Input logic, Status and SRP can be measured externaly with test points.
o Output voltage, Input logic, Status can be monitored with the Arduino Interface.
1.3 Demoboard package contents
In the zip package must be the following:
o Demoboard_BTT3018EJ_User_Manual_Vx.x
o Demoboard_BTT3018EJ.exe
o Demoboard_BTT3018EJ.ino
GND
V_IN V_OUT
BTT3018EJ
Arduino connector
V_DD
Arduino connector

User Manual 3 <Revision 1.0>
2017-11-
22
Demoboard BTT3018EJ User Manual
LOAD
POWER Supply
24V
1.4 Typical connection
With Arduino Shield
Without Arduino shield (For Oscilloscope monitoring)
BOTTOM ON TOP

User Manual 4 <Revision 1.0>
2017-11-
22
Demoboard BTT3018EJ User Manual
2 Demoboard configuration
o If an Arduino board is used, configuration needs to be set in the software. Please refer to 3.2.3
Demoboard configuration panel.
2.1 Status pin connection
o BTT3018EJ can be controlled with pin pulled-up to Vdd to allow fault monitoring.
o If no diagnosis is needed, the Status pin can be connected to the Input pin
o Use Jumper to choose configuration.
2.2 Slew Rate pin configuration
o Use jumper to choose SRP resistor value from GND to 160kΩ. Values of SMD resistors on the
boards are the same that are characterized in the Datasheet (GND, 2.2kΩ, 5.8kΩ, 10kΩ, 58kΩ,
160kΩ). Use jumper accordingly.
3 Software utilisation
o Software “Demoboard_BTT3018EJ.exe” is a GUI for Windows OS, used with the Arduino UNO
board with the dedicated code “Demoboard_BTT3018EJ.ino”.
3.1 Installation
o User has to install the Arduino IDE software to allow communication between computer and
Arduino board.
o Once the program is installed, connect the Arduino shield. Double-click the
“Demoboard_BTT3018EJ.ino” Arduino code and upload it.
o When the code is correctly uploaded/ installed, the user can plug the demoboard on the Arduino
shield. The green LED must turn on, meaning that BTT3018EJ logic is supplied.
o Then, launch “Demoboard_BTT3018EJ.exe”.
 Click on “Ports” to select the right communication port on your Arduino board.
 Click on “Start” to start the system.
• If it’s not working, check your port name.
Rstatus SMD resistor
Jumper position for
Vstatus pulled-up
Jumper position for
Vstatus=Vin
RSRP=GND
RSRP=2.2kΩ
RSRP=5.8kΩ
RSRP=10kΩ
RSRP=58kΩ
RSRP=160kΩ

User Manual 5 <Revision 1.0>
2017-11-
22
Demoboard BTT3018EJ User Manual
• Port name is usually called “COM X”, where “X” is a number.
 If installation is done and operational, user can see text transmitted by the Arduino board
below the port selector.
o When user wants to turn OFF the application, user has to click on “Stop” before closing the
windows (none application can be shut down before closing the communication with the
Arduino board).
 WARNING: when application is stopped, it has to be shut down then restarted again.
3.2 Features
Monitoring Panel
o BTT3018EJ color control has three possible states: . If FA, please stop and close the
program, then restart it again.
o If BTT3018EJ operates normally, Vstatus should appear in green.
o If BTT3018EJ is latched, status appears in red. Status needs to be reset by 5V pull-up if not
connected to Input.
Control Panel
o Button ON and OFF allow user to switch ON and OFF BTT3018EJ in continuous mode.
o Button “Pulse” creates a manageable pulse on each BTT3018EJ.
 User can create a pulse with period control
 The timing can be from 1ms to 1000s in logarithmic mode.
o Button PWM allows user to manage dutycyle and frequency.
Start/Stop the
connection
µ
C
Communication
statement
BTT3018EJ color
control
Vstatus control
and Vout measure

User Manual 6 <Revision 1.0>
2017-11-
22
Demoboard BTT3018EJ User Manual
Demoboard configuration panel
o To use the Vout measure, user needs to go to “demoboard configuration panel” to set the
monitoring resistors. It is a simple voltage divider that should be designed to protect the Arduino
microprocessor in current and voltage. Resistors can be connected in the “Tulip” connectors
without soldering. Examples of values:
 Rmonitor1 = 10kΩ
 Rmonitor2 = 1kΩ
o Vstatus can be in the pull up mode or can be connected to Vin, user needs to go to “demoboard
configuration panel” to set the right statement.
Set the monitoring resistor
then apply to make Vout
enabled
Click on ON/OFF to change
the status configuration
(Red: pulled-up to Vdd)
Turn ON/OFF
Continuous mode
The pulse mode
The PWM mode

User Manual 7 <Revision 1.0>
2017-11-
22
Demoboard BTT3018EJ User Manual
4 Board connectors description
4.1 Power connectors
Name Connector Type Description
JOUT P1 Power supply OUT
JGND P2 Ground power Ground
JVIN P3 Power input BTT3018EJ INPUT pin control to turn ON/OFF
JVDD P4 Power input 5V to provide logic supply Vdd pin (Do not use if shield is connected to the
Arduino board)
4.2 ARDUINO/XMC1100 connectors
Connector SV1
Name Pin Type Description
1 No connected
2 No connected
3 No connected
Gnd 4 Digital Ground Ground
5 No connected
6 Digital Input
IN 7 Digital Input To turn the device ON/OFF
8 Digital Input
STATUS 9 Digital Input To monitor the part status
10 Not connected
Connector SV2
Name Pin Type Description
- 1 No connected
- 2 No connected
- 3 No connected
- 4 No connected
- 5 No connected
- 6 No connected
- 7 No connected
- 8 No connected

User Manual 8 <Revision 1.0>
2017-11-
22
Demoboard BTT3018EJ User Manual
Connector SV3
Name Pin Type Description
- 1 No connected -
- 2 No connected -
- 3 No connected -
- 4 No connected -
- 5 No connected -
Gnd 6 Digital Ground Ground
Gnd 7 Digital Ground Ground
- 8 No connected -
Connector SV4
Name Pin Type Description
1 Analog input
Adc 2 Analog input Analog measurement for V_ds
3 Analog input
4 Analog input
5 No connected
6 No connected
4.3 Test points
Name Pin Type Description
IN 1 Digital Input Pin activation for BTT3018EJ
VDD 2 Logic SUPPLY Pin to provide supply to BTT3018EJ Logic
STATUS 3 Digital Input Pin to monitor the part status
OUT 4 Analog Input Pin to monitor Vout
GND 5 Analog input Pin to monitor GND

User Manual 9 <Revision 1.0>
2017-11-
22
Demoboard BTT3018EJ User Manual
5 Schematic

User Manual 10 <Revision 1.0>
2017-11-
22
Demoboard BTT3018EJ User Manual
6 B.O.M.
Item Qty Ref Value Package Ordering code
1 1 C1 100nF CMS0603
2 1 D3 Green led UTSS RS: 125-4513
3 5 GND POINT Test Point RS:262-2179
4 OUT POINT Test Point RS:262-2185
5 IN POINT Test Point RS:262-2185
6 ST POINT Test Point RS:262-2040
7 VDD POINT Test Point RS:262-2185
8 6 JP2 Pin header 2pins RS:251-8086
9 JP3 Pin header 2pins RS:251-8086
10 JP4 Pin header 2pins RS:251-8086
11 JP5 Pin header 2pins RS:251-8086
12 JP6 Pin header 2pins RS:251-8086
13 JP7 Pin header 2pins RS:251-8086
14 1 JP8 Pin header 3pins RS:251-8092
15 2 * Jumpers 2pins for pin headers RS:251-8503
16 4 CON OUT Red Borne Hirschmann 60V RS:738-547
17 CON GND Black Borne Hirschmann 60V RS:738-531
18 CON IN Red Borne Hirschmann 60V RS:738-547
19 CON VDD Red Borne Hirschmann 60V RS:738-547
20 1 R1 2k2 CMS0603
21 1 R2 5k8 CMS0603
22 1 R3 10k CMS0603
23 1 R4 58k CMS0603
24 1 R5 160k CMS0603
25 1 R6 560Ω CMS0603
26 1 R7 100kΩ CMS0603
27 2 TULIP2 2 x contacts à souder RS: 615-4850
28 TULIP3 2 x contacts à souder RS: 615-4850
29 1 SV1 CON10 RS: 547-3166
30 1 SV2 CON8 RS: 547-3166
31 1 SV3 CON8 RS: 547-3166
32 1 SV4 CON6 RS: 547-3166
33 1 IC1 BTT3018EJ TDSO8 Provided by Infineon

User Manual 11 <Revision 1.0>
2017-11-
22
Demoboard BTT3018EJ User Manual
7 Board Layout
7.1 TOP
7.2 BOTTOM

User Manual 12 <Revision 1.0>
2017-11-
22
Demoboard BTT3018EJ User Manual
7.3 MECHANICAL VIEW

User Manual 13 <Revision 1.0>
2017-11-
22
Demoboard BTT3018EJ User Manual
Revision History: V1.0
Previous Version: none
Revision Date Changes
1.0 November 22nd 2017 First release

Trademarks of Infineon Technologies AG
AURIX™, C166™, CanPAK™, CIPOS™, CoolGaN™, CoolMOS™, CoolSET™, CoolSiC™, CORECONTROL™, CROSSAVE™, DAVE™, DI-POL™, DrBlade™, EasyPIM™,
EconoBRIDGE™, EconoDUAL™, EconoPACK™, EconoPIM™, EiceDRIVER™, eupec™, FCOS™, HITFET™, HybridPACK™, Infineon™, ISOFACE™, IsoPACK™,
i-Wafer™, MIPAQ™, ModSTACK™, my-d™, NovalithIC™, OmniTune™, OPTIGA™, OptiMOS™, ORIGA™, POWERCODE™, PRIMARION™, PrimePACK™,
PrimeSTACK™, PROFET™, PRO-SIL™, RASIC™, REAL3™, ReverSave™, SatRIC™, SIEGET™, SIPMOS™, SmartLEWIS™, SOLID FLASH™, SPOC™, TEMPFET™,
thinQ!™, TRENCHSTOP™, TriCore™.
Trademarks updated August 2015
Other Trademarks
All referenced product or service names and trademarks are the property of their respective owners.
Edition <2016-07-19>
AppNote Number
Published by
Infineon Technologies France SAS
13610 Le Puy-Sainte-Réparade France
© 2020 Infineon Technologies AG.
All Rights Reserved.
Do you have a question about this
document?
Email: [email protected]
Document reference
IMPORTANT NOTICE
The information contained in this application note is
given as a hint for the implementation of the product
only and shall in no event be regarded as a
description or warranty of a certain functionality,
condition or quality of the product. Before
implementation of the product, the recipient of this
application note must verify any function and other
technical information given herein in the real
application. Infineon Technologies hereby disclaims
any and all warranties and liabilities of any kind
(including without limitation warranties of non-
infringement of intellectual property rights of any
third party) with respect to any and all information
given in this application note.
The data contained in this document is exclusively
intended for technically trained staff. It is the
responsibility of customer’s technical departments
to evaluate the suitability of the product for the
intended application and the completeness of the
product information given in this document with
respect to such application.
For further information on the product, technology
delivery terms and conditions and prices pleas
e
contact your nearest Infineon Technologies offic
e
(www.infineon.com).
WARNINGS
Due to technical requirements products may contai
n
dangerous substances. For information on the type
s
in question please contact your nearest Infineo
n
Technologies office.
Except as otherwise explicitly approved by Infineo
n
Technologies in a written document signed b
y
authorized representatives of Infineo
n
Technologies, Infineon Technologies’ products ma
y
not be used in any applications where a failure of th
e
product or any consequences of the use thereof ca
n
reasonably be expected to result in personal injury.
