Infineon Sense2GoL Pulse User manual

User Manual 1 V1.0
07/02/2020
User Manual
Sense2GoL Pulse (Pulsed Doppler) Software
User Manual
24 GHz-based radar applications
About this document
Scope and purpose
This user manual describes the Sense2GoL Pulse firmware, supported algorithms and the development
recommendations required to build an application around Infineon’s Sense2GoL Pulse demo kit.
It describes the demonstration firmware applications of the Sense2GoL Pulse Infineon radar demo board based
on the BGT24LTR11, with details of package architecture and contents.
This document provides guidelines for novice users on how to build and run Sense2GoL Pulse radar
applications such as motion detection, presence sensing, speed detection and direction of movement
(approaching or retreating), and also to support ease-of-use and faster-to-market integration.
Intended audience
This document is intended for users of the Sense2GoL Pulse demo kit who want to get started with Infineon’s
Sense2GoL Pulse firmware solution, test several sensing demonstrations, and implement custom radar
applications in the 24 GHz ISM band.
Related documents
Additional information can be found in the supplementary documentation provided with the Sense2GoL Pulse
Kit in the Infineon Toolbox or from www.infineon.com/24GHz:
24 GHz Radar Tools and Development Environment User Manual
AN598 –BGT24LTR11 Shield (Pulsed Doppler)
AN602 –Radar Baseboard XMC4700
AN605 –Radar Baseboard XMC4700 and BGT24LTR11 Shield with Arduino compatibility

User Manual 2 V1.0
07/02/2020
Sense2GoL Pulse (Pulsed Doppler) Software User Manual
24 GHz-based radar applications
Table of contents
Table of contents
About this document....................................................................................................................... 1
Table of contents............................................................................................................................ 2
List of figures ................................................................................................................................. 3
List of tables .................................................................................................................................. 4
1Introduction .......................................................................................................................... 5
2Basic radar Doppler concepts .................................................................................................. 6
3Hardware overview................................................................................................................ 7
3.1 Radar Baseboard XMC4700.....................................................................................................................7
3.1.1 Overview.............................................................................................................................................7
3.1.2 XMC4700 block diagram.....................................................................................................................8
3.2 BGT24LTR11 Shield.................................................................................................................................9
3.3 Sense2GoL Pulse ...................................................................................................................................10
4Firmware description ............................................................................................................11
4.1 Overview................................................................................................................................................11
4.2 Global architecture................................................................................................................................11
4.3 Firmware concept .................................................................................................................................13
4.4 Raw data acquisition.............................................................................................................................14
4.4.1 Doppler pulse generation ................................................................................................................14
4.4.2 Data sampling ..................................................................................................................................16
4.5 Radar control layer................................................................................................................................17
4.5.1 Radar control API .............................................................................................................................17
4.5.2 Data store module............................................................................................................................17
4.5.3 Data store and EEPROM management............................................................................................19
4.6 DAVE™ project overview........................................................................................................................20
4.7 Firmware package overview.................................................................................................................23
4.8 Footprint................................................................................................................................................23
4.9 Firmware timings ..................................................................................................................................24
4.10 Firmware customization and configuration.........................................................................................25
5Algorithm description............................................................................................................27
5.1 Target approaching/target departing ..................................................................................................27
5.2 Motion detected ....................................................................................................................................27
6References ...........................................................................................................................28
Revision history.............................................................................................................................29

User Manual 3 V1.0
07/02/2020
Sense2GoL Pulse (Pulsed Doppler) Software User Manual
24 GHz-based radar applications
List of figures
List of figures
Figure 1 Doppler effect......................................................................................................................................6
Figure 2 Radar Baseboard XMC4700.................................................................................................................7
Figure 3 XMC4700 block diagram......................................................................................................................8
Figure 4 BGT24LTR11 Shield board ..................................................................................................................9
Figure 5 Sense2GoL Pulse hardware platform...............................................................................................10
Figure 6 Firmware architecture.......................................................................................................................11
Figure 7 Firmware flow diagram.....................................................................................................................13
Figure 8 Raw data acquisition flow diagram..................................................................................................14
Figure 9 All control signals ..............................................................................................................................15
Figure 10 One pulse generation........................................................................................................................15
Figure 11 Frame structure and terminology ....................................................................................................16
Figure 12 Sense2GoL Pulse data acquisition and sampling flow ....................................................................16
Figure 13 Data acquisition flow diagram..........................................................................................................17
Figure 14 Data store hardware device and algorithm settings structures......................................................18
Figure 15 Interconnection of the data store module with other firmware modules......................................19
Figure 16 EEPROM block diagram.....................................................................................................................19
Figure 17 EEPROM structure .............................................................................................................................20
Figure 18 ADC DAVE™ app configuration..........................................................................................................22
Figure 19 DMA DAVE™ app configuration .........................................................................................................22
Figure 20 Package folder structure...................................................................................................................23
Figure 21 Raw data acquisition timings ...........................................................................................................24
Figure 22 Movement detection algorithm flow................................................................................................27

User Manual 4 V1.0
07/02/2020
Sense2GoL Pulse (Pulsed Doppler) Software User Manual
24 GHz-based radar applications
List of tables
List of tables
Table 1 Sense2GoL Pulse control and data signals description...................................................................14
Table 2 DAVE™ project apps used..................................................................................................................20
Table 3 PWM and GPIO pin configurations....................................................................................................21
Table 4 Sense2GoL Pulse firmware footprint................................................................................................24
Table 5 Define statements used for radar firmware configuration..............................................................25

User Manual 5 V1.0
07/02/2020
Sense2GoL Pulse (Pulsed Doppler) Software User Manual
24 GHz-based radar applications
Introduction
1Introduction
The Sense2GoL Pulse radar demo kit is a demonstration platform for Infineon’s silicon-germanium 24 GHz
radar chipset BGT24LTR11. It consists of two boards: the main Radar Baseboard XMC4700 and a radar front-
end board BGT24LTR11 Shield.
This document focuses on the demonstration firmware and the Graphical User Interface (GUI) for a pulsed
Doppler implementation.
The Sense2GoL Pulse board is designed to evaluate the capabilities of the BGT24LTR11 IC, comprising one
transmit and one receive channel with the XMC4700 microcontroller utilizing Infineon’s powerful, free-of-
charge toolchain DAVE™ for microcontroller programming.

User Manual 6 V1.0
07/02/2020
Sense2GoL Pulse (Pulsed Doppler) Software User Manual
24 GHz-based radar applications
Basic radar Doppler concepts
2Basic radar Doppler concepts
The main radar technique used for this demonstration is Continuous Wave (CW/Doppler) radar.
Doppler radar operates on the principle of sending a beam of electromagnetic radiation waves, tuned to a
precise frequency, toward a moving object. When the electromagnetic radiation wave hits the moving object, it
“bounces” back toward the source, which also contains a receiver. However, since the wave is reflected off a
moving object, the wave is shifted as outlined by the Doppler effect.
The wave that is coming back toward the radar is treated as an entirely new wave, as if it were emitted by the
target it bounced off. The target is acting like a new source for this new wave. When it is received at the radar,
this wave has a frequency different from the frequency that was originally sent toward the target.
Radar transceiver Low frequency Doppler signal
Amplitude depends on reflectivity and distance.
Figure 1 Doppler effect
Since the electromagnetic radiation was at a precise frequency when sent out and is at a new frequency on its
return, this can be used to calculate the velocity 𝑣of the target.
The change in phase between the transmitted and received signal is used to calculate the target’s velocity. The
Doppler effect shifts the received frequency up or down based on the radial velocity of the target (closing or
opening) in the beam, allowing for the direct and highly accurate measurement of target velocity.
Doppler shift 𝑓
𝑑and velocity 𝑣are dependent on each other according to the following equations:
𝑓
𝑑=2 . 𝑓𝑇𝑥 . 𝑣
𝑐 . cos 𝛼
𝑣 = 𝑐 . 𝑓
𝑑
2 . 𝑓𝑇𝑥. cos 𝛼
𝑓
𝑑
𝑓𝑇𝑥
𝑣
𝑐
𝛼
: Doppler frequency [Hz]
: Carrier frequency (24.0 x 109Hz)
: Object velocity [m/s]
: Speed of light in vacuum (3 x 108m/s)
: Angle between beam center and target moving direction

User Manual 7 V1.0
07/02/2020
Sense2GoL Pulse (Pulsed Doppler) Software User Manual
24 GHz-based radar applications
Hardware overview
3Hardware overview
The Sense2GoL Pulse radar system is a demo platform for Infineon’s 24 GHz BGT24LTR11 radar chipset. It
consists of two boards: the Radar Baseboard XMC4700 and a radar front-end board, BGT24LTR11 Shield.
3.1 Radar Baseboard XMC4700
This section gives an overview of the Radar Baseboard XMC4700 hardware platform, and more detailed
information can be found in the corresponding application note.
3.1.1 Overview
The Radar Baseboard XMC4700 is a generic sensor interface for Infineon’s 24 GHz radar sensors. The central
unit of the XMC4700 32-bit ARM® Cortex™-M4 based microcontroller can perform radar data processing or
forward the sensor data to a USB interface, serial interface or an Arduino interface. The board is designed to
allow customers to carry out prototyping and system integrations, as well as initial product feature evaluations.
An onboard debugger with licensed firmware from SEGGER allows easy debugging over USB. Infineon’s
powerful, free-of-charge toolchain DAVE™ can be used for programming the XMC4700 microcontroller. This
application note describes the key features and hardware configuration of the Radar Baseboard XMC4700 in
detail. Figure 2 shows the Radar Baseboard XMC4700 hardware platform.
55 mm
85mm
Arduino-compatible
connectors
Arduino-compatible
connectors
Connectors to
BGT24LTR11
Shield
LDO
LDO
J-K Flipflop
Current
sensor
XMC4700 MCU
XMC4200
Debugger MCU
Current
sensor
SD card
reader
Voltage level
translator
Cortex Debugger
Connector
XMC Boot Level
Jumper
Current
sensor
Linear Charge
Management
Controller
External Power
Connector
LiPo battery
connector
Figure 2 Radar Baseboard XMC4700

User Manual 8 V1.0
07/02/2020
Sense2GoL Pulse (Pulsed Doppler) Software User Manual
24 GHz-based radar applications
Hardware overview
3.1.2 XMC4700 block diagram
The Radar Baseboard XMC4700 embeds Infineon’s XCM4700, 32-bit ARM® Cortex™-M4 based microcontroller. It
can be used to perform radar data processing, configure the board’s peripherals and RF shield management,
and enable radar data communication via a USB or serial interface.
The Sense2GoL Pulse firmware is running in the XMC4700 microcontroller and configures the following
peripherals:
Analog Digital Converter (ADC)
Direct Memory Access (DMA)
General-Purpose Input Output (GPIO)
USIC for I2C serial interface
CCU8/4 for timer and PWM control signals
Capture and Compare Unit (CCU)
Hardware interrupts
USB interface for host communication
Figure 3 XMC4700 block diagram

User Manual 9 V1.0
07/02/2020
Sense2GoL Pulse (Pulsed Doppler) Software User Manual
24 GHz-based radar applications
Hardware overview
3.2 BGT24LTR11 Shield
This section gives an overview of the BGT24LTR11 Shield hardware platform. More detailed information can be
found in the corresponding application note.
The radar shield is shown in Figure 4. It contains the following:
RF part: consists of the Infineon 24 GHz radar MMIC BGT24LTR11 and includes micro-strip patch
antennas for the TX and RX sections.
S&H part: consists of SPST switches and hold capacitors to sample and hold the analog I/Q signals from
the MMIC using a control signal from the microcontroller.
Analog amplifier part: consists of two amplifier stages, used to smooth the sampled I/Q signals from
S&H circuitry and amplify them for the digital part.
EEPROM part: can be used to store data such as board identifier information, and RF shield hardware
settings.
Sample and
Hold Switches
BGT24LTR11 MMIC
PMOS
switch
Operational Amplifiers
(base band section)
Connectors to
Radar
Baseboard
External Pin
Headers
LDO
Voltage level
translator
55 mm
66mm
Arduino-compatible
connectors
Arduino-compatible
connectors
EEPROM
Figure 4 BGT24LTR11 Shield board

User Manual 10 V1.0
07/02/2020
Sense2GoL Pulse (Pulsed Doppler) Software User Manual
24 GHz-based radar applications
Hardware overview
3.3 Sense2GoL Pulse
Figure 5 shows the Sense2GoL Pulse radar system hardware platform, which consists of two boards: the Radar
Baseboard XMC4700 and the BGT24LTR11 Shield radar front-end board.
The BGT24LTR11 Shield should be plugged into the bottom side of the Radar Baseboard XMC4700 using the two
connectors X2 and X3.
Figure 5 Sense2GoL Pulse hardware platform

User Manual 11 V1.0
07/02/2020
Sense2GoL Pulse (Pulsed Doppler) Software User Manual
24 GHz-based radar applications
Firmware description
4Firmware description
4.1 Overview
The Sense2GoL Pulse FW is a piece of software written in C language to control different ICs and peripherals via
the host processor, which is the XMC4700 32-bit ARM® Cortex™-M4 MCU in the Radar Baseboard XMC4700.
The Sense2GoL Pulse firmware is developed with Infineon’s DAVE™4 (Digital Application Virtual Engineer), free
development toolchain. It is a C/C++-language software development and code generation tool for XMC™
microcontroller applications. It is based on graphical interface apps to configure the MCU peripherals (ADC,
DMA, CCU4 …), which reduces development time and allows for quick porting of the firmware across XMC™-
series MCUs.
The Sense2GoL Pulse firmware includes various radar demonstration applications to demonstrate the
Sense2GoL Pulse board’s capabilities and facilitate the development of user applications, and that can be used
for:
motion detection
speed detection and direction of movement, approaching or retreating
4.2 Global architecture
This section describes the software components of the Sense2GoL Pulse firmware illustrated in Figure 6.
DAVEAPPs generated code (ADC, DMA, CCU4, TIMER, USBD...)
XMC4700 Microcontroller
Host Communication Library / Micrium GUI
Interface
XMCLib (LLD library) CMSIS Drivers
BSP Drivers
BGT24LTR11 Sample & Hold
EEPROM
Radar
Control
Sence2GoLPulse Application Layer
Algorithms (RangeDoppler, Tracking, ...)
BGT Driver DMA Driver USB Inteface
Sence2GoLPulse
Data Store Radar Control Endpoint Interface
EEPROM LEDs Timer Current sensors
BSP for
Radar
Baseboard
XMC4700
BSP for BGT24LTR1 1 Shield
Figure 6 Firmware architecture
Sense2GoL Pulse application layer –a customer-specific layer that defines the entry point of the
Sense2GoL Pulse demonstration platform, and contains:

User Manual 12 V1.0
07/02/2020
Sense2GoL Pulse (Pulsed Doppler) Software User Manual
24 GHz-based radar applications
Firmware description
othe initialization functions for XMC™ peripherals, host communication library and radar control
layer
othe main application state machine
oa function template for the user to add their own code (data acquisition callbooks, algorithms
process…)
ofunctions and variables to manage the communication with Radar GUI interface.
Algorithms –contains the supported algorithms by the Sense2GoL Pulse demonstration platform
implementations, e.g. Range-Doppler, presence sensing used for processing and calculating
information out of radar raw data in order to detect stationary and moving objects (refer to the
algorithms section for more details).
Communication library –contains a set of functions to ensure USB data communication between the
Sense2GoL Pulse board and the Radar GUI tool:
odefines all communication endpoints
ocontains communication endpoints settings and configuration
ocontains a protocol communication layer.
Radar control layer –contains high-level functions that can be used to set the specific mode for the
Sense2GoL Pulse board, basically classified into three categories:
oradar control –offers high-level radar services to the user application and host communication
library layers, e.g. radar device initialization, radar start, radar stop, set/get calibration…
odata store –contains global structures for hardware settings and algorithms configuration
oendpoint interface –ensures communication between the host communication library and
radar control layer.
BSP driver –the Board Support Package (BSP) driver is a set of functions that can be used to control and
manage all components embedded in the Sense2GoL Pulse board, and it contains:
olow-layer functions to initialize andcontrol the specific boardfeatures (BGT24LTR11, Sample and
Hold (S&H), EEPROM, current sensors…)
ofunctions to control power-up and power-down sequences for all hardware components
ofunctions to manage the data acquisition process from BGT to XMC™ microcontroller internal
RAM memory (DMA, timer, ADC).
DAVE™ apps generated code –contains the generated library sources from DAVE™-configured building-
block apps for XMC4700 MCU peripherals. It contains Application Program Interfaces (APIs) and data
structures meant to be used in application code.
Libraries –contains the following libraries:
oCMSIS –Cortex Microcontroller Software Interface Standard (CMSIS) is a vendor-independent
hardware abstraction layer for the Cortex-M processor series and defines generic tool interfaces.
The CMSIS enables consistent device support and establishes simple software interfaces to the
processor and the peripherals, simplifying software reuse, reducing the learning curve for
microcontroller developers, and reducing the time-to-market for new devices.

User Manual 13 V1.0
07/02/2020
Sense2GoL Pulse (Pulsed Doppler) Software User Manual
24 GHz-based radar applications
Firmware description
oXMC-Lib –consists of various low-level drivers for the XMC™ microcontroller’s family peripherals.
Each driver consists of a set of routines and data structures covering all peripheral
functionalities. Built on top of the CMSIS, it provides access to all XMC4000 peripheral features.
4.3 Firmware concept
Sense2GoL Pulse firmware can be divided into repetitive and non-repetitive tasks. After device initialization,
control resides in the main loop, where two possible events can trigger further processing:
frame timer interrupt
GUI request by the host communication protocol.
Manage the communication with the Radar GUI interface.
A task-level flow diagram of the firmware is shown in Figure 7.
Device
Initialization
Start
Raw Data
Acquisiton
Radar Algorithm
Frame Timer
Interrupts GUI Request
Main Loop Host Communication
Protocol
Figure 7 Firmware flow diagram
Device initialization –this is the first task to be executed, onlyonce when the firmware is started. During
this task, the firmware initializes XMC™ peripherals and the Sense2GoL Pulse radar device, then registers
the used endpoints for the host communication. Program control then goes to the main loop.
Frame timer interrupt –this is a periodic hardware timer interrupt, which triggers the start of the new
frame raw data acquisition process.
Raw data acquisition –the BSP layer is configured to start collecting raw data from the radar device.
Radar algorithm –once raw data is collected, run the registered algorithm process in order to compute
the parameter of the target’s velocity.

User Manual 14 V1.0
07/02/2020
Sense2GoL Pulse (Pulsed Doppler) Software User Manual
24 GHz-based radar applications
Firmware description
4.4 Raw data acquisition
Figure 8 shows the main blocks of the Sense2GoL Pulse raw data acquisition phase in detail, before going
through the radar algorithm processing phase. There are more details about the chirp generation and data
sampling phases in the next sections.
Frame 1 Frame 2 Frame 3 Frame 4 ...
Radar Algorithm
Processing GUI RequestsData Acquisition
Pulse Generation Data Sampling
IDLE
Frame Timer
Interrupt
Figure 8 Raw data acquisition flow diagram
4.4.1 Doppler pulse generation
Pulse generation is the first part of the data acquisition process. It is triggered by an internal frame timer, which
will start generating pulses. The Sense2GoL Pulse firmware communicates and controls the BGT and S&H over
PWM signals. It generates periodic and continuous pulses based on the number of data samples required.
As shown in 15 and Table 1, the BGT24LTR11 Shield is controlled through three PWM signals and one normal
GPIO signal.
PWM1 and PWM2: PWM control signals for BGT_VCC and BGT_TX_ON, they are used to turn on the
BGT24LTR11 only during the “Pulse” duration and it remains off for the remaining time.
PWM3: Normal GPIO control signal for BGT_VCC_PTAT, it is used to turn on the VPTAT 1 ms before the
start of the first pulse of the frame and then remains on until the end of the frame time.
S&H_EN: PWM control signal for S&H, it is used to turn on the S&H only during the “Pulse” duration and
it remains off for the remaining time.
Table 1 Sense2GoL Pulse control and data signals description
Pin
Signal name
Pin description
BGT_VCC_PTAT
PWM3
Control signal for VCC_PTAT pin of BGT24LTR11
BGT_TX_ON
PWM2
Control signal for TX_ON pin of BGT24LTR11
BGT_VCC
PWM1
Control signal to turn on/off VCC for BGT24LTR11
SH_EN
S&H_EN
Control signal for S&H switches
IFI
IFI_HG
Second baseband amplifier stage output for IFI signal
IFQ
IFQ_HG
Second baseband amplifier stage output for IFQ signal

User Manual 15 V1.0
07/02/2020
Sense2GoL Pulse (Pulsed Doppler) Software User Manual
24 GHz-based radar applications
Firmware description
Figure 9 All control signals
The pulse width or BGT VCC on-time can vary between 1 and 10 µs, and it represent the time portion to have one
data sample. Short pulse width reduces the sample time of the BGT’s output signals, hence saving more power.
However, the time might not be enough to charge to the S&H, reducing the final signal strength at the output.
For more details about BGT24LTR11 Shield configuration and power saving, please refer to the BGT24LTR11
Shield hardware platform application note.
Figure 10 One pulse generation

User Manual 16 V1.0
07/02/2020
Sense2GoL Pulse (Pulsed Doppler) Software User Manual
24 GHz-based radar applications
Firmware description
Figure 11 shows the configuration of a frame. Each frame is a series of pulses, based on the number of samples,
followed by a frame off-time.
1 32 4 Nsamples
Frame ON time Frame OFF time
Frame time
Pulse width
1 2 Nskip
Figure 11 Frame structure and terminology
4.4.2 Data sampling
The data acquisition process for Sense2GoL Pulse application is shown in Figure 13.
The start of the data acquisition process will be triggered by an internal frame timer, which will start pulse
generation over PWM signals. The data sampling process is triggered by an internal PWM signal at the same time,
which triggers the ADC to start sampling data from the RX antenna.
Once an ADCsample is ready to be moved to the acquisition buffer, the DMA transfer starts. This taskis repetitive;
it will end once the number of required samples per frame is reached. At that moment, the DMA will stop the
transfer process by raising a transfer complete interrupt.
The frame size (or number of samples per frame) depends on the number sample required by the application or
the algorithm and the sample skip count. The sample skip count is the number of samples to be skipped in each
frame to get rid of the DC offset in the I and Q signals. The recommended sample skip count value is 100; these
samples are completely disregarded in the signal processing chain.
Figure 12 Sense2GoL Pulse data acquisition and sampling flow

User Manual 17 V1.0
07/02/2020
Sense2GoL Pulse (Pulsed Doppler) Software User Manual
24 GHz-based radar applications
Firmware description
Figure 13 gives the detailed flow diagram of the data acquisition phase. Here is a short description of each step
of the acquisition process:
Step 1 –configure and enable DMA: DMA source/destination address set-up; four DMA channels are
configured for the RX complex (I/Q) data samples (Q1 HG, I1 HG, Q1 LG and I1 LG).
Step 2 –configure pulse generation: Configure all PWM control signals for BGT and S&H.
Step 3 –trigger pulse generation:Triggered by an internal frame timer at the beginning of each frame;
start PWM pulse generation and ADC data sampling.
Step 4 –start ADC sampling:ADC sampling will start automatically at the same time as pulse generation; it
is controlled by an internal PWM signal in order to trigger equidistant ADC samples.
Step 5 –stop acquisition process:Based on the number of samples required, disables the DMA peripheral
and stops pulse generation and ADC sampling.
IDLE
Frame 1 Frame 2 Frame 3 Frame 4 ...
Radar Algorithm Processing GUI RequestsData Acquisition
Disable DMA, Stop ADC,
Stop Pulse Generation
Configure and
Enable DMA
Configure Pulse
generation: PWM
signals for BGT and
S&H
Start Pulse
Generation and
ADC sampling
DMA Sampling
Completed ? Yes
Figure 13 Data acquisition flow diagram
4.5 Radar control layer
The Sense2GoL Pulse software package provides a simple interface to the radar kit through the radar control
layer, which offers full flexibility to configure all radar parameters based on the application end requirements.
4.5.1 Radar control API
The APIs define the high-level interface used to configure the radar RF parameters, the behavior and
capabilities of the component, and its inputs and outputs, and provide a set of firmware methods to manage
radar functionalities. Radar control APIs are called from the application layer and are prefixed by “radar_”.
Detailed technical information about the radar APIs available to the user is provided in a compiled HTML file in
the Firmware_Software/Documentation/FW_API folder, where all the functions and parameters are described.
4.5.2 Data store module
The data store module is apart from the radar control layer; it mainly contains the hardware device settings
and the algorithm settings structures, as shown in Figure 14.

User Manual 18 V1.0
07/02/2020
Sense2GoL Pulse (Pulsed Doppler) Software User Manual
24 GHz-based radar applications
Firmware description
Figure 14 Data store hardware device and algorithm settings structures
These two structures are shared between all firmware modules. If a firmware module, e.g. the host
communication library or algorithm, requires one or more parameters from the settings structures, a fetch
operation is performed to get the up-to-date value from the data store, as shown in Figure 15. The resulting
structure holds the results of the last algo operation.
On the other hand, if there is an update for one or many parameters in the settings structures, a push/store
operation is performed to update the data store structures with the new changed value.
A shadow (or a copy) of the hardware settings structure is maintained in the data store, and it always contains
the old settings parameters. In case of unsupported parameters (e.g. the value is out of range), the current
hardware structure is discarded and overwritten by the shadow copy and the new required change will be
discarded.
At the beginning, the shadow and current settings structures parameters are set to the default settings values
from the config.h file. The user can change these default settings by updating the config.h file or through the
radar GUI tool interface.
In case of a valid hardware change request received from the GUI, the hardware structure will be updated with
the new value in the data store. The radar control sub-module will apply this change on the BSP driver before
the start of acquisition of the next new frame.

User Manual 19 V1.0
07/02/2020
Sense2GoL Pulse (Pulsed Doppler) Software User Manual
24 GHz-based radar applications
Firmware description
Figure 15 Interconnection of the data store module with other firmware modules
4.5.3 Data store and EEPROM management
The BGT24LTR11 Shield contains 16 K-Byte serial EEPROM, The I2C serial data interface is used to transfer
addresses and data into and out of the EEPROM.
EEPROM
VCC
VCC VSS
SCL
Connector to
Radar Baseboard XMC4700
SDA
I2C_EEPROM.SCL
I2C_EEPROM.SDA VCC
R83 R84
USIC
XMC4700
Figure 16 EEPROM block diagram
In Sense2GoL Pulse firmware, the EEPROM is used to store the hardware settings and the algorithm settings
structures as shown in Figure 14. In addition to that the EEPROM contains a unique, pre-defined and pre-
programmed string ID, which is used to identify the BGT24LTR11 Shield board.
When the Radar Baseboard XMC4700 boots up, the firmware detects if a radar shield is plugged into the
connectors. If the radar shield is plugged in correctly, it reads the information in the EEPROM’s memory to
determine what kind of shield is plugged into the interface. The power supply of the radar shield is only
enabled when the shield is correctly identified.

User Manual 20 V1.0
07/02/2020
Sense2GoL Pulse (Pulsed Doppler) Software User Manual
24 GHz-based radar applications
Firmware description
After that, the firmware reads the hardware and the algorithm settings from EEPROM. In case of valid settings
the firmware will start based on these new settings; otherwise it will start with the default settings and
overwrite the EEPROM settings section with the default settings values.
Figure 17 EEPROM structure
4.6 DAVE™ project overview
The Sense2GoL Pulse firmware is released as a ready-to-run DAVE™4 project, where source files are generated
based on the DAVE™ apps used, which are graphical-configurable application-oriented software components,
used to enable users’ quick reuse and customization.
Table 2 lists the DAVE™ apps used, based on the Sense2GoL Pulse board, to generate the appropriate firmware
source code.
Table 2 DAVE™ project apps used
DAVE™ app
Number of
instances
App description
ADC
4
Allows for digitizing analog signals using ADC via queue and scan
request sources with advanced features
CMSIS_DSP
1
Provides the CMSIS DSP software library, a suite of common
signal processing functions to apply on Cortex-M processor-
based devices
DIGITAL_IO
4
Used to configure a port pin as digital input/output
DMA_CH
4
Used to perform single- and multi-block data transfer using the
General Purpose Direct Memory Access (GPDMA) module on the
XMC4000
I2C_MASTER
1
Used for I2C serial interface communication
