InFocus LitePro 610 User manual

009-0279-00 (English)
Downloaded from ProjectorsManual.com Manuals

Don’t Look Into The Lens!
Be extremely carefulnot tolookdirectly into the lens when the projector is on.
The bright light can harm your eyes. Be especially careful to keep children from
looking into the lens.
Don’t Disassemble
Do not open the projector’s case! Doing so exposes youto an electric shock haz-
ard.Exceptfor the projectionlamp,there are no user-serviceable parts. All service
must be performed by an In Focus Systems Authorized Service Provider.
Avoid Hot Surfaces
The rear of the projector becomes very hot during operation. Avoid touching the
exhaust grill on the lamp door. Allow the projector to cool for at least 45 minutes
before opening the lamp door to replace the lamp. The inside of the lamp housing
can be very hot. Use extreme care. Avoid touching the hot surfaces inside.
Use Only The 610/620 Power Cord
Always use the power cord that came with the projector. Although other cords
might look the same, they have not been safety-tested with the 610 or 620. Never
use the power cord if it’s damaged or frayed. When you disconnect the projector,
always remove the power cord from the electrical outlet first, then from the pro-
jector.
Don’t Defeat The Purpose Of The Grounding Plug
The projector is grounded through the grounding conductor on the power cord.
To avoid electric shock, plug the power cord into a properly wired receptacle.
Avoid Liquid Spills
Don’t set drinks on top of the projector. Spilled liquids can flow insidecausing
damage.
Don’t Block Ventilation
Openings in the case provide ventilation to protect the projector from overheat-
ing. Keep loose papers and other objects away from the bottom, top and side
grills. Don’t place the projector on top of or close to a computer or other heat-pro-
ducing equipment.
SAFETY SUMMARY: Please
read these instructions before
using your LitePro 610 or 620.
Failure to comply could result in
fire, electrical shock, personal
injury or equipment damage.
Definition of Safety Icons
on Product Labels
Refer to the User’s
Guide for more
information.
Avoid hot surfaces.
Bulb explosion
hazard.
Downloaded from ProjectorsManual.com Manuals

i
TABLE OF CONTENTS
Safety Summary iii
Introduction 1
Image Resolution 1
Compatibility 2
Unpacking the Projector 2
Usage Guidelines 4
If You Need Assistance 4
Warranty 4
Setting up the Projector 5
Connecting the CableWizard to the Projector 6
Selecting Connectors on the CableWizard 7
Preparing to Connect Your Equipment to the Projector 8
Connecting an IBM-CompatibleDesktop Computer 9
Connecting an IBM-CompatibleLaptop Computer 11
Connecting a Macintosh Desktop Computer 13
Connecting an Apple PowerBook Computer 15
Connecting a Video Player 17
Connecting anExternal Speaker and a Subwoofer 19
Connecting a Microphone 19
Connecting a PS/2-Compatible Mouse 20
Connecting theRemote Control Cable 20
Powering up the Projector and Adjusting the Image 21
Turning Off the Projector 23
Using the Projector 25
Basic Image Adjustment 25
Using the Remote Control 25
Adjusting the Projector 26
Changing between Color and Monochrome Modes 28
Using the Remote and Keypad Buttons 29
Using the Disk Mouse 32
Using the On-Screen Menus 32
Display Menu Functions 34
Audio Menu Functions 35
Image Menu Functions 37
Controls Menu Functions 39
Downloaded from ProjectorsManual.com Manuals

ii
Table of Contents
Maintenance & Troubleshooting 41
Cleaning the Lens 41
Replacing the Projection Lamp 41
Resetting the Lamp Monitor Light 44
Replacing the Batteries in the Remote Control 44
Using the Kensington Lock 44
Troubleshooting 45
Solutions to Common Problems 46
Appendix 51
Specifications 51
Accessories 53
Portable and Laptop Activation Chart 55
Using Video Mirroring with a PowerBook Computer 59
Projected Image Size 60
Index 63
Downloaded from ProjectorsManual.com Manuals

iii
SAFETY SUMMARY
Please read these instructions carefully before using your LitePro
610 or 620. Failure to comply with them could result in fire, elec-
trical shock, personal injury or damage to equipment.
These graphics are used throughout this manual to draw your
attention to important information about the projectors.
NOTE: Additional useful details or tips.
CAUTION: Steps to avoid damage to your equipment.
WARNING: Steps to avoid personal injury.
These graphics are used on LitePro labels.
Attention: Refer to this User’s Guide for important
safety information.
Hot Surfaces: Avoid touching hot surfaces. Do nottouch
until the LitePro has cooled.
Lamp Explosion Hazard: If you continue to use the
lamp after the lamp monitor light comes on, it may
explode, severely damaging your LitePro. Be sure to
replace the lamp when the lamp monitor light comes on
as described in this User’s Guide. Refer to the section
titled “Replacing the Projection Lamp” for information
about changing the bulb.
Downloaded from ProjectorsManual.com Manuals

iv
Safety Summary
Do not look into the lens!
Be extremely careful not to look intothe projection lens when the
LitePro is turned on. The bright light may harm your eyes. Be
especially careful to keep children from looking into the lens.
Turning projector on and off
Allow the projector to warm up for three minutes before turning
it off; allow the projector to cool down for three minutes before
turning it back on. Repeatedly turning the projector on and off
without waiting three minutes may cause the lamp to explode.
Power source
Useonly a three-wire grounding type power source. Thenominal
power source should not exceed 240 volts rms between the sup-
ply conductors or between either conductor and the ground.
Power cord
Use only the power cord that was shipped with theLitePro.
Although other power cords mightbe similar in appearance,they
have not been safety-tested with the610 or 620. Do not use a
power cord if it has become damaged or frayed. Contact your In
Focus dealer or call In Focus if you need to replace your power
cord.
CAUTION: Be sure to replace
the projection bulb when the lamp
monitor light comes on as
described on page 41. If the lamp
remains in use too long, there is a
danger of bulb explosion. If this
happens, your LitePro will be
severely damaged.
Grounding
The projector is grounded through the grounding conductor on
the power cord. To avoid electric shock, plug the power cord into
a properly wired receptacle. Do notdefeat the purpose of the
grounding-type plug.
Lamp
To avoid overheating and unacceptable image quality, replace
the projection lamp with a lamp of the specified type. Refer to
page 52 for lamp specifications and to page 41 for instructions on
replacing the lamp.
Downloaded from ProjectorsManual.com Manuals

v
Lamp compartment
To avoid burns or an explosion hazard, do not open the lamp
module door until the projector is turned off and the lamp has
cooled. The hot lamp contains high pressure and can explode if
damaged or old. Follow the instructions in this manual for lamp
replacement carefully.
Hot surfaces
Allow the projector to cool at least 45 minutes before replacing a
lamp. When you open the lamp housing, be very careful not to
touch the hot surfaces inside.
Ventilation and overheating
Openings in the projector case provide ventilation to protect it
from overheating. Keep loose papers and other objects well away
from the bottom, top and side grills. Do not place the projector on
top of or close to a computer or other heat-producing equipment.
Liquid spills
Do not set drinks on top of the projector. Spilled liquids can flow
inside and cause damage.
NOTE: If you open the projector,
you will void the warranty.
Do not disassemble
All service must be performed by an In Focus Authorized Service
Provider. The only user-serviceable part in the projector is the
projection lamp, which you can replace by opening the lamp
cover in the front of the projector as described on page 41.Do not
open any other part of the projector. If your LitePro needs repair,
call In Focus Customer Service as described on page 4. Before
you call Customer Service, you may want to refer to “Trouble-
shooting” starting on page 45 to see if you can resolve the prob-
lem yourself.
Downloaded from ProjectorsManual.com Manuals

1
INTRODUCTION
The In Focus Systems LitePro®610 and 620 multimedia projec-
tors combine powerful and sophisticated features with easy-to-
use, intuitive controls. Built-in multimedia features include high-
fidelity stereo audio by JBL™, a palette of 16.7 million colors and
Digital Light Processing™ (DLP) technology. The 600 series pro-
jectors are ideal for high-performance business, training and
imaging applications thatdemand exceptional color quality. The
610 has VGA graphics, the 620 has SVGA graphics. The user
interfaces of the two products are identical; information in this
User’s Guide applies to both products.
Image Resolution
LitePro 610
The VGA resolution of the projected image of the 610 is 640x480.
The projector displays computer images that are 640x480 or
lower just as they appear on your computer’s monitor. Screen
resolutions between 640x480 and 800x600 are compressed to
640x480. The projector cannot compress screen resolutions above
800x600. If your computer’s screen resolution is higher than
800x600, reset it to a lower resolution before you connect the pro-
jector.
LitePro 620
NOTE: The 620 automatically
expands 640x480 images to
800x600. You can display these
images at 640x480 by turning off
the Auto Resize feature.See “Auto
Resize” on page 37 for more
information.
TheSVGAresolution of the projected image of the 620 is800x600.
The projector displays computer images that are 800x600 or
lower just as they appear on your computer’s monitor. Screen
resolutions between 800x600 and 1024x768 are compressed to
800x600. The projector cannot compress screen resolutions above
1024x768. If your computer’s screen resolution is higher than
1024x768, reset it to a lower resolution before you connect the
projector.
Downloaded from ProjectorsManual.com Manuals

2
Introduction
Compatibility
The projector is compatible with a wide variety of computers and
video devices, including:
•IBM-compatible computers, including laptops, up to 800x600
resolution (LitePro 610) or 1024x768 resolution (LitePro 620) at
60Hz.
•IBM PS/2 in VGA and MCGA modes.
•Apple Macintosh and PowerBook computers up to 800x600
resolution (LitePro 610) or 1024x768 resolution (LitePro 620).
•Various VCRs, camcorders and laser disc players.
The projector is not compatible with these systems:
•IBM-compatible computers in CGA or EGA graphics mode.
•Macintosh 128, 512, Plus, SE, SE/30 or Classic.
Unpacking the Projector
The projector comes with the parts shown in Figure 1. Check to
make sure all are included. If any parts are missing, contact your
In Focus dealer immediately.
If you are experienced in setting up presentation systems, use the
LitePro 610/620 Quick Start card that was included in the shipping
box. For complete details on connecting and operating the projec-
tor, refer to the appropriatesections of this User’s Guide.
NOTE: The contents of your
shipping box may vary depending
on the LitePro 610/620
configuration you ordered.
Downloaded from ProjectorsManual.com Manuals

3
FIGURE 1
Shipping box contents
1. LitePro 610 or 620 projector 6. CableWizard
2. LitePro 610/620 User’s Guide 7. CableWizard computer cable
3. power cord 8. CableWizard mouse cable
4. remote and batteries 9. CableWizard audio cable
5. RCA audio/video (A/V) cable Not shown: Quick Start card,
remote cable
1
2
3
4
5
6
7
8
9
Downloaded from ProjectorsManual.com Manuals

4
Introduction
Usage Guidelines
•Do not look directly into the projection lens when the projector
is turned on. The bright light may harm your eyes.
•The top and bottom of the projector can be very hot to the
touch after use. Use extreme care or let it cool before lifting it.
•Do not block the grills at the front, side, top or bottom of the
projector. Restricting the air flow through the projector can
cause it to overheat and turn off.
NOTE: If the projector overheats
and turns off, you must wait 45
seconds before you attempt to
turn it back on.
•Handle the projector as you would any product with glass
components. Be especially careful not to drop it.
•Avoid leaving the projector in directsunlight or extreme cold
for extended periods of time. If this happens, allow it to reach
room temperature beforeuse.
•Transport the projector in a vendor-approved hard or softcase.
Call your In Focus dealer for more information.
If You Need Assistance
The first place to look for help is in this manual. Be sure to check
the guidelines in “Troubleshooting” on page 45.
If this manual doesn’t answer your question, call your In Focus
dealer. You can also call In Focus Customer Service directly at
1-800-799-9911. Call between 6 a.m. and 5 p.m. PST, Monday
through Friday. In Europe, call In Focus inThe Netherlands at
(31) 23-5623200. In Singapore, call (65) 334-9005.
The In Focus World Wide Web address is http:\\www.infs.com.
Warranty
These products are backed by a limited one-year warranty. The
details of the warranty are printed at the back of this manual.
Longer term warranties can be purchased from your In Focus
dealer. Refer to page 54 for part numbers.
Downloaded from ProjectorsManual.com Manuals

5
SETTING UP THE PROJECTOR
1Place the projector on a flatsurface.
•The projector must be within 10 feet of your power source
and within 10 feet of your computer.
NOTE: An optional extension
cable, sold separately, lets you
increase the distance between the
projector and your computer to 50
feet. See “Accessories” on
page 53.
•If you want to project from behind a translucent screen, set
up the projector behind your screen. See “Rear Projection”
on page 40 to reverse the image.
•If you are installing the projector on the ceiling, see the
LitePro 610/620 Ceiling Mount Installation Guide for recom-
mendations. To turn the image upside down, see “Ceiling”
on page 39. The Ceiling Mount Kit is sold separately. See
“Accessories” on page 53.
2Position the projector the desired distance from thescreen.
•The distance from the lens of the projector to the screen
determines the size of the projected image. Figure 2 shows
three projected image sizes for the 610; Figure 3 shows
imagesizes for the 620. For more information, see “Pro-
jected Image Size” on page 60.
3Make sure the projector and your computer are turned off.
FIGURE 2
Projected image size for LitePro 610
5 ft.10 ft. 25 ft.
PROJECTOR
Downloaded from ProjectorsManual.com Manuals

6
Setting up the Projector
F
IGURE 3
Projected image size for LitePro 620
Connecting the CableWizard to the Projector
The CableWizard™ simplifies the connection process by provid-
ing a central hub for all the connections between the projector
and your computer. The connectors on theCableWizard are
labeled with icons.
Connect the end of the CableWizard cord to the con-
nector on the projector’s connector panel (Figure 4).
CAUTION: Turn off your
computer,monitor and the
projector whenever you connect
or disconnect cables.
FIGURE 4
Connecting the CableWizard cable to the projector
5 ft.10 ft. 25 ft.
PROJECTOR
Downloaded from ProjectorsManual.com Manuals

7
Selecting Connectors on the CableWizard
Turn the selector on the top of the CableWizard to reveal the
correct connectors for your computer.
FIGURE 5
Selecting connectors on the CableWizard
•If you’re connecting an IBM-compatible desktop or laptop com-
puter,turn theselector until the window displays “PC”.
NOTE: You must disconnect all
cables before turning the selector
on the CableWizard.
FIGURE 6
Selecting the IBM-compatible connectors on the CableWizard
•Ifyou’re connecting a Macintosh desktop or an Apple PowerBook
computer, turn the selector until the window displays “Mac™”
(Figure 7).
computer mouse monitor
audio
Downloaded from ProjectorsManual.com Manuals

8
Setting up the Projector
F
IGURE 7
Selecting the Macintosh connectors on the CableWizard
Preparing to Connect Your Equipment to the Projector
Now you’re ready to connect your equipment. Computers are
connected to the CableWizard. Video players and other equip-
ment, suchas external speakers, are connected directly to the
projector.
NOTE: Before you continue,
make sure the projector and your
equipment are turned off. If you’re
connecting a computer, make sure
the distance between it and the
projector is 10 feet orless and
you’ve selected the appropriate
connectors on the CableWizard.
Steps for connecting different types of equipment are given on
the pages listed below.
mouse
monitor
computer
audio
Computer/Equipment Page
IBM-compatible desktop computer page 9
IBM-compatible laptop computer page 11
Macintosh desktop computer page 13
Apple PowerBook page 15
Video player page 17
External speakers or subwoofer page 19
Microphone page 19
PS/2-compatible mouse page 20
Remote control cable page 20
Downloaded from ProjectorsManual.com Manuals

9
Connecting an IBM-Compatible Desktop Computer
1Locate the cable that connects your monitor to your computer.
Unplug it from the computer.
2Plug the end of the CableWizard computer cable into the
video connector on your computer.
3Plug the end of the CableWizard computer cable into the
connector on the CableWizard.
FIGURE 8
Connecting the CableWizard computer cable to an IBM-compatible desktop computer
Do you want to display the image on your computer’s monitor as
well as on the projection screen?
1Plug your monitor’s cable into the connector on the
CableWizard.
Do you want to play your computer’s audio on the projector?
1Unplug the audio cable, if present, from your computer.
2Plug either end of the CableWizard audio cable into the audio
connector on your computer.
3Plug the other end of the CableWizard audio cable into the
connector on the CableWizard.
computer cable
Downloaded from ProjectorsManual.com Manuals

10
Setting up the Projector
Do you want to control your computer’s mouse from the projector’s
remote or keypad?
1Unplug the mouse cable from your computer.
2Plug the end of the CableWizard mouse cable into the
mouse connector on your computer.
3Plug the end of the CableWizard mouse cable into the
connector on the CableWizard.
FIGURE 9
Connecting the CableWizard monitor, audio and mouse cables to an IBM-compatible
desktop computer
Now you’re ready to power up the projector and your computer.
Skip to “Powering up the Projector and Adjusting the Image” on
page 21.
audio cable
computer mouse cable
monitor cable
cable
Downloaded from ProjectorsManual.com Manuals

11
Connecting an IBM-Compatible Laptop Computer
1Plug the end of the CableWizard computer cable into the
video connector on your computer.
NOTE: Many laptop computers
do not automatically turn on their
external video port when a second-
ary display device such as a projec-
toris connected. Refer to your
computer manual for the com-
mand that activates the external
video port.Activation commands
for some laptop computers are
listed in the Appendix of this man-
ual on page 55.
2Plug the end of the CableWizard computer cable into the
connector on the CableWizard.
FIGURE 10
Connecting the CableWizard computer cable to an IBM-compatible laptop computer
NOTE: If you don’t want audio or
mouse control, you can use the
CableWizard Lite. CableWizard
Lite is ordered separately. See
“Accessories” on page 53.
Do you want to play your computer’s audio on the projector?
1Plug either end of the CableWizard audio cable into the audio
connector on your computer.
2Plug the other end of the CableWizard audio cable into the
connector on the CableWizard.
computer cable
Downloaded from ProjectorsManual.com Manuals

12
Setting up the Projector
Do you want to control the computer’s mouse from the projector’s
remote or keypad?
1Locate the mouse cable and unplug it from your computer.
2Plug the end of the CableWizard mouse cable into the
mouse connector on your computer.
3Plug the end of the CableWizard mouse cable into the
connector on the CableWizard.
FIGURE 11
Connecting the CableWizard audio and mouse cables to an IBM-compatible laptop
computer
Now you’re ready to power up the projector and your laptop.
Skip to “Powering up the Projector and Adjusting the Image” on
page 21.
audio cable
computer
mouse cable
cable
Downloaded from ProjectorsManual.com Manuals

13
Connecting a Macintosh Desktop Computer
1Locate the cable that connects the monitor to your computer.
Unplug it from the computer.
2Plug the end of the CableWizard computer cable into the
video connector on your computer.
3Plugthe endoftheCableWizardcomputercableintothe
connector on the CableWizard.
FIGURE 12
Connecting the CableWizard computer cable to a Macintosh desktop computer
Do you want to display the image on your computer’s monitor as
well as on the projection screen?
1Plug the monitor’s cable into the connector on the
CableWizard.
Do you want to play your computer’s audio on the projector?
1Unplug the audio cable, if present, from your computer.
2Plug either end of the CableWizard audio cable into the audio
connector on your Macintosh.
3Plug the other end of the CableWizard audio cable into the
connector on the CableWizard.
computer cable
Downloaded from ProjectorsManual.com Manuals
