Infomir MAG425A User manual

Instruction Manual
Android TVTM device
MAG425A

Android TV
TM
device MAG425A. Instruction Manual
Regulatory information
EU
This equipment has been tested and found to comply
with the essential requirements of the following
Directives: 2014/30/EU, 2014/35/EU, 2014/53/EU,
2009/125/EC, 2011/65/EU.
This product is in accordance with Directive 2012/19/EU
Hereby, Telecommunication Technologies LLC declares
that the radio equipment type 802.11a/b/g/n/ac
+ Bluetooth Low Energy 4.1 is in compliance with
Directive 2014/53/EU.The full text of the EU declaration
of conformity is available
at the following internet address: www.infomir.com
This device is certied for indoor deployment only in the
5150-5350 MHz band. Do not install or use this device
outdoors in that frequency in the Europian Union.
FCC
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference when the equipment is operated in a
residential installation. This equipment generates,
uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio
or television reception, which can be determined
by turning the equipment o and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment
and receiver.
•Connect the equipment to an outlet on a circuit
dierent from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV
technician for help.
FCC Caution:
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1) this device may not cause harmful interference, and
2) this device must accept any interference received,
including interference that may cause undesired operation.
CAUTION:
Unauthorized antennas, modications, or attachments
could damage the device and violate FCC regulations.

Changes or modications not expressly approved by
responsible party could void the user’s authority to
operate the equipment.
FCC Radiation Exposure Compliance:
This equipment complies with radio frequency (RF)
exposure limits set forth by the Federal Communications
Commission for an uncontrolled environment.
This equipment should be installed and operated
with a minimum distance of 20 centimeters between
the radiator and your body. This transmitter must not be
co-located or operating in conjunction with any other
antenna or transmitter.
Deployment Statement:
This device is certied for indoor deployment only in
the 5150 – 5250 MHz band. Do not install or use this
device outdoors in that frequency in the United States.
Note: Specications are subject to change without notice.
Infomir reserves the right to revise this publication and to
make changes in its content from time to time by posting
new specications and other content at www.infomir.com
Warranty term:
Europe, MEASA and Oceania:
2 years from date of sale (but not more than 2,5 years
from manufacture date).
The USA, Americas, Russia, Ukraine and other regions:
1 year from date of sale (but not more than 1,5 years
from manufacture date).
See the date of manufacture at «Product Information»
section. By virtue of the present Coupon, the absence
of defects in manufacturing of the product and its
compounds is warranted for a year-term counted since
date of sale. If during the mentioned warranty term
the defects of materials or operation of product will be
found, the product would be repaired or its defective
parts would be replaced free of charge in the warranty
processing center with compliance with warranty
conditions.
Warranty

Warranty processing centers
Europe:
ZLS Services GmbH
Hamburger Allee 56
60486, Frankfurt am Main, Germany
Tel.: +49 6196 204 83 18
e-mail: [email protected]om
The USA, Canada and Latin America:
Infomir USA
174 Bay 49th Street
Brooklyn, NY 11214 USA
Tel: +1 631 482 66 36
e-mail: [email protected]
Russia, Belarus:
Tel.: +38 048 759 09 00
e-mail: [email protected]om
MEASA and Oceania:
PROGRESSIVE TECHNOLOGY F.Z.E
Warehouse B1-40
Sheikh Rashid Bin Saeed Al Maktoum Street
Ajman Free Zone, 45573, Ajman, UAE
Tel: +971 6 740 37 55
e-mail: [email protected]om
Ukraine:
Telecommunication Technologies LLC
4/D, Nebesnoi Sotni Avenue
Odesa, 65121, Ukraine
Tel: +38 048 759 09 00
e-mail: [email protected]om
Warranty
Warranty Service Coupon
(to be lled in by a shop-assistant)
Date of Sale:
Company-Seller:
Address of Company-Seller:
Place of Stamp
I have no claims as to appearance and
package contents. I accept the conditions of
warranty service.
Signature of Customer:
Manufacturer:
Telecommunication Technologies LLC,
1 Mytna Square, Odessa, 65026, Ukraine

Warranty conditions
1. The present warranty is only valid if the defective
product is provided with property lled in Warranty
Service Coupon. If date of sale is not pointed, the
warranty term is counted since date of the product
manufacturing which is dened under serial number.
Warranty processing center reserves the right to
refuse free warranty service and parts replacement
in case the mentioned above documents are
not presented or the lled in it information is not
complete or unreadable.
2. The present warranty does not enable the right for
compensation and cover of loss received as a result
of rearrangement of the product.
3. The present guarantee is invalid if model or serial
number of the product is altered, erased, removed
or unreadable, or warranty seal is broken.
4. The present warranty does not cover the following:
4.1. Any adaptations and alterations with the aim of
perfection and widening of the common scope of
the product application specied in the Manual.
4.2. Devices and accessories not specied in the coupon.
4.3. Damage caused in result of:
a) Improper maintenance including but not limited by following:
(1) use of the product not according to its intended purpose
or Manual;
(2) mounting and maintenance of the product in conditions not
corresponding to safety standards and regulations valid in
the country of use;
(3) incorrect software installation provided by service operator.
b) Repair performed by not authorized service centers or dealers;
c) Accidents, lightning stroke, ood, re, incorrect ventilation;
d) Transporting excluding cases when it is carried out by ASC;
e) Faults of system in which the present product had been using.
5. These warranty conditions do not intend to restrict
or limit in any way statutory rights of customers
which may not be altered in some jurisdictions
and other customers’rights which may arise out
of any agreements with third parties, provided
that nothing contained in such agreements states
or implies that the manufacturer or manufacturer
aliates assume any obligations or liabilities other
than those expressly stipulated in this Warranty
Service Coupon.
While maintaining warranty liabilities on product
repair or replacement, Manufacturer takes no
responsibilities for personal data safety, including
logins, passwords, paid or free subscriptions, settings,
portals, media les, content and software installed or
set up by Customer or other third parties.

Copyrights and Trademarks
Notice of Copyright
Telecommunication Technologies LLC. All rights
reserved. The Information contained herein is the
property of Telecommunication TechnologiesLLC
(the Company). Not any part hereof can be copied,
reprinted, transferred, retyped, saved in search
engine, modied or translated into any other
language, including computer one, nor sublicensed
in any way, whether electronic, mechanical,
magnetic, optical, chemical, manual or other one,
without prior written consent by the Company
Manager responsible for the Product. Any Illegal use
of the materials contained herein, by any person,
will lead the person to the responsibility for the
Company’s damages.
Software Use Agreement
IMPORTANT - read carefully: when using the Software
with your device, you agree thereby with every
clauses of the Software Use Agreement. If you do not
agree with the terms and conditions of the Software
Use Agreement, you should immediately stop using
the device and return it to your services provider
completely.
License provision. Limitations
According to this Agreement, Telecommunication
Technologies LLC and your services provider are jointly
to provide you with non-exclusive and non- transferrable
license, without the right to sublicense, for use of all
software and documents with the product only.You
recognize and acknowledge thatTelecommunication
Technologies LLC and your services’provider may regularly
renew, change or extend the product software abilities.You
conrm that:
a) You will not take attempts to change, extend, or
decompile, disassembly, or redesign, nor otherwise get
access to the software source code.
b) You will not take attempts to delete or upload the
product software. Any sale or transfer of the product will be
ruled hereby.
Ownership
The Manufacturer and the Manufacturer’s own licensors
keep all the rights constituting ownership, Including
patent, copyright trademark, and other Intel factual
property for the Software; and any Improvement
and modication of the Software. You recognize and
acknowledge that the license according hereof does not
grant you ownership for the Software but only restricted
right of use It according to provisions of this Agreement.

Warranty for the Software
To the maximum extent according to applicable
law, the Company does not make any submission
and declines any and all warranties, whether
express or implied, as to the Software, including,
with no limitations, any implied demand warranties,
correspondence to target destination, abuse of
rights of third parties, neither those being result of
interrelations or result of commerce. The Company
does not guarantee the Software will be free of
defects or errors; that any defects or errors will be
corrected, or any function abilities of the Software will
meet all your requirements.
Warranty
Warranty for your product is supplied via your
services’ provider. In the event your product requires
maintenance service, you should contact the services’
supplier directly.
Trademarks
, Infomir, MAG - are trademarks of Infomir Group.
Android TVTM is the trademark of Google LLC.
HDMI is the trademark of HDMI Licensing, LLC.
The Bluetooth® word mark and logos are owned by
Bluetooth SIG, Inc.
Copyrights and Trademarks
Manufactured under license from Dolby Laboratories.
Dolby, Dolby Audio, and the double-D symbol are
trademarks of Dolby Laboratories.
DCP is the trademark of Digital Content Protection LLC.
Redesigning and disassembling is illegal. Microsoft
PlayReadyTM is the trademark of Microsoft Corporation.
Content owners use Microsoft PlayReady TM content
access technology to protect their intellectual property,
including copyrighted content. This device uses
PlayReady technology to access PlayReady-protected
content and/or WMDRM-protected content. If the
device fails to properly enforce restrictions on content
usage, content owners may require Microsoft to revoke
the device’s ability to consume PlayReady-protected
content. Revocation should not aect unprotected
content or content protected by other content access
technologies. Content owners may require you to
upgrade PlayReady to access their content. If you decline
an upgrade, you will not be able to access content that
requires the upgrade.
Telecommunication Technologies LLC disclaims
proprietary interest in the marks and names of others.

Product Care
Maintenance of Product
The product should not be disassembled. The tries of
the disassembling of the product may be dangerous
for your life and for serviceability of the product.
The self-supporting disassembling invalidates you
the product guarantee.
The maintenance should be aected by qualied
specialists in the warranty processing centers only.
The product possesses protective sealing.
Breaking or changing of the mentioned sealing
invalidates guarantee of the product.
Cleaning
The product and accessories should be rubbed with
dry cloth or tissue only.
To ensure safety, before shell cleaning switch the
power supply o the alternative current socket.
The shell may be cleaned from persistent spots with
a slightly wet cloth or cleaning tissue.
Do not use cleaner or polish, benzyl, solvents,
abrasive items, liquid or aerosol detergent means for
the product and accessories cleaning.
Terms of using
Safe and Ecient Using
Device does not contain harmful or hazardous
substances.
Accessories
Use the accessories supplied with your arrangement or
recommended by the manufacturer only. Using of the
accessories which are not supplied or not sanctioned
by the manufacturer may be dangerous for the User or
do harm to the arrangement operation. Using of the
not appropriate accessories eliminates guarantees of
the product therewith.
Water and Moisture
To avoid damage that can cause ignition of the present
product or lesion to the User with electrical current, the
product and its accessories should not be undergone
with any liquids, rain or high moisture.
Do not use the present product in the places where it
may be exposed to the contact with a liquid or vapor.

Specications
Physical Parameters
Model MAG425A
Weight: 180 g
Dimensions (approximately): 115 mm depth,
115 mm width, 28 mm height
Operation temperature and Humidity
1C - 40; 5% ~ 93%RH
Ethernet Interface
Ethernet Connector: RJ-45
Speed: 100 Mbit/s
Indicators: Green – Activity, Yellow – Connection
Wi-Fi Interface
Built-in Wi-Fi module: 5GHz ac 2.4GHz b/g/n 2T2R
Operating frequency bands: 802.11 b/g/n 2400-2483.5 MHz,
802.11 a/n/ac 5150-5825 MHz
Output power: 802.11 b/g/n <20 dBm,
802.11 a/n/ac <23 dBm
Bluetooth Interface
Bluetooth 4.1
Operating frequency bands: 2400-2483.5 MHz
Output power: <10 dBm
HDMI Interface
Type: HDMI 2.0
USB Interface
Type: USB2.0, USB 3.0
Supported Audio-Video Formats
Video codecs: H.265/HEVC Main/Main 10 prole,
4K x 2K@60 fps 10-bit decoding;
H.264/AVC BP/MP/HP@level 5.1, H.264/AVC MVC,
4K x 2K@30 fps decoding; 4K x 2K@60 fps 10-bit VP9
decoding; 1080p@60 fps VP6/8 decoding; 1080p@60 fps
MPEG-1 decoding; 1080p@60 fps MPEG-2 SP@ML, MP@HL
decoding; MPEG-4 SP@levels 0−3, ASP@levels 0−5, GMC,
short header format, 1080p@60 fps decoding
Video containers:TS, MTS, AVI, MPEG, MP4, MOV, MKV, M2TS, VOB
Audio Decoder: MPEG L1/L2/L3 AAC-LC, HE AAC V1/V2,
AAC ELD, PCM/WAVE, APE, FLAC, Ogg
This product supports Dolby Digital PlusTM
Subtitles: SRT, SSA/ASS, SUB
Supported video modes: PAL, NTSC, 576p, 720p, 1080p, 1080i, 4K
Power supply Interface
Connector: DC cylindrical 2.1 mm x 5.5 mm
Type: plug-and-socket, DC current, center plus
Input 12V
Power Consumption: max 4W in typical conditions
Outer Power Supply Unit
Type: Pulse with universal inlet
Input: 110-240 VAC, 50-60 Hz. 0,5A max
Output: 12V DC 1A
Package
Type: cardboard box
Dimensions (approx.):
214 mm width, 119 mm depth, 57 mm height
Shipping weight: 517 g

The Product Unpacking and Installation
After the product extraction out of the package it is
necessary to handle it with care, do not drop, shake
it and aord other inuence. The product is designed
for horizontal allocation onto at surface.
Do not place the product onto slippery surface, in place
where it may be exposed to vibration or hazard to drop
and other possible risks to the product to be damaged
which may cause invalidation the product guarantee.
Do not dispose the product onto soft surface like on
the carpet, bed, etc., for such surfaces cease access to
the ventilation openings and complicate air ow that
may cause the product overheating and invalidate
guarantee in result.
Do not locate the product into the furniture in
case of vacant clearance around the product is not
provided for the sucient product ventilation.
Do not place the product in place where it may be
exposed to inuence of direct sunlight, next to the
sources of open re and convectors.
Do not dispose the product on surfaces which in
operating process may get warm, for instance, video
record player or intensier and do not put anything
on the top of the shell as well. Do not cover the
product with anything.
Containing liquids objects, such as vase, plant pot
are not to be placed next to or on the product. Do
not touch or move the product during its operation.
Switch o the product if you need to shift it.
The product is intended for use indoors.
The power supply cord is to be put to prevent its
deformation and jamming and touching it well. The
power supply cord is not to be laid under the carpets
or blocked with anything where any damage may
not be noticed.
For AC/DC Adapter, the socket outlet must be near
the equipment and shall be easily accessible.
Power supply unit
The product should be used with power supply unit
provided by the manufacturer only.
The power supply unit is tted out with plug which
is intended for connecting to socket in your country
usage. In case of the necessity in the product
connecting in other country or in the region with
other data of electric circuit the power supply unit
adopted for use in the specied area should be
received from the manufacturer.
Operation
The outer power supply unit of the product is getting
warm in operation. In case of outer power supply unit
gets hot, switch o promptly and get in touch with the
equipment supplier for its replacement.

Protection from atmospheric electricity or not
using for a long time
On coming the thunderstorm and also in case of the
product is intended to be in no use for a long time,
disconnect the power supply cord out of socket,
switch o Ethernet, video and audio cables. It is to
protect the product from thunder discharges and
power surges in the circuit.
Usage with Plasma Displays
In the product usage for watching with plasma
screens do not pause the picture for more than 5
minutes, otherwise it with other objects as may cause
‘burn-out’ pixels on the screen. It is not considered
as a defect of the product but peculiarity of plasma
screens structure. The producer does not bear the
responsibility for damages had been caused in such
manner.
The Arrangement Designation
The product is intended to select digital audio &
video channels from transport streams, decode and
display them on TV. Any other use is prohibited. It
means Telecommunication Technologies LLC insists
on the product usage in entirely accordant to the law
of copyright. The compliance with the specied laws
leaves on conscience of the user. The unauthorized
copying of the protected materials or spreading of
the specied copies under denite conditions may
violate the law of copyright and is to be previously
adopted by possessor of the rights for the further
commercial use.
Updating Software
The product possesses the capability of automatic
software updating. The manufacturer and your
services provider reserve the right for automatic
software updating to improve the product functional
capability.
During the software updating the product should
not be used for watching and switched o until the
complete software updating. During the software
updating the product switching o is inadmissible.
The updating takes several minutes and since then
you are able to continue enjoy on all delights of
digital television services.

1. Fn button - Reset to factory
settings
2. USB
3. LED
4. Standby mode On/O
1. MicroSD
2. HDMI
3. Ethernet
4. Power Supply
Front Panel
Back Panel
About your MAG425A

Connecting with HDMI
Connecting to MAG425A
Warning! Switch o all the devices (TV, amplier, etc.) and take the power supply unit out of the socket
before connecting or disconnecting any cable.

Using Remote Control to control the Device
This section explains how to unpack Remote Control
(RC) and prepare it for work. Remote Control
requires two batteries type AAA, R03, LR03, UM-4, 286.
Important information about using batteries. Do
not mix dierent types of battery or old and new
batteries. Do not use rechargeable batteries with
the remote control. Remove the batteries from the
remote control if you are not going to use it for
several weeks, to avoid the risk of leakage. Please
respect your environment and any local regulations
and dispose of old batteries in a responsible manner.
Caution! Do not attempt to recharge the
batteries.Immediately remove any leaking
batteries. Take care when handling leaking
batteries as they may cause burns to the
skin or eyes, or other physical injuries.
Manual RС Pairing
1) Press the <<OK + HOME>> on RCU simultaneously
for 3 seconds, the LED blinks to acknowledge.
2) Hold (>2s) the “Standby mode On/O”button on
the top of the STB to run pairing process.
3) If pairing is successful, LED will provide
a conrmation blink.

RCU
Power
Mute
Vol –
Back
EPG
D-pad up
D-pad left D-pad right
D-pad down
D-pad center
(Select)
Vol +
Assistant/
Microphone
Play/Pause
Home
Apps

Product information
Product:
Serial Number:
MAC:
The set includes the following:
Set-Top Box
External Power Supply 12V
Remote Control
AAA batteries
Instruction manual
Package box
- 1 pcs.
- 1 pcs.
- 1 pcs.
- 2 pcs.
- 1 pcs.
- 1 pcs.
Optionally the set may include the following:
LAN network cable
HDMI cable length less than 3 m
IR Remote control
- 1 pcs.
- 1 pcs.
- 1 pcs.
Table of contents
Popular TV Tuner manuals by other brands

Fenger
Fenger FIP-1100 Installation & configuration manual

Hauppauge
Hauppauge WinTV-NOVA-S-USB2 (DVB-S) Quick installation guide

Pioneer
Pioneer GEX-P6400TVP Operation manual

tbs electronics
tbs electronics TBS6909 instruction manual

Eminent
Eminent EM7680 manual

Digital Devices
Digital Devices DuoFlex C/T installation instructions
