INFRARED CAMERAS T-CAM 380 P Series User manual

USER MANUAL
PLEASE READ THIS MANUAL BEFORE SWITCHING THE UNIT ON.
IMPORTANT SAFETY INFORMATION INSIDE.
2105 W. Cardinal Dr. Beaumont, TX 77705
ICI cameras fall under US Federal Law and Export Control.
Edit Text Outlines
IndustryIndustry

T-CAM 380 P-SERIES USER MANUAL
2
Revision History
Document created
Fixed typographical inaccuracies and updated manual layout

T-CAM 380 P-SERIES USER MANUAL
3
1.
2.
4.
5.
6.
7.
Contents
Disclaimers 6
1-1 Terms and Conditions......................................................................... 6
1-2 U.S. Government Regulations ............................................................. 6
1-3 Copyright ............................................................................................. 6
1-4 Quality Assurance ............................................................................... 6
1-5 Customer Help ..................................................................................... 6
7
2-1 Calibration........................................................................................... 7
2-2 Accuracy ............................................................................................. 7
2-3 Cybersecurity..................................................................................... 7
2-4 Disposal of Electronic Waste ............................................................ 7
2-5 Intended Use ..................................................................................... 8
2-6 Manual Update ................................................................................... 8
2-7 Scope of Application ......................................................................... 8
2-8 Authoritative Versions ...................................................................... 8
2-9 Training .............................................................................................. 9
12
14
5-1 Appearance and Definitions of Housing Interface ........................ 14
15
16
7-1 Tripod Setup..................................................................................... 16
7-2 Battery Installation ........................................................................... 18
7-3 Memory Card Installation.................................................................20
7-4 Charging Instructions: Option 1........................................................21
7-5 Charging Instructions: Option 2 ...................................................... 22
8-1 How to Charge the Battery .............................................................23
8-1-1 Charging via Type-C Cable................................................ 23
8-1-2 Charging via Power Adapter (not included)...................... 23
8-2 Power On/Off the Device.................................................................23
8-3 Power On/Off the Laser ...................................................................23
8-4 User Interface...................................................................................24
8-5 Open the Main Menu........................................................................24
8-6 Close the Main Menu .......................................................................24
8-7 Capture an Image or Video.............................................................. 25
8-8 Adding Voice Annotations to an Image or Video ...........................25
8-9 Review Images or Videos ................................................................26
8-10 Playing Videos .................................................................................26
8-11 Delete Images/Videos......................................................................26

T-CAM 380 P-SERIES USER MANUAL
4
8-12 Rename Images or Videos ..............................................................27
8-13 Center Point Temperature Measurement ......................................27
8-14 Hot Spot Temperature Tracking.....................................................27
8-15 Cold Spot Temperature Tracking ...................................................28
8-16 Spot Temperature Measurement ...................................................28
8-16-1 Move a Spot Temperature Measurement.......................28
8-16-2 Delete a Spot Temperature Measurement......................28
8-17 Line Temperature Measurement ....................................................29
8-17-1 Move a Line Temperature Measurement........................29
8-17-2 Delete a Line Temperature Measurement.......................29
8-18 Area Temperature Measurement ...................................................29
8-18-1 Move an Area Temperature Measurement.....................30
8-18-2 Delete an Area Temperature Measurement...................30
8-19 Image Modes ...................................................................................30
8-19-1 Image Alignment................................................................ 31
8-19-2 PIP Location.......................................................................32
8-20 Polarity..............................................................................................32
8-21 Auto Gain Control (AGC) and Manual Level & Span Adjustment..33
8-21-1 Auto Gain Control (AGC)...................................................33
8-21-2 Manual Level & Span Adjustment.....................................33
8-22 Emissivity .........................................................................................34
8-23 Non-uniformity Correction (NUC) .......................................................35
8-24 Ambient Temperature...........................................................................36
8-25 Temperature Units ................................................................................36
8-26 Distance .................................................................................................37
8-27 Distance Units........................................................................................37
8-28 Alarm Settings..................................................................................38
8-28-1 Enable Alarms....................................................................38
8-28-2 Temperature Threshold Adjustment ................................38
8-29 Transferring Image and Video Files to a Computer ...........................39
8-29-1 MicroSD Card ......................................................................39
8-29-2USB Mode ............................................................................39
8-29-3Live Streaming to a Computer ...........................................40
8-30 Temperature Scales..............................................................................40
8-31 WLAN Hotspot....................................................................................41
8-32 Date and Time Settings........................................................................42
8-33 Language Settings................................................................................42
8-34 Display Brightness Settings...............................................................43
8-35 Power Management Settings...............................................................43
8-36 Device Information..............................................................................44
8-37 Format the SD Card.............................................................................44
8-38 Factory Reset the Device.....................................................................45
46
9.

T-CAM 380 P-SERIES USER MANUAL
5
9-1 Cleaning the Germanium Lens..........................................................46
9-2 Disinfecting the Camera Surface.....................................................46
9-3 Device Calibration.............................................................................46
9-4 Storage ..............................................................................................46
47
10-1 Thermal imager does not power on...............................................47
10-2 Thermal imager shuts off unexpectedly........................................47
10-3 No thermal image ............................................................................47
10-4 Unclear or dark visible images .......................................................47
10-5 Temperature readings are incorrect ..............................................47
10-6 Camera out of focus........................................................................48
10-7 Memory card error...........................................................................48
49
11.

T-CAM 380 P-SERIES USER MANUAL
6
1. Disclaimers
Warranty Terms and Condition of Sale are made available online at:
This product may be subject to U.S. Export Regulations. Please send any
© 2021, Infrared Cameras, Inc. All rights reserved worldwide. No parts of the
software including source code may be reproduced, transmitted, transcribed
or translated into any language or computer language in any form or by any
means, electronic, magnetic, optical, manual or otherwise, without the prior
written permission of Infrared Cameras, Inc.
The documentation must not, in whole or part, be copied, photocopied,
reproduced, translated or transmitted to any electronic medium or machine
readable form without prior consent, in writing, from Infrared Cameras, Inc.
Names and marks appearing on the products herein are either registered
trademarks or trademarks of Infrared Cameras, Inc. and/or its subsidiaries. All
other trademarks, trade names or company names referenced herein are used
for identification only and are the property of their respective owners.
Infrared Cameras, Inc. is committed to a policy of continuous development;
therefore we reserve the right to make changes and improvements on any of
the products without prior notice.
For customer help, visit:
https://infraredcameras.com/support/
E-mail:
suppor[email protected]

T-CAM 380 P-SERIES USER MANUAL
7
Annual calibration to the thermal camera is recommended. Contact customer
service to schedule maintenance.
For very accurate results, we recommend that you wait a minimum of 5 minutes
after you have started the camera before measuring a temperature.
2. User Notice
substances that may be hazardous and present a risk to human health and
handled correctly.
Equipment marked with the below crossed-out wheeled bin is electrical and
electronic equipment. The crossed-out wheeled bin symbol indicates that
waste electrical and electronic equipment should not be discarded together
with unseparated household waste, but must be collected separately.
All local authorities have established collection schemes under which residents
can dispose of equipment at a recycling center or other collection points, or
WEEE will be collected directly from households. More detailed information is
available from the administration of the relevant local authority. Always dispose
of waste in accordance with local, state, and federal regulations.
After the products are connected to the Internet, they may face risks including
but not limited to network attacks, hacker attacks, virus infections, etc. The
company will not be responsible for the abnormal operation of the products and
any loss or liability caused therefrom shall be at your own risk.

T-CAM 380 P-SERIES USER MANUAL
8
The user manual will be updated from time to time. To access the latest manuals,
translations of manuals, and notifications, go to:
The manufacturer reserves the right to alter the specifications of the product
without prior notification. The manufacturer allows himself the right to modify
without any preliminary opinion the technical specifications of the product.
The authoritative version of this publication is English. In the event of
divergences due to translation errors, the English text has precedence.
Any late changes are first implemented in English. Other languages may or may
not be available.
are used for surface temperature assessment of
energy emitted from the first 1/1000th of an inch of a subject.
Environment of use: industrial and petrochemical buildings, electrical plants,
security rooms, science labs, animal reserves as well as environmental
conservatories, and aerial integrations, among others.
You agree that this product is for civilian use only, and shall not use applications
that may infringe the rights of third parties, medical and safety devices or other
applications where product failure may lead to life-threatening or personal injury,
as well as weapons of mass destruction, chemical and biological weapons,
nuclear explosions, unsafe use of nuclear energy, dangerous or humanitarian
purposes. Any loss or liability caused therefrom shall be at the your own risk.
Infrared Cameras, Inc. issues generic manuals that cover several cameras
within a model line.
This means that this manual may contain descriptions and explanations that do
not apply to your particular camera model. This manual may contain technical
inaccuracies or typographical errors.

T-CAM 380 P-SERIES USER MANUAL
9
To read about infrared training, visit:

T-CAM 380 P-SERIES USER MANUAL
10
3. Safety Information
•
interference received, including interference that may cause undesired
operation.
• To prevent eye damage and personal injury, do not look into the laser. Do
not point the laser directly at people or animals or indirectly off reflective
surfaces.
• Do not disassemble or modify the thermal device.
• Do not point the imager (with or without the lens cover) at intensive energy
sources, e.g. devices that emit laser radiation, or the sun. This can affect
the accuracy of the camera, and cause damage to the detector.
• Do not use the imager in an ambient temperature outside of the operation
range. High/low temperatures can cause damage to the device.
• Always charge the battery in the special temperature range. The
Charging the battery at temperatures outside this range can cause the
battery to become hot or to explode. It can also decrease the performance
or the life cycle of the battery.
• Do not continue to charge the battery if it does not become charged in
the specified charging time. If you continue to charge the battery, it can
become hot and cause an explosion or ignition. Injury to persons can occur.
• Do not attach the batteries directly to a car’s cigarette lighter socket. Using the
incorrect equipment can cause the battery to become hot or cause an
explosion.
• Only use the correct equipment to discharge the battery. Using the
incorrect equipment can decrease the performance or the life cycle of the
battery. Using the incorrect equipment can cause the battery to become
hot or cause an explosion.
• Do not connect the positive terminal and the negative terminal of the
battery to each other with a metal object (such as wire). Damage to the
batteries can occur.
• The battery contains safety and protection devices which, if they become
damaged, can cause the battery to become hot, or cause an explosion or
an ignition.
• Do not put holes in the battery with objects. Damage to the battery may occur.
• Do not hit the battery with a hammer or apply strong impacts or electric
shocks to it. Damage to the battery may occur.
• Do not put the battery in or near a fire, stove or other high-temperature
locations. Damage or ignition of the battery may occur.
• Do not put the battery in direct sunlight or other high-temperature
locations. Damage or ignition of the battery may occur.
• Do not solder directly onto the battery. Damage to the battery may occur.

T-CAM 380 P-SERIES USER MANUAL
11
• Do not get water or salt water on the battery or device or permit the device
or battery to get wet. Damage to the battery may occur.
• Remove any water or moisture on the battery before you install it. Damage
to the battery may occur.
• If there is a leak from the battery and the fluid gets into the eyes, do not
rub the eyes. Flush well with water and immediately get medical care.
• Always dispose of battery in accordance with local, state and federal
regulations.
• Do not use the battery if, when used, charged, or placed in storage, there
is an unusual smell from the battery, the battery feels hot, changes color,
changes shape, or is in an unusual condition. Speak with a sales office if
one or more of these problems occurs.
• Clean the case with a damp cloth and a weak soap solution. Do not use
abrasives, isopropyl alcohol, or solvents to clean the case or lens/screen.
• Be careful when cleaning the infrared lens. Do not clean the infrared lens
too vigorously. This can damage the anti-reflective coating.
• Avoid condensation. Taking the imager from cold to hot will cause
condensation in thermal imager. To protect the imager, power on the
device and wait until it becomes warm enough for the condensation to
evaporate.
• Keep device out of reach of children.
• After the eyepiece is used for long time, its contrast will be lowered, and
the scene will be whitened. You can switch to the LCD display, and switch
back to the eyepiece some time later.
• Storage: If you do not use the imager for a long period of time, put the
device in a cool and dry environment. Batteries should be stored in an
will discharge time and should be fully charged before storage. It is
recommended to fully recharge the batteries every 3 months to prevent
damage. Store the device in an ambient temperature of -40 °C to 70 °C

T-CAM 380 P-SERIES USER MANUAL
12
Accuracy ± 2 °C (± 3.6 °F) or ± 2%
-20 °C to 550 °C (-4 °F to 1022 °F)
-10 °C to 50 °C (14 °F to 122 °F)
-20 °C to 60 °C (-4 °F to 140 °F)
Detector Array UFPA (VOx)
FOV 43.7° x 31.9°
IFOV 1.98 mrad
3.2 mm
Focus Manual
< (50 mK) 0.05 °C at 30 °C (86°F)
25 Hz
10% to 95% non-condensing
> 99 %
2 m (6.56’)
25 G/2 G
256.4 mm x 105.1 mm x 105.3 mm (L x W x D ± 0.5 mm)
(10.09” x 4.14” x 4.15” (L x W x H ± 0.02”))
5 V DC 2 A
Li-ion, rechargeable/replaceable
Operation Time 4 hours
3 hours
Adjustable
670 g (1.48 lbs)
Interface USB Type-C, MicroSD
MP4 (without data)
IR JPG
7 options
IR, Fusion (ICI Dual Vision), Visible, Picture-in-Picture
Data Transmission USB Type-C, WiFi support
4. Technical Specifications

T-CAM 380 P-SERIES USER MANUAL
13
Screen
0.01 to 1.0
°C, °F, °K
IP54
Adjustable
5 MP
No
No
Yes
Yes
Yes
No
Class II 650 nm, < 1 mW
Multinational
Voice annotation

T-CAM 380 P-SERIES USER MANUAL
14
1. Lens Cover
2. Laser
3. Digital Camera
4. Shutter Trigger
5. Germanium Lens
6. SD Card Slot
7. USB Slot
5.
1.
2.
3.
4.
7.6.
8. Touchscreen
9. Previous/Back (Cancel)
10. OK/Menu
11. Navigation (up, down, left, right)
12. Microphone
13. Review
14. Power/Laser
12.
13.
14.
10.
8.
9.
11.
5. Structure

T-CAM 380 P-SERIES USER MANUAL
15
T-Cam device USB to Type-C Cable
Battery ChargerBattery x2
Power Adapter MicroSD Card
6. Package Includes

T-CAM 380 P-SERIES USER MANUAL
16
or
Mount the fully charged T-Cam
to a tripod using the ¼-20
mount located on the bottom of
the device handle.
The T-Cam can be used
as a handheld device.
A.
7. Quick Start Instructions

T-CAM 380 P-SERIES USER MANUAL
17
B.
Power on device.

T-CAM 380 P-SERIES USER MANUAL
18
A.
C.
B.
D.
Hold the camera firmly in both hands
placing a thumb on the grip lines.
Keep pressing the grip lines and
pull battery cover up to remove it.
Press the grip lines firmly
to create a gap.
Ensure metal contacts are aligned,
then push battery into battery bay.

T-CAM 380 P-SERIES USER MANUAL
19
F.
G.
E.
Pressing the grip lines, align
battery cover to battery bay and
press the cover toward the device.
Close gap by releasing the battery cover.
To replace a battery held in the
battery bay push the battery
buckle. Battery will be ejected.

T-CAM 380 P-SERIES USER MANUAL
20
A.
Insert the Micro-SD Card into the
top of the T-Cam device until a
clicking sound is heard.
Table of contents
Other INFRARED CAMERAS Thermal Camera manuals
