INIM NRB100 Assembly instructions

1
Installation and programming manual
NRB100
Self-powered hornstrobe
for outdoor use
Installation and programming manual

2
NRB100 Self-powered hornstrobe
Table of
contents
Table of contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Chapter 1 Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1-1 About this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1-2 Manufacturer's details. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1-3 Product description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Chapter 2 Hornstrobe description . . . . . . . . . . . . . . . . . 4
2-1 Box contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2-2 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2-3 Lights signalling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Chapter 3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . 8
3-1 Installation guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3-2 2 wire connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3-3 3 wire connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3-4 Extra connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Chapter 4 Programming . . . . . . . . . . . . . . . . . . . . . . . . 10
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Directives 2004/108/EC (EMCD) and 2006/95/EC (LVD). . . . . . . . . 11

Overview 3
Installation and programming manual
Chapter 1
OVERVIEW
1-1
About this manual
MANUAL CODE DCMIINE0NRB100
REVISION 2.00
1-2Manufacturer's details
Manufacturer: INIM Electronics s.r.l.
Place of production: Via Fosso Antico - Centobuchi
63076, Monteprandone (AP) - Italy
Tel.: [phone]
Fax: [phone]
e-mail: [email protected]
Web: www.inim.biz
Any persons authorized by the manufacturer to repair or replace any part of this
device hold authorization to work on INIM Electronics devices only.
1-3Product description
The heavy duty NRB100 hornstrobe unit is especially designed to allow maximum
installation flexibility and durability.
A microprocessor continuously monitors all the device parameters and assures high-
reliability and first-rate performance.
A tamper output with a configurable balance resistor permits full-integration with
every type of system.
Optimized flexibility allows you to choose the wiring method you prefer (activation and
signalling by means of 2 or 3 wires, etc.).
Ready-to-go factory settings (refer to Table 6 "Programming phases") ensure fast and
easy installation with few or even no changes.
MAIN FEATURES • Power supply and alarm trigger input
• Alarm trigger input (BELL)
• Alarm trigger input (FLASH)
• Trigger input for ancillary LED
• Programmable input polarity
• Tamper signal output
• Strobe flasher
•Piezoelectrichorn
• 4 Programmable tones
• Dislodgement and open-casing protection
• Battery test circuit
• Houses 12V 2.1Ah backup battery
•IP34Rated
• Security rating 2
• Standards applied: EN 50131-1:2006+A1:2009
EN 50131-4:2009
CEB T014:2013-04 (ed.3)
• Stainless-steel casing

4Hornstrobe description
NRB100 Self-powered hornstrobe
Chapter 2
HORNSTROBE
DESCRIPTION
2-1
Box contents
Inside the box you will find:
• NRB100 hornstrobe
• 2 frontplate screws (4x22)
• 3 wall plugs (screw 4x35) for mounting the backplate
• 1 wall plug (screw 3.5x50) for tamper microswitch
• Plastic spacer
• Installation and programming manual
• Drilling pattern
2-2Technical description
Note The devices that supply power to the hornstrobe must have a limit of 1.5 A.
The material of the backup battery case must be HB flammability class or better.
The maximum duration of the alarm sound of the warning device may be subject to
variation depending on local or national requirements.
Table 1: Technical specifications
Supply voltage nominal
13.8V
range 13.2 - 14.0 V
Current draw minimum
40 mA
maximum 70 mA
Warning device type
for outdoor use, self-powered,
type Z
Horn output
(l=3m)
110 dB(A)
Acoustic output type tones
Flashes per minute 30
Maximum alarm time
(maximum sound time duration)
8 min
Protection rating IP34
Security grade (EN50131-4) 2
Environmen-
tal operating
conditions
Temperature
from -25 to +70 °C
Relative humidity 93% without condensation
Environmental class (EN50130-5) IV
Battery 12V - 2.1Ah
Installation wall mounting
Dimensions (L x H x D) 293 x 203 x 52 mm
Weight (without battery) 1.5 Kg

Hornstrobe description 5
Installation and programming manual
Table 2: Description of parts
A Terminal board
B Programming button
C Battery wires
D Jumpers for tamper balance configuration
E STATUS LED - Red
F PRG LED - Green
G Red programming LEDs
H Strobe
I Open casing and Dislodgement tamper microswitch
L Frontplate
M Grill
N Frontplate screw locations
O Cable entry
P Backbox screw locations
Q Tamper- microswitch screw location
R Battery housing
S Piezoelectric horns
Table 3: Terminal board
n. icon/
name Description
1+
Positive power terminal supports 13.8V.
In 2-wire connections, this terminal will also
operate as an alarm trigger.
2- Negative power terminal
3+-B
BELL trigger terminal with programmable
polarity
4+-F
Strobe trigger terminal (FLASH) with pro-
grammable polarity
5 - 6 T/AF
Tamper terminal with configurable balance
resistors
7LED LED activation signal input
FW0000NRB100
X.XX
0118
0155-0019
ATR16-SP
03/06/2009
QC
Passed
SBQC0000IN057
AB
E
F
H
G
C
I
D
L
N
N
M

6Hornstrobe description
NRB100 Self-powered hornstrobe
WARNING! Do not touch the hornstrobe board while the Mains is connected.
Electric shock risk!
O
N
N
M
P
P
I
Q
R
S
O
P
N
N
P
P
Q
M

Hornstrobe description 7
Installation and programming manual
2-3Lights signalling
STROBE FLASHER The strobe (Table 2, H) will flash at 2 second intervals in the event of tamper (wire
cutting) or when activated via the +-F terminal.
STATUS LED This LED (Table 2, E) will blink at 2 second intervals during the installation phase.
During normal functioning, it will blink at half-second intervals if the battery drops
below 11V (if this occurs, the horn and strobe flasher will shutdown). This LED will
stop signalling the battery fault when the battery voltage restores to above 12V.
If duly programmed, this LED can be activated directly via the LED terminal (refer to
paragraph 3-4 Extra connections and Chapter 4 - Programming).
PRG LED This LED (Table 2, F) is activated via the LED terminal (refer to paragraph 3-4 Extra
connections and Chapter 4 - Programming).
PROGRAMMING
LEDS
These LEDs (Table 2, G) signal the current Programming phase and any save
operations relating to the selected settings (refer to Chapter 4 - Programming).
Table 4: Tamper device
A Tamper screw
B Spacer
C Microswitch
D Screw location
E Microswitch-block location
F Rawplug
G Frontplate screw
H Frontplate screw location
A
B
C
F
G
H
ED

8Installation
NRB100 Self-powered hornstrobe
Chapter 3
INSTALLATION
The hornstrobe should be mounted high up on an even surface, in such way that it is
out of reach but clearly on view and therefore may serve as a visible deterrent against
break-in.
3-1Installation guidelines
1. Remove all power.
WARNING! Before opening the hornstrobe, wait 30 seconds at least. Electric
shock risk!
2. Open the device casing.
3. Configure the balance resistor (refer to paragraph 3-4 Extra connections), if you
wish to forward tamper signals to the control panel.
4. Pull the connection wires through the cable entry (Table 2, O).
5. Using the wall plugs, attach the backplate to the wall (Table 2, N).
Note Ensure that the grill (Table 2, M) is located on the under part of the device.
6. If you want to enable the tamper remove the microswitch-block from its loca-
tion (Table 4, E), then insert into this location the spacer (Table 4, B) and the
screw (Table 4, A); be careful the microswitch (Table 4, C) position is below the
screw.
7. Locate the battery into its housing (
Table 2, R ) and complete the wiring. Ensure
that the battery polarity is correct.
8. Complete the device wiring. The STATUS LED (Table 2, E) will blink at 2 second
intervals during this phase.
9. Configure the device as described in Chapter 4 - Programming.
10. Using the screw locations (Table 2, N) for correct alignment, close the casing
and secure it in place with the screws. The tamper microswitch (Table 2, I) will
close and the STATUS LED will bink at half-second intervals.
11. Powerup the device. The STATUS LED will go Off.
3-22 wire connection
This standard wiring method triggers the device using a "Positive Removed" signal.
This wiring method needs to disable through programming the inputs +-B and +-F or
to connect the terminals of these imputs with the + power terminal.
The "Positive Removed" signal will trigger both the horn and strobe.

Installation 9
Installation and programming manual
3-33 wire connection
This wiring method triggers alarm signalling on the both the horn and strobe through
the +-B and +-F inputs.
The +-B and +-F inputs must be configured as "Negative Removed" (refer to Table 6
"Programming phases").
The wiring diagram shows a 3 wire connection configured as "Negative Removed".
The "Positive Removed" signal will still trigger both the horn and strobe.
3-4Extra connections
The STATUS and PRG LEDs (Table 2, E and Table 2, F) can be activated by connecting
the LED input to Negative (-).
f you wish to forward tamper signals to the intrusion control panel, connect terminals
5and 6of the Hornstrobe terminal board directly to a terminal on the intrusion
control panel.
The balance resistance is zero at default but can be configured directly on the
Hornstrobe motherboard by cutting the jumpers B1, B2 or B3 (Table 2, D).
The balance resistance value (obtained by cutting the jumpers) resulting from the
configuration of the jumpers is shown in the following table:
In the event of tamper, the contact on terminals 5and 6will open.
Table 5: Tamper balance resistance
Resistor
(Ohm) Jumpers
B1 (1-2) B2 (3-4) B3 (5-6)
0CLOSECLOSECLOSE
1K OPEN CLOSE CLOSE
2K2 CLOSE OPEN CLOSE
3K2 OPEN OPEN CLOSE
4K7 CLOSE CLOSE OPEN
6K9 CLOSE OPEN OPEN
7K9 OPENOPENOPEN
1K 2K2 4K7
Tamper

10 Programming
NRB100 Self-powered hornstrobe
Chapter 4
PROGRAMMING
The Hornstrobe can be programmed only during the installation, therefore, it is
necessary to ensure that:
• the device is not powered; battery and mains must be disconnected
• the tamper microswitch is open
• the intrusion control panel is set to ignore tamper on the Hornstrobe (e.g. in
programming status)
To change the default settings, work through the following steps:
1. Remove the Hornstrobe frontplate.
2. Powerup the device; the red LED will blink at 2 second intervals.
3. Press and hold the PROGRAM button (Table 2, B), programming LEDs B1, B2 and B3
(Table 2, G) will blink in binary sequence in order to allow you to select one of the 5 pro-
gramming phases.
4. To select a phase, release the PROGRAM button when the LEDs indicate the combination
that indicates the desired phase (refer to
Table 6 "Programming phases" ).
5. The combination of blinks on the STATUS and PRG LEDs indicates the current configura-
tion of the selected phase. To change the configuration, press and release the PROGRAM
button instantly until the desired combination of blinks appears on the STATUS and PRG
LEDs.
6. To exit the programming phase, wait 20 seconds without touching the PROGRAM button.
The Programming LEDs will blink to signal the end of the programming session.
7. Complete the installation phase in accordance with the instructions described in para-
graph 3-1 Installation guidelines at step 10.
DCMIINE0NRB100-R200-20160429
Table 6: Programming phases
Phase Programming LEDs STATUS
LED PRG LED Programming
DL3 DL2 DL1
0 OFF OFF OFF - - Exits programming without saving changes
1OFFOFFON
OFF OFF Input
+-B deactivated
OFF ON Input
+-B activated
The Horn will activate if Negative is Removed
ON OFF Input
+-B activated
The Horn will activate if the Positive is Removed at
DEFAULT
2 OFF ON OFF
OFF OFF Input
+-F deactivated
OFF ON Input
+-F activated
The strobe will activate if Negative is Removed
ON OFF Input
+-F activated
The strobe will activate if Positive is Removed at
DEFAULT
3 OFF ON ON
OFF OFF
LED Input deactivated
OFF ON
LED Input activates STATUS LED
ON OFF
LED Input activates PRG LED at DEFAULT
ON ON LED Input activates STATUS and PRG LEDs
4ONOFFOFF
OFF OFF Select tone no.1 for the Horn
at
DEFAULT
OFF ON Select tone no.2 for the Horn
ON OFF Select tone no.3 for the Horn
ON ON Select tone no.4 for the Horn
5ONONON
OFF OFF Horn activated - Strobe activated at
DEFAULT
OFF ON Horn activated - Strobe deactivated
ON OFF Horn deactivated - Strobe activated
ON ON Reset factory default settings

11
Installation and programming manual
Warranty INIM Electronics s.r.l. (Seller, Our, Us) warrants the original purchaser that this
product shall be free from defects in materials and workmanship under normal use for
a period of 24 months. As INIM Electronics s.r.l. does not install this product directly,
and due to the possibility that it may be used with other equipment not approved by
Us; INIM Electronics s.r.l. does not warrant against loss of quality, degradation of
performance of this product or actual damage that results from the use of products,
parts or other replaceable items (such as consumables) that are neither made nor
recommended by INIM Electronics. Seller obligation and liability under this warranty is
expressly limited to repairing or replacing, at Seller's option, any product not meeting
the specifications. In no event shall INIM Electronics s.r.l. be liable to the purchaser or
any other person for any loss or damage whether direct ot indirect or consequential or
incidental, including without limitation, any damages for lost profits, stolen goods, or
claims by any other party caused by defective products or otherwise arising from the
incorrect or otherwise improper installation or use of this product.
This warranty applies only to defects in parts and workmanship relating to normal use.
It does not cover:
• damage arising from improper maintenance or negligence
• damage caused by fire, flood, wind or lightning
•vandalism
• fair wear and tear
INIM Electronics s.r.l. shall, at its option, repair or replace any defective products.
Improper use, that is, use for purposes other than those mentioned in this manual will
void the warranty. Contact Our authorized dealer, or visit our website for further
information regarding this warranty.
Limited war-
ranty
INIM Electronics s.r.l. shall not be liable to the purchaser or any other person for
damage arising from improper storage, handling or use of this product.
Installation of this Product must be carried out by qualified persons appointed by INIM
Electronics. Installation of this Product must be carried out in accordance with Our
instructions in the product manual.
Copyright The information contained in this document is the sole property of INIM Electronics
s.r.l. No part may be copied without written authorization from INIM Electronics s.r.l.
All rights reserved.
Directives
2004/108/
EC (EMCD)
and 2006/
95/EC (LVD)
Hereby INIM Electronics s.r.l. declares that NRB100 sounders are in compliance with
the essential requirements and other relevant provisions of directive 2004/108/EC and
2006/96/EC.
The full declarations of conformity of the above-mentioned devices are available at
URL:
www.inim.biz\certifications

via Fosso Antico snc - fraz. Centobuchi
63076 Monteprandone (AP) ITALY
Tel. [phone] _ Fax [phone]
[email protected] _ www.inim.biz
ISO 9001 Quality Management
certified by BSI with certificate number FM530352
