Ink Bird IHC-200-WIFI User manual

尺寸：80x160mm
类型：翻书

IHC-200-WIFI
Humidity Controller
(English)
%RH
%RH
SV
PV

Contents
Introduction01 -------------------04
Product Features02 ---------------05
Specifications03 -----------------05
Wi-Fi Connection04 --------------06
Settings05 ------------------------11
Basic Operations06 ---------------13
Sensor Fault Alarm07 ------------17
Important Safeguards08 ----------17
Warranty09 -----------------------18

Introduction
US Sockets
EU Sockets
UK Sockets
AU Sockets
01
ʏ PV: In the normal mode, it displays current
humidity; in the setting mode, it displays menu
code.
ʐ SV: In the normal mode, it displays the
setting humidity value; in the setting mode, it
displays the setting value.
ʑ Red Indicator Light: The indicator light will
turn red when the humidification output is on
and the indicator light will turn off when the
humidification output is off.
ʒʓGreen Indicator Light: The indicator light
will turn green when the dehumidification
output is on and the indicator light will turn off
when the humidification output is off. If the
green indicator light blinks, the device is in the
mode of dehumidification delay protection
state and the humidification output is off.
ʔ WORK1: Humidification Output Socket.
ʕ WORK2: Dehumidification Output Socket.
ʖ Setting Button( ), Increase Button( ),
Decrease Button( ): More details on Settings.
WIFI
SET
%RH
%RH
ʗʘ
ʒ
ʔ
ʓ
ʙ
ʕʖ
ʗʘ
ʗʘ
ʗʘ
4

Product Features
02
Plug-n-Play
Dual Relay Output: Support both humidifying
equipment and dehumidifying equipment at
the same time.
Display Screens: Display set humidity value
and the measured humidity value at the
same time.
Support Humidity Calibration
Support Dehumidification Control Delay
Protection
Settable High/Low Humidity Alarm
Probe Fault Alarm
Wi-Fi Smart App
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Specifications
03
;TQYFLJ;FH-_
Current: 10A
Maximum Power:
1200W (120Vac), 2200W (220Vac)
-ZRNINY^2JFXZWJRJSY7FSLJc7-
Humidity Display Accuracy: 0.1%RH
7JQFYN[J-ZRNINY^&HHZWFH^YT7-
Typ: ±3%RH, Max: ±5%RH
Display Unit: %RH
Operating Ambient Temperature:
өcөӬcӬ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
5

Wi-Fi Connection
04
8YTWFLJ9JRUJWFYZWJөcөӬcӬ
8YTWFLJ-ZRNINY^c7-
(not frozen or dewed)
Warranty:
Controller: 2 years
Probe: 1 year
Ɣ
Ɣ
Ɣ
Scan QR code to download
6
Pro APP
4.2 Connect to your phone
ʒRegister before using the Pro app. Select
your Country/Region, enter your
e-mail, then a verification code will be sent
to your mailbox, enter it to confirm your
identity and the registration is done.
4.1 Download Pro App
Search the keyword “Pro App” in Appstore r
Google Play to get the app, or you can scan
the following QR code directly to download
and install the app.

ʔTap “+” or “add device” button in home
page of the APP to add the device.
ʕPress and hold the button for 2
seconds to reset the Wi-Fi when the
controller is under normal working state.
The controller will enter the Smartconfig
configuration state by default. You can short
press the button to switch between the
Smartconfig configuration mode and the AP
mode.
As the WIFI module need time for data
processing, so it will take about 5 seconds
to display the corresponding LED symbol
and state if the Wi-Fi states change.
4.3 Quick Connection
(1) Plug the device in the socket and make
ʓ Then press “Add Home” button to create
your home.
WIFI
WIFI
7

sure that the device is in the Smartconfig
state (the LED symbol is flashing rapidly,
interval flashing 250ms).
(2) Check if the LED symbol is blinking
rapidly and confirm on your app if it is, then
enter your Wi-Fi password to connect to
wireless network, click “Confirm” to connect
the device.
3TYJ9MJIJ[NHJTSQ^XZUUTWYX,-_
Wi-Fi router.
4.4 Connect the device in AP mode
ʒPlug the device in the socket and make
sure that the device is in the AP
Configuration State (the LED symbol is
flashing slowly, interval flashing 1500ms).
ʓ Click “Confirm indicator slowly blink” and
then select Wi-Fi network, enter Wi-Fi
password, click “Confirm” to enter
8

connection process.
ʔ Press “Connect now” and it will go to your
WLAN Setting interface on your smart
phone, select the “SmartLife-XXXX” to
directly connect to the router without
putting in password.
ʕ Go back to the app to enter into the
automatic connection interface.
ʖ Click “Done” after adding device
successfully and enter into the device
controlling interface.
ʗ In the humidity control mode, users can
do some control function settings with the
app.
9

4.5 Wi-Fi State
Smartconfig State: The Wi-Fi indicator light
is flashing rapidly, interval flashing 250ms.
AP State: The Wi-Fi indicator light is flashing
slowly interval flashing 1500ms.
Connection Fail State: The Wi-Fi indicator
light turns off.
Connection Succeed State: The Wi-Fi
indicator light keeps on.
Ɣ
Ɣ
Ɣ
Ɣ
Back to Front Page
Humidification Differential Value
Dehumidification Differential Value
Alarm High Humidity Limit
Alarm Low Humidity Limit
Dehumidification Delay Time
Humidity Calibration
Back to Home Page
Cancel Alarm Voice
Current Humidity
Control Mode
SV: Humidity Setting Value
Device Information
Device Name
Humidity Trend Diagram
Menu Setting
10

Settings
05
5.1 Key Setting
5.1.1 Factory Reset
Hold the button and turn on the device,
the buzzer will beep shortly to remind the
users that all parameters of the the humidity
probe are restored to factory settings.
5.1.2 Fast Setting
Press the button lightly to enter quick
set-up mode and set the value, the SV
screen will display the current setting value
and keep flashing. Press the button or
the button to change the value, hold the
button or the button to change the value
quickly, press the button again to save
settings and quit the setting mode, the
controller will also save settings and quit
the setting mode if there is no operation for
10 seconds.
5.1.3 Normal Setting
Hold the button for 2 seconds to enter
setting mode when the controller working
normally, the PV screen will display the code
“HS” of the first menu item and the SV
screen will display the corresponding
setting value. Press the button to switch
between menu items, press the button or
WIFI
WIFI
WIFI
SET
SET
SET
SET
11

the button to change the value, the value
will be saved automatically when you switch
to another menu item by pressing the
button.
Press and hold the button for 2 seconds
to save settings and quit the setting mode,
the controller will also quit the setting mode
and turn to normal working mode if there’s
no operation for 30 seconds.
5.2 Flowchart of the Settings
SET
SET
SET
SET
SET
SET
SET
SET
SET
Press“SET”Key for over 2
seconds to enter parameters
setting mode
Humidity Setting
Value
Humidification
difference value
Dehumidification
difference value
Alarm High
humidity Limit
Alarm Low
humidity Limit
Dehumidification
Delay Time
Humidity
Calibration
No Key for 30 seconds
or Presss “SET” key
over 2 second?
Working normally
HS
50.0%RH
HD
5.0%RH
DD
5.0%RH
AH
7-
AL
5.0%RH
PT
0 Minute
CA
0.0%RH
12

5.3 Icons in this Manual
Basic Operations
06
6.1 Instructions for Humidity Control
Setting(HS,HD,DD)
The PV Screen displays the measured value
of current humidity when working normally,
recognize and switch between
humidification mode and dehumidification
mode automatically.
.KYMJRJFXZWJI-ZRNINY^5;Ճ-ZRNINY^
Setting Value (HS)-Humidification Differential
Value (HD), the equipment will enter
humidification state, the red led is on, WORK1
output socket turns on. If the measured
-ZRNINY^5;Մ-ZRNINY^8JYYNSL;FQZJ-8
the red led is off, WORK1 output socket turns
off.
IconSymbol Function Setting
Range factory
Settings Note
HS Humidity Setting
Value 7-c7- 50.0%RH
HD Humidification
Difference Value 7-c7- 5.0%RH 8JJ
DD Dehumidification
Difference Value 7-c7- 5.0%RH
5.0%RH
8JJ
8JJ
8JJ
AH Alarm High
Humidity Limit 7-c7- 7-
AL Alarm Low
Humidity Limit 7-c7-
PT Dehumidification
Delay Time c2NSZYJX 0 Minute
CA Humidity Calibration 7-c7- 0.0%RH
13

.KYMJRJFXZWJI-ZRNINY^5;Մ-ZRNINY^
Setting Value (HS)+Dehumidification
Differential Value (DD), the equipment will
enter dehumidification state, the green led is
on, WORK2 output socket turns on. If the
green led is blinking, indicating that the
dehumidification device is in the state of the
dehumidification delay protection, WORK2
output socket turns off. If the measured
-ZRNINY^5;Ճ-ZRNINY^8JYYNSL;FQZJ-8
the green led is off, WORK2 output socket
turns off.
Example: HS=50.0%RH, HD=5.0%RH,
))"7-.K5;YMJRJFXZWJIMZRNINY^
Մ7--8))YMJJVZNURJSY\NQQ
enter the dehumidification state, the green
led is on, WORK2 output socket turns on. If
5;Ճ7--8YMJLWJJSQJINXTKK
WORK2 output socket turns off.
.K5;Ճ7--8-)YMJJVZNURJSY\NQQ
enter the humidification state, the red led is
on, WORK1 output socket turns on.
.K5;Մ7--8YMJWJIQJINXTKK
WORK1 output socket turns off.
Note: There is no need to judge the
differential value of humidification or
dehumidification when power on or exiting
the setting state. For example: when power
on or exiting the setting state HS=50.0%RH,
-)"7-))"7-.K5;YMJ
measured humidity) > 50.0%RH (HS), it will
JSYJWYMJIJMZRNINKNHFYNTSXYFYJ<MJS5;Ճ
50.0%RH (HS), the dehumidification stops,
then return to normal humidity control mode.
If PV < 50.0%RH, it will enter the humidifica-
14

YNTSXYFYJ<MJS5;Մ7-YMJMZRNIN-
fication stops, then return to normal
humidity control mode.
6.2 High/Low Humidity Alarm (AH,AL)
The equipment will alarm if the value of
RJFXZWJIMZRNINY^5;ՄYMJXJY[FQZJTK
high humidity alarm (AH), the PV screen will
display the set value of high humidity alarm
(AH) and the current humidity value
alternately, the buzzer will alarm like
“bi-bi-Biii”until the value of measured
humidity (PV) < the set value of high
humidity alarm (AH). You can also stop the
alarming by pressing any button of the
equipment.
The equipment will alarm if the value of
RJFXZWJIMZRNINY^5;ՃYMJXJY[FQZJTK
Low humidity alarm (AL), the PV screen will
display the set value of low humidity alarm
(AL) and the current humidity value
alternately, the buzzer will alarm like
“bi-bi-Biii” until the value of measured
humidity (PV) > the set value of low humidi-
ty alarm (AL). You can also stop the
alarming by pressing any button of the
equipment.
Note: The setting value of low humidity
alarm (AL) should be less than the setting
value of high humidity alarm(AH).
6.3 Dehumidification Delay Time (PT)
The equipment will not start immediately in
15

the mode of dehumidification for the first
time if the measured value is larger than the
sum value of set humidity value and
dehumification return difference, the
equipment will start to dehumidify after the
set delay time.
The equipment will dehumidify immediately if
the interval time of two adjacent
dehumidification is longer than the delay time.
The equipment will dehumidify after delay
time if the interval time of two adjacent
dehumidification is shorter than the delay
time.
The delay time start timing when last
dehumidification is done.
Note: There is no need to judge the delay time
when power on or exiting the setting state.
6.4 Humidity Calibration (CA)
If the measured humidity differs from the
standard humidity, you can calibrate the
device by adding or reducing the correction
value to align the measured humidity to the
standard humidity. The calibrated
humidity = the measured humidity value + the
calibration value.
16

Sensor Fault Alarm
07
If the humidity sensor is in circumstances of
short circuit or open circuit, the controller
will enter probe fault mode and stop
running, the buzzer will alarm and the
screen will display ER. You can press any
key to stop the buzzer and the controller will
back to normal working state when all
malfunctions are resolved.
Important Safeguards
08
It's important that you take special care
when using electrical appliances. Follow our
tips to stay safe.
Read all instructions.
Check that flexible leads and the appliance
are in good condition.
Check your plug sockets are not overloaded
with too many electrical appliances as this
can lead to overheating.
Do not use appliance for other than
intended use.
Do not cut the cord, or put it on hot
surfaces.
Do not place on or near a hot gas or electric
burner, or in a heated oven.
Don’t try to clean or repair the appliance
when it is still plugged in.
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
17

Don’t wrap flexible cables around the
appliance when it is still warm.
Switch off the device when not in use.
Please disconnect the power as soon as
possible if the device falls into the water, the
Warranty does not include water damage.
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
Children should be supervised to ensure
that they do not play with the appliance.
Close supervision is necessary when any
appliance is used by or near children.
Warranty
09
Ɣ
Ɣ
Ɣ
Ɣ
18
This Limited Warranty applies only to IHC-
200-WIFI Humidity Controller.
What is Covered and for How Long
Warrants that all new products are
free from defects in manufacturing,
materials and workmanship for a period of
one year from date of retail purchase.

specific return and shipping instructions by
email.
Email Address: [email protected]
You may be asked to complete a warranty
service request form. And to help ensure
warranty claims are for Inkbird products, our
technical support department may also
require you to email a copy of your purchase
receipt to us.
Label and ship the product, freight prepaid,
to the address provided by Inkbird.
Ɣ
19
What this Warranty Does not Cover
The warranty does not cover defects or
malfunction caused by misuse, abuse or
improper maintenance, failure to follow
operating instructions, or use with
equipment with which it is not intended to
be used. Also, the warranty will not apply to
damage caused by unauthorized alteration,
modification or repair of the product. does
not warrant or provide service or
support for any third party products,
including, but not limited to iPhones and
Android Phones.
How to Obtain Warranty Service
To obtain warranty service for products
purchased from a third-party, retail or
directly from Inkbird you must return the
product with proof of purchase using the
following procedures:
ƔContact Customer Support for
