Innodisk EGSS-32R1 User manual

www.innodisk.com
Headquarters (Taiwan)
5F., No. 237, Sec. 1, Datong Rd.,
Xizhi Dist., New Taipei City 221,
Taiwan
Tel: [phone]
Email: [email protected]
Branch Offices:
USA
[email protected]
[phone]
Europe
[email protected]
[phone]
Japan
[email protected]
[phone]
China
[email protected]
[phone]
www.innodisk.com
© 2014 Innodisk Corporation.
All right reserved. Specifications
are subject to change without
prior notice.
June 26, 2015
Mechanical Drawing
Specifications
Features
Form-
Factor
M.2
2242-B-M
Input I/F
SATA
III
Output I/F
SATA
III
Output Connector
SATA
7pin x 2
Bridge
JMS562
TDP
1.65W (3.3V x 498mA)
Dimension (
WxLxH
)
22 x 42 x 11mm,
Weight: 5.5g
Temperature
Operation: STD: 0
°C ~ +70°C Storage: -55°C ~ +95°C
Environment
Vibration: 5G @7~2000Hz, Shock: 50G @ 0.5ms
Notes
1. RAID
Mode Setting:
[J2:J1]
RAID0: 23:23,
RAID1: 23:12, PM: 12:12
2.
Press tact switch SW1 for reset.
M.2 2242 to Dual SATA III RAID Module
−Supports SATA to dual SATA III Port Multiplier.
−Supports H/W RAID 0/1 over SATA.
−30µ golden finger, 3 years warranty.
−Industrial design, manufactured in innodisk Taiwan
EGSS-32R1
Order information
EGSS-32R1-C1
M.2 to Dual SATA III RAID Module
SATAIII 7pin male
Tact switch
Pin header
SW1

www.innodisk.com
RAID Mode Setting LED Assignment
J1 J2
RAID 0 23 23
RAID 1 12 23
Port Multiplier
12 12
Red
Power
Green
Access
Blue
Error
Green + Blue
Rebuild
Installation Guide
Please connect SSD in EGSS-32R1
SATA slot.
Please connect EGSS-32R1 to onboard
M.2 slot.
Please use jumper J1/J2 to change
RAID mode as above setting list.
1 2
3 4
Please push tact switch 3 seconds for reset.
