Innotech SmartControl EXCA234CAT5 Series User manual

Warnings
Camera Package Contents
Mounting the Camera
Camera Gimbal
NOTE: EXCA234 Series base is shown. If camera base looks
different from picture; gimbal removal, installation and
rotation remain the same
Quick Installation Guide: SMARTCONTROL®CAT5 SERIES
Innotech Security EXCA234CAT5 Series Outdoor Vandal Dome Camera
1. Install according to instructions and in conformance with all local codes
2. Do not subject cables/wiring to stress or crimping
3. Only use Innotech supplied accessories, brackets and housings if required
4. Only use power sources with proper ratings
5. Do not drop the camera or subject it to physical/electrical shock or radiation
6. Do not point the camera at strong light
7. DO NOT TOUCH THE CAMERA LENS
Camera gimbal (snap-lock) with RJ45 connector and test
monitor connector, base and dome
Separate test monitor cable (black wire/yellow
connector/white plug)
(1) Allen wrench (Dome)
(4) Screws, (4) Anchors
1. Remove the dome, remove the camera gimbal (grasp & pull
out from the base), remove the grommet in the base, remove
the 4 mounting hole plugs in base.
2. Prepare the camera mount by drilling 4 holes using the base as a
template.
3. Attach the base to a solid flat surface using the anchors & screws
provided (unless using the AM7 Wall Mount Bracket).
4. Connect the RJ45 Plug on one end of the CAT5 cable to the RJ45
connector on the underside of the camera gimbal, coming
through the base bottom (grommet) or through the side
knockout. Connect the RJ45 plug on the other end of the CAT5
cable to the appropriate Innotech SMARTCONTROL® CAT5
Decoder. The maximum distance from the decoder to the camera
is 1,000 ft.
5. Re-insert the grommet and camera gimbal in the base.
6. Apply power to the SMARTCONTROL® CAT5 Decoder.
7. Attach the test monitor cable (provided) to the test monitor
connector on the camera gimbal & use a test monitor for lens
adjustments.
8. Adjust the camera lens position (by rotating the camera gimbal),
adjust the zoom (outer ring) and adjust the focus (inner ring).
9. Adjust the camera OSD settings (refer to: Quick Camera Setup
Menu for the appropriate camera sensor).
10. Remove the test monitor cable & re attach the dome.
To remove gimbal, pull straight up from base
To install gimbal, insert straight into base
To rotate gimbal in base, hold by hinges & turn
*** Always hold camera gimbal by the hinges ***

Quick Installation Guide: SMARTCONTROL®CAT5 SERIES
Innotech Security EXCA234CAT5 Series Outdoor Vandal Dome Camera
Dome
RJ45 Connector - To
SMARTCONTROL®
CAT5 Decoder
Grommet
Mounting
Hole Plugs
Camera Gimbal
Base
