OWNER’S MANUAL
Mobile Audio System
• PLL Synthesizer Stereo Radio
• Car CD/MP3/WMA Player
• Automatic Memory Storing
• Full Detachable Panel
• Preset Equalization
• Auxiliary Input Function
IN-CS102

2
CONTENTS
Installation ...........................................3
Take out screw before installation.........3
DIN Front-Mount (Method A) ................3
Installing the unit.................................3
Removing the unit...............................4
DIN Rear-Mount (Method B) .................5
Using the detachable front panel ......6
Wiring Connection ..............................7
Operation .............................................8
Location of keys....................................8
Switching on/off the unit ......................9
Faceplate release..................................9
Sound adjustment.................................9
Loudness ..............................................9
Set the clock .........................................9
Mute ......................................................9
Equalization...........................................9
Liquid crystal display ...........................9
Flashing LED .........................................9
Reset function.......................................9
Radio operation ..................................10
Switching to radio mode...................10
Selecting the frequency band...........10
Selecting station ...............................10
Local/distant .....................................10
Automatically memory storing &
program scanning.............................10
Station storing ..................................10
Mono/stereo .....................................10
CD operation.......................................11
Switching to CD mode......................11
Selecting tracks ................................11
Pausing playing ................................11
Previewing all tracks.........................11
Repeating the same track.................11
Playing all tracks in random..............11
Ejecting a disc ..................................11
MP3 operation ....................................11
Switching to CD (MP3) mode............ 11
Ejecting a disc................................... 11
Selecting tracks in single step........... 11
Pausing playing................................. 11
Previewing all tracks ......................... 11
Repeating the same track ................. 11
Playing all tracks in random .............. 11
Selecting tracks by AS/PS/ D-AUD
button ...............................................11
Display information ........................... 12
WMA operation.................................13
Audio DSP (MP3/WMA decoder)......13
Disc notes ...........................................14
Specification..................................... 15
Trouble shooting .............................. 16

3
INSTALLATION
Notes:
• Choose the mounting location where
the unit will not interfere with the
normal driving function of the driver.
• Before finally installing the unit,
connect the wiring temporarily and
make sure it is all connected up
properly and the unit and the system
work properly.
• Use only the parts included with the
unit to ensure proper installation.
The use of unauthorized parts can
cause malfunctions.
• Consult with your nearest dealer if
installation requires the drilling of holes
or other modifications of the vehicle.
• Install the unit where it does not get in
the driver’s way and cannot injure the
passenger if there is a sudden stop,
like an emergency stop.
• If installation angle exceeds 30˚ from
horizontal, the unit might not give its
optimum performance.
• Avoid installing the unit where it would
be subject to high temperature, such
as from direct sunlight, or from hot air,
from the heater, or where it would be
subject to dust, dirt or excessive
vibration.
DIN FRONT/REAR-MOUNT
This unit can be properly installed either
from “Front” (conventional DIN Front-
mount) or “Rear” (DIN Rear-mount
installation, utilizing threaded screw holes
at the sides of the unit chassis).
For details, refer to the following
illustrated installation methods.
TAKE OUT SCREW BEFORE
INSTALLATION
Before install the unit, please remove the
two screws.
DIN FRONT-MOUNT (Method A)
Installation Opening
This unit can be installed in any dashboard
having an opening as show below:
Installing the unit
Be sure you test all connections first, and
then follow these steps to install the unit.
1. Make sure the ignition is turned off,
and then disconnect the cable from
the vehicle battery's negative (-)
terminal.
2. Disconnect the wire harness and the
antenna.
3. Press the release button on the front
panel and remove the control panel
(see the steps of “removing the front
panel”).
4. Lift the top of the outer trim ring then
pull it out to remove it.
5. The two supplied keys release tabs
inside the unit's sleeve so you can
remove it. Insert the keys as far as they
will go (with the notches facing up) into
the appropriate slots at the middle left
and right sides of the unit. Then slide
the sleeve off the back of the unit.
30˚
182 mm
53 mm
Take out screw before installation

grounding of the unit.
Note to install the short threading
terminal of the mounting bolt to the back
of the unit and the other long threading
terminal to the dashboard.
10. Reconnect the cable to the vehicle
battery's negative (-) terminal. Then
replace the outer trim ring and install
the unit's front panel. (see the steps
of “installing the front panel”).
Removing the unit
1. Make sure the ignition is turned off,
and then disconnect the cable from
the vehicle battery's negative (-)
terminal.
2. Remove the metal strap attached the
back of the unit (if attached).
3. Press the release button to remove
the front panel.
4. Lift the top of the outer trim ring then
pull it out to remove it.
5. Insert both of the supplied keys into
the slots at the middle left and right
sides of the unit, then pull the unit out
of the dashboard.
4
6. Mount the sleeve by inserting the sleeve
into the opening of the dashboard and
bend open the tabs located around the
sleeve with a screwdriver. Not all tabs
will be able to make contact, so
examine which ones will be most
effective. Bending open the appropriate
tabs behind the dashboard to secure
the sleeve in place.
7. Reconnect the wire harness and the
antenna and be careful not to pinch
any wires or cables.
8. Slide the unit into the sleeve until it
locks into place.
9. To further secure the unit, use the
supplied metal strap to secure the back
of the unit in place. Use the supplied
hardware (Hex Nut (M5mm) and Spring
Washer) to attach one end of the strap
to the mounting bolt on the back of
the unit. If necessary, bend the metal
strap to fit your vehicle's mounting
area. Then use the supplied hardware
(Tapping Screw (5x25mm) and Plain
Washer) to attach the other end of
metal strap to a solid metal part of the
vehicle under the dashboard. This strap
also helps ensure proper electrical
INSTALLATION
Front Panel
Outer Trim Ring
L Key
Sleeve
R Key
Sleeve
Dashboard
Screwdriver
Tabs
Spring Washer
Tapping Screw
Plain Washer
Hex Nut
Metal Strap
Mounting Bolt

DIN REAR-MOUNT (Method B)
If your vehicle is a Nissan, Toyota, follow
these mounting instructions.
Use the screw holes marked T (Toyota),
N (Nissan) located on both sides of the
unit to fasten the unit to the factory radio
mounting brackets supplied with your
vehicle.
To fasten the unit to the factory radio
mounting brackets.
Align the screw holes on the bracket with
the screw holes on the unit, and then
tighten the screws (5x5mm) on each side.
Note: the outer trim ring, sleeve and the
metal strap are not used for method B
installation.
INSTALLATION
5
Dashboard or
Console
Side view showing
Screw Holes marked T, N
Factory Radio
Mounting
Bracket
Hook
Screw
Screw
Hook

USING THE DETACHABLE FRONT PANEL
REMOVING THE FRONT PANEL
1. Press the release button ( ) on the
front panel and pull off the front panel.
2. Keep front panel into the case.
INSTALLING THE FRONT PANEL
To install the front panel, insert the panel
into the housing and make sure the panel
is properly installed. Otherwise,
abnormality occurs on the display or some
keys will not function properly.
Release Button
Front Panel
Precautions when handing
1. Do not drop the front panel.
2. Do not put pressure on the display or
control buttons when removing or
installing the front panel.
3. Do not touch the contacts on the front
panel or on the main unit body. It may
result in poor electrical contact.
4. If any dirt or foreign substances
adhered on the contacts, they can be
removed with a clean and dry cloth.
5. Do not expose the front panel to high
temperatures or direct sunlight in
anywhere.
6. Keep away any volatile agents (e.g.
benzene, thinner, or insecticides) from
touching the surface of the front panel.
7. Do not attempt to disassemble the
front panel.
6
Protective Case
Front Panel

7
WIRING CONNECTION
FRONT Lch
SPEAKER
GREEN
GREEN/BLACK
MEMORY
BACK-UP (B+)
MAIN UNIT
Rch RED
Lch WHITE
AUX IN CABLE
IGNITION
SWITCH (ACC+)
POWER
ANTENNA
RED
GROUND (B–)
YELLOW
BLACK
BLUE REAR RCA CABLE
(BLACK)
ANTENNA CONNECTOR
(GREY) Rch RED
Lch WHITE
WHITE
WHITE/BLACK
REAR Lch
SPEAKER
VIOLET
VIIOLET/BLACK
GREY
GREY/BLACK
FRONT Lch
SPEAKER
REAR Rch
SPEAKER
FRONT RCA CABLE
(BROWN)
Rch RED
Lch WHITE
FUSE
FUSE

8
1224
OPERATION
LOCATION OF KEYS
715 51 4
6
2
13
178
10
11
1619 21 2018 22 231493

9
OPERATION
SWITCHING ON/OFF THE UNIT
Switch on the unit by pressing any button
(except button (7) and button (4)).
When system is on, press PWR button
(9) to turn off the unit.
FACEPLATE RELEASE
Press button (7) to detach the
removable faceplate.
SOUND ADJUSTMENT
Press SEL button (10) shortly to select
the desired adjustment mode.
The adjustment mode will change in
the following order:
By rotating the VOLUME knob (11)
clockwise or counterclockwise, it is
possible to adjust the desired sound
quality.
Press and hold the SEL button (10) for
several seconds to enter into the
selection for the situation of beep sound,
then rotate the VOLUME knob (11)
clockwise or counter-clockwise to select
as follows:
- BEEP 2’nd mode:
The beep is only generated when
all allowed double function button
is pressed long (several seconds).
e.g.
When preset button is pressed.
When BND/LOU button (13) is
pressed.
When AS/PS button (18) is pressed.
- BEEP ALL mode:
The beep is generated when every key
is pressed.
- BEEP OFF mode:
The beep is disabled.
LOUDNESS
Press BND/LOU button (13) for
several seconds to reinforce the bass
output. Press it for several seconds again
to release this function.
VOL BAS TRE BAL FAD
(Volume) (Bass) (Treble) (Balance) (Fader)
SET THE CLOCK
Press the DSP button (15), the clock is
shown on the LCD display. Then hold
down the button until the clock flashes.
Then press the MANU/SKIP button
(17) to change hours or MANU/SKIP
button (16) to change minutes.
MUTE
Press MUT button (3) to mute down the
sound instantly. If any button is pressed
in the mute state, the mute state is
released.
EQUALIZATION
Press EQ button (19) to turn on
equalization function and to select
desired audio mode. There are five kinds
of mode as below:
LIQUID CRYSTAL DISPLAY
Exhibit current frequency and activated
functions on the display (8).
FLASHING LED
If the front panel does not install in the
main unit, the LED (12) will be flashing.
RESET FUNCTION
RESET button (24) must be activated
with either a ballpoint pen or thin metal
object and it should be pressed for more
than one second.
The RESET button is to be activated for
the following reasons:
- Initial installation of the unit when all
wiring is completed.
- All the function buttons do not operate.
- Error symbol on the display.
Note: If press RESET button (24), the
unit can’t work yet, please use a cotton
swab soaked in isopropyl alcohol to clean
the socket on the back of the front panel.
BEEP 2ND BEEP ALL BEEP OFF
FLAT CLASSICS POP M ROCK M DSP OFF

RADIO OPERATION
•SWITCHING TO RADIO MODE
Press MOD button (6) shortly to
select radio mode, the radio mode
appears in the display together with
the memory band and frequency.
•SELECTING THE FREQUENCY
BAND
At radio mode, press BND/LOU button
(13) shortly to select the desired band.
The reception band will change in the
following order:
•SELECTING STATION
Press MANU/SKIP button (17)
or MANU/SKIP button (16)
shortly to activate automatic seek
function. Press for several seconds
until “MANUAL”appears on the
display, the manual tuning mode is
selected. If both buttons have not
been pressed for several seconds, they
will return to seek tuning mode and
“AUTO”appears on the display.
•LOCAL/DISTANT
Press LOC button (2) to select
between local and distant stations.
Local setting for reception of strong
station, and a distant setting for
reception of weaker stations. This
function is effect during AUTO SEEK
operation.
•AUTOMATIC MEMORY STORING &
PROGRAM SCANNING
- Automatic memory storing
Press AS/PS button (18) for several
seconds, the radio searches from
the current frequency and checks
the signal strength until one cycle
search is finished. And then 6
strongest stations are stored into the
corresponding preset number
button.
- Program scanning
Press AS/PS button (18) shortly to
scan preset station. When the field
strength level is more than the
threshold level of stop level, the radio
is holding at that preset number for
several seconds with release mute,
then searches again.
•STATION STORING
Press any one of the preset buttons
(14) (1 to 6) to select a station, which
had been stored in the memory. Press
this button for several seconds (until
2ND beeps come out), current station
is stored into the number button.
•MONO/STEREO
Press MON button (1) to select mono
or stereo mode. You can sometimes
improve reception of distant stations
by selection mono operation.
10
OPERATION
FM1 FM2 FM3 AM
