Insignia NS-CLLT01 User manual

User Guide
Digital FM Clock Radio with Dock for iPhone5
NS-CLLT01
Before using your new product, please read these instructions to prevent any damage.
NS-CLLT01_14-0316_MAN_V4_ENG.fm Page 1 Wednesday, May 28, 2014 6:40 AM

2
Insignia NS-CLLT01 Digital FM Clock Radio with Dock for iPhone5
www.insigniaproducts.com
Insignia NS-CLLT01
Digital FM Clock Radio with Dock for
iPhone5
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Important Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Set up your clock radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Use your clock radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Clean your clock radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Legal notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
One-year limited warranty - Insignia . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Introduction
Congratulations on your purchase of high-quality Insignia Digital FM
Clock Radio with Dock for iPhone5. This system represents the state of the
art in clock radio design and is designed for reliable and trouble-free
performance.
This User Guide explains how to correctly set up, operate, and get the best
performance from your Insignia clock radio. Read this guide carefully
before setting up your clock radio, then keep it handy for quick reference.
NS-CLLT01_14-0316_MAN_V4_ENG.fm Page 2 Wednesday, May 28, 2014 6:40 AM

3
Insignia NS-CLLT01 Digital FM Clock Radio with Dock for iPhone5
www.insigniaproducts.com
Important Safety Instructions
Electric shock warning
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with a dry cloth.
• Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding-type plug.
A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong is provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement of
the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
• Only use attachments or accessories specified by the manufacturer.
• Unplug this system during lightning storms or when unused for long
periods of time.
Warning
To reduce the risk of electric shock, do not remove
the cover or back. There are no user-serviceable parts
inside. Refer servicing to qualified service personnel.
This lightning flash with arrowhead
symbol within an equilateral triangle is
intended to alert the user to the
presence of uninsulated dangerous
voltage within your clock radio’s
enclosure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature
accompanying your clock radio.
CAUTION
Risk of Electric Shock
Do Not Open
NS-CLLT01_14-0316_MAN_V4_ENG.fm Page 3 Wednesday, May 28, 2014 6:40 AM

4
Insignia NS-CLLT01 Digital FM Clock Radio with Dock for iPhone5
www.insigniaproducts.com
• Refer all servicing to qualified service personnel. Servicing is required
when the system has been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled or objects have fallen into
the system, the system has been exposed to rain or moisture, does not
operate normally, or has been dropped.
• To reduce the risk of fire or electric shock, do not expose this system to
rain or moisture.
• The shock hazard marking and associated graphical symbol are provided
on the supplied AC adapter.
• The system shall not be exposed to dripping or splashing and objects
filled with liquids should not be placed on the system.
• The AC plug or AC adapter is used as the disconnect device. The
disconnect device shall remain readily available.
• Batteries (battery pack and batteries installed) should not be exposed to
excessive heat such as sunshine or fire.
Features
Package contents
Your clock radio includes the following items:
• Clock radio with dock for iPhone5
®
(iPhone is not included)
•ACadapter
• “AA” batteries (2)
•UserGuide
NS-CLLT01_14-0316_MAN_V4_ENG.fm Page 4 Wednesday, May 28, 2014 6:40 AM

5
Insignia NS-CLLT01 Digital FM Clock Radio with Dock for iPhone5
www.insigniaproducts.com
LCD Front Panel display
#Item Description
1ALARM 1 indicator When lit, indicates that alarm 1 is set.
2 TIME/ALARM display In standby mode, shows the current time.
In radio mode, shows the current freqency.
3ALARM 2 indicator When lit, indicates that alarm 2 is set.
4SLEEP indicator When lit, indicates that the sleep timer is set.
5PM indicator When lit, indicates that time shown on display is PM.
NS-CLLT01_14-0316_MAN_V4_ENG.fm Page 5 Wednesday, May 28, 2014 6:40 AM

6
Insignia NS-CLLT01 Digital FM Clock Radio with Dock for iPhone5
www.insigniaproducts.com
Top panel
#Item Description
1 Lightning connector Connect your iPhone here to listen to it on the clock radio speakers.
2iPhone
®
docking pad Holds your iPhone while it’s connected to the clock radio.
3SOURCE button Press repeatedly to cycle through the available sound sources
(FM(rAd, iPhone(doc), and AUX IN(Au.).
4/|(STANDBY/ON) button In alarm mode, press to silence the alarm for 24 hours. In radio mode,
press to turn the radio on or off.
5VOLUME +/– button Press to increase or decrease volume.
6TIME SET button Press to set the time.
7ALARM 1 button Press to set Alarm 1. The Alarm 1 indicator lights.
8PRESET button When presetting stations, press to select the preset number.
When listening to the radio, press to select a preset station.
9 (play/pause)/MEM
(memory) button
During iPhone playback, press to pause playback. Press again to
resume playback.
When presetting FM stations, press to memorize a station.
10 SLEEP button Press to set the sleep timer. You can select 90, 60, 45, 30, 15, or OFF.
The time appears on the display.
11 - HOUR/MIN -
TUNING button
In time set mode, press to set the hours and minutes.
In FM mode, press to tune the radio to the next or previous station.
Press and hold to search for a station.
In iPhone mode, press to skip to the next or previous track. Press and
hold to go to a specific point on a track.
12 ALARM 2 button Press to set Alarm 2. The Alarm 2 indicator lights.
13 SNOOZE/DIMMER button When the alarm sounds, press to mute the alarm for nine minutes.
Press and hold to adjust the display brightness.
14 LCD display Shows the time, radio station, and indicator lights.
STANDBY
/ ON SLEEP
TUNING
NS-CLLT01_14-0316_MAN_V4_ENG.fm Page 6 Wednesday, May 28, 2014 6:40 AM

7
Insignia NS-CLLT01 Digital FM Clock Radio with Dock for iPhone5
www.insigniaproducts.com
Back panel
#Item Description
1 Stereo speakers Provide sound for playback.
2 FM antenna wire Improves FM radio reception.
3 AUX IN jack Plug an external sound source, such as an MP3 player, into
this connector using a 3.5mm plug.
4 USB jack Plug a USB device into this connector to charge it (use for
charging only - Max. 500 mA).
5DC IN 5V jack Plug the AC adapter into this connector.
NS-CLLT01_14-0316_MAN_V4_ENG.fm Page 7 Wednesday, May 28, 2014 6:40 AM

8
Insignia NS-CLLT01 Digital FM Clock Radio with Dock for iPhone5
www.insigniaproducts.com
Set up your clock radio
Install the backup batteries
The clock radio uses a backup battery system to provide continuous alarm
operation and clock settings in the event of a power failure. If the backup
batteries have been installed and a power failure occurs or the AC cord is
accidentally disconnected, the display will not remain lit, but the current
time and alarm time settings will be temporarily maintained. Otherwise,
you must reset the time and alarm settings.
Make sure that the AC cord is connected. Otherwise all settings may be
lost during battery replacement.
1Turn your clock radio over so the bottom is facing up, then open the
battery compartment cover located on the bottom of your clock radio
by inserting your fingernail and lifting up on the cover.
2Insert two "AA" batteries (included) into the battery compartment.
Make sure that the + and – symbols on the batteries align with the +
and – symbols inside the battery compartment.
3Close the battery compartment.
Caution
• Do not recharge, short, disassemble, or heat the
batteries, or dispose of in a fire.
• Dispose of batteries in the proper manner, according to
federal, state, and local regulations.
• Remove the batteries when the charge is depleted or if
your clock radio will be left unplugged for an extended
period.
• Battery chemicals can cause a rash. If the batteries leak,
clean the battery compartment with a cloth. If chemicals
touch your skin, wash immediately.
• Do not use a mixture of old and new batteries.
• Do not mix alkaline, standard (carbon-zinc), and
rechargable batteries.
NS-CLLT01_14-0316_MAN_V4_ENG.fm Page 8 Wednesday, May 28, 2014 6:40 AM

9
Insignia NS-CLLT01 Digital FM Clock Radio with Dock for iPhone5
www.insigniaproducts.com
Connect the AC adapter
Make sure that the AC power outlet matches the AC adapter’s power
specifications (120 V ~ 60 Hz) prior to plugging in the adapter.
1Plug the small DC power connector into the DC IN 5V jack on the back
of your clock radio.
2Plug the other end of the AC power adapter into a power outlet.
Set the clock
1In standby mode (the time is shown on the display), press and hold the
TIME SET button on the top of your clock radio for three seconds.
The hour and minutes digits blink.
2Press the - HOUR button to set the correct hour.
3Press the MIN - button to set the correct minutes.
4Press the TIME SET button to confirm.
Hour digits Minutes digits
PM indicator
NS-CLLT01_14-0316_MAN_V4_ENG.fm Page 9 Wednesday, May 28, 2014 6:40 AM

10
Insignia NS-CLLT01 Digital FM Clock Radio with Dock for iPhone5
www.insigniaproducts.com
Use your clock radio
Before using your clock radio, make sure that all connections are secure,
then plug the AC adapter into your clock radio and an AC power outlet.
Turn your clock radio on and off
1Press /| (STANDBY/ON). Your clock radio turns on.
2Press the SNOOZE/DIMMER button repeatedly to cycle through the
available brightness levels (high, medium, and low) of the LCD.
3Press
/| (STANDBY/ON) again to switch your clock radio to standby
mode.
Set and use the alarm
1Press and hold the ALARM 1 or ALARM 2 button. The “ALARM 1” or
“ALARM 2” indicator and the hours and minutes digits start to blink.
2Press the - HOUR button to set the hour.
3Press the MIN - button to set the minutes.
4Press the VOLUME +/- button to set the volume of the alarm.
5Press the SOURCE button to set the alarm to wake to radio (rAd),
iPhone (doc), or Buzzer (bU).
6Press ALARM 1 or ALARM 2 to confirm and save the alarm settings.
The alarm indicator lights.
Mute, turn off, or cancel the alarm
1Press the SNOOZE/DIMMER button to mute the alarm for nine
minutes.
Note
• Your clock radio must be in standby mode to set the
alarm.
• Your clock radio can be set to activate twice a day by
setting different times in ALARM 1 and ALARM 2.
Hour digits Minutes digits
PM indicator
Alarm 1
indicator
Alarm 2
indicator
NS-CLLT01_14-0316_MAN_V4_ENG.fm Page 10 Wednesday, May 28, 2014 6:40 AM
