Insignia NS-DPFC01 User manual

Clock Radio with LCD Photo Viewer
NS-DPFC01
User Guide
NS-DPFC01 09-0621_MAN_ENG_V2.fm Page 1 Friday, July 24, 2009 12:14 PM

NS-DPFC01 09-0621_MAN_ENG_V2.fm Page 2 Friday, July 24, 2009 12:14 PM

www.insigniaproducts.com 3
Insignia NS-DPFC01
Clock Radio with LCD Photo Viewer
Contents
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Setting up your clock radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Using your clock radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Legal notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
90-day limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Welcome
Congratulations on your purchase of a high-quality Insignia product. Your
NS-DPFC01 represents the state of the art in clock radios and is designed
for reliable and trouble-free performance.
Important safety instructions
1Read these instructions.
2Keep these instructions.
3Heed all warnings.
4Follow all instructions.
5Do not use this apparatus near water.
6Clean only with dry cloth.
7Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
8Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
NS-DPFC01 09-0621_MAN_ENG_V2.fm Page 3 Friday, July 24, 2009 12:14 PM

4
Insignia NS-DPFC01 Clock Radio with LCD Photo Viewer
www.insigniaproducts.com
10 Protect the power cord from being walked on or pinched particularly
at plugs, convenience receptacles, and the point where they exit from
the apparatus.
11 Only use attachments/accessories specified by the manufacturer.
12 Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13 Unplug this apparatus during lightning storms or when
unused for long periods of time.
14 Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been
dropped.
15 To reduce the risk of fire or electric shock, do not expose this device to
rain, moisture, dripping, or splashing, and no objects filled with liquids,
such as vases, shall be placed on it.
16 An apparatus with a three-prong, grounding-type plug is a Class I
apparatus, which needs to be grounded to prevent possible electric
shock. Make sure that you connect this Class I device to a
grounding-type, three-prong outlet.
17 The wall plug is the disconnecting device. The plug must remain
readily operable.
18 Batteries should not be exposed to excessive heat such as sunshine,
fire, or the like.
Features
Package contents:
• Clock radio with LCD Photo Viewer
•ACAdapter
• Remote control with bracket
• Battery (CR2032 x 1)
•USBCable
• User Guide
•QSG(QuickSetupGuide)
Warning
Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type.
NS-DPFC01 09-0621_MAN_ENG_V2.fm Page 4 Friday, July 24, 2009 12:14 PM

5
Insignia NS-DPFC01 Clock Radio with LCD Photo Viewer
www.insigniaproducts.com
Top view
# Description Function
1 Photo display LCD screen where photos are displayed.
2 Remote sensor Receives the infrared signal from the remote control. Point the remote control at this
sensor.
3PHOTO MENU
button
Press to display the photo menu on the LCD.
4ZOOM button Press to zoom in on the photo being displayed.
5DEL/COPYbutton Press to delete or copy photos while in thumbnail picture mode.
6RADIObutton Press once to turn the radio on. Press again to turn the radio off.
7SNOOZE/DIMMER
button
Press to temporarily turn off the alarm (snooze), when the alarm is sounding. Press to
set the backlight level to high, middle, or low, when the alarm is off.
8ALARM 1button Press to set Alarm 1.
PHOTO MENU ZOOM DEL/COPY
VOL+ PRESET+ PHOTO
DISPLAY
SLEEP ALARM 1
VOL-
TUNE+
TUNE-
PREV NEXT
RADIO
MEMORYPRESET- TIME SET ALARM 2
SNOOZE/DIMMER
ENTER
2
13 4
8
9
10
11
56
12
13
14
15
16
17
18
19
20
21
23
7
22
NS-DPFC01 09-0621_MAN_ENG_V2.fm Page 5 Friday, July 24, 2009 12:14 PM

6
Insignia NS-DPFC01 Clock Radio with LCD Photo Viewer
www.insigniaproducts.com
9SLEEPbutton Press to set the sleep timer, which automatically turns off the radio after the time
duration selected. Press repeatedly to select the duration.
10 PHOTO DISPLAY
button
Press once to turn the photo display on. Press again to turn the photo display off.
11 PRESET+button In radio mode, press to select the next preset station. In memory mode, press to select
the preset number for the station.
12 VOL+ button Press to increase the radio volume.
13 TUNE+button In radio mode, press to tune the radio to a higher station.
In photo zoom mode, press to pan up in the photo.
14 ENTERbutton Press to confirm your selection in photo menu mode.
15 PREV button In photo playback mode, press to select the previous photo.
In photo zoom mode, press to pan left in the photo.
In photo menu mode, press to move the cursor.
16 TUNE–button In radio mode, press to tune the radio to a lower station.
In photo zoom mode, press to pan down in the photo.
17 NEXT button In photo playback mode, press to select the next photo.
In photo zoom mode, press to pan right in the photo.
In photo menu mode, press to move the cursor.
18 VOL–button Press to decrease the radio volume.
19 PRESET–button In radio mode, press to select the previous preset station. In memory mode, press to
select the preset number for the station.
20 MEMORYbutton Press to set radio station presets.
21 TIME SETbutton Press and hold briefly to set the time.
22 ALARM 2button Press to set Alarm 2.
23 Clock display Displays the current time, radio, and alarm information.
# Description Function
NS-DPFC01 09-0621_MAN_ENG_V2.fm Page 6 Friday, July 24, 2009 12:14 PM

7
Insignia NS-DPFC01 Clock Radio with LCD Photo Viewer
www.insigniaproducts.com
Side and back views
# Description Function
1 Card slot Plug an SD, MMC, MS, or XD card into this slot.
2 USB port Plug an external USB device into this port.
3 USB cable port Plug a USB cable from a computer into this port.
4 Backup battery slot Insert a backup battery into this opening.
5 Remote control Remotely control your radio with this remote control.
6 Remote control storage
bracket
Store your remote control in this bracket.
7DC INjack Plug the output cable of the AC adapter into this jack.
8ANT The FM antenna to improve reception.
1
2
3
45 6
78
NS-DPFC01 09-0621_MAN_ENG_V2.fm Page 7 Friday, July 24, 2009 12:14 PM

8
Insignia NS-DPFC01 Clock Radio with LCD Photo Viewer
www.insigniaproducts.com
LCD display
# Description Function
1 Alarm 1 status icon Indicates the status of Alarm 1. The icon to the right of the status icon indicates your
selection.
• Bell icon–wake to buzzer
• Music note icon–wake to radio
• No icon–alarm 1 off
2 Alarm 2 status icon Indicates the status of Alarm 2. The icon to the right of the status icon indicates your
selection.
• Bell icon–wake to buzzer
• Music note icon–wake to radio
• No icon–alarm 2 off
3 Main display Shows the current time, radio frequency, sleep time setting, or alarm ring time.
4 FM Lights when radio is on.
5 SNOOZE Lights when snooze is on.
6 SLEEP Lights when the sleep timer is set.
7 VOL (volume) Shows the volume setting of the radio.
8 Preset station number Indicates the preset number selected.
9 MEM icon Indicates a preset is selected.
12 3 4567
89
NS-DPFC01 09-0621_MAN_ENG_V2.fm Page 8 Friday, July 24, 2009 12:14 PM

9
Insignia NS-DPFC01 Clock Radio with LCD Photo Viewer
www.insigniaproducts.com
Remote control
# Description Function
1PHOTO MENU button Press to display the photo menu on the LCD.
2PREV button
TUNE+ button
NEXT button
TUNE– button
In photo playback mode, press to select the previous photo.
In photo zoom mode, press to pan left in the photo.
In photo menu mode, press to move the cursor.
In radio mode, press to tune the radio to a higher station.
In photo zoom mode, press to pan up in the photo.
In photo playback mode, press to select the next photo.
In photo zoom mode, press to pan right in the photo.
In photo menu mode, press to move the cursor.
In radio mode, press to tune the radio to a lower station.
In photo zoom mode, press to pan down in the photo.
3ENTER button In Press to confirm your selection in photo menu mode.
4ZOOM button Press to zoom in on the photo being displayed.
5ROTATE button Press to rotate the displayed photo in 90° steps.
6PHOTO DISPLAY button Press once to turn the photo display on. Press again to turn the photo display off.
+
TUNE+
PREV NEXT
ENTER
TUNE-
ROTATE ZOOM
DEL/
COPY
MENU
DISPLAY
1
2
4
5
3
6
7
NS-DPFC01 09-0621_MAN_ENG_V2.fm Page 9 Friday, July 24, 2009 12:14 PM

10
Insignia NS-DPFC01 Clock Radio with LCD Photo Viewer
www.insigniaproducts.com
Setting up your clock radio
Supplying power
Your clock radio is powered by an AC adapter.
Plugging in your clock radio
To plug in your clock radio:
1Place your clock radio in a convenient place and find an AC power
outlet within range of the AC adapter.
2Plug the AC adapter into the AC power outlet.
3Plug the AC adapter into the DC IN socket on the radio.
Installing the backup battery
You can install a backup battery (included) to provide temporary power in
case the AC power fails. The backup battery only maintains the correct
time.
To install a backup battery:
1Unplug your clock radio, then turn it around to the back and remove
the circular backup battery cover by unscrewing it.
2Insert one (1) CR2032 button cell battery (included) into the battery
compartment. Make sure that the + symbol on the battery is facing up.
3Reinstall the backup battery slot cover.
7DEL/COPY button Press to delete or copy photos while in thumbnail picture mode.
Caution
To protect your clock radio during thunderstorms, unplug the AC
power adapter from the AC power outlet.
# Description Function
NS-DPFC01 09-0621_MAN_ENG_V2.fm Page 10 Friday, July 24, 2009 12:14 PM

11
Insignia NS-DPFC01 Clock Radio with LCD Photo Viewer
www.insigniaproducts.com
4Plug in your radio.
Installing the remote control and remote control bracket
To install the remote control and remote control bracket:
1Put the remote control bracket onto the bracket holder (at the back of
the clock radio).
2Push the bracket downward until it clicks into place.
3Insert the remote control into the bracket.
Removing the remote control and remote control bracket
To remove the remote control and remote control bracket:
1Remove the remote control as shown below.
Cautions
Follow these precautions when using a battery in this device:
• Use only the size and type of battery specified.
• Make sure that you follow the correct polarity as indicated
in the battery compartment when installing the battery. A
reversed battery may cause damage to the clock radio.
• If your clock radio is not to be used for a long period of
time, remove the battery to prevent damage or injury from
possible battery leakage.
• The battery should not be exposed to excessive heat, such
as sunshine, fire, or the like. Dispose of the used battery as
hazardous waste.
• There is a danger of explosion if the battery is incorrectly
replaced. Replace only with the same or equivalent type.
NS-DPFC01 09-0621_MAN_ENG_V2.fm Page 11 Friday, July 24, 2009 12:14 PM

12
Insignia NS-DPFC01 Clock Radio with LCD Photo Viewer
www.insigniaproducts.com
2Push the bracket upward from the bottom until it can be removed.
Setting up the LCD
To set up the LCD:
1While in Photo mode, press PHOTO MENU to display the photo
menu OSD (on-screen display). The following menu opens.
Caution
• We suggest that you keep the bracket installed.
• If you decide to remove the bracket, you may need to
push bracket hard to remove it
• When you remove the bracket, keep your fingers and
body clear above the bracket to avoid possible impact by
the bracket, when it pops out.
NS-DPFC01 09-0621_MAN_ENG_V2.fm Page 12 Friday, July 24, 2009 12:14 PM

13
Insignia NS-DPFC01 Clock Radio with LCD Photo Viewer
www.insigniaproducts.com
2Press PREV or NEXT to highlight Photo Setup, then press
ENTER to confirm. The Photo Setup menu opens.
3Press TUNE+, or TUNE– to select LCD Setup, then press
ENTER. The LCD Setup menu opens.
4Press TUNE+, or TUNE– to select Brightness, Contrast, or
Color.
5Press PREV or NEXT to adjust your selection, then press
ENTER when you are through to save your settings.
NS-DPFC01 09-0621_MAN_ENG_V2.fm Page 13 Friday, July 24, 2009 12:14 PM

14
Insignia NS-DPFC01 Clock Radio with LCD Photo Viewer
www.insigniaproducts.com
Using your clock radio
Using the clock and alarm
To set the clock:
1Press and hold TIME SET until the hour blinks on the display.
2Press TUNE+ or TUNE– to set the hour.
3Press TIME SET. The minutes blink on the display.
4Press TUNE+ or TUNE– to set the minutes.
5Press TIME SET to store the setting.
To set the alarm:
1Press and hold ALARM 1 (or ALARM 2, depending on the alarm you
want) until the hour blinks.
2Press TUNE+ or TUNE– to set the hour.
3Press ALARM 1 (or ALARM 2, depending on the alarm you want).
The minutes blink on the display.
4Press TUNE+ or TUNE- to set the minutes.
5Press ALARM 1 (or ALARM 2)to store the setting.
6Press ALARM 1 (or ALARM 2)repeatedly to set the alarm mode.
Settings include:
• Wake to buzzer–Bell icon appears to the right of the alarm icon
• Wake to radio–Music note icon appears to the right of the alarm icon
• Alarm off–Alarm icon disappears.
To turn the alarm off:
• Press any button other than SNOOZE/DIMMER to turn off the alarm
while the alarm is sounding. The alarm will be set for the same time the
following day.
• If you do not want to set the alarm for the next day, press ALARM 1 or
ALARM 2 repeatedly until the alarm icon disappears from the display.
To use the snooze:
• While the alarm is sounding, press SNOOZE/DIMMER. The alarm turns
back on automatically 9 minutes later.
• To cancel snooze (the alarm will not turn back on), press any button other
than SNOOZE/DIMMER. The alarm will be set for the same time the
following day.
NS-DPFC01 09-0621_MAN_ENG_V2.fm Page 14 Friday, July 24, 2009 12:14 PM

15
Insignia NS-DPFC01 Clock Radio with LCD Photo Viewer
www.insigniaproducts.com
Playing the radio
To play the radio:
1Press RADIO to turn on your clock radio.
• To tune the radio up or down and select the station you want,
press TUNE+ or TUNE–.
• To auto search for stations, press and hold TUNE+ or
TUNE– for more than two seconds.
• To adjust the volume to a comfortable level, press either the
VOL+ or VOL– button.
• To tune to the next preset station, press PRESET+.
• To tune to the previous preset station, press PRESET–.
2Press RADIO to turn off the clock radio.
Setting and using radio presets
To use presets:
1Press RADIO to turn on your clock radio.
2Press TUNE+ or TUNE– to tune the radio up or down and select
the station you want.
3To save the station as a preset, press MEMORY. “MEM” and “01” blink
on the display.
4Press PRESET+ or PRESET- to select the preset number you want
to designate for that station.
5Press MEMORY again to confirm the setting. The station is stored in
memory.
6Repeat Steps 2 to 5 to store as many as 20 presets.
7To select a preset station, briefly press PRESET+ or PRESET–
repeatedly until you reach the station you want. “MEM” appears on the
display, along with the preset number selected and the station
frequency.
Setting the sleep timer
To set the sleep timer:
1Press SLEEP once when the radio is on. The “SLEEP” indicator
appears in the display, and “90” appears (blinking) on the display
(indicating that the clock radio will turn off after 90 minutes).
Note
Standby mode is when only the clock is displayed. The radio
defaults to standby mode when the AC adapter is first
connected.
NS-DPFC01 09-0621_MAN_ENG_V2.fm Page 15 Friday, July 24, 2009 12:14 PM

16
Insignia NS-DPFC01 Clock Radio with LCD Photo Viewer
www.insigniaproducts.com
2Repeatedly press SLEEP to decrease the sleep timer in 10 minute
increments.
3To cancel the sleep function, repeatedly press SLEEP until “00” shows
on the display.
Adjusting the backlight
To set the backlight level:
1Make sure the power is connected.
2Press SNOOZE/DIMMER to set the display backlight to a
comfortable level, except when the alarm is on. Your choices include
High, Middle, or Low.
Displaying photos
You can view photos on your clock radio from three sources:
1. A compatible USB device connected to the USB port.
2. A memory card (SD/MMC/MS/XD) plugged into the memory card slot
on the side of your clock radio.
3. The clock radio’s internal memory (approximately 128 MB).
Connecting your clock radio to your computer
Photos can be transferred to your clock radio using your personal
computer.To connect to a computer you need a USB cable (provided).
To connect your clock radio to your computer:
1Plug in your clock radio (refer to “Plugging your clock radio”).
2Plug the small end of the USB cable into the USB cable port on the
clock radio, then plug the large USB connector into a USB port on your
computer.
Note
Your clock radio may not work with all versions of Microsoft
Windows.
NS-DPFC01 09-0621_MAN_ENG_V2.fm Page 16 Friday, July 24, 2009 12:14 PM

17
Insignia NS-DPFC01 Clock Radio with LCD Photo Viewer
www.insigniaproducts.com
3When the computer recognizes the clock radio as a drive you can
operate the clock radio as a USB drive.
To display photos:
1Press PHOTO DISPLAY (see “Top view” on page 5) in radio or standby
mode. The pictures playback automatically (if Slideshow Auto Play is
ON).
2Press PREV to select the previous photo, or NEXT to select the
next photo.
3Press PHOTO DISPLAY again to turn off photo display.
Notes
• When your clock radio is connected to the computer with
the USB cable,the large USB port of your clock radio cannot
be used at the same time.
• Your clock radio appears as a removable drive.The letters
of the drives may be different on your computer,depending
on how many drives already exist.
• Files can be transferred from your computer to your clock
radio by draggin the files from a folder on you computer to
your clock radio.
Note
The default seeting of Slideshow Auto Play is ON when you have
photos in internal memory, a memory card containing photos is
plugged into the memory card slot, or a USB device containing
photos is plugged into the USB port.
NS-DPFC01 09-0621_MAN_ENG_V2.fm Page 17 Friday, July 24, 2009 12:14 PM

18
Insignia NS-DPFC01 Clock Radio with LCD Photo Viewer
www.insigniaproducts.com
Changing the display
To use the photo menu:
1While in Photo mode, press PHOTO MENU to display the photo
menu OSD (on-screen display). The following menu opens.
2Press PREV or NEXT to highlight Photo Source, then press
ENTER to confirm. The Photo Source menu opens.
NS-DPFC01 09-0621_MAN_ENG_V2.fm Page 18 Friday, July 24, 2009 12:14 PM

19
Insignia NS-DPFC01 Clock Radio with LCD Photo Viewer
www.insigniaproducts.com
3Press PREV or NEXT to highlight the photo source you want, then
press ENTER to confirm.The Thumbnails menu opens.
4Press PREV, NEXT, TUNE+, or TUNE– to select the photo
you want, then press ENTER to view the photo in full screen.
Showing a slideshow
To show a slideshow:
1While in Photo mode, press PHOTO MENU to display the photo
menu OSD (on-screen display). The following menu opens.
NS-DPFC01 09-0621_MAN_ENG_V2.fm Page 19 Friday, July 24, 2009 12:14 PM

20
Insignia NS-DPFC01 Clock Radio with LCD Photo Viewer
www.insigniaproducts.com
2Press PREV or NEXT to highlight Photo Setup, then press
ENTER to confirm. The Photo Setup menu opens.
3Press TUNE+, or TUNE– to select the slideshow/playback mode
you want.
4Press ENTER or NEXT to open the submenu.
5Press TUNE+, or TUNE– to select the setting you want, then
press ENTER to confirm.
6Press PHOTO MENU to exit the onscreen menus. The slideshow starts
automatically if the setting of Slideshow Auto Play is ON.
Zooming in on a photo
To zoom in on a photo:
1In photo mode, press ZOOM to zoom in on a photo.
2Press ZOOM repeatedly to cycle through available settings.
3Press PREV, NEXT, TUNE+, or TUNE– to pan around the
photo.
Deleting or copying photos
To delete photos or copy photos (to internal memory):
1In the Thumbnails menu, press PREV, NEXT, TUNE+, or
TUNE– to select the photo you want to delete.
NS-DPFC01 09-0621_MAN_ENG_V2.fm Page 20 Friday, July 24, 2009 12:14 PM
