www.insignia-products.com 1
Welcome
Congratulations on your purchase of a high-quality Insignia product.
Your IS-PDVD10 represents the state of the art in portable DVD
player design, and is designed for reliable and trouble-free
performance.
Contents
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Getting to know your DVD player . . . . . . . . . . . . . . . . . . . . . . . 7
Basic setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Basic operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Advanced setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Advanced operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Español. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Features
Large content display — 10.2'' TFT wide-screen LCD display for a
cinematic video experience.
High resolution panel — Adopts MPEG-2 encoding format and
brings the horizontal resolution to over 500 lines.
10-2 inch swivel screen DVD.book Page 1 Tuesday, June 21, 2005 7:37 AM

2
IS-PDVD10 monitor portable DVD player
www.insignia-products.com
Compatibility — Playback compatible with DVD+R/RW, DVD-R/RW,
CD, CD-R/RW, MP3, and Picture CDs.
High-quality sound — Use either the built-in stereo speakers for
virtual surround sound or optional external speakers for digitally
enhanced audio.
Unique functions:
• Anti-shock protection lets you enjoy DVD playbacks anywhere.
• Parental lock makes it easy to control the content of the discs.
• Seven preset equalizers help to enhance playback of your
favorite music.
Highly adaptable — Watch home movies from a camcorder with
available AV mini-jack input that allows the player to be used as a
monitor.
Highly portable — Enjoy up to 3 hours of continuous playback with
included Li-ion battery.
Convenient multi-function remote — Useful functions such as fast
forward, fast reverse, slow play, frame-by-frame play, repeat, and
program play at the touch of the fingertip.
Zoom function — Enlarge pictures 2×, 3×, or 4×, or shrink to 1/2, 1/
3, or 1/4 of the original size.
10-2 inch swivel screen DVD.book Page 2 Tuesday, June 21, 2005 7:37 AM

3
IS-PDVD10 monitor portable DVD player
www.insignia-products.com
Safety precautions
The lightning flash with arrowhead symbol within a
triangle is intended to alert you to the presence of
uninsulated dangerous voltage within the player's
enclosure that may be of sufficient magnitude to
constitute risk of electric shock to persons.
The exclamation point within a triangle is intended to
alert you to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the player.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Warning To reduce the risk of fire or electric shock, do not expose this player
to rain or moisture. Dangerous high voltage is present inside the
enclosure. Do not open the case.
Warning To prevent electric shock, match the wide blade on the plug to the
wide slot and fully insert the plug.
Caution The player employs a laser system. To ensure the proper use of the
player, read this manual carefully and keep it for future reference. If
the player requires servicing, contact the seller or our service
center. For more information, see “Maintenance” on page 45.
To prevent direct exposure to the laser radiation, do not open the
case. Invisible laser radiation is present when the case is opened or
the interlocks are defeated. Do not stare into the laser beams.
Use of any controls, adjustments, or procedures other than those
specified herein may result in hazardous radiation exposure.
Caution Any change or modification to the player not expressly approved by
the manufacturer or its authorized parties could void your authority
to operate the player.
10-2 inch swivel screen DVD.book Page 3 Tuesday, June 21, 2005 7:37 AM

4
IS-PDVD10 monitor portable DVD player
www.insignia-products.com
Specific instructions
•Read instructions—Read all the safety and operating before
operating the player.
•Retain instructions—Retain the safety and operating
instructions for future reference.
•Warnings—Adhere to all warnings on the player and in the
operating instructions.
•Follow instructions—Follow all operating and use
instructions.
•Cleaning—Unplug this player from the power outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
•Handling—Take care not to drop the player or subject it to
strong shocks, which may cause damage or malfunction.
•Attachments—Use of attachments not recommended by the
player manufacturer may cause hazards.
•Using headphones:
• To avoid hearing damage caused by a sudden increase in
volume, keep the volume at the lowest level before
playback, then adjust it to a comfortable level.
• Keep the volume at a moderate level to protect your ears.
• To avoid traffic accidents, never wear headphones when
driving a car or riding a bicycle.
• Placement
Avoid placing the player in the following places:
• Under direct sunlight or near a source of heat, such as a
heater or header duct.
• In a closed automobile, on a dashboard or a parcel shelf.
Excess heat may deform the cabinet or cause malfunction.
• Where it is very dusty or sandy.
• In wet or humid places, such as a bathroom.
• Near sources of strong magnetism, such as a television or a
magnet.
• Where there is a lot of movement or vibration, such as on a
car dashboard or on an unstable shelf.
• Where it is extremely hot or cold.
• Where the player is exposed to rain or water.
•Power sources—This player operates on an AC adapter, car
adapter, or rechargeable battery.
• Make sure that the input voltage of the AC adapter is
compatible with the local voltage. Otherwise, the AC
adapter and the player may be damaged.
10-2 inch swivel screen DVD.book Page 4 Tuesday, June 21, 2005 7:37 AM

5
IS-PDVD10 monitor portable DVD player
www.insignia-products.com
• When connecting with a car (cigarette lighter) adapter, be
sure the input voltage of the adapter is identical with car
voltage.
• Unplug the AC adapter from the outlet, or remove the
rechargeable batteries, when the player will not be used for
an extended period of time.
• Hold the plug while unplugging the AC adapter. Do not pull
on the power cord.
•Grounding or polarization—This player may be equipped
with a polarized alternating-current line plug (a plug having one
blade wider than the other). This plug will only fit into the power
outlet one way. This is a safety feature. If you are unable to
insert the plug fully into the outlet, try reversing the plug. If the
plug still fails to fit, contact your electrician to replace your
obsolete outlet. Do not defeat this safety feature of the
polarized plug.
•Power cord protection—Power supply cords should be routed
so that they are not likely to be walked on or pinched by items
placed on or against them. Pay particular attention to cords at
plugs, receptacles, and the point where they exit from the
player.
•Lightning—For added protection during a lightning storm, or
when the player is left unattended and unused for long periods
of time, unplug it from the power outlet. This will prevent
damage to the player due to lightning and power-line surges.
•Overloading—Do not overload power outlets, extension cords,
or integral convenience receptacles as this can result in a risk
of fire or electric shock.
•Object and liquid entry—Never push objects of any kind into
this player. That could cause a fire or electric shock. Never spill
liquid of any kind on the player.
•Servicing—Do not try to service this playerplayer yourself.
Service must be done by qualified service personnel only.
•Damages requiring service—Unplug this player from the
power outlet and refer servicing to qualified service personnel
under the following conditions:
• When the power supply cord or plug is damaged.
• If liquid has been spilled, or objects have fallen into the
player.
• If the player has been exposed to rain or water.
Warning To avoid electric shock, do not touch the AC adapter with wet
hands.
10-2 inch swivel screen DVD.book Page 5 Tuesday, June 21, 2005 7:37 AM

6
IS-PDVD10 monitor portable DVD player
www.insignia-products.com
• If the player does not operate normally by following the
operating instructions. Adjust only those controls that are
covered by the operating instructions. The improper
adjustment of other controls may result in damage and will
often require extensive work by a qualified technician to
restore the player to its normal operation.
• If the player has been dropped or damaged in any way.
• When the player exhibits a distinct change in performance
which may indicate a need for service.
• Replacement parts—When replacement parts are required,
be sure the service technician uses replacement parts that are
specified by the manufacturer or that have the same
characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock, or other hazards.
•Safety check—Upon completion of any service or repair to
this player, ask the service technician to perform safety checks
to determine that the player is in proper operating condition.
Note When player is in use for a long period of time, the surface of the
player will be hot. This will not affect its operation.
10-2 inch swivel screen DVD.book Page 6 Tuesday, June 21, 2005 7:37 AM

7
IS-PDVD10 monitor portable DVD player
www.insignia-products.com
Getting to know your DVD player
Identification of controls and connections
THE DVD PLAYER
Item Name Function or control
1TFT LCD screen Displays the picture
2Speakers Provide the sound
3Open button Opens the DVD/CD tray
4Power On/Charge
indicator Indicates when power is on or the battery is charging.
5Remote sensor Receives commands from remote control.
6Play button Starts playback of the DVD or CD.
12 PHONE POWER ON OFF
AV O U T C O A X I A L AV I N
VOLUME DC O UT 5V DC IN 9V
1918 21 2423 2522
20
1
2
3
765 84
9
10
678
11
11
12
13
2
14
14
15
16 17
10-2 inch swivel screen DVD.book Page 7 Tuesday, June 21, 2005 7:37 AM

8
IS-PDVD10 monitor portable DVD player
www.insignia-products.com
7Pause button Pauses the playback of the DVD or CD.
8Stop button Stops the playback of the DVD or CD.
9Direction buttons Changes the direction of the DVD and
navigates the OSD or on-screen menus.
10 Enter Confirms a selection or operation.
11 Prev/Next Causes the DVD or CD to skip forward or back.
12 FR/FF button Fast Reverses or Fast Forwards a DVD or CD.
13 OSD Opens the On Screen Display to adjust the
picture or change settings.
14 Menu Accesses the DVD/CD menu.
15 Top menu Accesses the DVD title menu.
16 Source button Switches between signal sources (DVD, AV
OUT, AVIN).
17 Monitor Accesses the monitor adjustment menu.
18 Phone jack Provides output signal for earphones.
19 Power On/Off Turns the player on or off.
20 Volume Increases or decreases the output sound level.
21 AV out Outputs the picture and sound to another
display.
22 Coaxial Provides coaxial digital audio output.
23 DC out Provides power to an optional TV tuner.
24 AV in Accepts input signal from an optional TV tuner.
25 DC In Connects to AC adapter.
Item Name Function or control
10-2 inch swivel screen DVD.book Page 8 Tuesday, June 21, 2005 7:37 AM

9
IS-PDVD10 monitor portable DVD player
www.insignia-products.com
THE REMOTE CONTROL
Item Name Function or control
1OSD Opens the on-screen display to adjust the
picture. For more information, see “Playback
options - OSD” on page 39.
ANGLE LANGUAGE
PLAY MODE
OSD
RESUME
AUDIO MODE
SLOW PAUSE STOP
A-B
RETURN
ZOOMSETUP
SEARCH SKIP
TIME SEARCH
CLEARMENUTOP MENU
DIGEST
+10 10/0
56
89
4
7
2
REPEAT
RC-1700
SUBTITLE
1
4
3
6
5
7
10
9
11
12
8
2
13
14
16
15
17
18
19
20
23
21
22
25
24
26
13
10-2 inch swivel screen DVD.book Page 9 Tuesday, June 21, 2005 7:37 AM
