Insignia NS-HZ335-C User manual

SETTING UP YOUR SWITCH
1Connect HDMI cables (not included) from your
source devices to the switch’s INPUT ports.
2Connect an HDMI cable from your TV (or projector)
to the switch’s OUTPUT port.
3Connect the power adapter from the DC 5V port to
a power outlet. The power LED and an input LED
light up.
Before using your new product, please read these instructions to prevent any damage.
PACKAGE CONTENTS
• 3-Port HDMI switch
• Power adapter (Micro USB)
• Quick Setup Guide
Back view
HDTV
or 3D TV
Satellite
receiver
DVD or
Blu-ray
player
Game
console
FEATURES
• HDMI® 3D & 4K video format supported
• HDMI® 2.0 / HDCP 2.2 compliant
• DTS-HD®, Dolby® TrueHD lossless compressed
digital audio compliant
• Plug-and-Play, installs in seconds
• Connect up to three HDMI sources using only one
HDMI port on your TV
• Supports full 4K HDR signals up to 18 Gbps
• Push-button selection for easily changing the input
Note: HDMI cable(s) not included
Your 3-Port HDMI Switch supports the latest 4K video
and next-generation audio signals.
Note: In the unlikely event that a feature is not supported,
neither the picture nor the sound quality would be
degraded.
Power adapter
HDMI
cable
HDMI
cable
HDMI
cable
HDMI
cable
QUICK SETUP GUIDE
3-Port
HDMI Switch
NS-HZ335 / NS-HZ335-C
Power port HDMI output
HDMI inputs
Top view
SELECT
Select
button

V3 ENGLISH 21-0875
USING YOUR SWITCH
1Turn on your TV and source device.
2To select a source device, press the SELECT
button repeatedly until the LED indicator lights
for the source device you want.
3Use your source device as usual to play video
and audio.
Note: You may leave the power on while not in use.
SPECIFICATIONS
• Dimensions (L × W × H): 5.1 × 2.9 × 0.8 in. (13 × 7.6 × 2.1 cm)
• Weight: 0.21 lbs. (96.3g)
• Power supply with micro USB connector: 5V DC/600mA
• Resolution: 480p, 720p, 1080p, and 4K (up to 4K at 60Hz or
1080p at 120Hz)
• Frame Rate: Up to 4k at 60 Hz (1080p at 120 Hz)*
• Color: Deep Color, HDR, and other expanded color spaces
• Audio:Works with all audio formats supported by the HDMI
standard
*Note: TVs with high internal refresh rates (such as 240 Hz) are compatible.
The specications refer to source signal and notTV refresh rate.
TROUBLESHOOTING
No video and/or audio
• Make sure that all connections are correct and secure.
• Make sure that the switch is plugged in and turned on.
• Make sure that the switch is set to the correct source device.
• Make sure that yourTV (or projector) is set to the input/source that your
switch is connected to.
• Make sure that the audio and video formats (such as a Blu-ray disc) are
supported by the source device and display that you are using.
• Unplug the switch’s power cable, wait 10 seconds, then plug it back in again.
• Make sure that yourTV or projector supports the video resolution that your
source device is using.
• Make sure that your HDMI cable is not damaged.Try connecting a dierent
HDMI cable.
• Long HDMI cables may cause signal loss.Try a dierent, shorter HDMI cable.
HDCP error
• Unplug your switch’s power cable, wait 10 seconds, then plug it back in.
• If you connect any output to your video recorder, the HDCP may automatically
lock up audio. Make sure your video recorder supports HDCP.
The input source will not change
• Unplug the HDMI cable and plug it in again.
My display does not show 4k or 3D content
• Make sure that your source device and display support 4K or 3D content and
that you have 4K or 3D content on your source device.
Note: For maximum compatibility, this device will not relay CEC commands between devices.
Power, input switching, and other controls must be done on individual devices.
NOTICE
• Manufacturer reserves the right to make changes in the hardware, packaging,
and any accompanying documentation without prior written notice.
• HDMI®, the HDMI® Logo, and High-Denition Multimedia Interface are
trademarks or registered trademarks of HDMI® Licensing LLC.
• NS-HZ335 incorporates HDMI® technology.
• Trademarks and brand names are the properties of their respective owners.
LEGAL NOTICES
FCC Statement
1. FCC Caution - §15.21:
Changes or modications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
2. FCC Statement - §15.105(b):
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable protection
against harmful interference in a residential installation.This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
ONEYEAR LIMITED WARRANTY
Visit www.insigniaproducts.com for details.
CONTACT INSIGNIA:
For customer service, call 1-877-467-4289 (U.S. and Canada)
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its aliated companies.
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richeld, MN 55423 U.S.A.
©2021 Best Buy. All rights reserved.
