insize ISP-A5000 User manual

www.insize.com
ISP-A5000/A5000E
PROFILE PROJECTOR
OPERATION MANUAL
V0
MN-ISP-A5000/A5000E-EMN-ISP-A5000/A5000E-E

1
Description
1
2
3
4 5
6
7
8
9
10
1Key functions:
1. LCD Display 2. Soft Keys 3. LCD Standby On / Off Key 4. Feature
Measurement Keys 5. Help Keys 6. Arrow Keys For Navigation 7. Utility
Keys 8. Numeric / Function Keys 9. Coordinate And Unit Switch Buttons
10. Axis Reset Keys
Point Feature key
Line Feature Key
Circle feature key
Distance Feature Key
Angle Feature Key
Skew Feature Key
Wonder Feature Key
Inch / mm Key
Absolute / Increment Key
Polar / Cartesian Key
Point create function
Arc create function
Construct
Line create function
Circle create function

2
Cross Hair measurement
Automatic Edge Detector measurement (ISP-A1000E)
Counter clock wise direction
Clock wise direction
Degree Decimal mode (90.0000°)
Degree Minutes Seconds display mode (90°.00'.00'')
Contrast level increase
Contrast level decrease
Select
Exit
Open
Yes
No
On (Disable)
Off (Enable)
Auto edge detection setup (ISP-A1000E)
Engineering Setup
View Results
Delete Selected Result
Delete all result
A
Program menu
Tolerance option
Print Result Buffer
Repeat Function
Ce n tre - Ne a r-F a r Ke y. Visi b le o n ly wh e n re s ult i s
constructed Distance Either from two lines or two circles.
Center Distance between two circles or lines
Nearest Distance between two circles or lines
Farthest Distance between two circles or lines
25
The surfaces of optical parts should be kept clean. They should not
be touched with hands. If any dirt, oil fleck or dust are found on the
surfaces, they should be removed with soft brushes, or they should
be removed with clean linen or lens paper soaked in methyl benzol
or in a mixture of alcohol and ether. Try to rub the optical surfaces as
less as possible.
The instrument should not be operated with a big force. All bare
metal surfaces of the instrument and the accessories should be
wiped clean and coated with protection grease after operation.
When work-piece with larger diameter is to be measured, take down
objectives 50x and 100x and place them into the accessory box.
Objectives, guides and condenser have higher precision. They
should not be dismantled optionally. If it is necessary, they should be
sent to the specialized factories for repair.
2
3
4
5

3
2Back panel:
1
2
3
4567
8
910
1. ON/OFF Switch 2. Spare Fuse (250VAC, 800mA) 3. Power Inlet Point
4. Connector for Edge Detector (Optional) 5. Rotary Encoder Input 6. Y
Linear Encoder Input 7. X Linear Encoder Input 8. Printer Interface 9.
Foot Switch connector 10. USB Connector
3Layout of the Screen:
1 2 3 4 5
6
7
8
10
9
1. Unit
2.Measurement Mode
3.Coordinate System
4.Permenent Storage
5.Message Window
6.X Axis
7.Y Axis
8.Angular display
9.Scroll Soft Key status
10.Soft Key
The setup can be accessed by pressing the followed by key .
The user will be prompted for password. The password is “98563”.
Use [ ]or [ ] key to scroll within the menu.
Setup
24
Point Tolerance:
Highlight the desired point feature from the result list. Press
{ } key and then Press { } key.
1
Enter the nominal values for X and Y co-ordinates. Also enter the
tolerance zone.
Tolerance zone is the radius within which the point should be
located. If the point is located outside the zone, tolerance fails.
Press { } key then enter the nominal values for X and Y
co-ordinates. Also enter the +/- values for each nominal
value.
Limits allow the user to set upper and lower limits on a value.
For example, a nominal value of 10.3250 might have an upper
limit of 10.3260 and a lower limit of 10.3240. For example, if a
part drawing gives a +/- tolerance of 0.005, simply enter 0.005 in
the plus and minus fields.
After set press { } key. The result of tolerance Pass or Fail is
shown for the selected feature.
Use the same way to set Tolerance for line, angle, circle and
distance.
2
Maintenance
1The projector is a kind of precision optical instrument. Attention
should be paid to its maintenance so as to guarantee the precision
and lengthen life of the instrument. The instrument should be
installed in a clean room, the temperature of which should be
maintained at 20° ± 5℃. The relative humidity of the room should
not exceed 60﹪ so as to prevent the optical parts and reflecting
mirror from molding and to keep the high quality of the image.

4
No. of Axis: Selects the no. of axes to display.
Annot Bck/ Annot Fwd: Selects Forward annotation or Backward
annotation.
Annotation points: This is used to set Annotation points for each
measurements.
Relational parameter: This is used for Wonder function.
Sleep Mode Time(Min): DRO stand-by Time to save power.
Key Beep Enable: Enables / disables beep on every key press.
Program Lock: Enables / Disables new Programs.
Persist Memory: Enables / Disables Permanent storage of result
memory.
Diagnostics: Keyboard diagnostic.
Select Axis: Axis specific settings.
Apply Comp X-axis: X axis calibration selection:
None – No calibration;
L.comp – Linear compensation;
S.Comp – Segmented error;
compensation;
Grid – Grid Compensation.
Apply Comp Y-axis: X axis calibration selection:
None – No calibration;
L.comp – Linear compensation;
S.Comp – Segmented error;
compensation;
Grid – Grid Compensation.
Edit User info: Enables user to set user information like Customer
Name, Machine Name and Operator Name.
Serial Communication: Enables the user to set the Serial
communications parameters.
Cross hair and mounted edge detector probe may have physical
position offsets, hence to obtain accurate results; we must do the
cross calibration process for every magnifications.
If we don’t execute cross cal, and if we probe a circle by cross
hair and by edge detector, in both cases, we will get diameter
equal but centre coordinates will be different.
In this mode the user has to probe a circle using Edge detector
and again probe the same circle using cross hair. The result of
Cross calibration is displayed as shown below.
Save the changes and exit Edge detector calibration.
3
Measurements using Edge Detector mode:
For performing feature measurements using Edge detector,
select Edge mode by pressing { } soft key in DRO mode.
Now press any feature key and probe points using Edge detector.
Rest procedure remains same as explained in Geometric Feature
Measurement chapter.
4
Tolerance
Tolerance helps users maximize productivity. A tolerance is an
acceptable deviation from the nominal specification of a part. For
example, a pin might have a nominal diameter of 5.000 mm. Without
tolerance, only pins with a diameter of .5.000 mm are acceptable.
This means that pins that measure 4.999 mm or 5.001 must be
rejected. With tolerance an acceptable deviation from the nominal
specification is defined. For example, the diameter of 5.000 mm
might have a tolerance of +/- .05. This means that pins as small as
4.950 mm and as large as 5.050 mm are acceptable.
23

5
Set Factory Settings: All the engineering settings are set to
factory default parameters.
Configure Footswitch: Enables the user to assign any key from
keyboard to footswitch 1 and 2.
X, Y Liner Setup
Scale Resolution: Sets the scale (encoder) resolution(0.1, 0.2,
0.5, 1, 2, 5, 10, 20, 50µm).
Display Resolution: Sets the display resolution(0.1, 0.2, 0.5, 1, 2,
5, 10, 20, 50µm).
Axis Direction: Sets encoder counting direction.
Machine ref: Sets machine reference for the axis.
Count per Revoln (CPR): In case of auto, the DRO calculates the
counts between the two index marks and calculates the CPR
automatically. In case of manual selection the user needs to enter
the CPR value.
Resolution (Deg): Selects the display resolution for the angular
axis(0.5, 0.2, 0.1, 0.05, 0.01, 0.005, 0.001, 0.0005°).
Axis Direction: Sets encoder counting direction(CW or CCW).
Machine Ref: Sets machine reference for the axis.
Count Mode: Selects the counting mode(Rollover or Continues).
Display Mode: Selects the display units: DDMMSS or DDDEC.
Axis Lock: Enables / Disables the angular axis position settings.
Z Angular Axis
Axis calibration is required to compensate for errors arising due to
wear and tear in machine, encoder misalignment etc. Each axis can
be calibrated for Linear Errors or Segmented errors as applicable.
Axis Calibration
22
Screen Gain (<10000) – This sets the gain of the amplifier. The
gain depends on the magnification and the light source. Adjust
this such that the Screen intensity on light region displays counts
above 3000 counts to 4000. In case of higher magnifications
where the counts doesn't reach the required value even if the gain
is set to 100, then minimum of 2000 counts should be ensured for
good results. Press { }key to set the gain value.
Now bring the screen sensor in the light region and press { }
key.
Now move the screen sensor in to dark region. Press { } k ey
to teach dark to the DRO. Here note that the counts in the dark
region are less than that in the light region.
NOTE: Every time the light intensity changes it is recommended
to teach light and dark region to the D RO for p roper
measurements. No need to change the gain of the system.
Now perform Edge calibration. In this mode the selection is
provided for bore or shaft measurements. If the user wants to
check bore jobs he has to perform bore calibration using F.O.
Edge detection prior to measurements.
NOTE: It is mandatory to calibrate the type of job either bore or
shaft prior to measurements using F.O. Edge detection.
Now probe the circle as per procedure explained earlier. Press
[ ] key to complete the measurement. Following screen is
displayed.
Now enter the standard diameter of the circle. The DRO will
calc ulate the calibration factor and apply it during the
measurements by Edge detector.
Cross Calibration:
The cross calibration function eliminates the difference between
2

6
Linear Error Correction(L.Comp/LEC):
In this mode place a slip gauge of standard length on the X-Y
table. Align it properly for calibration.
Now bring cross hair to one of the edge of slip. Reset the axis.
Now move the crosshair to other end of the slip and note down the
display reading. Now enter the Linear compensation mode for
that axis by selecting {L. Comp} at “Apply Comp X Axis”.
Enter the standard value as the slip value and the observed value
using the numeric keys on keyboard. Press [Enter] to confirm.
The DRO will calculate the linear calibration factor and stores into
its memory. The user can edit this calibration factor by changing
the observed value or the standard value in the same mode. After
doing this you may check the axis performance by measuring
different slips and confirm the accuracy.
1
Segmented Error Correction (S.Comp / SLEC):
Segmented Linear Error Compensation (SLEC) is used when the
results of the comparison with a reference standard shows non-
linear error. In SLEC the entire axis travel is divided into user
defined segments. The error in each segment is compensated
with a single correction factor. Each correction point is measured
with respect to the starting point. This starting point is usually set
close to the end of the scale. This starting point can coincide with
the absolute datum point or Home reference.
2
21
DRO mode press { } key to enter Edge detector calibration.
Following screen will be displayed.
A
The Setup depends on the magnification and the light intensity.
DRO allows the user to save up to 10 magnifications. These
magnifications can be recalled any time when the magnification
on the machine is changed. Following soft keys are available on
this screen:
Using this option a new magnification setup can be saved.
The user is asked to enter the name of magnification level
by displaying the data entry screen. On entering the name
the DRO displays FO setup.
Open the selected magnification setup. The DRO will
display the Setup for the selected magnification as shown
below:
Exit from the setup.
Delete the selected magnification setup.
Use the setup parameter for the selected magnification.
Using this the selected magnification level can be
renamed.
A
Following are the FO Setup parameters and their significance:

7
Perform Machine reference in the axis settings. After
performing machine reference do not set or reset the axis till
the complete SLEC calibration is complete.
Divide the travel into user defined segments.
Enter into standard measurement mode (DRO mode).
Note down all the standard values and the observed values for
each segment.
Enter the setup mode and select {S.Comp} for the respective
axis.
Start entering the standard values and observed values one
by one.
Press {Next} every time the values for that segment are
entered.
Press [Enter] to complete the SLEC entry.
On pressing the [Enter] key all the entered segments are
stored and the SLEC compensation is applied to that axis.
The “No. of SLEC Segs” Indicate the maximum no. of
segments entered prior to this entry.
Calibration Procedure:
Select the {S.Comp}key for the respective axis which is to be
edited.
Select the required segment by pressing {Next}.
Enter the new Standard and observed values and select the
next segment by pressing {Next}.
Calibration Edit Procedure:
When all the segments are complete press [Enter] key.
20
Edge Detector(For ISP-A1000E)
Optical Edge detection can be used with DRO to increase throughput
rates, increase measurement accuracy, improve measurement
consistency and reduce operator fatigue. In this mode after selecting
a point the user is not required to press [ ] key but the point is
probed automatically as the sensor travels from either Light to Dark
or Dark to Light region.
A
Fiber-optic cables cannot be bent to a radius less than one inch
without degrading performance. Be careful to prevent bending or
pinching the cables.
Fiber-optic cables cannot be exposed to temperature higher than
70 degrees Celsius without degrading performance.
Use of C.V.T. (Constant Voltage Transformer) is recommended
for better performance of edge detection circuit as fluctuations
may cause intensity variations on the screen.
Edge Detector Calibration:
Before using Edge detector for measurements it is necessary to
calibrate it. It is necessary to calibrate the DRO prior to this
calibration. Mount the demonstration slide on to the X-Y table. In
1

8
Grid Calibration:
It is also referred to as Non Linear Error correction (NLEC).
In this the entire measurement area is divided in to a grid. Each
grid cell compensates for variation with its own error correction
coefficient. It is mandatory to set the machine reference for each
axis before NLEC.
Specify the nominal and measured X and Y coordinates from the
standard during the setup process. NLEC requires a repeatable
machine zero defined on startup.
3
The changes will get saved in the memory and are applied.
The user will have to perform machine reference on every power
ON if SLEC is selected for an axis.
Machine Reference
Here the Machine reference can be set forthe selected axis. The
standard reference output from the encoder is used for referencing.
This is used only in case Segmented Linear compensation is to
selected.
19

9
Calibration Procedure:
Keep the encoder position near to the desired reference on the
encoder.
Press { }key in “Machin e Ref . ” in axis setti n g s .
“Homing”Message is shown on the screen.
Pass the reference mark on the encoder. Here the DRO will reset
the axis on the reference mark.
Go to the machine reference position and press { }key.
Normally this is the start position of the segnments
Calibration procedure for Z (Angular) Axis
Manual Calibration of Z axis:
User can calibrate angular axis manually by pressing manual
softkey. Display value will show counts of respective rotation.
User will enter angle of rotation in seconds. Now user can
calculate calibration factor by pressing calc softkey.After
calibration press [Enter] to save the calibration factor. Press
[Cancel] if the user wishes to exit without saving.
1
Auto Calibration of Z axis:
User can calibrate the angular axis automatically by selecting the
{ }key. The DRO waits for two complete rotations of the
encoder and then calculates the calibration factor by calculating
the counts between the two reference marks on the encoder. To
calibrate the Z axis using auto mode requires only one condition
that it must have only one reference mark for each rotation.
2
18

10
Point Measurement:
Measurement
1
Press [ ] key to measure a point.
Now move the X-Y table near to the desired point. Match cross
hair on the point and press [ ] key.
Take more points or if sufficient points are taken press [ ]
key.
A
Line Measurement:
A line can be measured by selecting between 2 to 20 points.
2
Press [ ] key to measure a line.
Now target a point on the line and match cross hair on it. Press
[ ] key.
A
Now in similar manner probe sufficient points to form a best fit
line. And then press [ ] key.
A
Circle Measurement:
A circle can be measured by selecting between 3 to 30 points.
3
Press [ ] key to measure a circle.
17
Press key which displays the list of measured features.
A
Scroll using the navigation keys and press {}key to select the
feature. On pressing the will select the previous result
automatically.
Press [ ] key to complete the construction and calculate
the result.
Different types of construction:

11
Now target a point on the circle and match cross hair on it.
Press [ ] key.
A
Now in similar manner probe sufficient points to form a best fit
circle. And then press [ ] key.
A
ARC Measurement:
An arc can be measured by selecting between 3 to 30 points.
Press { }key to measure a circle.
Now target a point on the Arc and match cross hair on it. Press
[ ]key.
Now in similar manner probe sufficient points to form a best fit
arc. And then press[ ] key.
A
Distance Measurement:
Using this feature distance between two points can be measured.
Press [ ] key to measure distance between two points.
Now target the required point and match cross hair on it.
Press [ ]key.
A
Now target the second point. And then press [ ] key. The
distance between these two points will be displayed in the
result screen.
A
4
5
16
Result Buffer View:
To view a results measured press { } key. A graphical view
of results will be displayed. Use up-down arrow keys to move next
or previous results one by one or press { } key to recall
particular result.
9
: Exit from result buffer view.
: Visible only if result is Constructed Distance from two
circle or two line results. Toggle between Centre-Near-Far
distances.
: Delete result. Here the operator is prompted with two
options:
: Delete current result;
: Delete all results.
: Tolerance options for current result.
: Recall particular result.
: Print the result buffer via thermal printer(Optional).
Construction:
Feature construction is the process of combining existing
features to generate a new feature.
New feature can be constructed using existing features that were
measured or constructed.
The result of construction is displayed in the result window. Also
the user can see the constructed feature graphically. Form is not
applicable to constructed features, apart from that these features
are same as any measured or probed feature.
Construction Procedure:
10
Press the desired feature which is to be constructed.


12
Angle Measurement:
Angles can be measured by probing points between two lines. In
this mode the DRO automatically prompts the user to measure
1st line and the 2nd line. Each line can be measured by probing
between 2 to 20 points. Accuracy of this measurement is
increased if more number of points are probed over greater
distances.
After probing both the lines the angle between them is
determined by using best fit algorithm.
The measured angle can be displayed in 4 ways. The user can
change the angle display using [ ] key of the 3rd axis. The four
angle measurement types are as shown below.
6
Press [ ] key to measure angle.“Probe Line 1” message will
be displayed.
Now measure 1st line by targeting the required point and
match cross hair on it. Press [ ] key.
Now similarly target more points. And then press [ ] key to
end probing line 1. “Probe Line 2” message will be displayed.

Similarly probe line 2 and press [ ] key. The angle result
screen will be displayed.

Wonder Measurement:
Wonder feature helps to minimize key presses during feature
measurement. Also it automatically detects which geometrical
shape has been probed. This feature can be activated once or
repeat.
8
15
Skewing the job is also possible from constructed features. The
result of constructed feature should a line, since skew is applied
on a probed line.
For example, if a line is constructed from a circle and a line. The
result line is the skewed line. And all the measurements are with
respect to this line.
If we press [ ] key in normal counting mode,. Now if we probe
the points (without pressing feature key), and press [ ] key,
the DRO will show the result of probed feature.
If we want to probe the feature again without pressing feature
key, we have to press [ ] key again.
A
A
If we press [ ] key twice, symbol will be displayed on the DRO
screen at right top corner. Now we can probe the features
repeatedly without pressing feature keys.
A
Pressing [ ] key will exit from Wonder feature.
In SETUP MODE, there is one option, to set “Relational
Parameter OFF” or “Relational Parameter ON”.
To detect an angle, two main things must be considered while
probing the points.
1) There are two limbs of angle and on both limbs; equal number
of points must be probed.
2) On either limb, at least three points must be probed.
A

13 14
Skewing the Job:
During measurement of any part for its dimensions, it is
necessary to perfectly align the part on the co-ordinate
measuring system. Any misalignment of part will result in
inaccurate measurements.
The part to be measured cannot be aligned exactly with co-
ordinate measuring system of machine. Therefore it is necessary
to skew the Job prior to measurement.
The skew function converts machine co-ordinates to part co-
ordinates by electronically compensating for part misalignment.
7
Note: As shown in the above figure, the part must be placed within
45 degrees of the machine’s co-ordinate system.
Procedure for skewing the job:
Press [ ] key. Following screen will be displayed.
Press [ ] key to complete skew measurement. The result
s c r e e n i s d i s p l a y e d a s s h o w n b e l o w. A n y f e a t u r e
measurement done henceforth will be with respect to skewed
co-ordinates. For indication of skew, the X and Y axis labels
are represented as shown below.
Now probe line which is to be skewed. Use standard
procedure for line measurement. Probing more points will
increase the accuracy of skew measurement.
A
Pressing [ ] key will exit from skew mode. The DRO will
prompt to cancel skew. Now on the DRO functions in normal
mode.
