SAGE Analytics The Luminary User manual

Start Measuring Samples
1
2
3
The Beacon measures the potency
percent (percent weight) of each of
these values: THC-A, Delta-9 THC,
Total THC, Total Potential THC, CBD-A,
CBD, Total CBD and Total Potential CBD*
On the touchscreen, choose your
sample type and continue:
Dry Sample (Buds, Trimmings)
Clean the measurement window, ensuring
there is no residue or haze remaining.
Place the clean, empty bud holder on the
measurement window, aligning the holder
with the adjacent pins.
Loosely fill the bud holder all the way to
the top with ground sample.
Press the bud holder cap in place, which
compresses the sample for measurement.
Press CALC to obtain the potencies
for the sample.
4
5
6
7
Once the potencies are displayed on the
touchscreen, enter the relevant information
regarding the product name, sample type,
and your name.
Press PRINT to print out the CannaMetric™ Profile Label.
A disposable sample cell is used to measure concentrates. The cell
contains an external reflector (the white side) that is used to pass the
light shone through the sample, back through the
sample, and on to the instrument detector.
1
2
3
4
5
6
Concentrate (Extracts, Waxes, Hash, Kief)
Sage Assist: 855-882-4750 • Email: [email protected] • Web: www.sageanalytics.com
The LuminaryTM Beacon
Quick Start Guide
Beacon Label Printer
White reference puck
Bud holder
Set Up the System
Start the Beacon
Wait 20 Minutes for Warm Up
Connect the CannaMetric™Label Printer
Clean the Measurement Window
Conduct a Black Calibration
Conduct a White Calibration
Start Measuring Samples
Disposable sample cell
The Beacon performs an instantaneous and accurate measurement of
potency in cannabis products. It shines and analyzes near infrared light
to report on information about the molecules in each sample.
The Beacon uses light. Measurement accuracy requires cleanliness.
1
2
3
4
5
6
7
8
8
Dry Sample
Buds and Trimmings
Concentrate
Extracts, hash, waxes, and
products you can see through
Note: Steps 2 through 6 must be conducted every time
the Beacon is turned off and back on again.
Snap the disposable sample cell halves
together. Place the empty disposable sample
cell onto the measurement window such that
the round indentation in the center of the
disposable is on the bottom, close the lid,
and press NEXT . This will establish a baseline
measurement for just the sample cell.
Using the same sample cell, add the concen-
trate to the indentation inside the sample cell,
which is the sample well, and snap the cell
shut. We recommend adding a small amount
with a spatula and spreading evenly in the
sample well. Only fill the round well; there is
no need to fill the entire inside of the sample
cell, as only the sample contained in the well
will be measured. Given the thickness of these
types of samples, a little can go a long way.
Place the disposable sample cell onto the
measurement window such that the round
indentation in the center of the disposable is
on the bottom, close the lid, and press NEXT .
The cell is designed to fit in the square portion
of the Beacon measurement window.
Press CALC to obtain the potencies for the sample.
Once the potencies are displayed on the touchscreen, enter the relevant
information regarding the product name, sample type, and your name.
Press PRINT to print out the
CannaMetric™ Profile Label.
*Refer to the “Cannabinoid Explanation” sheet for further information on each of these values.

To perform the black calibration, simply close the sample holder lid,
and press NEXT. The system will conduct the calibration, and will
move on to the white calibration screen.
Get the white reference puck:
Place the white side of the puck
down on the Beacon measurement
window. Ensure that the puck is
covering the window. For this step
do not close the lid.
Press NEXT to perform the calibration
then remove and appropriately store the puck.
Conduct a Black Calibration
Conduct a White Calibration
1
The white reference is encapsulated in glass. Be careful not to touch
the white area, get it dirty, or scratch the glass. The Beacon assumes
the white area is 100% reflective for producing a maximum signal for
measurement. Use the rubbing alcohol wipes to clean it when necessary.
A daily calibration is required to normalize the system. It must be known
how the Beacon responds to the maximum amount of light coming into
the window (white calibration) and no light coming in (black calibration).
1
2
3
Carefully remove the Beacon from the box.
Place the unit on a flat and stable work surface. Keep it away from
any bright lights or strong air flow, such as a fan.
Plug in the Beacon and turn it on.
Set Up the System
AC power connection Power switch
1
2
3
Connect the
CannaMetric™ Profile Label Printer
1Place the label printer next to the Beacon,
and connect using the USB connection
port in the back of the Beacon. The power
cable on the printer should be connected
to the printer and the wall outlet.
7
1
2
46
Start the Beacon Interface
After turning on the Beacon base, a blank screen will appear, followed by
a screen indicating that the system is loading (which takes approximately
30 seconds). Once the system has loaded, you will be automatically
taken to Step 3.
The cleaner the window the more of the sample is detected
and reliably measured.
Clean the window after every measurement.
Let the window dry completely before you place a sample on it.
The window is made of sapphire and is very difficult to scratch
(but please don’t try).
Clean the Measurement Window
Tips
5
The Beacon sees the sample through the measurement window.
It is critical to keep this window clean by using rubbing alcohol wipes.
1
2
Clean the measurement window
with alcohol wipes and allow to
completely dry.
If the wipe leaves a foggy
residue, wipe o with a clean,
lint-free cloth
3Wait 20 Minutes for Warm Up
When you first turn it on, the Beacon requires
20 minutes for the lamp to warm up and reach
a stable system temperature. On the touch-
screen, the warm up window looks like this:
