Micromeritics AccuPyc 1330 User manual

AccuPyc 1330
Quick Reference Guide
(mt micromeritics " -----'

USING THE KEYS
To select the primary
function on the face of
the key, press only that
To select the alternate
---- function printed above
key. For example: ___ _
press l ir · lto enter
the key, fIrst press the
white key, then press
the number 6. the kiY' For
Ip~Ts"l; : . 1
press""" """
to print areport.
STANDARD KEYS -------------------
Enter the numbers 0 through 9.
Enter a decimal point or a dash for sampie ID.
Complete an entry or begin an action.
Display the next message when in display mode. Display the
next multiple choice item when in a command mode.
Clear a message when in display mode. Clear an entry when
in a command mode.
Save the information you entered and return to display mode.
Change the keypad mode. The keypad may be used in either
primary function mode or alternate function mode.
When you press the white key to enter alternate function
mode, a plus sign (+) appears in the upper right corner of
the displayand the commands written above the keys
become available.
To exit alternate function mode, press the white key again.
The plus sign (+) will be removed from the display.

KEYCOMBINATIONS-------------------
ZERO
CALIBRATE
MANUAL
S ET UP
TRANSMIT
ESCAPE
ANALYZE
REVIEW
PRINT
FILL
EXPAND
VENT
,----------, 11 Hol
I li~ nl
'----------'
II i! i l
II
(i! (I
II i!
nil
I i7il
(when in
Manual Mode)
kIä'l
(whenin
Manual Mode)
l /g . Il
(when in
Manual Mode)
Zero the pressure transdueer.
Calibrate the pyenometer.
Manually eontrol the valves.
Mter pressing
the Manual key, you may use the FILL,
EXPAND, and VENT keys to open and
c10se the valves.
Display
or edit analysis parameters, report
options, calibration volumes, data transmis-
sion parameters, unit types, and operating
language.
Transmit analysis
or calibration data over the
serial line.
If an automatie operation is in
progress, transmit a partial report.
Delete all data entered in the eurrent mode
and return to display mode.
If an automatie
operation is in progress, eancel it.
Perform
an analysis.
Review
or edit eompleted analysis or calibra-
tion data.
Print analysis or ealibration report. If an auto-
matie operation is in progress, print a partial
report.
Open and c10se the fill valve. The indieator
above the FILL
key is on when the valve is
open and
off when the valve is elosed.
Open and c10se the expansion valve. The
indicator above the EXPAND key is on
when the valve is open and
off when the
vaIVe is c1o s ed .
Open and c10se the vent valve. The indicator
above the VENT key is
on when the valve
is open
and off when the valve is elosed.

PERFORMING AN ANALYSIS ----------------
1. Weigh the empty sampie cup and record the weight
2. Place sampie in the cup and dry it thoroughly in an oven.
3. After preparing the sampie. weigh the cup and sampie and record the weight. Subtract
the empty sampie cup weight from the sampie cup plus sampie weight to determine the
sampie weight Record the sampie weight.
4. Remove the cell chamber cap.
5. Insert the sampie cup into the cell chamber and replace the cell chamber cap.
6. Press LI _-----' I[ @liN nonthepycnometerkeypad.
7. If Sampie ID is displayed. enter the ID and press lEl'tltill. If not, skip to step 8.
8. If Sampie Weight is displayed. enter the weight and press l ' Ii!rtli'~I. If not. skip to step 9.
9. Press I El'tltä Ito start the analysis.
10. As the analysis is perforrned. status messages are displayed. When the analysis is com-
plete. the pycnometer beeps three times. Remove the sampie from the cell chamber.
11. The Reload prompt is displayed. Press tooolOEI to cycle through the error messages and
repon data.
CHANGING THE OPERATING LANGUAGE -------------
1. If an automatie operation is in progress. wait until it is complete.
2. Press
LI _---'lljjwill to return to display mode if you are in another mode of operation.
3. Press L.I _-,ll lm ä :;n I.
4. Press ICHOlCEI until Unit type? is displayed.
5. Press
I mll~1 until Language? is displayed.
6.
Press I ~I until the desired language is displayed. Then press 1 : ~AYl!) I.
P art No. 133-429()3.()()

ACCUPYC 1330
Kurzbedienungsanleitung
'---- Iffif micromeritics ~

Benutzung derTastatur
Um die Standard-Belegung zu
erhalten, drücken Sie die Taste
mit dem entsprechenden
Symbol-Aufdruck.
Zum Beispiel: Drücken Sie
D:::J ,um die Zahl ,,6"
einzugeben.
Standard-Belegung
Taste
I ENTERI
(Eingabe)
ICHOiCIj
(Auswahl)
ICLEARI
(Löschen)
ISAYE I
(Sichern)
Wirkung
Um die zweite Tasten-Belegung
zu aktivieren, die über der
jeweiligen Taste angegeben ist,
drücken Sie die weiße Taste und
anschließend die gewünschte
Funktionstaste.
Zum Beispiel: Drücken Sie
c==J D:::J ,um ein Meßproto-
koll ausdrucken
zu lassen.
Eingabe derZiffern 0 - 9.
Dezimal-Punkt oder Bindestrich bei der
Eingabe der Probenbezeichnung.
Beenden
der Eingabe oderStarten einer
Messung.
Auswahl der nächsten Meldung im Anzeige-
Modus, Anzeigen der nächsten Auswahlmög-
lichkeit
im Programmier-Modus.
Löschen einer Meldung
im Anzeige-Modus
oder einer Eingabe im Programmier-Modus.
Sichern der eingegebenen Angaben und
Rückkehr in den Anzeige-Modus.
Wechsel derTastatur-Belegung zwischen
Standard- und Kombinationsbelegung. Die
Tastatur kann in einem der beiden Modi
betrieben werden.
Nach dem Drücken der weißen Taste erscheint
ein Plus-Zeichen ("
+") in der oberen rechten
Ecke der LCD-Anzeige und die überden
Tasten angebrachte Belegung wird wirksam.
Durch erneutes Drücken der weißen Taste wird
das Plus-Zeichen gelöscht und die Standard-
belegung wird wirksam.

Tasten-Kombinationen
Funktion Tasten
NULL.abgleich c:::J c::I:J
CAL.ibrieren
MANUELL
SETUP
(Voreinstellungen)
SENDEN
c:::J o::J
ESCAPE c:::J ICLEARI
(Verlassen)
ANALYS.ieren
c:::J ~
EDIT c:::J c::::I=:J
(Verändern)
DRUCKEN c:::J c::::I=:J
Wirkung
Nullabgleich des Druckaufnehmers.
Starten des Kalibrationsprogramms.
Manuelle Bedienung der drei Ventile. Nach dem
Drücken dieser Tastenkombination können die
drei Tasten
der ersten Reihe benutzt
werden
(s. unten).
Anzeigen oder Ändern
der voreingestellten
Analysenbedingungen,
der Protokoll-Optionen,
der Kalibrations-Volumina,
der verwendeten
Druckeinheit oder
der Bedienungs-Sprache.
Übertragen von Analysen- oder Kalibrations-
Daten über die serielle Schnittstelle. Wenn eine
automatische Messung läuft, wird ein Teilbericht
gesendet, ohne die Messung zu unterbrechen.
Löschenallereingegebenen Daten in
der g\lrade
gewählten Funktion und Rückkehr in den An-
zeige-Modus (Gegenteil von
ENTER). Wenn
eine automatische Messung läuft, wird sie
abgebrochen.
Beginn einer automatischen Messung.
Editieren einer beendeten Messung oder
der
Kalibrationsdaten.
Drucken eines Analysen- oder Kalibrations-
Protokolls über die parallele Schnittstelle.
Wenn eine automatische Messung läuft, wird
ein Teilbericht gedruckt, ohne die Analyse
zu
unterbrechen.
Tasten der oberen Reihe (Orange-farbene Beschriftung):
Aktiv, wenn die manuelle Betriebsart eingestellt ist
(c:::J MANUELL):
FÜLLEN
o::J
EXPAND.ieren CCJ
BELÜFTEN CCJ
Öffnen und Schließen des Füll-Ventils.
Öffnen und Schließen des Expansions-Ventils.
Öffnen und Schließen des Belüftungs-Ventils.
Die Leuchtdiode über derjeweiligen Taste leuchtet auf, wenn das betreffende
Ventil geöffnet ist und erlischt nach dem Schließen.

Durchführen einer Analyse
1. Wiegen Sie den leeren, sauberen Probenbecher.
2. Füllen Sie die Probe in den Becher und trocknen Sie sie gründlich.
3. Die vorbereitete, abgekühlte Probe wird mit dem Probenbecher erneut
gewogen. Die Differenz zwischen diesem Gewicht und dem leeren Becher
ergibt die Einwaage (nur für Dichtebestimmung erforderlich).
4. Öffnen Sie die Probenkammer.
5. Setzen Sie den Probenbecher ein und verschließen Sie die Probenkammer.
6. Drücken Sie die Tastenkombination für ANALYS.ieren (c::::::J ~)
7. Wenn die Probenbezeichnung erfragt wird, geben Sie sie über die Tastatur
ein und drücken !
ENTER!. Wenn nicht, weiter bei Punkt 8.
8.
Wenn das Probengewicht erfragt wird, geben Sie es über die Tastatur ein
und drücken !ENTERI Wenn nicht, weiter bei Punkt
g.
g.
Drücken Sie ! ENTER! zum Starten der Analyse. Mit ESCAPE (c::::::J ! CLEAR!)
kann abgebrochen werden.
10. Während der Analyse werden auf der LCD-Anzeige Statusmeldungen
angezeigt. Das Ende der Messung wird durch drei helle Töne signalisiert.
Entfernen Sie die Probe aus der Probenkammer.
11. Die Meldung "NEULADEN" wird angezeigt. Drücken Sie mehrmals
!CHOIC!l (Auswahl), um eventuell vorhandene Fehlermeldungen sowie die
Meßdaten auf der LCD-Anzeige anzuzeigen.
Ändern der Bedienungssprache (Englisch -+ Deutsch)
1. Warten Sie das Ende einer laufenden automatischen Messung ab.
2. Stellen Sie mit ESCAPE (c::::::J ! CLEAR!) den Anzeige-Modus ein.
3. Drücken Sie SET UP (c::::::J c::I::l).
4. Drücken Sie CHOICE, bis die Anzeige "Unit Type" erscheint.
5. Drücken Sie ENTER, bis "Language?" erscheint.
6. Drücken Sie CHOICE, bis die gewünschte Sprache angezeigt wird.
7. Drücken Sie SAVE; die LCD-Anzeige zeigt die Aufforderung "Neuladen" an.

lffif' micromeritics@
AccuPyc 1330 Pycnometer
Operator's Manual
Part Number: 133-42801-01
22 August 1990

WARRANTY
MICROMERITICS INSTRUMENT CORPORATION warrants for one year from the date of shipment each instru-
ment manufactured by it to be free from defects in material and workmanship impairing its usefu1ness under normal
use and service conditions except as note<! herein.
Ourliability under this warranty is limite<! to repair, servicingand adjUSbnent, free of chargeat our plant, of any instru-
ment or defective parts, when returned prepaid to us, andwbich ourexamination discloses to have been defective. The
purchaser is responsible for a11 transportation charges involving the sbipment of materials for warranty repairs. Failure
of any instrument or product due to operator error, improper installation, unauthorized repair or alteration, failure of
utilities, or environmental contamination will not constitute a warranty claim. The Materials ofconstruction used in
MICROMERITICS instruments and o!her products were chosen after extensive testing and experience for !heir
reliability and durability. However, these materialscannotbe totally guaranteed against wear and/ordecomposition by
chemical action (corrosion) as a result of normal use.
Repair parts are warrante<! to be free from defects in material and workmansbip for 90 days from the date of shipmenL
No inslrument or product shall be returned to MICROMERITICS prior to notification ofalleged defect and authoriza-
tion to return the inslrument or product. All repairs or replacements are made subject to factory inspection of returned
parts.
MICROMERITICS shall be released from all obligations under its warranty in the event repairs or modifications are
made by persons other than its own authorized service personnel unless such work is authorized in writing by
MICROMERITICS.
The obligations of this warranty will be limite<! under the following conditions:
1. Certain productssold by MICROMERITICS are the products ofreputable manufacturers, soldunder!heirrespec-
tive brand narnes or Irade narnes. We, therefore, make no express or irnplied warranty as to such products. We
shall use our best efforts to obtain from the manufacturer, in accordance with his customary practice, the repair
or replacement of such of bis products that may prove defective in workmanship or materials. Service charges
made by such manufacturer are the responsibilityoftheultimatepurchaser. This statesourentireliability inrespect
to such products, except as an authorized person of MICROMERITICS may otherwise agree to in writing.
2. If an instrument or product is found defective during the warranty period, replacemenl parts may, al the discre-
tion of MICROMERITICS, be sent to be instalied by the purchaser, e.g., printe<! circuit boards, check valves,
seals, etc.
3. Expendable items, e.g., sarnple tubes, detectorsource lamps, indicatorlamps, fuses, valveplugs (rotor) and stems,
seals
and O-rings, ferrules, etc., are excluded from this warranty except for manufacturing defects. Such items
which perforrn satisfactorily during the first 45days after thedate ofshipment are assumed to be free of manufac-
turing defects.
Purchaser agrees to hold MICROMERITICS harmless from any patent infringement action brought against
MICROMERITICS if, at the request of the purchaser, MICROMERITICS modifies a standard product or manufac-
tures a special product to the purchaser'sspecifications.
MICROMERITICS shall not be liable for consequential or other type damages resulting from the use of any of its
products other than the liability state<! above. This warranty is in lieu of allotherwarranties, express orirnplied, includ-
ing, but not limite<! to the implied warranties ofmerchantability or fitness for use.
One Micromeritics Drive •
Domestic Sales - (404) 662·3633
International Sales - (404) 662·3660
Norcross, GA 30093-1877 • Telex: 682-7018
Domestic Repair Service - [phone]
Customer Service -
[phone]
Form No. ~l04-OO
280d 1988

AccuPyc 1330
TABLE OF CONTENTS
Table of Contents
1. GENERAL DESCRIPTION
Organization of the Manual ..................................... 1-1
Equipment Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Pycnometer Keypad ......................................... 1-4
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
2. INSTALLATION
Unpacking and lnspection ...................................... 2-1
Equipment Damage or Loss During Shipment . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Equipment Return ....................................... 2-1
Selecting the Location ........................................ 2-2
Gas Requi,rements .......................................... 2-2
Equipment Setup
........................................... 2-3
Selecting the Input Power ................................... 2-3
Rear Panel Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Turning on the Pycnometer ................................... 2-10
Entering Analysis and Report Parameters ..........•.......... . ..... 2-11
Selecting Units ofPressure Measurement and Operating Language .............. 2-12
Greasing the ChamberCap O-ring ............................... 2-13
Verifying Operation .......................................... 2-14
3. PERFORMING AN ANALYSIS
Setting Regulator Pressure .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Preparing and Loading a Sampie ................................... 3-2
Starting the Analysis ......................................... 3-4
U sing the Default Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Using Modified Analysis Parameters .............................. 3-4
Viewing orPrinting Analysis Results ................................ 3-5
4. GENERAL OPERATING INSTRUCTIONS
Monitoring the System ................... . . . . . . . . . . . . . . . . . . . . . 4-1
Status Messages Displayed During an Automatie Operation . . . . . . . . . . . . . . . . . . 4-1
Error and Report Messages .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
15 Dec 89

TABLE OF CONTENTS
AccuPyc 1330
Canceling an Automatie Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-4 a
Entering Commands ........................................ .4-5 ' ..
Perfonning an Analysis ........................... . ........ .4-6
Reviewing
and Editing Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-7
Reviewing
and Editing Analysis Results and Parameters ..... . . . . . . . . . . . .4-7
Reviewing
and Editing Calibration Results and Parameters ...............4-8
Printing Repons ........................................ .4-9
Transmitting Repons
..................................... .4-13
Calibrating tbe Pyenometer
.................................. .4-14
Zeroing tbe Pressure Transdueer
............................... .4-15
Manually Controlling tbe
Valves ............................... .4-16
Editing tbe Set-Up Parameters
................................ .4-17
Analysis or Calibration Parameters
........................... .4-18
Report Options
.......................................4-21
Calibration Volumes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-23
Data Transmission
.....................................4-24
Unit Types and Operating Language . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-25
5. TROUBLESHOOTING AND MAINTENANCE
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Error and Status Messages ......................................5-4
Queued Messages ........................................5-4
Messages Displayed During an Automatie Operation ..................... 5-10
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-12
Greasing tbe Chamber Cap O-ring
...............................5-12
Replaeing tbe Chamber Cap O-ring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-13
Cheeking tbe Cell
and Expansion Chambers for Leaks . . . . . . . . . . . . . . . . . . . . .5-15
Cleaning tbe Pyenometer
....................................5-17
Recovering from aPower Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-17
Replaeing Fuses
.........................................5-17
6. ORDERING INFORMATION
APPENDICES
Appendix A: Changing tbe Analysis Module
Appendix
B: Analysis Theory
Appendix
C: CalibrationTheory
Appendix
D: Format ofTransmitted Data
ii 15 Dec 89

CHAPTER 1
GENERAL DESCRIPTION
• Organization of the Manual
• Equipment Description
• Pycnometer Keypad
• Specifications

AccuPyc 1330 GENERAL
DESCRIPTION
GENERAL DESCRIPTION
ORGANIZATION OF THE MANUAL
This manual describes how 10 iosta1l, operate, and maintain the AccuPyc 1330 Pycnometer. The
manual is divided into six chapters.
Chapter 1
Chapter 2
Chapter 3
Chapter 4
Chapter 5
Chapter 6
Provides a general description and specifications
of the pycnometer.
Provides unpacking and iospection information, and iosta1lation iostructioos.
Provides iostructioos for performing an analysis.
Provides detailed operating iostructioos.
Provides troub1eshooting and maintenance procedures and error messages.
Provides information on ordering parts and accessories for the pycnometer.
Several appendices are also
inc1uded.
EQUIPMENT DESCRIPTION
The AccuPyc 1330 Pycnometer is an easy-to-use, fully-automatic gas displacement pycnometer.
Analyses are initiated with a keystroke. Once an analysis is initiated, data are collected, calcula-
tions performed, and results displayed without further operator intervention. The pycnometer may
be operated in any
of four languages: English, German, Spanish, or French. The language used
may be changed by a simple keystroke sequence.
The AccuPyc 1330 Pycnometer's unique run precision feature increases the precision
of analysis
results by reporting data from five consecutive runs that are within a user-specified tolerance.
This feature allows early termination
of analyses, thereby decreasing the number of runs needed
for accurate results.
The AccuPyc 1330 Pycnometer, shown in the following illustration. contaios a keypad, a display
area, and an analysis chamber (referred to
as the cell chamber). The pycnometer is controlled by
commands entered through the keypad. The operational status
of the pycnometer can be continu-
ally monitored on the display. The optional printer prints out complete analysis and calibration
re-
sults. In addition. aserial port is provided for data transmission 10 other devices.
15 Dec 89
1-1

GENERALDESCRIPTION AccuPyc 1330
Cell Chamber Cap
Display Area
Keypad
Figure 1-1. AccuPyc 1330 Pycnometer
The AccuPyc 1330 Pycnometer determines density and volwne by measuring the pressure change
of heliwn in a calibrated volwne. The schematic diagram. which is included above the keypad.
indicates system status. The three indicators show the current state
of the fill. expansion, and
vent valves. The indicator is lit when a valve is open.
1-2
Gell Chamber
Expansion Chamber
Fill Valve
Indicator
1 /
Expansion
Valve Indicator
Vent Valve
Indicator
Figure 1-2. Schematic Diagram
15 Dec 89

AccuPyc 1330
GENERAL DESCRIPTION
In addition to analysis, there are two other automatie operations performed by the pyenometer:
calibration and transducer zero reset.
Analysis measures sampIe volume, from which density ean be derived automatically
if sampIe
weight has been entered. The unit comes pre-programmed with default conditions and ready to
perform analyses. It ean be easily reprogrammed to meet your speeifie needs. You ean modify
your own analyses by entering the following parameters: number
of purges, purge fill pressure,
number
of runs, run fill pressure, equilibration rate, and run precision. The run precision option
allows early termination
of the analysis if the last five runs are all within a user-specified toler-
anee. By modifying these parameters, you retain control over the two main sections
of the analy-
sis: purge and run.
A purge is used strietly for sampIe clean up and air and moisture removal from the ehamber's in-
side. It is aecomplished by c10sing off the pyenometer bloek and filling the cell chamber to the
designated purge
fill pressure. The ehambers are then vented to atmosphere, resulting in elimina-
tion
of water vapor or other contaminants. A run is used for eollecting the preeise, accurate data
used in repon caleulations.
Calibration
is used to determine the size of the eell and expansion chambers within the instru-
ment. After ealibration, the cell and expansion ehamber volumes are automatically stored
in the
set-up parameters.
The zero funetion is used
to caleulate a new zero pressure offset. It is measured when the system
is at atmospherie pressure and thermal equilibrium and is subtraeted from all subsequent pressure
readings in order
to obtain a true gauge pressure.
22 Aug 90 1-3

GENERAL DESCRIPTION AccuPyc 1330
PYCNOMETER KEYPAD
FlLL EXPAND VENT o
ANALVZE REVIEW PRINT
MANUAL SETUP TRANSMIT ESCAPE
ZERO CALIBRATE
Figure 1-3. Pycnometer Keypad
Most keys on the keypad perfonn one primary and one alternate funetion. The primary funetion
of any key is indieated by the number or command on the face of the key. The alternate funetion
is indieated by the command above the key.
To se1eet the alternate funetion printed above the key,
PRINT -- lfirst Pi~.I............. I, ~en press the key. For examp1e: press
L .. . ..... 6 ........ .J to poot. Refer to Tab1e 1-2.
I ___ To seleet the primary funetion on the face of the key,
.. .......... press only that key. For examp1e: press niilllIl to enter
the number
6. Refer to Tab1e 1-1.
1-4
15 Dec 89

ACcuPyc 1330
GENERAL DESCRIPTION
Tables I-I and 1-2 describe how the keys are used to control and monitor the pycnometer.
lellöl~1
15 Dec 89
Table 1-1. Standard Keys
Enter the numbers 0 through 9.
Enter a decimal point or a dash for sampie ID.
Complete an entry
or begin an action.
Display the next message when in display mode. Display the next
multiple choice item when
in a command mode.
Clear a message when
in display mode. Clear an entry when in a
command mode.
Save the information you entered and return to display mode.
Change the keypad mode. The keypad may be used in either pri-
mary function mode or alternate function mode.
When you press the white key to enter alternate function mode, a
plus sign (+) appears
in the upper right corner of the displayand
the commands written above the keys become available.
To exit alternate function mode, press the white key again. The
plus sign (+) will be removed from the display.
1-5

GENERAL DESCRIPTION
ZERO
CALffiRATE
MANUAL
SEfUP
TRANSMIT
ESCAPE
ANALYZE
REVIEW
PRINT
FILL
EXPAND
VENT
1-6
AccuPyc 1330
Tabte 1-2. Key Combinations
)7:il (when in
manual
mode)
I ;)'III\tl (when in
manual
mode)
lJ :1 (when in
manual
mode)
Zero the pressure transducer.
Calibrate the pyenometer.
Manually contral the valves. After pressing the
Manual key, you may use the PUL, EXPAND,
and VENT eommands to open and elose the
valves.
Display
or edit analysis parameters, repon
.options, ealibration volumes, data transmission
parameters, unit types, and operating language.
Transmit analysis
or ealibration data over the
serial line.
If an automatie operation is in prog-
ress, transmit a partial repon.
Delete
a1l data entered in the eurrent mode and
return to display mode. If an automatie opera-
tion is in progress, eancel the operation.
Perform an analysis.
Review or edit completed analysis or ealibration
data.
Print analysis or ealibration report
If an auto-
matie operation is in progress, print a partial
report
Open and elose the fill valve. The indicator
above the FILL key is on when the valve
is
open and off when the valve is elosed.
Open and elose the expansion valve. The indica-
tor above the EXPAND key is on when the
valve
is open and off when the valve is elosed.
Open and elose the vent valve. The indicator
above the VENT key
is on when the valve is
open
and off when the valve is elosed.
15 Dec 89 •

ÄCCUPyc 1330
GENERAL DESCRIPTION
SPECIFICATIONS
Tab1e 1-3. AccuPyc 1330 Pycnometer Speci(lCations
Temperature Stable between 15 and 35 °C (59 to 96 0F)
Humidity 20 to 80% relative, non-eondensing
Vo1tage 100/120 or 220/240 VAC ±1O%
Current 0.5A (100/120 VAC); 0.25A (220/240 VAC)
Frequeney 50/60 Hz
Sample Volume 0.5 -100 mL
Standard Sample Holder 19 mm OD x 39.8 mm long x 0.254 mm wall (0.750 in. OD x
1.570 in. long
±O.OO5 in. x omo in. wall) for standard (10 mL)
holder
Optional Sample Modules Provide ranges
of 1 to 100 mL
Precision
Aeeuraey
Cabinet
Gases
Reprodueibility typieally to within ±O.OI % of the nominal full-
seale ce11 ehamber volume.* Reproducibility guaranteed to within
±O.02% of the nominal full-seale volume on clean, dry, thermally
equilibrated samples.
Aeeurate to within 0.03%
of reading plus 0.03% of nominal full-
seale ce11 ehamber volume.*
311 mm W x 173 mm H x 357 mm D
(12
in. W x 7 in. H x 14 in. D)
.Research grade helium is recommended. If unavailable, use helium
with a dewpoint
of -67 °C (-88 0F) or lower.
*Nominal full-seale ee11 ehamber volume is the samp1e eapaeity..
15 Dec 89 1-7
