Inspired by drive APP-1000XS User manual

WARNING!
Read ALL instructions before using this product!
P Pod Postural Support System
APP-1000XS
APP-2000S
APP-3000M
APP-4000L
APP-5000XL

IMPORTANT SAFETY RULES
• Determine, with a physician or therapist, the suitability of this product for the
intended user.
• Make sure the Seat Cover is securely fastened to the Positioning Pod
before each use.
• Make sure the pelvic strap is secured around the user when in use.
• NEVER leave the P Pod close to any open ame (i.e. open gas re).
• NEVER remove the foam beads from its sealed bag.
• NEVER leave user unattended in the P Pod.
• Make sure the Mobility Base are secured in place when using the P Pod with
the Mobility Base.
• SAVE THESE INSTRUCTIONS.
• Fire retardant materials have been used in the construction of this seating
system.
• It is important that no accelerants are introduced to the materials (e.g. Hairs
pray, fabric cleaners, deodorants, polish etc..), as this may adversely affect
the re retardancy of your equipment.
Thank you for choosing Columbia Medical.
FIRE RETARDANCY
2
IMPORTANT SAFETY RULES

INTRODUCTION
• The P Pod provides overall postural support by distributing the user’s weight
evenly over a large support surface.
• It is recommended that the amount of time a user sits in the P Pod is
controlled, this should not exceed more than 3 hours at a time.
• Removing the user from the P Pod is advised after such a period to offer
a change of posture. By doing this you will improve the user’s tolerance to
sitting in the P Pod on a daily basis.
Seat Cover
Flip-over Headrest
Positioning Pod
Pelvic Belt
Bolster Support
Bean Bag Base
P POD PARTS
3
INTRODUCTION

1. Remove all of the P Pod parts from
the packaging and separate the
parts from each other if necessary.
2. Give the Bean Bag Base and the
Bolster Support a good shake to
agitate the beads inside.
3. Attach the Bolster Support to the
Bean Bag Base by aligning the
hook and loop straps and press
down (Fig 1).
4. Place the Positioning Pod on the
Bolster and Bean Bag. Secure all
of the hook and loop straps on
Positioning Pod to the Bean Bag
Base (Fig 2).
5. Adjust the P Pod so that it is in a
reclined position (Fig. 3A) prior to
placing the user into the Pod.
Figure 1
Figure 2
Figure 3BFigure 3A
4
ASSEMBLY OF THE P POD

It is recommended that users over 44 lb be hoisted/lifted into the P Pod.
Manually lifting the user is not recommended.
Follow the hoist/lift manufacturer’s instructions.
All P Pods are equipped with a Flip-over Headrest and a Padded Pelvic Belt.
Before placing the user in the P Pod, make sure both the Headrest and Pelvic
Belt are not buried underneath the Positioning Pod as it will be difcult to retrieve
them once the user is seated in the seat.
1. Adjust the P Pod so that it is in a
reclined position (Fig. 3A) prior to
placing the user into the Pod.
2. Hook both sides of the Pelvic Belt
into the side loops on the seat
cover (Fig 4).
3. Lower the user into the P Pod.
Make sure that the hips / pelvis of
the user are positioned as far back
as possible into the Positioning
Pod.
4. Secure the Pelvic Belt around the
user (Fig 5) and adjust the strap
length as necessary.
Note: it may be necessary to
remove the Positioning Pod from
the Bean Bag Base to adjust the
length of the belt straps from the
rear if the straps are too long in the front.
5. Adjustments to the position of the Positioning Pod on the Bean Bag can be
done by simply holding the pod and move it into different position.
Note: When using the hoist or lift, make sure that you follow the device
manufacturing’s instructions regarding the proper use.
Figure 5
Figure 4
5
POSITIONING THE USER

FLIP-OVER HEADREST
1. The headrest height can be adjusted by
shortening or lengthening the straps above the
headrest (Fig. 6).
MOBILITY BASE
Notes:
• It is essential that the user is removed
from the P Pod before installing and
removing the pod from the base.
• The Mobility Base is for indoor use only.
• The Mobility Base should NEVER be
used for transporting the user in a
moving vehicle.
• Make sure the brake is engaged when
the Mobility Base is stationary.
• Some of the beads may need to be
removed from the Bean Bag Base in
order for it to t inside the Mobility Base.
• NEVER LEAVE THE USER UNATTENDED
IN THE MOBILITY BASE.
1. Before placing the P Pod onto the base make
sure that the foot brake is engaged (Fig. 7).
2. Place the P Pod onto the base.
3. Pull the two rear straps on the Bean Bag Base
and wrap them over the back of the Mobility
Base and attach back on the Bean Bag (Fig. 8).
4. To position the push handle, release the two
locking latches (Fig. 9) then rotate the handle
into position and re-tighten both locking
latches.
5. The user can now be positioned in the P Pod
(see Positioning the User section).
6. Release the rear brake before moving the base.
Figure 6
Figure 7
Figure 8
Figure 9
6
ACCESSORIES

FREESTANDING TRAY
1. Insert the two legs of the top frame into the
base frame (Fig. 10) and loosely tighten the
knobs on both sides.
2. If the tray is folded down, release the
adjustment handles (Fig. 11) and adjust the
angle of the tray.
3. Once the user is positioned in the P Pod,
place the tray in front and adjust the height
and angle of the tray accordingly.
LAP TRAY
1. With the user properly positioned in the P
Pod, place the tray with the bean bag side
down on the user’s lap (Fig. 12).
2. Lift up the two rear straps from the P Pod
cover. Attach the lap tray straps on the
Bean Bag Base then re-attach the cover
straps on top of the Lap Tray straps (Fig.
13).
Figure 12
Figure 13
Figure 10
Figure 11
7
ACCESSORIES

FOOT BOLSTER
1. Remove the Positioning Pod and
Bolster from the Bean Bag Base.
2. Lap the two straps of the Foot Bolster
on top of the Bean Bag (Fig 14). Attach
the hook and loop of the straps to the
rear of Bean Bag (Fig. 15).
3. Place the Bolster and Positioning Pod
back on the P Pod. Buckle the Foot
Bolster to the straps making sure the
at side of the Foot Bolster is facing up
(Fig. 16).
4. Adjust the height of the Foot Bolster by
lengthening or shorten the straps (Fig.
17).
Figure 14
Figure 15
Figure 16 Figure 17
8
ACCESSORIES

ACTIVITY FRAME
1. Place the base frame on the oor
with the feet facing down and the two
T-bars in the upright position (Fig. 18).
2. Slide the top frame into the T bars
and loosely tighten the locking knobs
(Fig. 19).
3. Position the Activity Frame over the P
Pod (Fig. 20).
4. Adjust the height of the frame and
tighten the knobs.
5. The position of the hooks on the
Activity Frame can be adjusted
by unscrewing the hook (Fig. 21)
and move the black stopper along
the frame until desired position is
achieved, then re-tighten the hook.
Figure 18
Figure 19
Figure 20 Figure 21
9
ACCESSORIES

• Do not use bleach.
• Do not iron.
• It is recommended that P Pod covers NOT be washed with other items.
Seat Cover
1. Remove the Positioning Pod from the Bean
Bag and Bolster. Unbuckle the Pelvic Belt
from the back and push the straps through
the slots (Fig 22). Remove the cover from the
Positioning Pod.
2. Fold back all of the seat straps (Fig. 23) to
prevent the hook parts from damaging the
cover during cleaning.
3. Unzip the Flip-over Headrest cover and
remove the inner foam (Fig. 24). DO NOT
try to wash the inner foam as it is sealed
in a special membrane and it CANNOT be
removed under any circumstances. Simply
wipe the foam with damp cloth.
4. Follow the washing instruction label on the
inside of the Seat Cover.
5. After cleaning, install the Seat Cover back
on the Positioning Pod. Make sure that the
washing labels are positioned at the top of the
seat (Fig. 25).
Bolster Support and Bean Bag Covers
6. Unzip the outer covers of the Bolster Support
and Bean Bag and remove the inner bags that
contain beads. DO NOT attempt to unzip the
inner bags.
7. Follow the washing instruction label.
Positioning Pod
8. Wipe the Positioning Pod with mild detergents.
9. Air dry the Positioning Pod. DO NOT use
excessive heat to dry the Positioning Pod
as the shape of the seat can be damaged or
deformed by the heat.
Figure 23
Figure 24
Figure 25
Figure 22
10
CLEANING

• Once a week remove the Pod & Bolster from the Bean Bag and give the bag
a good shake to agitate the beads contained inside to maintain their volume
and shape.
• Periodically check for wear & tear on the covers and that the bag containing
the balls is not split or damaged allowing them to spill out (see safety notes
above).
• Pay particular attention to the Positioning Pod to make sure this is still in good
condition.
11
MAINTENANCE

WARRANTY
Inspired by Drive warrants this product to be free of defects in material
and workmanship. Our obligation under this warranty is limited to
repair or replacement of any part or entire unit at our option for a
period of one year from date of delivery to the original purchaser. The
warranty does not include cost of inconvenience, property damage,
misuse, abuse, crash or similar incidents. The warranty will not
apply if product has been tampered with or repaired by unauthorized
individuals.
C0000-10-62 (Rev B) 04/2017
