INSTYLE Ecoustic Intersect Landscape Assembly instructions

Ecoustic®Intersect
Installation + Care

INSTYLE.COM.AU
Components - Landscape
SUPPLIED IN EACH BOX
INTERSECT PANEL - 5 EDGES
Available in 6 colourways. 1 per box (Box 3).
POSTS
Black nish. 2 per box (Box 2).
INTERSECT PANEL - 4 EDGES
Available in 6 Colourways. 1 per box (Box 3).
BASE
Black nish. 1 per box (Box 1).
SHORT SCREWS
For securing base to posts. 8 per box (Box 2).
X 8 X 20
LONG SCREWS
For securing Intersect panels to posts. 20 per box (Box 2).

INSTYLE.COM.AU
Components - Portrait
SUPPLIED IN EACH BOX
INTERSECT PANEL - 5 EDGES
Available in 6 colourways. 1 per box (Box 3).
POSTS
Black nish. 2 per box (Box 2).
INTERSECT PANEL - 4 EDGES
Available in 6 colourways. 1 per box (Box 3).
BASE
Black nish. 1 per box (Box 1).
SHORT SCREWS
For securing base to posts. 8 per box (Box 2).
X 8 X 20
LONG SCREWS
For securing Intersect panels to posts. 20 per box (Box 2).

INSTYLE.COM.AU
ASSEMBLY INSTRUCTIONS
Step 1
Carefully slide both Intersect posts through
the Intersect base, avoiding contact between
the posts and the base until the post feet
come into contact with the base
Step 2
Fasten each of the 8 short base screws
supplied through the post feet into the
Intersect base
Step 3
Remove Intersect panels from protective
surrounds
Step 4
Position the Intersect 5-edged panel between
the Intersect posts with short edge of the panel
aligned horizontally onto the base
Intersect posts
Intersect base
Felt disc pad
Post feet
8 short (base) screws
Intersect panel
Protective surrounds
10 long (panel) screws
5 edged panel
Step 5
Align panel holes with post threads and
lightly fasten 10 of the 20 long (panel)
screws supplied into the posts through the
5-edged panel
Ecoustic®Intersect Installation

INSTYLE.COM.AU
ASSEMBLY INSTRUCTIONS
Step 6
Lower the 4-edged Intersect panel over the
installed panel ensuring the slots of each
panel intersect.
Step 7
Align holes of the 4-edged panel with post
threads and lightly fasten remaining 10
long (panel) screws supplied into the posts
through the 4-edged panel.
Step 8
Check both Intersect panels are resting on
the face of each post, then nally check
tighten all 20 of the long (panel) screws.
Your Intersect Partition is now complete!
Important: Please handle Intersect Partitions
by holding onto the posts rather than the
panels.
4-edged Intersect
panel
10 remaining long
(panel) screws
Ecoustic®Intersect Installation

INSTYLE.COM.AU
Ecoustic®Intersect Care
Please Note
• Consideration must be given to any possible effect of the cleaning regime on the underlying glue or backing board. It is recommended
that spot cleaning only is used and that it is carried out by a professional cleaner.
Regular Care
• Protect from direct heat and sunlight.
• To prevent dust build up, lightly dust with a soft cloth or vacuum with a soft brush attachment.
Spot Cleaning
• Professional cleaning is always recommended.
• Always test any cleaning products on an inconspicuous area prior to commencing cleaning.
• Blot any excess spills from the material with a dry clean sponge or cloth.
• Treat all stains and spills as soon as possible.
• Most marks can be spot cleaned by lightly wetting the affected area with a mild detergent and warm water solution.
• Do not saturate the panel, screen or felt.
• Do not scrub or abrade the product as this will affect the surface nish.
• Once the stain or mark has been loosened then blot the excess solution out with a dry clean cloth.
• Sponge afterwards with clean warm water and mop any excess moisture with a dry clean sponge or cloth.
• The product can also be spot cleaned with dry cleaning uid. Lightly sponge a small amount of dry cleaning uid and blot.
• Dry away from direct heat and sunlight.
• Avoid the use carpet shampoos.
