intatec IntaKlean Nano IKN34 Release note

In this procedure document we have endeavoured to make the
information as accurate as possible.
We cannot accept any responsibility should it be found that in
any respect the information is inaccurate or incomplete or
becomes so as a result of further developments or otherwise.
Intatec Ltd
Airfield Industrial Estate
Hixon
Staffordshire
ST18 0PF
Tel: [phone]
Fax: [phone]
email: [email protected]
web: www.intatec.co.uk
© Intatec Ltd 2021
IntaKlean Nano
IKN34
Installation & Servicing Instructions

© Intatec Ltd 2021 1
LOCATION
The IntaKlean Nano is a magnetic system filter designed to remove ferrous and non
ferrous material from fluid systems.
IKN34 has been specifically designed to be installed directly underneath the relevant
heat source such as boilers, heaters and Heat Interface Units.
For maximum system component protection we advise that the IntaKlean Nano is
installed onto the return leg of the circuit, between the last radiator and the boiler.
Return
Return
Combi/Sealed System
with through wall supply
Open Vented System
Header Tank
Vent
Pipe
ü
ü
ü
Return
Combi/Sealed System

© Intatec Ltd 2021 2
LOCATION
The IntaKean Nano can be configured to suit site conditions with the position of the
ball valve, connector and drain utilising any of the 3 connections on the filter pot.
Ensure that the system is drained down and all system pressure has been released.
On open vented systems, make sure that the feed and expansion tank is isolated.
When siting the IntaKlean Nano magnetic system filter, great care should be taken to
place the filter so that access for the removable magnetic probe and drain plug is
available. Doing this will aid the servicing of the filter and any chemical dosing in the
future.
COMPONENTS
12
3
4
5
6
5
7
8
Item Qty Component
1 1 Filter pot
2 1 Transparent cap
3 1 Filter cartridge
4 1 Magnet
5 3 Sealing washer
6 1 Drain cap and strap
7 1 Connector
8 1 Ball valve with union connection

© Intatec Ltd 2021 3
INSTALLATION
If an existing system, drain the heating system and locate the return pipe where the
IntaKlean Nano will be located.
If a new system locate the return pipe.
The whole system should be thoroughly flushed, prior to fitting the IntaKlean Nano, to
remove any debris that may be in the supply pipework.
Installation steps:
1. Assemble the isolating valve, connector and blanking
cap onto the filter body using the sealing washers
provided and tighten.
2. The IntaKlean Nano will connect directly to the
heating return on the boiler and the pipework can be
configured to suit one of the configurations shown
in the Location Diagram on page 2.
3. Offer the assembly up to the in place pipework
connections, tighten accordingly.
4. Fill the system with fluid with the isolating valve
closed.
5. Open the ball valves and allow the system to fill,
check all joints for leakage.
Connection
under boiler

© Intatec Ltd 2021 4
COMMISSIONING
The commissioning procedure should be carried out as follows;
1 Making sure that all open ends of the system are closed, begin to refill the system.
2 Bleed radiators as required.
3 Open any manual air vents installed in the system to release any trapped air.
N.B. – Air may continue to be present in system pipework for a small period as the
central heating is run after installation of the IntaKlean Nano. We recommend that you
check the radiators and air vents again to ensure that all air has been purged from the
system.
DIMENSIONS
G¾
29
40.5
40.5
Ø66
111.5
87
G¾

© Intatec Ltd 2021 5
CLEANING AND SERVICING
We recommend that the IntaKlean Nano is serviced once every twelve months or in
line with the servicing schedule of the boiler, or according to water conditions.
Prior to cleaning the IntaKlean Nano ensure that the working environment is safe.
Inta recommend that the boiler is turned off before commencing any maintenance
works. Caution should also be taken regarding the temperature of the contents of the
filter.
1. Isolate IntaKlean Nano from the
system by shutting the isolating ball
valve and other isolating valves to
the boiler.
2. Place a suitable container underneath
the filter and remove the drain cap.
3. Allow the filter contents to drain into
the container and replace the drain
cap.
4. Rotate the magnet to disengage it and
allow it to be withdrawn.
5. Using a suitably sized spanner on the
hexagon at the top of the transparent
cap unscrew it and remove the filter
cartridge.
6. Remove any residual debris from both
the filter pot and transparent cap using
a soft cloth or disposable paper towel
and rinse in clean water.
7. Rinse the filter cartridge in clean water
to remove any debris.
8. Re-assemble the filter and
re-commission as detailed in the
COMMISSIONING section of these
instructions. Ensure that
the SERVICE SCHEDULE is completed
each time the filter is serviced.
9. Replace the ‘O’ ring cap seals if damaged.
WARNING - EXCESSIVE TIGHTENING OF THE CAP TO THE FILTER POT MAY
IRREPARABLY DAMAGE THE FILTER.
Drain at
bottom
Loosening
transparent cap
Rotate and
withdraw
magnet

© Intatec Ltd 2021 6
CHEMICAL DOSING
To dose the system using the IntaKlean Nano, follow the below procedure;
1. The transparent cap must be in the horizonal position.
2. Ensure the working environment is safe and the boiler is turned off at the switch.
3. Isolate the IntaKlean Nano from the system by shutting other isolating valves to the
boiler with Nano ball valve open.
4. Place a suitable container underneath the filter and remove the drain cap.
5. Allow the filter contents to drain into a container.
6. Connect a hose connector with a hose to the drain connection and add the dosing
chemicals.
7. Allow the dosing chemical to flow into the main pipework system.
8. Repeat until the specified amount of chemicals have introduced in the system.
9. Re-commission the system as per the previous instructions in the
COMMISSIONING section.
10. Complete the SERVICE SCHEDULE below..
SERVICE SCHEDULE
Tick as appropriate
Service
Number Date Attending
engineer
Filter contents
drained
Filter
disassembled
and cleaned
Inhibitor
added
System
cleanser
added
1
2
3
4
5
6
7
8
9
10

© Intatec Ltd 2021
Intatec Ltd
Airfield Industrial Estate
Hixon
Staffordshire
ST18 0PF
Tel: [phone]
Fax: [phone]
email: [email protected]
web: www.intatec.co.uk
E & O.E
20-10-21
Please Leave this Manual for the User
To activate your product warranty please visit
www.intatec.co.uk
and click on Product Registration
TECHNICAL SUPPORT & WARRANTY
The IntaKlean Nano magnetic central heating system filter is covered by a two year
warranty against manufacturing fault.
To register your product for warranty, please visit www.intatec.co.uk.
For technical assistance, please contact our dedicated technical support line on
01889 272 199.
