Intek MX-8000U User manual

INSTRUCTION MANUAL
136-174 MHz VHF FM / 8CH / 5W-25W
PROFESSIONAL MOBILE RADIO
PC PROGRAMMABLE
MX-8000V
438-490 MHz UHF FM / 8CH / 5W-25W
PROFESSIONAL MOBILE RADIO
PC PROGRAMMABLE
MX-8000U

INSTRUCTION MANUAL
MX-8000V/MX-8000U
VHF / UHF PROFESSIONAL MOBILE RADIO
MANDATORY SAFETY INSTRUCTIONS TO
INSTALLERS AND USERS
Use Only manufacturer or dealer supplied antennas.
Antenna minimum safe distance: 108 cm.
Antennas used for this transmitter must not exceed
an antenna gain of 3 dBi.
Antenna mounting: The antenna supplied by the
manufacturer or radio dealer must not be mounted
at a location such that during radio transmission, any
person can come Closer than the above indicated
minimum safe distance to the antenna (i.e. 108cm).
16
Vehicle installation: The antenna can be mounted at
the center of a vehicle metal roof or trunk lid if the
minimum safe distance is observed.
Antenna substitution: Don't substitute any antenna
for the one supplied or recommended by the
manufacturer or radiodealer. You may be exposing
person(s) toexcessive radio frequency radiation.You
may contact your radio dealer or the manufacturer for
further instructions.
WARNING !
Maintain a separation distance from the antenna to
person(s) at least 108cm.

.
NOTICE !
It is recommended to carefully read this owne r ’s manual before using the
product. This will also help the user to prevent using the radio in violation of
the regulations valid in the country where the product is used, as well as to
avoid any possible inte rferences with others ervices.
NOTICE !
This transceiver has been factory pre - programmed, in order for the user to
test it right after purchase . It is th e user ' s responsibilit y t o re - progra m
th e radio , in accordanc e wit h the specifications for the fre quency channels
assigned by the local authorit y.
NOTICE !
This transceiver is programmable via PC, using the dedicated software and
the PC interface cabl e (optiona l items) . An y programmin g o r modificatio n o f
th e origina l defaul t settin g mus t be made by a specialised technician or by
an authorised service centre. Some functions of this transceive r migh t b e
programme d in violatio n o f th e technica l rule s in forc e fo r th e us e o f th e VHF
an d UH F F M bands . I t i s th e use r ’s responsibilit y t o chec k tha t an y
mod ificatio n t o the programming will be done in compliance with the
current regulations. Any modification to the product , alteratio n o f th e interna l
circuit , o f th e externa l structur e o f th e radi o o r an y programming in violatio n o f
th e curren t regulation s wil l automaticall y voi d th e produc t certificatio n an d you r
right to us e th e product . INTE K S.R.L . decline s an y responsibilit y concernin g
an y modificatio n o f the product , mad e b y th e use r o r b y a thir d part y, afte r deliver y
o f th e product.
CONTENTS
1. Package-opened Inspection and Installing................................. 2
2. Radio Overview......................................................................... 4
3. Basic Operation......................................................................... 6
4. Programmable Button Function................................................. 7
5. Radio call................................................................................... 8
6. Talk-around................................................................................ 9
7. Scan........................................................................................... 9
7.1 Start/End Scan Function........................................................... 9
7.2 Nuisance Delete........................................................................ 9
8. PublicAddress......................................................................... 10
9. Lone worker............................................................................. 10
10. EmergencyAlarm..................................................................... 10
11. Remote kill, stun, activate and revive..................................... 11
12. Wired Clone Mode....................................................................12
13. Trouble Shooting Guide.......................................................12-13
14. Major Specifications................................................................. 13
1

Accessories
Quantity
Fixed bracket
1
Power Cable
1
Hand Microphone
1
Microphone Hanger
1
M4*10 Combination Screw
4
M4*16 Self-tapping Screw
2
M5*16 Self-tapping Screw
4
Instr
uction Manual
1
Protective tube
2
1. Package-opened Inspection and Installing
Please check the host in the package and the supplied accessories in
the following table before using. Any articles are found lost or
damaged, please contact the distributor without delay.
1.1 Supplied Accessories
Microphone
Hanger
protective
tube M4x10
Combination
Screw
M5x16 / M4x16
Self-tapping
Screw
Power Cable Hand Microphone Fixed bracket
2 3
1.2 Preparation
1.2.1Connection of Power Cable
First of all, please check whether there is a hole for the power
cable on the insulating board. If no, please bore the board with
the suitable drill bit and fix a rubber grommet on it.
Afterwards, please have the cable pass through the insulating
board and lead from the car into the car engine. Connect the red
conductor to the positive terminal of the accumulator and the black
conductor to the negative terminal.
At last, ring the remained conductor and fix it.
Note: Please maintain the sufficient relaxation of the power
cable to make it convenient to dismantle the radio in the
state of power connection.
1.2.2Radio Installing
Warning: For passengers' safety, please fix the radio firmly
on the fixed bracket so that the radio will not be loosened in
case of collision.
The fixed bracket is taken as an example. Draw the position
and drill a hole on the instrument panel first, and then install
the fixed bracket with 4 M5*16 self-tapping screws. (Note:
please fix the radio at the position convenient for
operation and control, and leave an enough space for
fixation and connection of the cable.)
Slide the radio into the fixed bracket and fix it with 4 M4*10
combination screws (plus plain washer and spring
washer).
(Different combinations of fixing holes are selectable to
adjust the radio to the proper height and visual angle.)

Displa y
Descriptio n
SCAN indicator
Scan indication: on when scan is enabled .
LOW indicator
Power level indication: on when in low powe r.
Indicates the current channel in normal use,
ranging from 1~8.
Indicates the current squelch level when
squelch selection is enabled,ranging from
0.~9.
Displays " B " when Public Address is enabled.
Displays " - " when the radio has no channel.
Displays " U " when the radio is in the remote
stun status.
Displays " h " when the radio is in the remote
kill status.

Connect the antenna and the power cable to the radio.
 Install the microphone hanger at the position easy to use, with
2 M4*16 self -tapping screws. (The microphone and its cable
should be fixed at the position not affecting safe driving.)
 Connect the microphone to the microphone jack on the front
panel of the radio and put it on the hange r.
Note: When replacing the protective tube for the power cable,
please use the one of the same specification without fail. It is not
allowed to change it into the tube of higher capacit y.
7. P1button (programma ble button)
8. P2 button (programmable button)
9. P3button (programmable button)
10. PTT button (on the hand microphone)
Press the PTT button first, and then speak to the microphone to transmit the
voice to the othe r. Loosen to receive.
2. 2 Displa y S cree n
8
2 Radio Overview
2.1 Description of
External V iew
1. power button
Press this button for
a long time (more than
1.5 seconds) to switch
The radio on/o ff.
2. LED indicator
The red indicator will light while
transmit ting; the green indicator
Will light when it receives the carrie r.
3. / button (programmable button)
4. Display screen
For details, see Display .
5. Volume Control knob
To be used to adjust volume.
6. Microphone/Programming Interface
4 5

Display
Description
Displays " P " when the radio enters the PC
Programming Mode.
Displays " t " when the radio enters the PC
Adjustment Mode.
Displays " C " when the radio enters the Wired
Clone Mode 。
0. None
No function
1.Channel Up
Select the next channel
2.Channel Down
Select the previous channel
3.Talk-around
Switch the radio mode between talk-around and repeater.
4.Call Button1
Sends the DTMF/2Tone code assigned to call 1 button.
5.Call Button2
Sends the DTMF/2Tone code assigned to call 2 button.
6.Lone worker
Enables Lone worker function
7.Emergency
Alarm
Press the button programmed as “ Emergency Alarm ”
to set alarm tone according to the programming software
or send your own ID or background voice to your partner
or the system.
8.Emergency
Alarm Off
Press this button to quit the Emergency Alarm mode.
9.Scan
Start/end the scanningfunction of system.
10.Nuisance Delete
Press this button Nuisance Delete when the radio enables
11.Hi-Low Power
Switch
the scan function and stays at the noise channel.
Press toswitchbetweenhighand lowpowerof the sending
power of the radio, when the “ LOW ” is on the display,
in the normal voice. Please keep the microphone about 3 or 4 cm
far from your mouth.After speaking, please loosen the PTT button.
5. Receive:
The radio will return to the receiving state after you loosen the
PTT button. The distributor may have set the CTCSS/DCS
signaling in your radio. On the channels with CTCS S/DCS are
set, you can only hear the call from other radio with the same
CTCSS/DCS.
2.3 Rear Panel
1. Antenna Interface
2. Power Interface
3. External Speaker Interface
3 2 1
4. Programmable Button Function
P1, P2 , P3 / can be programmed as one of the following
functions.
3. Basic Operation
1. Startup:
Press the red POWER button for a long time (at least 1.5
seconds) to switch the radio on/off
2. Volume:
Press the MONITOR or Squelch Off button to listen to the
background noise first, and then adjust the volume by turning the
volume control knob.
3. Channel
The radio can provide 8 general channels. Press the CHANNEL
UP or CHANNEL DOWN button to select the channel.(Refre to P7
4 Programmable Button Function)
4. Transmission:
To send a call, press the PTT button and speak to the microphone
67

the current sending power is low.
12.Monitor
Hold to disable C TCSS/DCS signaling according to the
momentary
setting to resume normal operation.
13.Monitor
Press to disable CTCSS/DCS signaling to receive signals
that cannot be heart in normal operation, press again to
resume normal operation.
14.Squelch off
Hold to enable squelch and loosen to resume normal
momentary
operation.
15.Squelch off
Press this button to open the squelch. Press it again
to return to the normal operation.
Press this button in the selective call state to quit such a state.
16.Lone worker
After enabling the Lone worke r, press this button to
reset
reset the Lone worker timer and the timing resumes.
Start/end the public address function. Press this button and
17 .Public the function will be activated.PressthePTTbutton and speak
Address to the micro-phone so that you can hear your voice through
the external speaker.Press this button once again and return
to the normal user mode.
Press this button to enter the Squelch Level Adjustment
18.Squelch
Mode first, and then press the / button to adjust the level.
Level
Press the PTTbutton to save the selected squelch level and
Selection
quit this mode. Press any other button to quit without saving.
6. Talk-around
In the communication network, you can expand communication
range through the repeater, but when the mobile radio is out of the
communication range, you can connect with other radio in the
talk-around method.
Switch the talk-around or repeater mode through "Talk-around"
button.
7. Scan
The radio can be programmed to scan multiple channels to receive
signals.
7.1 Start/End Scan Function
Press the button programmed for "Scan" to enable scanning.
When the scan function is enabled, the "SCAN" indicator is on and
the channels being scanned are also displayed. Press the "Scan"
button again to disable scanning and the"SCAN" indicator will be
out.
5. Radio call
A. Press the button programmed as "call Button 1" or "call Button 2"
to send the preset code .
B. Press "PTT" and talk with the microphone in the normal voice.
Please keep the microphone about 3-4cm away from your lips.
When finish talking,release "PTT".
7.2 Nuisance Delete
If a channel continuously generates noise or interference, press
the button to remove this channel from the scan list temporarily.
Note: the priority channel can't be removed and the last one in the
scan list, either.Quit the Scan mode and enter it again, the deleted
channel will be added to the scan list again.
8 9

8. Public Address
Press the button programmed for "Public Address", "b" will be
displayed.Press the PTT button, the voice from the MIC of the
radio will be directly sent to the external speakers through the
interface on the back.
Press the "PublicAddress"button again to disable the public
software or sendYour ownID or background voice to your partner
or the system.
In the EmergencyAlarm Mode, press the button "Emergency Alarm
Off" to quit the EmergencyAlarm Mode and disable the alarm tone
or stop sending itand resume normal operation.
address function.
9. Lone worker
If Lone worker is set to be enabled, press the button "Lone
worker" to enable the Lone Worker Mode. Start the Lone
worker timer and when the preset Lone worker time is
reached, the radio will alarm, after the alarm time,the radio will
enter the Emergency Alarm Mode.
In the Lone worker Mode, press the "Lone worker" button
again to quit the Lone worker mode.
In the Lone worker Mode, press the button programmed for
"Lone worker reset" the specific button to select lone worker
reset mode or any button (any button to select lone worker
reset mode), the Lone worker timer will reset and start timing
again.
11. REMOTE KILL, stun activate and revive
If the radio received DTMF code programmed as remote stun,
theradiowillentertheremotestunstatus,afterreplying
according to the setting, "u" will be displayed. The radio can only
receive signals and cannot send signals. If the radio received
DTMP code programmed as remote un-stun, the radio will quit
the remote stun status and enter normal operation.
If the radio received DTMF code programmed as remote kill, the
radio will enter the remote kill status, after replying according to
the setting, "h" will be displayed.The radio cannotsend or receive
signals. If the radio received DTMP code is programmed as
revive, the radio will quit the remote kill status and enter normal
operation.
12. Wired Clone Mode
If the wired clone function is enabled, the radio will not quit after
entering the wired clone mode.To return to normal user mode,
10. EmergencyAlarm
Press the button programmed for "Emergency Alarm" (the
time of pressing must be longer than the de-bounce time of
the emergency alarm switch) to enter the Emergency Alarm
mode. "E" will be displayed. You can set alarm tone according
to the programming
the user needs to restart the machine.
The operating steps go as follows:
1. Press [P1] buttons for power-on until show"C" and enter the
10 11

NO.
Problem
Solution
B.Thehigh-frequencyamplifyingtubeQ18 isbroken.
Pleasechange it.
C.Thesquelch levelissettohighPleaseresetthe
squelchlevel.
D.Themixedtube Q19isbroken.Pleasechangeit.
E.TheFMIC6 isbroken.PleasechangeIC.
5
The red transmission
Indicator lights but no
sound is heard.
A.Powermodule IC1damaged,nopoweroutput,
pleasechangethemodule.
B.MICdamaged,pleasechangeit.
6
The green receiving
indicator lights but no
sound is heard.
A.Thespeakerisbroken.Pleasechangeit.
B.TheaudiopoweramplifierIC7isbroken.Please
changeIC.
NO.
Problem
Solution
1
Power on
Failure
A. The powe r cable is not connecte d with the accumulato r or the host
reliabl y. Please connect the power cable reliabl y.
B. The protective tube of power cable is burnt out. Please change it.
C. The power button is of poor contact. Please change the silica
gel button or PCB button.
D. The rechargeable battery is out of powe r. Please recharge or
change a new one.
E. CPU is broken, Please change the IC.
2
Phaselockloop
unlocked
(Beeping)
A. Channel frequency beyond the range, reset channel data.
B. The crystal X1 of phase lock loop is broken. Please change it.
C. The oscillator tube is broken. Please change it.
D. The IC3 of phase lock loop is broken. Please change IC.
3
Notalkback
A. The frequency is not right. Please reselect the channel
of the same frequenc y.
B. The CTCSS/DCS code is not the same. Please reset it.
C. It is out of the effective communication range.
4
Noreceiving
signal
A. The antenna is not in good contact. Please fasten the antenna
head.
clone mode. If the function is disabled, it will enter the user
mode.
2. Connect the slave radio with the wired clone cable first, and
then turn on.
3. Press button [P2] on the master radio for starting clone. During
transmitting the data, the master radio lightens red, and the
slave radio lightens green and indicates "P". After the slave
radio receiving all the data, the red light on the master radio is
off,andtheslave radio restarts.
4. You can keep cloning according to step 3 above.
13. Trouble Shooting Guide
14. Major Specifications
FrequencyRange: 136MHz~174MHz (MX-8000V)
438MHz~490MHz (MX-8000U)
ChannelNumber: 8
Channel Spacing: 25kHz (wide band)
12.5kHz(narrowband)
Operating Voltage: 13.6V Dc ± 10%
OperatingTemperature: -25 °C / -+55 °C
Dimension: 150 x 53 x 130 mm
Weight: 1030g
12 13

Declaration of Conformity MX-8000V
With the present declaration, we certify that the following products :
INTEK MX-8000V
comply with all the technical regulations applicable to the above mentioned products
in accordance with the EC Directives 2006/95/EC, 2004/108/EC, 99/5/EC.
Type of product : VHF PMR Transceiver
Details of applied standards : EN 300 086 -1/-2 1, EN 301 489-1-5
EN 60950-1
Manufacturer : INTEK S.R.L.
Via G. Marconi, 16
20090 Segrate, Italy
Tel. [phone] / Fax. [phone]
E-mail : [email protected]
Contact Reference : Armando Zanni
Tel. [phone] / Fax. [phone]
E-mail : [email protected]
Segrate, 13/11/2009 dr. Vittorio Zanetti
(General Manager)
DECLARATION OF CONFORMITY
EC Certificate of Conformity
(to EC Directive 2006/95, 2004/108, 99/5)
RoHS
2002/95/EC
Declaration of Conformity MX-8000U
With the present declaration, we certify that the following products :
INTEK MX-8000U
comply with all the technical regulations applicable to the above mentioned products
in accordance with the EC Directives 2006/95/EC, 2004/108/EC, 99/5/EC.
Type of product : UHF PMR Transceiver
Details of applied standards : EN 300 086 -1/-2 1, EN 301 489-1-5
EN 60950-1
Manufacturer : INTEK S.R.L.
Via G. Marconi, 16
20090 Segrate, Italy
Tel. [phone] / Fax. [phone]
E-mail : [email protected]
Contact Reference : Armando Zanni
Tel. [phone] / Fax. [phone]
E-mail : [email protected]
Segrate, 13/11/2009 dr. Vittorio Zanetti
(General Manager)
DECLARATION OF CONFORMITY
EC Certificate of Conformity
(to EC Directive 2006/95, 2004/108, 99/5)
