Intel D865GRH User manual

November 2003
Order Number: C53954-001
The Intel®Desktop Board D865GRH may contain design defects or errors known as errata that may cause the product to deviate from published specifications. Current
characterized errata are documented in the Intel Desktop Board D865GRH Specification Update.
Intel®Desktop Board
D865GRH
Technical Product Specification

Revision History
Revision Revision History Date
-001 First release of the Intel®Desktop Board D865GRH Technical Product
Specification.
November 2003
This product specification applies to only the standard Intel®Desktop Board D865GRH with BIOS
identifier BF86510A.86A.
Changes to this specification will be published in the Intel Desktop Board D865GRH Specification
Update before being incorporated into a revision of this document.
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL®PRODUCTS. NO LICENSE,
EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED
BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR SUCH
PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED
WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES
RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT,
COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. INTEL PRODUCTS ARE NOT INTENDED FOR USE IN
MEDICAL, LIFE SAVING, OR LIFE SUSTAINING APPLICATIONS.
Intel Corporation may have patents or pending patent applications, trademarks, copyrights, or other intellectual property
rights that relate to the presented subject matter. The furnishing of documents and other materials and information does not
provide any license, express or implied, by estoppel or otherwise, to any such patents, trademarks, copyrights, or other
intellectual property rights.
Intel may make changes to specifications and product descriptions at any time, without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked “reserved”or “undefined.”
Intel reserves these for future definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising
from future changes to them.
Intel®desktop boards may contain design defects or errors known as errata, which may cause the product to deviate from
published specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your product order.
Copies of documents which have an ordering number and are referenced in this document, or other Intel literature, may be
obtained from:
Intel Corporation
P.O. Box 5937
Denver, CO 80217-9808
or call in North America 1-800-548-4725, Europe 44-0-1793-431-155, France 44-0-1793-421-777,
Germany 44-0-1793-421-333, other Countries 708-296-9333.
Intel, Pentium, and Celeron are registered trademarks of Intel Corporation or its subsidiaries in the United States and other
countries.
* Other names and brands may be claimed as the property of others.
Copyright 2003, Intel Corporation. All rights reserved.

iii
Preface
This Technical Product Specification (TPS) specifies the board layout, components, connectors,
power and environmental requirements, and the BIOS for the Intel®Desktop Board D865GRH. It
describes the standard product and available manufacturing options.
Intended Audience
The TPS is intended to provide detailed, technical information about the Desktop Board D865GRH
and their components to the vendors, system integrators, and other engineers and technicians who
need this level of information. It is specifically not intended for general audiences.
What This Document Contains
Chapter Description
1 A description of the hardware used on the Desktop Board D865GRH
2 A map of the resources of the Desktop Board
3 The features supported by the BIOS Setup program
4 The contents of the BIOS Setup program’s menus and submenus
5 A description of the BIOS error messages, beep codes, and POST codes
Typographical Conventions
This section contains information about the conventions used in this specification. Not all of these
symbols and abbreviations appear in all specifications of this type.
Notes, Cautions, and Warnings
✏ NOTE
Notes call attention to important information.
# INTEGRATOR’S NOTES
Integrator’s notes are used to call attention to information that may be useful to system
integrators.
CAUTION
Cautions are included to help you avoid damaging hardware or losing data.

Intel Desktop Board D865GRH Technical Product Specification
iv
WARNING
Warnings indicate conditions, which if not observed, can cause personal injury.
Other Common Notation
# Used after a signal name to identify an active-low signal (such as USBP0#)
(NxnX) When used in the description of a component, N indicates component type, xn are the relative
coordinates of its location on the Desktop Board D865GRH, and X is the instance of the
particular part at that general location. For example, J5J1 is a connector, located at 5J. It is
the first connector in the 5J area.
GB Gigabyte (1,073,741,824 bytes)
GB/sec Gigabytes per second
KB Kilobyte (1024 bytes)
Kbit Kilobit (1024 bits)
kbits/sec 1000 bits per second
MB Megabyte (1,048,576 bytes)
MB/sec Megabytes per second
Mbit Megabit (1,048,576 bits)
Mbit/sec Megabits per second
xxh An address or data value ending with a lowercase h indicates a hexadecimal value.
x.x V Volts. Voltages are DC unless otherwise specified.
* This symbol is used to indicate third-party brands and names that are the property of their
respective owners.

v
Contents
1Product Description
1.1 Overview ....................................................................................................................12
1.1.1 Feature Summary ........................................................................................12
1.1.2 Manufacturing Options .................................................................................13
1.1.3 Board Layout................................................................................................14
1.1.4 Block Diagram..............................................................................................15
1.2 Online Support ...........................................................................................................16
1.3 Operating System Support .........................................................................................16
1.4 Design Specifications .................................................................................................17
1.5 Processor ...................................................................................................................20
1.6 System Memory .........................................................................................................21
1.6.1 Memory Configurations ................................................................................23
1.7 Intel®865G Chipset....................................................................................................28
1.7.1 Intel 865G Graphics Subsystem...................................................................29
1.7.2 Universal 0.8 V / 1.5 V AGP 3.0 Connector..................................................37
1.7.3 USB..............................................................................................................38
1.7.4 IDE Support .................................................................................................38
1.7.5 Real-Time Clock, CMOS SRAM, and Battery...............................................40
1.8 I/O Controller ..............................................................................................................40
1.8.1 Serial Port ....................................................................................................41
1.8.2 Parallel Port..................................................................................................41
1.8.3 Diskette Drive Controller ..............................................................................41
1.8.4 Keyboard and Mouse Interface ....................................................................41
1.9 Audio Subsystem........................................................................................................42
1.9.1 Audio Subsystem Software ..........................................................................42
1.9.2 Intel®Flex 6 Audio Subsystem .....................................................................42
1.9.3 Audio Connectors.........................................................................................44
1.10 LAN Subsystem..........................................................................................................45
1.10.1 Intel®82547EI Platform LAN Connect Device ..............................................45
1.10.2 RJ-45 LAN Connector with Integrated LEDs ................................................45
1.10.3 LAN Subsystem Software ............................................................................46
1.11 Hardware Management Subsystem............................................................................46
1.11.1 Hardware Monitoring and Fan Control ASIC ................................................46
1.11.2 Thermal Monitoring ......................................................................................46
1.11.3 Fan Monitoring .............................................................................................48
1.11.4 Chassis Intrusion and Detection...................................................................48
1.12 Power Management ...................................................................................................48
1.12.1 ACPI.............................................................................................................48
1.12.2 Hardware Support ........................................................................................51
1.13 Trusted Platform Module ............................................................................................56
1.13.1 System Requirements..................................................................................56
1.13.2 Warning of Potential Data Loss....................................................................56
1.13.3 Security Precautions ....................................................................................57

Intel Desktop Board D865GRH Technical Product Specification
vi
1.13.4 Trusted Platform Module Ownership ............................................................59
1.13.5 Enabling the Trusted Platform Module .........................................................59
1.13.6 Assuming Trusted Platform Module Ownership............................................60
1.13.7 Recovery Procedures...................................................................................61
1.13.8 Clearing Trusted Platform Module Ownership..............................................62
1.13.9 Software Support .........................................................................................62
2Technical Reference
2.1 Introduction.................................................................................................................63
2.2 Memory Resources ....................................................................................................63
2.2.1 Addressable Memory ...................................................................................63
2.2.2 Memory Map ................................................................................................65
2.3 DMA Channels ...........................................................................................................65
2.4 Fixed I/O Map.............................................................................................................66
2.5 PCI Configuration Space Map ....................................................................................67
2.6 Interrupts ....................................................................................................................68
2.7 PCI Interrupt Routing Map..........................................................................................69
2.8 Connectors .................................................................................................................71
2.8.1 Back Panel Connectors................................................................................72
2.8.2 Internal I/O Connectors ................................................................................73
2.8.3 External I/O Connectors...............................................................................81
2.9 Jumper Blocks............................................................................................................85
2.9.1 Front Panel Audio Connector/Jumper Block.................................................85
2.9.2 BIOS Setup Configuration Jumper Block......................................................86
2.10 Mechanical Considerations.........................................................................................87
2.10.1 I/O Shield .....................................................................................................88
2.11 Electrical Considerations ............................................................................................89
2.11.1 DC Loading ..................................................................................................89
2.11.2 Add-in Board Considerations........................................................................89
2.11.3 Fan Connector Current Capability ................................................................89
2.11.4 Power Supply Considerations ......................................................................90
2.12 Thermal Considerations..............................................................................................90
2.13 Reliability ....................................................................................................................93
2.14 Environmental ............................................................................................................93
2.15 Regulatory Compliance ..............................................................................................94
2.15.1 Safety Regulations .......................................................................................94
2.15.2 EMC Regulations .........................................................................................94
2.15.3 European Union Declaration of Conformity Statement .................................95
2.15.4 Product Ecology Statements ........................................................................96
2.15.5 Product Certification Markings (Board Level) ...............................................96
3Overview of BIOS Features
3.1 Introduction.................................................................................................................97
3.2 BIOS Flash Memory Organization ..............................................................................97
3.3 Resource Configuration..............................................................................................98
3.3.1 PCI Autoconfiguration ..................................................................................98
3.3.2 PCI IDE Support...........................................................................................98
3.4 System Management BIOS (SMBIOS).......................................................................99

Contents
vii
3.5 Legacy USB Support ..................................................................................................99
3.6 BIOS Updates ..........................................................................................................100
3.6.1 Language Support......................................................................................100
3.6.2 Custom Splash Screen...............................................................................101
3.7 Recovering BIOS Data .............................................................................................101
3.8 Boot Options.............................................................................................................102
3.8.1 CD-ROM Boot............................................................................................102
3.8.2 Network Boot..............................................................................................102
3.8.3 Booting Without Attached Devices .............................................................102
3.8.4 Changing the Default Boot Device During POST........................................102
3.9 Fast Booting Systems with Intel®Rapid BIOS Boot..................................................103
3.9.1 Peripheral Selection and Configuration ......................................................103
3.9.2 Intel Rapid BIOS Boot ................................................................................103
3.10 BIOS Security Features............................................................................................104
4BIOS Setup Program
4.1 Introduction...............................................................................................................105
4.2 Maintenance Menu ...................................................................................................106
4.3 Main Menu................................................................................................................107
4.4 Advanced Menu........................................................................................................108
4.4.1 PCI Configuration Submenu.......................................................................109
4.4.2 Boot Configuration Submenu .....................................................................110
4.4.3 Peripheral Configuration Submenu.............................................................111
4.4.4 Drive Configuration Submenu ....................................................................113
4.4.5 Floppy Configuration Submenu ..................................................................117
4.4.6 Event Log Configuration Submenu.............................................................118
4.4.7 Video Configuration Submenu....................................................................119
4.4.8 USB Configuration Submenu .....................................................................120
4.4.9 Chipset Configuration Submenu.................................................................121
4.4.10 Fan Control Configuration Submenu ..........................................................124
4.4.11 Hardware Monitoring..................................................................................125
4.5 Security Menu ..........................................................................................................126
4.6 Power Menu .............................................................................................................127
4.6.1 ACPI Submenu ..........................................................................................127
4.7 Boot Menu................................................................................................................128
4.7.1 Boot Device Priority Submenu....................................................................129
4.7.2 Hard Disk Drives Submenu ........................................................................130
4.7.3 Removable Devices Submenu ...................................................................130
4.7.4 ATAPI CD-ROM Drives Submenu..............................................................131
4.8 Exit Menu .................................................................................................................131
5Error Messages and Beep Codes
5.1 BIOS Error Messages...............................................................................................133
5.2 Port 80h POST Codes..............................................................................................135
5.3 Bus Initialization Checkpoints ...................................................................................139
5.4 Speaker....................................................................................................................140
5.5 BIOS Beep Codes ....................................................................................................140

Intel Desktop Board D865GRH Technical Product Specification
viii
Figures
1. Desktop Board D865GRH Components .....................................................................14
2. Block Diagram ............................................................................................................15
3. Memory Channel Configuration ..................................................................................23
4. Examples of Dual Channel Configuration with Dynamic Mode ...................................24
5. Example of Dual Channel Configuration without Dynamic Mode ................................25
6. Examples of Single Channel Configuration with Dynamic Mode.................................26
7. Examples of Single Channel Configuration without Dynamic Mode............................27
8. Intel 865G Chipset Block Diagram..............................................................................28
9. Back Panel Audio Connector Options for Flex 6 Audio Subsystem ............................42
10. Adapter for S/PDIF Back Panel Connector.................................................................43
11. Flex 6 Audio Subsystem Block Diagram .....................................................................43
12. LAN Connector LED Locations ...................................................................................45
13. Thermal Monitoring.....................................................................................................47
14. Location of the Standby Power Indicator LED ............................................................54
15. Detailed System Memory Address Map......................................................................64
16. Back Panel Connectors ..............................................................................................72
17. Audio Connectors .......................................................................................................74
18. Power and Hardware Control Connectors ..................................................................76
19. D865GRH Add-in Board and Peripheral Interface Connectors ...................................79
20. External I/O Connectors .............................................................................................81
21. Connection Diagram for Front Panel Connector .........................................................82
22. Connection Diagram for Front Panel USB Connectors ...............................................84
23. Location of the Jumper Blocks....................................................................................85
24. Desktop Board D865GRH Dimensions.......................................................................87
25. I/O Shield Dimensions ................................................................................................88
26. Localized High Temperature Zones............................................................................91
Tables
1. Feature Summary.......................................................................................................12
2. Manufacturing Options ...............................................................................................13
3. Specifications .............................................................................................................17
4. Supported System Bus Frequency and Memory Speed Combinations.......................21
5. Supported Memory Configurations .............................................................................22
6. Characteristics of Dual/Single Channel Configuration with/without Dynamic Mode.....23
7. Direct Draw Supported Modes....................................................................................30
8. Video BIOS Video Modes Supported for Analog CRTs...............................................31
9. Supported Modes for DDR400/DDR333 Dual Channel Configuration.........................32
10. Supported Modes for DDR266 Dual Channel and DDR333/DDR400 Single
Channel Configurations ..............................................................................................33
11. Supported Modes for DDR266 Single Channel Configuration.....................................34
12. LAN Connector LED States ........................................................................................45
13. Effects of Pressing the Power Switch .........................................................................49
14. Power States and Targeted System Power ................................................................49
15. Wake-up Devices and Events.....................................................................................50
16. Fan Connector Function/Operation.............................................................................52

Contents
ix
17. System Memory Map..................................................................................................65
18. DMA Channels ...........................................................................................................65
19. I/O Map ......................................................................................................................66
20. PCI Configuration Space Map ....................................................................................67
21. PCI Configuration Space Bus Number Options ..........................................................67
22. Interrupts ....................................................................................................................68
23. PCI Interrupt Routing Map..........................................................................................70
24. Auxiliary Line In Connector.........................................................................................75
25. ATAPI CD-ROM Connector ........................................................................................75
26. Front Panel Audio Connector .....................................................................................75
27. Rear Chassis Fan Connector .....................................................................................76
28. ATX12V Power Connector..........................................................................................77
29. Processor Fan Connector...........................................................................................77
30. Main Power Connector ...............................................................................................77
31. Front Chassis Fan Connector.....................................................................................78
32. Chassis Intrusion Connector.......................................................................................78
33. SCSI Hard Drive Activity LED Connector (Optional) ...................................................80
34. Serial ATA Connectors ...............................................................................................80
35. Auxiliary Front Panel Power/Sleep/Message-Waiting LED Connector ........................82
36. Front Panel Connector ...............................................................................................82
37. States for a One-Color Power LED.............................................................................83
38. States for a Two-Color Power LED.............................................................................83
39. Front Panel Audio Connector/Jumper Block ...............................................................86
40. BIOS Setup Configuration Jumper Settings................................................................86
41. DC Loading Characteristics ........................................................................................89
42. Fan Connector Current Capability ..............................................................................89
43. Thermal Considerations for Components ...................................................................92
44. Desktop Board D865GRH Environmental Specifications ............................................93
45. Safety Regulations .....................................................................................................94
46. EMC Regulations........................................................................................................94
47. Product Certification Markings....................................................................................96
48. Boot Device Menu Options.......................................................................................102
49. Supervisor and User Password Functions ................................................................104
50. BIOS Setup Program Menu Bar ...............................................................................105
51. BIOS Setup Program Function Keys ........................................................................106
52. Maintenance Menu ...................................................................................................106
53. Main Menu................................................................................................................107
54. Advanced Menu........................................................................................................108
55. PCI Configuration Submenu .....................................................................................109
56. Boot Configuration Submenu....................................................................................110
57. Peripheral Configuration Submenu...........................................................................111
58. Drive Configuration Submenu...................................................................................113
59. SATA/PATA Submenus............................................................................................116
60. Floppy Configuration Submenu ................................................................................117
61. Event Log Configuration Submenu ...........................................................................118
62. Video Configuration Submenu..................................................................................119
63. USB Configuration Submenu....................................................................................120
64. Chipset Configuration Submenu ...............................................................................121

Intel Desktop Board D865GRH Technical Product Specification
x
65. Burn-In Mode Submenu ...........................................................................................123
66. Fan Control Configuration Submenu ........................................................................124
67. Hardware Monitoring Display....................................................................................125
68. Security Menu ..........................................................................................................126
69. Power Menu .............................................................................................................127
70. ACPI Submenu.........................................................................................................127
71. Boot Menu................................................................................................................128
72. Boot Device Priority Submenu..................................................................................129
73. Hard Disk Drives Submenu ......................................................................................130
74. Removable Devices Submenu..................................................................................130
75. ATAPI CD-ROM Drives Submenu ............................................................................131
76. Exit Menu .................................................................................................................131
77. BIOS Error Messages...............................................................................................133
78. Uncompressed INIT Code Checkpoints....................................................................135
79. Boot Block Recovery Code Checkpoints ..................................................................135
80. Runtime Code Uncompressed in F000 Shadow RAM ..............................................136
81. Bus Initialization Checkpoints ...................................................................................139
82. Upper Nibble High Byte Functions............................................................................139
83. Lower Nibble High Byte Functions............................................................................140
84. Beep Codes..............................................................................................................141

11
1 Product Description
What This Chapter Contains
1.1 Overview ....................................................................................................................12
1.2 Online Support ...........................................................................................................16
1.3 Operating System Support .........................................................................................16
1.4 Design Specifications .................................................................................................17
1.5 Processor ...................................................................................................................20
1.6 System Memory .........................................................................................................21
1.7 Intel®865G Chipset....................................................................................................28
1.8 I/O Controller ..............................................................................................................40
1.9 Audio Subsystem........................................................................................................42
1.10 LAN Subsystem..........................................................................................................45
1.11 Hardware Management Subsystem............................................................................46
1.12 Power Management ...................................................................................................48

Intel Desktop Board D865GRH Technical Product Specification
12
1.1 Overview
1.1.1 Feature Summary
Table 1 summarizes the major features of the Intel®Desktop Board D865GRH.
Table 1. Feature Summary
Form Factor microATX (9.60 inches by 9.60 inches [243.84 millimeters by 243.84 millimeters])
Processor • Support for an Intel®Pentium®4 processor in an mPGA478 socket with a
400/533/800 MHz system bus
• Support for an Intel®Celeron®processor in an mPGA478 socket with a
400 MHz system bus
Memory • Four 184-pin DDR SDRAM Dual Inline Memory Module (DIMM) sockets
• Support for DDR 400, DDR 333, and DDR 266
NOTE: System resources (such as PCI and AGP) require physical memory address
locations that reduce available memory addresses above 3 GB. This may result in
less than 4 GB of memory being available to the operating system and
applications. For more information about the latest list of tested memory, refer to
the Intel World Wide Web site at:
http://support.intel.com/support/motherboards/desktop/
Chipset Intel®865G Chipset, consisting of:
• Intel®82865G Graphics and Memory Controller Hub (GMCH)
• Intel®82801EB I/O Controller Hub (ICH5)
• 4 Mbit Firmware Hub (FWH)
Video • Intel®Extreme Graphics 2 controller
• Universal 0.8 V / 1.5 V AGP 3.0 connector supporting 1x, 4x, and 8x AGP cards
or an AGP Digital Display (ADD) card
• Integrated retention mechanism
Audio Flex 6 audio subsystem using the Analog Devices AD1985 codec
I/O Control SMSC LPC47M172 LPC Bus I/O controller
USB Support for USB 2.0 devices
Peripheral
Interfaces
• Eight USB ports
• One serial port
• One parallel port
• Two Serial ATA IDE interfaces
• Two Parallel ATA IDE interfaces with UDMA 33, ATA-66/100 support
• One diskette drive interface
• PS/2* keyboard and mouse ports
LAN Support Gigabit (10/100/1000 Mbits/sec) LAN subsystem using the Intel®82547EI Platform
LAN Connect (PLC) device
continued

Product Description
13
Table 1. Feature Summary (continued)
BIOS • Intel/AMI BIOS (resident in the 4 Mbit FWH)
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and SMBIOS
Instantly Available
PC Technology
• Support for PCI Local Bus Specification Revision 2.2
• Suspend to RAM support
• Wake on PCI, RS-232, front panel, PS/2 devices, and USB ports
Expansion
Capabilities
Three PCI bus add-in card connectors (SMBus routed to PCI bus connector 2)
Hardware Monitor
Subsystem
• Hardware monitoring and fan control ASIC
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Three fan connectors
• Three fan sense inputs used to monitor fan activity
• Fan speed control
Security Trusted Platform Module (TPM)
For information about Refer to
The board’s compliance level with ACPI, Plug and Play, and SMBIOS Section 1.4, page 17
1.1.2 Manufacturing Options
Table 2 describes the manufacturing options on the Desktop Board D865GRH. Not every
manufacturing option is available in all marketing channels. Please contact your Intel
representative to determine which manufacturing options are available to you.
Table 2. Manufacturing Options
SCSI Hard Drive
Activity LED
Connector
Allows add-in hard drive controllers (SCSI or other) to use the same LED as the
onboard IDE controller.
For information about Refer to
Available configurations for the Desktop Board D865GRH Section 1.2, page 16

Intel Desktop Board D865GRH Technical Product Specification
14
1.1.3 Board Layout
Figure 1 shows the location of the major components on the Desktop Board D865GRH.
OM16498
GB
AF DC E
I
L
J
K
H
PO
S
QRTVX
W U
N
Z
AA
BB
CC
DD
EE
GG
FF
M
Y
A Audio codec R SCSI hard drive activity LED connector (optional)
B Front panel audio connector S Front chassis fan connector
C ATAPI CD-ROM connector T Chassis intrusion connector
D Ethernet PLC device (Optional) U 4 Mbit Firmware Hub (FWH)
E AGP connector V Speaker
F Rear chassis fan connector W BIOS Setup configuration jumper block
G Back panel connectors X Auxiliary front panel power LED connector
H +12V power connector (ATX12V) Y Trusted Platform Module
I mPGA478 processor socket Z Front panel connector
J Processor fan connector AA Serial ATA connectors
K Intel 82865G GMCH BB Front panel USB connector
L DIMM Channel A sockets CC Intel 82801EB I/O Controller Hub (ICH5)
M DIMM Channel B sockets DD Front panel USB connector
N I/O controller EE Battery
O Power connector FF PCI bus add-in card connectors
P Diskette drive connector GG Auxiliary line-in connector
Q Parallel ATA IDE connectors
Figure 1. Desktop Board D865GRH Components

Product Description
15
1.1.4 Block Diagram
Figure 2 is a block diagram of the major functional areas of the Desktop Board D865GRH.
Intel 865G Chipset
Intel 82801EB
I/O Controller Hub
(ICH5)
Intel 82865G
Graphics and
Memory Controller
Hub (GMCH)
Intel 82802AB
4 Mbit
Firmware Hub
(FWH)
AHA
Bus
System Bus
(400/533/800 MHz)
mPGA478
Processor Socket
Parallel ATA IDE
Connectors (2)
Diskette Drive
Connector
LPC Bus
I/O
Controller PS/2 Keyboard
PS/2 Mouse
Parallel Port
Serial Port
Parallel ATA
IDE Interface
LPC
Bus
Hardware
Monitoring
and Fan
Control ASIC
OM16507
AD1985
Audio Codec
Mic In
Front Left and Right Out
CD-ROM
Line In
LAN
Connector
10/100
LAN PLC
(Optional)
CSMA/CD
Unit Interface
AGP
Interface
Universal 0.8/
1.5 V AGP 3.0
Connector
= connector or socket
PCI Bus
SMBus
AC
Link
Back Panel/
Front Panel
USB Ports
USB
Dual-Channel
Memory Bus
SMBus
PCI Slot 1
PCI Slot 2
PCI Slot 3
Center and LFE Out
Rear Left and Right Out
S/PDIF
Serial ATA IDE
Connectors (2)
Serial ATA
IDE Interface
VGA
Port
Display
Interface
Channel A
DIMMs (2)
Channel B
DIMMs (2)
LAN
Connector
Gigabit
LAN
PLC
(Optional) CSA
Interface
Auxiliary Line In
Figure 2. Block Diagram

Intel Desktop Board D865GRH Technical Product Specification
16
1.2 Online Support
To find information about…Visit this World Wide Web site:
Intel Desktop Board D865GRH under
“Desktop Board Products”or “Desktop
Board Support”
http://www.intel.com/design/motherbd
http://support.intel.com/support/motherboards/desktop
Available configurations for the Desktop
Board D865GRH
http://developer.intel.com/design/motherbd/rh/rh_available.htm
Processor data sheets http://www.intel.com/design/litcentr
ICH5 addressing http://developer.intel.com/design/chipsets/datashts
Custom splash screens http://intel.com/design/motherbd/gen_indx.htm
Audio software and utilities http://www.intel.com/design/motherbd
LAN software and drivers http://www.intel.com/design/motherbd
1.3 Operating System Support
The Desktop Board D865GRH supports drivers for all of the onboard hardware and subsystems
under the following operating systems:
• Microsoft Windows* XP Professional
• Microsoft Windows 2000 Professional
For information about Refer to
Supported drivers Section 1.2
✏ NOTES
• Native USB 2.0 support has been tested with drivers for Windows 2000 (with Service Pack 3)
and Windows XP (with Service Pack 1) and is not currently supported by any other operating
system in the list above. Check Intel’s Desktop Board website for possible driver updates for
other operating systems.
• Third party vendors may offer other drivers.

Product Description
17
1.4 Design Specifications
Table 3 lists the specifications applicable to the Desktop Board D865GRH.
Table 3. Specifications
Reference
Name
Specification
Title
Version, Revision Date,
and Ownership
The information is
available from…
AC ’97 Audio Codec ’97 Revision 2.2,
September 2000,
Intel Corporation.
ftp://download.intel.com/labs/
media/audio/download/ac97r2
2.pdf
ACPI Advanced Configuration and
Power Interface
Specification
Version 2.0,
July 27, 2000,
Compaq Computer
Corporation,
Intel Corporation,
Microsoft Corporation,
Phoenix Technologies
Limited, and
Toshiba Corporation.
http://www.acpi.info/spec.htm
AGP Accelerated Graphics Port
Interface Specification
Revision 3.0,
September 2002,
Intel Corporation.
http://www.agpforum.org/spec
s_specs.htm
ASF Alert Standard Format (ASF)
Specification
Version 1.03,
June 20, 2001,
DMTF,
Intel Corporation.
http://www.dmtf.org/standards
/documents/ASF/DSP0114.pd
f
ATA/
ATAPI-5
Information Technology-AT
Attachment with Packet
Interface - 5 (ATA/ATAPI-5)
Revision 3,
February 29, 2000,
Contact: T13 Chair,
Seagate Technology.
http://www.t13.org/
ATX ATX Specification Version 2.1,
June 2002,
Intel Corporation.
http://www.formfactors.org/for
mfactor.asp
ATX12V ATX/ATX12V Power Supply
Design Guide
Version 1.2,
August 2000,
Intel Corporation.
http://www.formfactors.org/for
mfactor.asp
BIS Boot Integrity Services (BIS)
Application Programming
Interface (API)
Version 1.0,
August 4, 1999,
Intel Corporation.
http://www.intel.com/labs/man
age/wfm/wfmspecs.htm
continued

Intel Desktop Board D865GRH Technical Product Specification
18
Table 3. Specifications (continued)
Reference
Name
Specification
Title
Version, Revision Date and
Ownership
The information is
available from…
DDR
SDRAM
Double Data Rate (DDR)
SDRAM Specification
Version 1.0,
June 2000,
JEDEC Solid State Technology
Association.
http://www.jedec.org/
Design Specification for a
184 Pin DDR Unbuffered
DIMM
Revision 1.0,
October 2001,
JEDEC Solid State Technology
Association.
http://www.jedec.org/
Intel®JEDE DDR
200/266 Unbuffered
DIMM Specification
Addendum
Revision 0.9,
September 27, 2001,
Intel Corporation.
http://developer.intel.com/te
chnology/memory/index.ht
m
EHCI Enhanced Host
ontroller Interface
Specification for
Universal Serial Bus
Revision 1.0,
March 12, 2002,
Intel Corporation.
http://developer.intel.com/te
chnology/usb/download/ehc
i-r10.pdf
EPP IEEE Std 1284.1-1997
(Enhanced Parallel Port)
Version 1.7,
1997,
Institute of Electrical and
Electronic Engineers.
http://standards.ieee.org/re
ading/ieee/std_public/descri
ption/busarch/1284.1-
1997_desc.html
El Torito Bootable CD-ROM
Format Specification
Version 1.0,
January 25, 1995,
Phoenix Technologies Limited
and International Business
Machines Corporation.
http://www.phoenix.com/res
ources/specs-cdrom.pdf
LPC Low Pin Count Interface
Specification
Revision 1.0,
September 29, 1997,
Intel Corporation.
http://www.intel.com/design
/chipsets/industry/lpc.htm
MicroATX microATX Motherboard
Interface Specification
Version 1.1,
June 2002,
Intel Corporation.
http://www.formfactors.org/f
ormfactor.asp
PCI PCI Local Bus
Specification
Revision 2.2,
December 18, 1998,
PCI Special Interest Group.
http://www.pcisig.com/speci
fications
PCI Bus Power
Management Interface
Specification
Revision 1.1,
December 18, 1998,
PCI Special Interest Group.
http://www.pcisig.com/speci
fications
Plug and
Play
Plug and Play BIOS
Specification
Version 1.0a,
May 5, 1994,
Compaq Computer Corporation,
Phoenix Technologies Limited,
and Intel Corporation.
http://www.microsoft.com/h
wdev/tech/PnP/default.asp
continued

Product Description
19
Table 3. Specifications (continued)
Reference
Name
Specification
Title
Version, Revision Date
and Ownership
The information is
available from…
PXE Preboot Execution
Environment
Version 2.1,
September 20, 1999,
Intel Corporation.
ftp://download.intel.com/lab
s/manage/wfm/download/p
xespec.pdf
SFX SFX/SFX12V Power
Supply Design Guide
Version 2.0,
May 2001,
Intel Corporation.
http://www.formfactors.org/f
ormfactor.asp
SMBIOS System Management
BIOS
Version 2.3.1,
March 16, 1999,
American Megatrends
Incorporated,
Award Software International
Incorporated,
Compaq Computer Corporation,
Dell Computer Corporation,
Hewlett-Packard Company,
Intel Corporation,
International Business Machines
Corporation,
Phoenix Technologies Limited,
and SystemSoft Corporation.
http://www.dmtf.org/downlo
ad/standards/DSP0119.pdf
TFX12V TFX12V Power Supply
Design Guide
Revision 1.01,
May 2002,
Intel Corporation.
http://www.formfactors.org/f
ormfactor.asp
UHCI Universal Host Controller
Interface Design Guide
Revision 1.1,
March 1996,
Intel Corporation.
http://developer.intel.com/d
esign/USB/UHCI11D.htm
USB Universal Serial Bus
Specification
Revision 2.0,
April 27, 2000,
Compaq Computer Corporation,
Hewlett-Packard Company,
Lucent Technologies Inc.,
Intel Corporation,
Microsoft Corporation,
NEC Corporation, and
Koninklijke Philips Electronics
N.V.
http://www.usb.org/develop
ers/docs
WfM Wired for Management
Baseline
Version 2.0,
December 18, 1998,
Intel Corporation.
http://www.intel.com/labs/m
anage/wfm/wfmspecs.htm

Intel Desktop Board D865GRH Technical Product Specification
20
1.5 Processor
✏ NOTE
Refer to Thermal Considerations (Section 2.12, page 90) for important information when using an
Intel Pentium 4 processor operating above 2.80 GHz with this Intel desktop board.
The board is designed to support the following:
• Intel Pentium 4 processors in an mPGA478 processor socket with a 400/533/800 MHz system
bus
• Intel Celeron processors in an mPGA478 processor socket with a 400 MHz system bus
See the Intel web site listed below for the most up-to-date list of supported processors.
For information about…Refer to:
Supported processors for the D865GRH board http://www.intel.com/design/motherbd/rh/rh_proc.htm
CAUTION
Use only the processors listed on web site above. Use of unsupported processors can damage the
board, the processor, and the power supply.
# INTEGRATOR’S NOTES
• Use only ATX12V-, SFX12V-, or TFX12V-compliant power supplies with the Desktop Board
D865GRH. ATX12V, SFX12V, and TFX12V power supplies have an additional power lead
that provides required supplemental power for the processor. Always connect the 20-pin and
4-pin leads of ATX12V, SFX12V, and TFX12V power supplies to the corresponding connectors
on the desktop board, otherwise the board will not boot.
• Do not use a standard ATX power supply. The board will not boot with a standard ATX power
supply.
• Refer to Table 4 on page 21 for a list of supported system bus frequency and memory speed
combinations.
For information about Refer to
Power supply connectors Section 2.8.2.3, page 76
