Intel® Desktop Board
DH55PJ
Specification Update
December 2011
Order Number: E96959-005
The Intel®Desktop Board DH55PJ may contain design defects or errors known as errata, which may cause the product to deviate
from published specifications. Current characterized errata are documented in this Specification Update.

2 Intel Desktop Board DH55PJ Specification Update
Revision History
Revision Revision History Date
-001 This document is the first Specification Update for the Intel®Desktop
Board DH55PJ
April 2010
-002 Update to the General Information section July 2010
-003 Update to the General Information section December 2010
-004 Update to the Specification Changes section March 2011
-005 Update to the Specification Changes section December 2011
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL®PRODUCTS. NO LICENSE,
EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS
GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR
SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR
IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR
WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT
OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. INTEL PRODUCTS ARE NOT
INTENDED FOR USE IN MEDICAL, LIFE SAVING, LIFE SUSTAINING APPLICATIONS.
Intel may make changes to specifications and product descriptions at any time, without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked “reserved”
or “undefined”. Intel reserves these for future definition and shall have no responsibility whatsoever for
conflicts or incompatibilities arising from future changes to them.
The Intel®Desktop Board DH55PJ may contain design defects or errors known as errata which may cause
the product to deviate from published specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your
product order.
Copies of documents which have an ordering number and are referenced in this document, or other Intel
literature, may be obtained from:
Intel Corporation
P.O. Box 5937
Denver, CO 80217-9808
or call in North America 1-800-548-4725, Europe 44-0-1793-431-155, France 44-0-1793-421-777,
Germany 44-0-1793-421-333, other Countries 708-296-9333
Intel and the Intel logo are registered trademarks of Intel Corporation in the U.S. and other countries.
* Other names and brands may be claimed as the property of others.
Copyright ©2010, 2011 Intel Corporation.

Intel Desktop Board DH55PJ Specification Update 3
Contents
Specification Update for the Intel®Desktop Board DH55PJ
Terminology ............................................................................................ 5
General Information ................................................................................. 5
Summary of Changes ............................................................................... 6

4 Intel Desktop Board DH55PJ Specification Update
Specification Update for the
Intel®Desktop Board DH55PJ
This document is an update to the specifications contained in the Intel®Desktop Board
DH55PJ Technical Product Specification (Order Number: E95284). It is intended for
hardware system manufacturers and software developers of applications, operating
systems, or tools. It will contain Specification Changes, Errata, Specification
Clarifications, and Documentation Changes.
Refer to the Intel®Core™ i7-800 and Intel®Core™ i5-700 Desktop Processor Series
Specification Update (Order Number: 322166) as well as to the Intel®Core™ i5-600,
Intel®Core™ i3-500 Desktop Processor Series and Intel®Pentium®Processor G6950
Series Specification Update (Order Number: 322911) for specification updates
concerning supported processors that may apply to the desktop board DH55PJ. Unless
otherwise noted in this document, it should be assumed that any Processor errata for a
given stepping are applicable to the Altered Assembly (AA) revision(s) associated with
that stepping.
Refer to the Intel®5 Series Chipset and Intel®3400 Series Chipset Specification
Update (Order Number: 322170) for specification updates concerning the Intel®H55
Express Chipset that may apply to the desktop board DH55PJ. Unless otherwise noted
in this document, it should be assumed that any Platform Controller Hub errata for a
given stepping are applicable to the Altered Assembly (AA) revision(s) associated with
that stepping.

Intel Desktop Board DH55PJ Specification Update 5
Terminology
Specification Changes are modifications to the current published specifications.
These changes will be incorporated in the next release of the specifications.
Errata are design defects or errors. Characterized errata may cause the desktop
board behavior to deviate from published specifications. Hardware and software
designed to be used with any given Altered Assembly (AA) and BIOS revision level
must assume that all errata documented for that AA and BIOS revision level are
present on all desktop boards.
Specification Clarifications describe a specification in greater detail or further
highlight a specification’s impact to a complex design situation. These clarifications
will be incorporated in the next release of the specifications.
Documentation Changes include typos, errors, or omissions from the current
published specifications. These changes will be incorporated in the next release of the
specifications.
General Information
Basic Desktop Board DH55PJ Identification Information
AA Revision BIOS Revision Notes
E93812-300 TCIBX10H.86A.0032 1,2
E93812-301 TCIBX10H.86A.0035 1,2
E93812-302 TCIBX10H.86A.0037 1,2
E96351-300 TCIBX10H.86A.0032 1,2
E96351-301 TCIBX10H.86A.0035 1,2
E96351-302 TCIBX10H.86A.0037 1,2
Notes:
1. The AA number is found on a small label on the component side of the board.
2. The Intel®H55 Express Chipset used on this AA revision consists of the following component:
Device Stepping S-Spec Numbers
82H55 Platform Controller Hub (PCH) B3 SLGZX

6 Intel Desktop Board DH55PJ Specification Update
Summary of Changes
The following table indicates the Specification Changes, Errata, Specification
Clarifications, or Documentation Changes that apply to the Intel®Desktop Board
DH55PJ. Intel intends to fix some of the errata in a future revision of the desktop
board, and to account for the other outstanding issues through documentation or
specification changes as noted.
The following notations are used in the table:
Doc: Document change or update that will be implemented.
Plan Fix: This erratum may be fixed in a future revision of the desktop board, driver, or BIOS.
Fixed: This erratum has been previously fixed.
No Fix: There are no plans to fix this erratum.
Shaded: This erratum is either new or modified from the previous version of the document.
No. Plans Specification Changes
1 Doc Updated Section 2.2.2.1, Section 2.2.2.2, and Section 2.2.2.6 of the Technical
Product Specification as shown in the Specification Changes Section below.
2 Doc Corrected the number of Conventional PCI connectors in Section 2.2.2.2 of this
Specification Update from three to one.
No. Plans Errata
There are no characterized erratum for this product
Specification Changes
The Specification Changes listed in this section apply to the Intel®Desktop Board
DH55PJ Technical Product Specification (Order Number E95284).
1. Updated Section 2.2.2.1 Signal Table for the Connectors and Headers,
Section 2.2.2.2 Add-in Card Connectors, and Section 2.2.2.6 Front Panel USB
Headers of the Intel Desktop Board DH55PJ Technical Product Specification as
shown below.
2.2.2.1 Signal Tables for the Connectors and Headers
Table 1. Front Panel USB Header 2
Pin Signal Name Pin Signal Name
1 +5 VDC 2 +5 VDC
3 D−4 D−
5 D+ 6 D+
7 Ground 8 Ground
9 KEY (no pin) 10 LED#

Intel Desktop Board DH55PJ Specification Update 7
2.2.2.2 Add-in Card Connectors
The board has the following add-in card connectors:
•One PCI Express 2.0 x16: this connector supports simultaneous transfer speeds of
up to 8 GB/s of peak bandwidth per direction.
•Two PCI Express 2.0 x1: each of these connectors support simultaneous transfer
speeds of up to 250 MB/s (2.5 GT/s) of peak bandwidth per direction.
•Three Conventional PCI (rev 2.3 compliant) connectors.
2.2.2.6 Front Panel USB Headers
Figure 12 is a connection diagram for the front panel USB headers.
NOTES
•The +5 V DC power on the USB headers is fused.
•Use only a front panel USB connector that conforms to the USB 2.0 specification for
high-speed USB devices.
•USB Header 2 (FP USB 2) has Pin 10 routed to the HDD LED to support specific
USB SSD devices. Connecting any device to this header, that has any connection to
Pin 10, may cause the HDD LED to behave erratically or stay on continuously.
Figure 1. Connection Diagram for Front Panel USB Headers
Figure 2. Connection Diagram for Front Panel USB Header 2

8 Intel Desktop Board DH55PJ Specification Update
2. Corrected the number of Conventional PCI connectors in Section 2.2.2.2 of this
Specification Update from three to one.
2.2.2.2 Add-in Card Connectors
The board has the following add-in card connectors:
•One PCI Express 2.0 x16: this connector supports simultaneous transfer speeds of
up to 8 GB/s of peak bandwidth per direction.
•Two PCI Express 2.0 x1: each of these connectors support simultaneous transfer
speeds of up to 250 MB/s (2.5 GT/s) of peak bandwidth per direction.
•One Conventional PCI (rev 2.3 compliant) connectors.
