Intel i875P User manual

TRADEMARK
All products and company names are trademarks or registered
trademarks of their respective holders.
These specifications are subject to change without notice.
Manual Revision 2.0
May 29, 2003
User’User’
User’User’
User’ss
ss
s
ManualManual
ManualManual
Manual
IntelIntel
IntelIntel
Intel i875Pi875P
i875Pi875P
i875P mainboardmainboard
mainboardmainboard
mainboard
for Intel Socket 478 processorfor Intel Socket 478 processor
for Intel Socket 478 processorfor Intel Socket 478 processor
for Intel Socket 478 processor
$ 2+) 

DISCLAIMER OF WARRANTIES:
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE
DESCRIPTION ON THE FACE OF THE MANUFACTURER LIMITED
WARRANTY. THE MANUFACTURER EXPRESSLY EXCLUDES ALL
OTHER WARRANTIES, EXPRESS OR IMPLIED, REGARDING ITS
PRODUCTS; INCLUDING ANY IMPLIED WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR
NONINFRINGEMENT. THIS DISCLAIMER OF WARRANTIES SHALL
APPLY TO THE EXTENT ALLOWED UNDER LOCAL LAWS IN THE
COUNTRY PURCHASED IN WHICH LOCAL LAWS DO NOT ALLOW
OR LIMIT THE EXCLUSION OF THE IMPLIED WARRANTIES.

80 Port Frequently Asked Questions
Below is a list of some basic POST Codes possible problems and solutions. For
more detailed information about POST Codes refer to Appendix D in this manual.
POST CODE Problem Soluti on
FFh or CFh 1.BIOS chip inserted
incorrectly
2. Incorrect BIOS update
version
3. Mainboard problem
4. dd-on card inserted
incorrectly.
1. Reinsert the BIOS
chip
2. Download the correct
BIOS version update
from the manufacturer's
Web site.
3. Replace mainboard
4. Remove and replace the
add-on card
C1h - C5h 1. Memory module
inserted incorrectly
2. Memory compatibility
problem
3. Memory module
damaged
1. Reinsert memory
module
2. Replace memory
with correct type
3. Replace memory
module
2Dh 1. Error occured in VG
BIOS
2. VG card inserted
incorrectly
1. Replace VG card
2. Reinsert the VG
card
26h Overclock error Clear CMOS or press the insert
key to power on the system
07h - 12h 1. Init keyboard
controller error
2. RTC error
1. Ensure that the keyboard and
mouse are connected
correctly.
2. Replace the RTC battery.
Initial Keyboard

Table of Contents
Section 1 Introduction
Package Contents ...................................................... 1-1
Overview
Intel Pentium 4 Processors......................................... 1-2
Chipset Components.................................................. 1-2
Accelerated Graphics Port ......................................... 1-3
Ultra ATA66/100 ........................................................ 1-3
Hardware Monitoring................................................. 1-3
LAN (Optional) .......................................................... 1-3
Serial ATA .................................................................. 1-4
Mainboard Form-Factor ............................................. 1-5
I/O Shield Connector.................................................. 1-6
Power-On/Off (Remote).............................................. 1-6
System Block Diagram ............................................... 1-7
Section 2 Features
Mainboard Features ................................................... 2-1
Section 3 Installation
Mainboard Layout ..................................................... 3-2
Easy Installation Procedure
CPU Installation ......................................................... 3-3
Jumper Settings.......................................................... 3-5
System Memory Configuration .................................. 3-6
Expansion slots .......................................................... 3-9
Device Connectors..................................................... 3-11
External Modem Ring-in Power ON and
Keyboard Power ON Function (KBPO) ..................... 3-17
STR (Suspend To RAM) Function .......................... 3-18
Supports AGP Card 3.3V Protection .......................... 3-19
Page

Section 4 Award BIOS Setup
Main Menu ................................................................ 4- 1
Standard CMOS Setup ............................................... 4- 2
Advanced BIOS Features .......................................... 4- 3
Advanced Chipset Features ...................................... 4- 6
Integrated Peripherals ................................................ 4- 8
Power Management Setup ......................................... 4-16
PNP/PCI Configuration Setup.................................... 4-20
PC Health Status ........................................................ 4-22
Power BIOS Features ................................................. 4-24
Defaults Menu ........................................................... 4-28
Supervisor/User Password Setting ............................ 4-29
Exit Selecting .............................................................. 4-30
Section 5 Driver Installation
Easy Driver Installation.............................................. 5-1
C-Media Audio Configuration Brief Guide ................ 5-2
Appendix Appendix A
Update Your System BIOS ......................................... A-1
Appendix B
EEPROM BIOS Remover ........................................... B-1
Appendix C
GHOST 7 Quick Users Guide (Optional) ................... C-1
Appendix D
POST Codes .............................................................. D-1

Page Left Blank

Introduction
Page 1-1
B
A
C
D
USERS
MANUAL
E
or
G
F
I
J
Section 1
INTRODUCTION
Package Contents
Contents
A. Mainboard
B. Users manuals
C. Floppy disk drive cable
D. Hard drive cable or round cable
E. CD and diskette (drivers and
utilities
F. I/O Shield
Deluxe Pack Items
G. Game port cable
H. S-ATA data and power cable
Other Optional Items
I. Extra USB2.0 port cable
J. S/PDIF Module
H
If you need the other optional item,
please contact your dealer for
assistance.

Introduction
Page 1-2
Intel®Pentium®4 processors
The Intel Pentium 4 processor, Intel's most advanced, most powerful processor for
desktop PCs and entry-level workstations, is based on Intel NetBurstTM
microarchitecture. The Pentium 4 processor is designed to deliver performance
across applications and usages where end-users can truly appreciate and experience
the performance. These applications include Internet audio and streaming video,
image processing, video content creation, speech, 3D, CAD, games, multimedia, and
multi-tasking user environments. The Pentium 4 processor delivers this world-class
performance for consumer enthusiasts and business professional desktop PC users
as well as for entry-level workstation users.
Intel adds support for Hyper-Threading Technology to the Pentium 4 processor
family. HT Technology allows a single, physical Pentium 4 processor to function as
two logical processor for next generation multi threaded application.
For more information about all the new features the Pentium 4 delivers check out
the Intel website at http://www.intel.com
Chipset Components
This board is designed with Intel® 875P (Canterwood chipset. The Intel® 875P chipset
consists of the Memory Controller Hub (MCH , and the I/O Controller Hub (ICH5/R .


Memory Controller Hub (MCH)
The MCH provides the interconnect between the AGP, DDR SDRAM and the
system logic. It integrates:
- Supports for single processor with a data transfer rate of 533/800MHz.
- Supports dual channel of 333/400 DDR SDRAM up to 4GB.
- 8X/4X 1.5V AGP interface (Only support 1.5V on AGP interface .
- Downstream hub link for access to the ICH5/R.


I/O Controller Hub (ICH5/R)
The I/O controller Hub provides the I/O subsystem with access to the rest of the
system. Additionally, it integrates many I/O functions:
- Upstream hub link for access to the MCH

Introduction
Page 1-3
- 2-Channel Ultra ATA/100 Bus Master IDE controller
- USB controller
- SMBus controller
- LPC / Flash BIOS interface
- PCI 2.3 interface
- Integrated System Management Controller
Accelerated Graphics Port (AGP)
The AGP slot on the board is compliant with the new AGP 3.0 specification. This
new specification enhances the functionality of the original AGP specification by
allowing 8X data transfers ( 8 data samples per clock resulting in maximum band-
width of 2.1GB/s. In addition, it defines 1.5 volt power supply operation. Complying
with this specification, this board supports external AGP-8X/4X cards with Fast
Write Transactions. Only 1.5V AGP cards are supported.
Ultra ATA/66/100
The ICH5/R provides an Ultra ATA/66/100 Bus Master IDE controller. This controller
supports Ultra ATA/66/100 protocols which are ideal to support demanding applica-
tions such as real-time video, multimedia, and a high performance operating system.
A new IDE cable is required for Ultra ATA/66/100; this cable is an 80-pin conductor
cable which is backward compatible with ATA/33 connectors.
Hardware Monitoring
Hardware monitoring enables you to monitor various aspects of the system operation
and status. The features include CPU temperature, voltage and fan speed in RPMs.
LAN (Optional)
This mainboard is optionally mounted with LAN chip. It allows the mainboard to
connect to a local area network by means of a network hub.

Introduction
Page 1-4
Serial ATA
The evolutionary serial ATA interface replaces the standard parallel ATA physical
storage interface. The serial ATA specification provides scalability and allows
future enhancements to the computing platform. Serial technology overcomes
performance limits of parallel interface architecture, meeting the escalating need for
faster data throughput in servers and storage devices.
Serial ATA is completely software compatible with parallel ATA, requiring no
modification to your operating system. The serial ATA interface cable requires lower
voltages and uses smaller cable connectors, providing ease of installation. You can
easily upgrade storage devices that are compatible with the serial ATA interface
specification.

Introduction
Page 1-5
Mainboard Form-Factor
This board is designed with ATX form factor - the latest industry standard for
chassis design. The ATX form factor is essentially a Baby-AT baseboard rotated
90 degrees within the chassis enclosure and a new mounting configuration for
the power supply. With these changes the processor is relocated away from the
expansion slots, allowing them all to hold full length add-in cards. ATX defines a
double height aperture to the rear of the chassis which can be used to host a
wide range of onboard I/O. Only the size and position of this aperture is defined,
allowing PC manufacturers to add new I/O features (e.g.; TV input, TV output,
joystick, modem, LAN, audio, etc. to systems. This will help systems integrators
differentiate their products in the marketplace, and better meet your needs.
 By integrating more I/O down onto the board and better positioning the hard
drive and floppy connectors material cost of cables and add-in cards is
reduced.
 By reducing the number of cables and components in the system, manufac-
turing time and inventory holding costs are reduced and reliability will
increase.
 By using an optimized power supply, it's possible to reduce cooling costs
and lower acoustical noise. An ATX power supply, which has a side-
mounted fan, allows direct cooling of the processor and add-in cards making
a secondary fan or active heatsink unnecessary in most system applications.
PCI slots
Expandable I/O
Figure 2: Summary of ATX chassis features
CPU Socket
Single chassis
fan for system
ATX
Power
Supply
ATX power connector
Floppy
connectors
AGP slot
3 1/2-inch
Bay
5 1/4-inch
Bay
ATX 12V power
connector
IDE connectors

Introduction
Page 1-6
Power-On/Off (Remote)
This board has a 20-pin ATX and a 4-pin ATX12V power supply connector (Figure
4 . For power supplies that support the Remote On/Off feature, this should be
connected to the mainboard front panel PW_ON connector for the computer power
On/Off button.
The board has been designed with Soft Off" function. You can turn off the system
in two ways: by pressing the front panel power On/Off button or using the "Soft
Off" function (incorporated in the mainboards onboard circuit controller that can
be controlled by an operating system such as Windows®XP/ME/2000/98.
Note: For maintaining the DDR SDRAM power during STR (ACP S3) function, it is
strongly recommended to use power supplies that have a +5VSB current of (>
=) 2A. Please check the 5VSBs specification that has been printed on the
power supplys outer case.
Note: The board requires a minimum of 250 Watt power supply to operate. Your
system configuration (amount of memory, add-in cards, peripherals, etc.) may
exceed the minimum power requirement but to ensure that adequate power is
provided, use a 300 Watt (or greater) power supply. Also your power supply
must support 4-pin ATX 12V connector.
I/O Shield Connector
The board is equipped with an I/O back panel (Figure 3 . Ensure that your computer
case has the appropriate I/O cutout.
Figure 3: I/O ports
PW-ON
Case (chassis) Power ON/OFF button (PW-ON)
POWER SUPPLY
12V 4-pin
20-pin
Figure 4: Simple ATX power ON/OFF co troller
COM1
Parallel Port
COM2
RJ-45 LAN
(Optional)
USB2.0
port
USB2.0
port
PS/2
Mou e
PS/2
Keyboard Mic-in/Center&Subwoofer (Pink)
Line-out/Front out (Green)
Line-in/Rear out (Blue)

Introduction
Page 1-7
Figure 5: System Block Diagram
System Block Diagram

Introduction
Page 1-8
Page Left Blank

.A=JKHAI
Page 2-1
Section 2
FEATURES
Mainboard Features
Processor
Socket 478 Intel® Pentium® 4 and Celeron processors from 1.7GHz up to
3.2 GHz
Supports the following System Bus and Memory Combination:
FSB533 / DDR333 (PC2700)
FSB800 / DDR333 (PC2700)*
FSB800 / DDR400 (PC3200)
* When configured to FSB800/DDR333, adaptive synchronization a igns to the
c osest FSB to memory c ock ratio, setting memory channe to 320MHz.
Supports Hyper-Threading Technology
To enable the Hyper-Threading Technology function on your computer
system requires ALL of the following platform components:
)CPU: An Intel® Pentium® 4 Processor with HT Technology.
)Chipset: An Intel® Chipset that supports HT Technology.
)BIOS: A BIOS that supports HT Technology and has it enabled.
)OS: An operating system that supports HT Technology.
Performance will vary depending on the specific hardware and software
you use. See <http://www.intel.com/info/hyperthreading> for information
including details on which processor support HT Technology.
Chipset
Intel 875P Chipset (875P ICH5R or ICH5)
Main Memory
Four 184-pin DDR DIMM sockets for PC2700/3200 (DDR-333/400) DIMMs
Supports ECC DIMMs
Supports 128-bit dual channel memory architecture
Supports up to 4GB memory size

.A=JKHAI
Page 2-2
BIOS
Flash EEPROM with Award BIOS
- ACPI v2.0 compliant
- S3 (Suspend to DRAM) sleep-state support
- SMBIOS (System Management BIOS) v2.2 compliant
- Supports Power failure recovery
- Able to wake the computer from specific states by LAN, Power switch,
PME#, RTC alarm, USB, PS2 KB, PS2 mouse, Modem Ring-in COM#1
Onboard PCI Devices
LAN --> Integrates 10/100Mps Fast Ethernet controller with Broadcom
BCM4401 LAN Chipset
Integrates 1Gbps Fast Ethernet controller with Broadcom
BCM5705/5788 LAN Chipset (for high-end model only)
IDE --> 2 ordinary IDE Port with PIO/Ultra DMA-33/66/100 for up to 4
devices
4 extra IDE Port by HPT374 with Ultra DMA-133 & IDE RAID
for up to 8 devices (Optional)
Legacy IO Controller
Winbond W83627HF LPC IO controller with floppy, printer, game, serial
and SIR interface
udio
Six channel audio with analog and digital output using CMI9739A AC97
CODEC
- AC97 v2.2 compliant
- In 2-CH mode, supports Line-In (Blue), Line-Out (Green) and Mic-In
(Pink) at rear panel
- In 6-CH mode, supports Rear speaker-out (Blue), Front speaker-out (Green),
Center&Subwoofer speaker-out (Pink) at rear panel
- Supports CD-In, Aux-In and S/PDIF-In/out interface
- Supports Line-out and Mic-In for front panel
(Optional)

.A=JKHAI
Page 2-3
Peripheral Interfaces
PS/2 keyboard and mouse ports (at rear panel)
One Parallel (printer) port (at rear panel)
Two Serial ports (at rear panel)
Eight USB2.0 ports (4 at rear panel)
One RJ45 LAN connector (at rear panel)(Optional)
One game port
One floppy drive interface
Two IDE interface
Four extra IDE&RAID interface (Optional)
Two Serial ATA interface
Three Fan connectors
Front Panel Controller
Supports Reset & Soft-Off switches
Supports HDD & Power LEDs
Supports PC speaker
Expansion Slots
One AGP slots supporting 1.5v 4X/8X AGP&ADD card
- AGP v3.0 compliant
Five PCI slots with Bus Master support
- PCI v2.3 compliant
Other Features
Magic Health  a H/W monitoring software utility, for voltages, tempera-
tures and fan-speeds sensing
EZ Boot  An easy way let end-user can choose to boot from hard drive,
CD-ROM, floppy, 
Supports exclusive KBPO (Keyboard Power On) function
Excellent Overclocking capabilities through
- subtle voltage tuning for CPU, Memory, AGP

.A=JKHAI
Page 2-4
- subtle frequency tuning on FSB
- Supports complete Asynchronous FSB/Memory and Asynchronous
FSB/AGP, PCI scheme for overclocking
Supports AGP card 3.3V Protection
P80P for system debugging
Form Factor
305mm x 245 mm ATX size

Installation
Page 3-1
Section 3
INSTALLATION

Installation
Page 3-2
Mainboard Layout
