Intel DP43BF Reference guide

ATX Form Factor
Intel®Desktop Boards DP43BF
and DP43BFL Classic Series
Intel Matrix Storage Technology can also
improve the performance of disk-intensive
retrieval applications such as editing home
videos. By combining two to six drives in a
RAID 0 conguration, data can be accessed
on each drive simultaneously, speeding up
response time on data-intensive applications.
Intel® Matrix Storage Technology
(DP43BF only)
The Intel Desktop Board DP43BF features
ICH10R and Intel® Matrix Storage Technology
that supports RAID 0, 1, 5, and 10. Intel
Matrix Storage Technology provides new
levels of protection, performance, and
expandability for desktop platforms.
Whether using one or multiple hard drives,
users can take advantage of enhanced
performance and lower power consump-
tion. When using more than one drive, the
user has additional protection against data
loss in the event of hard drive failure.
Valuable digital memories are protected
against a hard drive failure when the
system is congured for any one of three
fault-tolerant RAID levels: RAID 1, 5, or 10.
By seamlessly storing copies of data on
one or more additional hard drives, any
hard drive can fail without data loss or
system downtime.
The ideal platform for a discrete
graphics system with performance
and reliability built in
The Intel® Desktop Boards DP43BF and
DP43BFL support the Intel® Core™2 Quad**,
Intel® Core™2 Duo, Intel® Pentium®, and Intel®
Celeron® processors in the LGA775 package.
Both boards support dual-channel DDR3
with four connectors for 1333 / 1066 MHz
memory support (8 GB1max). As ATX form
factor discrete graphics desktop boards,
the Intel Desktop Boards DP43BF and
DP43BFL offer abundant expansion capa-
bilities including one PCI Express* 2.0 x16
graphics connector, two PCI Express* 2.0 x1
connectors, two IEEE 1394a ports (DP43BF
only), one eSATA port (DP43BF only), and
four PCI connectors. Premium features such
as Intel® Matrix Storage Technology (DP43BF
only), Intel® High Denition Audio2(Intel® HD
Audio) with 7.1 + 2-channel multistreaming
and an S/PDIF audio port enhance applica-
tion performance, system reliability, and the
digital media experience.
PRODUCT BRIEF
Intel® Desktop Boards DP43BF
and DP43BFL Classic Series
DP43BF board shown
1 2 3 4
Protection via RAID 5
Performance via RAID 0
Important Data / Applications on RAID 5
• Operating system / business applications
• Personal media, photos, and videos
• Financial records
Non-Critical Data / Applications on RAID 0
• Games
• Pagefile / scratch disks
• Digital media workspace
MATRIX RAID ON FOUR HARD DRIVES

2
Intel® Desktop Boards DP43BF and DP43BFL
Classic Series
The boxed Intel® Desktop Boards DP43BF and DP43BFL solutions include:
• ATX 2.2 compliant I/O shield
• SATA and ATA 100 / 66 cables
• Board and back panel I/O layout labels
• Quick reference guide
• Intel® Express Installer driver and software CD
• Microsoft* Windows* 7 Premium and Windows Vista* Premium WHQL certified
The takeaway software included with the Intel® Desktop Boards DP43BF and
DP43BFL works best for your everyday computing.
CAPABILITY SOFTWARE INCLUDED:
Productivity • Intel® Integrator Assistant (Internet Download)
• Laplink* PCmover* Express
Entertainment • DivX* for Windows*
Antivirus • Norton Internet Security*

3
9.6” (24.38 cm)
11.6” (29.46 cm)
6
810
1
2
3
4
13
5
11
7
9
Intel® Desktop Boards DP43BF and DP43BFL
Classic Series
Features and Benets
7Ten-channel Intel® High Denition
Audio2: Audio subsystem with ve
analog audio outputs and one optical
S/PDIF digital audio output (7.1 +
2 independent multistreaming).
8PCI Express* 2.0 x16 graphics
connector: Delivers up to 8 GB/s
bandwidth.
9Two PCI Express* x1 connectors
10 Four PCI connectors
11 Twelve Hi-Speed USB 2.0 ports:
Six back panel ports and six additional
ports via three internal headers.
12 Two IEEE 1394a ports (DP43BF):
One external port and one additional
port via internal header.
13 ATX form factor
12
DP43BF board shown
1Supports the Intel® Core™2 Quad**,
Intel® Core™2 Duo, Intel® Pentium®,
and Intel® Celeron® processors in the
LGA775 package.
2Intel® P43 Express Chipset with
ICH10R (DP43BF) or ICH10 (DP43BFL)
3Dual-channel DDR3 with four
connectors for 1333 / 1066 MHz
memory support (8 GB1max): Four
DIMM connectors designed to support
the latest DDR3 technology.
4Five SATA ports (3.0 Gb/s) with
Intel® Matrix Storage Technology
(DP43BF): Facilitate high-speed
storage and data transfers at up
to 3.0 Gb/s for each of ve ports.
Supports RAID 0, 1, 5, and 10.
5One eSATA port (3.0 Gb/s) (DP43BF):
For high-speed external storage.
6Integrated 10/100/1000 Network
Connection

PROCESSOR
Processor Support
•Intel®Core™2Quad**processorsintheLGA775
 package
•Intel®Core™2DuoprocessorsintheLGA775
 package
•Intel®Pentium®processorsintheLGA775package
•Intel®Celeron®processorsintheLGA775package
•SupportsIntel®64architecture3
CHIPSET
Intel® P43 Express Chipset
•Intel®82P43GraphicsandMemoryControllerHub
 (GMCH)
•Intel®82801JRI/OControllerHub(ICH10R)(DP43BF)
 Intel®82801JBI/OControllerHub(ICH10)(DP43BFL)
•Intel®FastMemoryAccess
Intel® I/O Controller Hub (ICH)
•FiveSATAports(3.0Gb/s)
•OneeSATAport(3.0Gb/s)(DP43BF)
•Integrated10/100/1000NetworkConnection
•TwelveHi-SpeedUSB2.0ports(sixbackpanel
 portsandsixadditionalportsviathreeinternal
 headers)
System BIOS
•16MbFlashEEPROMwithIntel®Platform
 InnovationFrameworkforEFIPlugandPlay,
 IDEdriveauto-configure
•Advancedconfigurationandpowerinterface
 V2.0b,DMI2.0,multilingualsupport
•SerialPeripheralInterface(SPI)Flash
For ordering information, visit www.intel.com
For the most current product information, visit
http://developer.intel.com/products/desktop/motherboard/
1 System resources and hardware (such as PCI and PCI Express*) require physical memory address locations that can reduce available addressable system memory. This could result in a reduction of as much
as 1 GB or more of physical addressable memory being available to the operating system and applications, depending on the system conguration and operating system.
2 Intel® High Denition Audio requires a system with an appropriate Intel® chipset and a motherboard with an appropriate codec and the necessary drivers installed. System sound quality will vary depending
on actual implementation, controller, codec, drivers, and speakers. For more information about Intel® HD Audio, refer to www.intel.com/design/chipsets/hdaudio.htm
3 64-bit computing on Intel® architecture requires a computer system with a processor, chipset, BIOS, operating system, device drivers, and applications enabled for Intel® 64 architecture. Processors will not
operate (including 32-bit operation) without an Intel 64 architecture-enabled BIOS. Performance will vary depending on your hardware and software congurations. See http://developer.intel.com/technology/
intel64/index.htm for more information.
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS
IS GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY
EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY,
OR INFRINGEMENT OF ANY PATENT, COPYRIGHT, OR OTHER INTELLECTUAL PROPERTY RIGHT.
Intel products are not intended for use in medical, life-saving, or life-sustaining applications. Intel may make changes to specications and product descriptions at any time, without notice.
All products, dates, and gures specied are preliminary based on current expectations, and are subject to change without notice. Availability in different channels may vary.
Actual Intel® Desktop Board may differ from the image shown.
Intel, the Intel logo, Intel Core, Pentium, and Celeron are trademarks of Intel Corporation in the U.S. and other countries.
* Other names and brands may be claimed as the property of others.
** Supports 95 W Thermal Design Power, Intel® Core™2 Quad Processors with 1333 / 1066 MHz system bus. For information, visit http://processormatch.intel.com
Copyright © 2010 Intel Corporation. All rights reserved. 0210/FZ/MS/PDF 323353-001US
Intel® Desktop Boards DP43BF and DP43BFL
Classic Series
Technical Specications
SYSTEM MEMORY
Memory Capacity
•Four240-pinDIMMconnectorssupportingupto
 fourdouble-sidedDIMMs(8GB1max)
Memory Types
•DDR31333/1066SDRAMmemorysupport
•Non-ECCMemory
Memory Modes
•Dual-orsingle-channeloperationsupport
Memory Voltage
•1.35Vto1.65V
Hardware Management Features
•Processorfanspeedcontrol
•Systemchassisfanspeedcontrol
•Voltageandtemperaturesensing
•Fansensorinputsusedtomonitorfanactivity
•PowermanagementsupportforACPI1.0b
Expansion Capabilities
•FourPCIbusadd-incardconnectors
•TwoPCIExpress*x1busadd-incardconnectors
•OnePCIExpress2.0x16graphicsconnector
Headers
•Oneserialportheader
•TwoIEEE1394aports(oneexternalportand
 oneadditionalportviainternalheader)(DP43BF)
Audio
•Ten-channelIntel®HighDefinitionAudio2codec
JUMPERS AND FRONT PANEL CONNECTORS
Jumpers
•Singleconfigurationjumperdesign
•JumperaccessforBIOSmaintenancemode
Front-Panel Connectors
•Reset,HDDLED,PowerLEDs,poweron/off
•Front-panelHi-SpeedUSB2.0headers
•Front-panelaudioheader
MECHANICAL
Board Style
•ATX2.2-compliant
Board Size
•9.6”x11.6”(24.38cmx29.46cm)
Baseboard Power Requirements
•ATX12V
ENVIRONMENT
Operating Temperature
•0°Cto+55°C
Storage Temperature
•-20°Cto+70°C
REGULATIONS AND SAFETY STANDARDS
United States and Canada
 CSA/UL60950-1,FirstEdition(BinationalStandard)
Europe
 (LowVoltageDirective2006/95/EC)
 EN60950-1
International
 IEC60950-1
EMC Regulations(testedinrepresentativechassis)
United States
 FCC47CFRPart15,SubpartB
Canada
 ICES-003ClassB
Europe
 (EMCDirective2004/108/EC)
 EN55022andEN55024
Australia / New Zealand
 EN55022ClassB
Japan
 VCCIV-3,V-4ClassB
South Korea
 KN-22andKN-24
Taiwan
 CNS13438ClassB
International
 CISPR22ClassB
Environmental Compliance
Europe
 EuropeRoHS(Directive2002/95/EC)
China
 ChinaRoHS(MIIOrder#39)
