Intel® Desktop Board D201GLY2
Product Guide
Order Number: E17767-001

Revision History
Revision Revision History Date
-001 First release of the Intel®Desktop Board D201GLY2
Product Guide
September 2007
If an FCC declaration of conformity marking is present on the board, the following statement applies:
FCC Declaration of Conformity
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
For questions related to the EMC performance of this product, contact:
Intel Corporation, 5200 N.E. Elam Young Parkway, Hillsboro, OR 97124,
1-800-628-8686
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the receiver.
•Connect the equipment to an outlet on a circuit other than the one to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications to the equipment not expressly approved by Intel Corporation could void the
user’s authority to operate the equipment.
Tested to comply with FCC standards for home or office use.
Canadian Department of Communications Compliance Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set
out in the Radio Interference Regulations of the Canadian Department of Communications.
Le présent appareil numerique német pas de bruits radioélectriques dépassant les limites applicables aux
appareils numériques de la classe B prescrites dans le Réglement sur le broullage radioélectrique édicté par
le ministére des Communications du Canada.
Disclaimer
Information in this document is provided in connection with Intel®products. No license, express or implied,
by estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided
in Intel’s Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel
disclaims any express or implied warranty, relating to sale and/or use of Intel products including liability or
warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent,
copyright or other intellectual property right. Intel products are not intended for use in medical, life saving,
or life sustaining applications. Intel may make changes to specifications and product descriptions at any
time, without notice.
Desktop Board D201GLY2 may contain design defects or errors known as errata which may cause the
product to deviate from published specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing
your product order.
Copies of documents which have an ordering number and are referenced in this document, or other Intel
literature, may be obtained from Intel Corporation by going to the World Wide Web site at:
http://www.intel.com/ or by calling 1-800-548-4725.
Intel, the Intel logo, and Celeron are trademarks of Intel Corporation in the United States and other
countries.
* Other names and brands may be claimed as the property of others.
Copyright © 2007, Intel Corporation. All rights reserved.

iii
Preface
This Product Guide gives information about board layout, component installation, and
regulatory requirements for Intel®Desktop Board D201GLY2.
Intended Audience
The Product Guide is intended for technically qualified personnel. It is not intended for
general audiences.
Intended Uses
All Intel®Desktop Boards are evaluated as Information Technology Equipment (I.T.E.)
for use in personal computers (PC) for installation in homes, offices, schools, computer
rooms, and similar locations. The suitability of this product for other PC or embedded
non-PC applications or other environments, such as medical, industrial, alarm systems,
test equipment, etc. may not be supported without further evaluation by Intel.
Document Organization
The chapters in this Product Guide are arranged as follows:
1 Desktop Board Features: a summary of product features
2 Installing and Replacing Desktop Board Components: instructions on how to install
the Desktop Board and other hardware components
3 Updating the BIOS: a description of how to update the BIOS
A BIOS Error Messages: information about BIOS error messages
B Regulatory Compliance: safety and EMC regulations and product certifications
Conventions
The following conventions are used in this manual:
CAUTION
Cautions warn the user about how to prevent damage to hardware or loss of data.
NOTE
Notes call attention to important information.

Intel Desktop Board D201GLY2 Product Guide
iv
Terminology
The table below gives descriptions to some common terms used in the product guide.
Term Description
GB Gigabyte (1,073,741,824 bytes)
GHz Gigahertz (one billion hertz)
KB Kilobyte (1024 bytes)
MB Megabyte (1,048,576 bytes)
Mbit Megabit (1,048,576 bits)
MHz Megahertz (one million hertz)
Box Contents
•Intel Desktop Board
•I/O shield
•One ATA-66/100 cable
•One Serial ATA (SATA) cable
•Quick Reference Guide
•Configuration and safety labels
•Intel®Express Installer driver CD-ROM

v
Contents
1Desktop Board Features
Supported Operating Systems..............................................................................10
Desktop Board Components.................................................................................11
Processor..........................................................................................................13
Main Memory.....................................................................................................13
Chipset.............................................................................................................14
Graphics Subsystem...........................................................................................14
Audio Subsystem ...............................................................................................14
Input/Output (I/O) Controller ..............................................................................15
LAN Subsystem .................................................................................................15
LAN Subsystem Software.............................................................................16
RJ-45 LAN Connector LEDs...........................................................................16
Hi-Speed USB 2.0 Support ..................................................................................17
Enhanced IDE Interface ......................................................................................17
Serial ATA.........................................................................................................17
Expandability.....................................................................................................17
BIOS................................................................................................................17
IDE Auto Configuration................................................................................18
PCI Auto Configuration ................................................................................18
Security Passwords.....................................................................................18
Power Management Features ...............................................................................18
ACPI.........................................................................................................19
Hardware Support ......................................................................................19
Power Connectors ...............................................................................19
Fan Headers .......................................................................................19
+5 V Standby Power Indicator LED ...............................................................19
LAN Wake Capabilities..........................................................................20
Wake from USB ..................................................................................21
Wake from PS/2 Keyboard/Mouse..........................................................21
PME# Wakeup Support ........................................................................21
Battery.............................................................................................................21
Real-Time Clock.................................................................................................21
2Installing and Replacing Desktop Board Components
Before You Begin ...............................................................................................23
Installation Precautions.......................................................................................24
Prevent Power Supply Overload ....................................................................24
Observe Safety and Regulatory Requirements.................................................24
Installing the I/O Shield ......................................................................................25
Installing and Removing the Desktop Board ...........................................................26
Installing and Removing Memory..........................................................................27
Installing DIMMs ........................................................................................27
Removing DIMMs........................................................................................29
Connecting the IDE Cable....................................................................................29
Connecting the Serial ATA (SATA) Cable................................................................31
Connecting Internal Headers................................................................................32
Installing a Front Panel Audio Solution...........................................................33
Connecting Hi-Speed USB 2.0 Headers ..........................................................34

Intel Desktop Board D201GLY2 Product Guide
vi
Connecting the Front Panel Header ...............................................................34
Connecting the Chassis Fan .................................................................................35
Connecting Supply Power Cables..........................................................................36
Setting the Desktop Board Jumpers ......................................................................37
Front Panel Audio Header/Jumper Block.........................................................37
BIOS Configuration Jumper..........................................................................38
Clearing Passwords.....................................................................................39
Replacing the Battery .........................................................................................40
3Updating the BIOS
Updating the BIOS with the Intel®Express BIOS Update Utility.................................45
Updating the BIOS with the Iflash Memory Update Utility.........................................45
Obtaining the BIOS Update File ....................................................................45
Updating the BIOS with the Iflash Memory Update Utility .................................46
Recovering the BIOS...................................................................................46
ABIOS Error Messages
BIOS Front-panel Power LED Codes ......................................................................47
BIOS Error Messages..........................................................................................47
BRegulatory Compliance
Safety Standards ...............................................................................................49
Place Battery Marking .................................................................................49
European Union Declaration of Conformity Statement..............................................50
Product Ecology Statements ................................................................................51
Recycling Considerations .............................................................................51
Lead-free 2LI/Pb-free 2LI Board ...................................................................54
Restriction of Hazardous Substances (RoHS) ..................................................55
European Union RoHS..........................................................................55
China RoHS ........................................................................................55
EMC Regulations ................................................................................................58
Ensure Electromagnetic Compatibility (EMC) Compliance..................................59
Product Certifications..........................................................................................60
Board-Level Certification Markings ................................................................60
Chassis and Component Certifications............................................................61

Contents
vii
Figures
1. Intel Desktop Board D201GLY2 Components ....................................................11
2. Back Panel Audio Connectors .........................................................................15
3. LAN Connector LEDs .....................................................................................16
4. Location of the Standby Power Indicator ..........................................................20
5. Installing the I/O Shield ................................................................................25
6. Desktop Board D201GLY2 Mounting Screw Holes ..............................................26
7. Use DDR2 DIMMs .........................................................................................27
8. Installing a DIMM .........................................................................................28
9. Connecting the IDE Cable ..............................................................................30
10. Connecting the Serial ATA Cable .....................................................................31
11. Internal Headers ..........................................................................................32
12. Location of the Chassis Fan Header .................................................................35
13. Connecting a 2 x 10 or 2 x 12 Power Supply Cable ............................................36
14. Desktop Board Jumpers.................................................................................37
15. Removing the Battery ...................................................................................44
16. Desktop Board D201GLY2 China RoHS Material Self Declaration Table..................57
Tables
1. Feature Summary.......................................................................................... 9
2. Desktop Boards D201GLY2 Components ..........................................................12
3. RJ-45 10/100 Ethernet LAN Connector LEDs.....................................................16
4. Front Panel Audio Header Signal Names...........................................................33
5. Hi-Speed USB 2.0 Header Signal Names ..........................................................34
6. Front Panel Header Signal Names ...................................................................34
7. Front Panel Audio Header/Jumper Block...........................................................38
8. Jumper Settings for the BIOS Setup Program Modes..........................................38
9. Front-panel Power LED Blink Codes .................................................................47
10. BIOS Error Messages ....................................................................................47
11. Safety Standards..........................................................................................49
12. Lead-Free Second Level Interconnect Marks .....................................................55
13. China RoHS Environmentally Friendly Use Period Mark .......................................56
14. EMC Regulations...........................................................................................58
15. Product Certification Markings ........................................................................60

Intel Desktop Board D201GLY2 Product Guide
viii

9
1 Desktop Board Features
This chapter briefly describes the main features of Intel®Desktop Board D201GLY2.
Table 1 summarizes the features of the Desktop Board.
Table 1. Feature Summary
Form Factor Mini-ITX (171.45 millimeters [6.75 inches] x 171.45 millimeters
[6.75 inches])
Processor Intel®Celeron®processor
Main Memory •One 240-pin SDRAM Dual Inline Memory Module (DIMM) socket
•533/400 MHz single channel DDR2 SDRAM interface
•Supports up to 1 GB of system memory
Chipset •SiS662* Graphics and Memory Controller (Northbridge)
•SiS964* I/O Controller (Southbridge)
Graphics SiS Integrated Mirage* 1 Graphics Engine
Audio •ADI AD1888 Audio Codec
•Support for AC’97 two-channel audio
Expansion
Capabilities
One PCI bus add-in card connector
Peripheral
Interfaces
•Six USB 2.0 ports
―Two ports routed to the back panel
―Four ports routed to two USB headers
•One IDE interface with ATA-100/66 support (two devices)
•Two Serial ATA (1.5 Gb/s) interfaces
•One VGA connector
•One parallel port
•One serial port
•PS/2* keyboard and mouse ports
BIOS •Intel®BIOS
•Support for SMBIOS
•Intel®Rapid BIOS Boot
•Intel®Express BIOS Update
LAN Support •10/100 Mb/s LAN Subsystem
Power
Management
•Support for Advanced Configuration and Power Interface (ACPI); no
support for S3
•Wake on USB, PCI, PS/2, LAN, and front panel

Intel Desktop Board D201GLY2 Product Guide
10
Related Links:
For more information about Desktop Board D201GLY2, including the Technical Product
Specification (TPS), BIOS updates, and device drivers, go to:
http://support.intel.com/support/motherboards/desktop/
Supported Operating Systems
The Desktop Board supports the following operating systems:
•Microsoft Windows Vista* Starter Edition
•Microsoft Windows* XP Professional
•Microsoft Windows XP Home
•Microsoft Windows XP Starter Edition

Desktop Board Features
11
Desktop Board Components
Figure 1 shows the location of the major components on Desktop Board D201GLY2.
Figure 1. Intel Desktop Board D201GLY2 Components

Intel Desktop Board D201GLY2 Product Guide
12
Table 2. Desktop Boards D201GLY2 Components
Label Description
A PCI bus add-in card connector
B Hi-speed USB 2.0 headers
C Front panel audio header
D Back panel connectors
E Rear fan (3-pin) header
F 12 V processor core voltage connector (2 x 2)
G Main power connector (2 x 10)
H Processor
I DDR 2 DIMM connector
J IDE connector
K Serial ATA connectors
L Front panel header
M Battery
N BIOS configuration jumper
Related Links:
Go to the following links for more information about:
•Desktop Board D201GLY2 http://www.intel.com/design/motherbd
http://support.intel.com/support/motherboards/desktop
•Audio software and utilities http://www.intel.com/design/motherbd
•LAN software and drivers http://www.intel.com/design/motherbd

Desktop Board Features
13
Processor
CAUTION
Failure to use an appropriate power supply and/or not connecting the 12 V (2 x 2)
power connector to the Desktop Board may result in damage to the board, or the
system may not function properly.
Desktop Board D201GLY2 includes an Intel Celeron processor. The processor is
soldered to the Desktop Board and is not customer upgradeable.
Main Memory
NOTE
To be fully compliant with all applicable Intel®SDRAM memory specifications, the
board should be populated with DIMMs that support the Serial Presence Detect (SPD)
data structure. If your memory modules do not support SPD, you will see a
notification to this effect on the screen at power up. The BIOS will attempt to
configure the memory controller for normal operation.
The Desktop Board has one 240-pin Double Data Rate 2 (DDR2) SDRAM Dual Inline
Memory Module (DIMM) connector with gold-plated contacts. It supports:
•533/400 MHz unbuffered, non-registered DDR2 DIMMs
•Serial Presence Detect (SPD) memory only
•Non-ECC memory
•Up to 1 GB of system memory utilizing 512 Mb or 1 Gb technology
Related Links:
Go to the following links or pages for more information about:
•The latest list of tested memory,
http://support.intel.com/support/motherboards/desktop/
•SDRAM specifications, http://www.intel.com/technology/memory/
•Installing memory, page 27 in Chapter 2

Intel Desktop Board D201GLY2 Product Guide
14
Chipset
The chipset used on Desktop Board D201GLY2 consists of the following devices:
•SiS662 Graphics and Memory Controller (Northbridge)
•SiS964 I/O Controller (Southbridge)
Graphics Subsystem
The Desktop Board D201GLY2 graphics subsystem features the SiS* Mirage* 1
Graphics Engine which is integrated in the SiS662 Graphics and Memory Controller.
Audio Subsystem
Desktop Board D201GLY2 includes a 2-channel audio subsystem based on the
following devices:
•SiS964 I/O Controller
•ADI AD1888 audio codec
The subsystem features:
•S/N (signal-to-noise) ratio: 90 dB
•Microphone input that supports dynamic, condenser, and electret microphones
The subsystem supports the following audio interfaces:
•Front panel audio header, including pins for:
―Line out
―Microphone in
•Back panel audio connectors (see Figure 2):
―Line In
―Line Out
―Mic In

Desktop Board Features
15
Item Description
A Line In
B Line Out
C Mic In
Figure 2. Back Panel Audio Connectors
NOTE
The back panel audio line out connector is designed to power headphones or amplified
speakers only. Poor audio quality occurs if passive (non-amplified) speakers are
connected to this output.
Related Links:
Go to the following link or pages for more information about:
•Audio drivers and utilities http://support.intel.com/support/motherboards/desktop/
•Installing a front panel audio solution (page 33)
Input/Output (I/O) Controller
The super I/O controller features the following:
•One serial port
•One parallel port with Extended Capabilities Port (ECP) and Enhanced Parallel Port
(EPP) support
•Serial IRQ interface compatible with serialized IRQ support for PCI systems
•PS/2-style mouse and keyboard interfaces
•Intelligent power management, including a programmable wake up event interface
•PCI power management support
LAN Subsystem
The LAN provides the following functions:
•10/100 Mb/s Ethernet LAN
•Support for RJ-45 connector with status indicator LEDs
•Programmable transit threshold
•Configurable EEPROM that contains the MAC address

Intel Desktop Board D201GLY2 Product Guide
16
LAN Subsystem Software
For LAN software and drivers, refer to the D201GLY2 link on Intel’s World Wide Web
site at:
http://support.intel.com/support/motherboards/desktop
RJ-45 LAN Connector LEDs
Two LEDs are built into the RJ-45 LAN connector located on the back panel (see
Figure 3).
Figure 3. LAN Connector LEDs
Table 3 describes the LED states when the board is powered up and the
10/100 Ethernet LAN subsystem is operating.
Table 3. RJ-45 10/100 Ethernet LAN Connector LEDs
LED LED State Indicates
Off LAN link is not establishedA (Green)
On LAN link is established
Blinking LAN activity is occurring
Off 10 Mbits/s data rate is selectedB (Yellow)
On (steady state) 100 Mbits/s data rate is selected

Desktop Board Features
17
Hi-Speed USB 2.0 Support
NOTE
Computer systems that have an unshielded cable attached to a USB port might not
meet FCC Class B requirements, even if no device or a low-speed USB device is
attached to the cable. Use a shielded cable that meets the requirements for a
full-speed USB device.
The Desktop Board supports up to six USB 2.0 ports (two ports routed to the back
panel and four ports routed to two internal USB 2.0 headers). The USB 2.0 ports are
backward compatible with USB 1.1 devices. USB 1.1 devices will function normally at
USB 1.1 speeds.
USB 2.0 support requires both an operating system and drivers that fully support
USB 2.0 transfer rates. Disabling Hi-Speed USB in the BIOS reverts all USB 2.0 ports
to USB 1.1 operation. This may be required to accommodate operating systems that
do not support USB 2.0.
Enhanced IDE Interface
The IDE interface handles the exchange of information between the processor and
peripheral devices such as hard disks and optical drives inside the computer. The
interface supports:
•Up to two IDE devices (such as hard drives)
•ATAPI-style devices (such as CD-ROM or DVD drives)
•Older PIO Mode devices
•Ultra DMA-33/66/100 modes
Serial ATA
The Desktop Board supports two Serial ATA channels (1.5 Gb/s), connecting one
device per channel.
Expandability
The Desktop Board supports one PCI add-in card.
BIOS
The BIOS provides the Power-On Self-Test (POST), the BIOS Setup program, the PCI
and IDE auto-configuration utilities, and the video BIOS.

Intel Desktop Board D201GLY2 Product Guide
18
IDE Auto Configuration
If you install an IDE device (such as a hard drive) in your computer, the auto-
configuration utility in the BIOS automatically detects and configures the device for
your computer. You do not need to run the BIOS Setup program after installing an
IDE device. You can override the auto-configuration options by specifying manual
configuration in the BIOS Setup program.
PCI Auto Configuration
If you install a PCI add-in card in your computer, the PCI auto-configuration utility in
the BIOS automatically detects and configures the resources (IRQs, DMA channels,
and I/O space) for that add-in card. You do not need to run the BIOS Setup program
after you install a PCI add-in card.
Security Passwords
The BIOS includes security features that restrict whether the BIOS Setup program can
be accessed and who can boot the computer. A supervisor password and a user
password can be set for the BIOS Setup and for booting the computer, with the
following restrictions:
•The supervisor password gives unrestricted access to view and change all Setup
options. If only the supervisor password is set, pressing <Enter> at the password
prompt of Setup gives the user restricted access to Setup.
•If both the supervisor and user passwords are set, you must enter either the
supervisor password or the user password to access Setup. Setup options are then
available for viewing and changing depending on whether the supervisor or user
password was entered.
•Setting a user password restricts who can boot the computer. The password
prompt is displayed before the computer is booted. If only the supervisor
password is set, the computer boots without asking for a password. If both
passwords are set, you can enter either password to boot the computer.
Related Links:
For instructions on resetting the password, see Clearing Passwords on page 39.
Power Management Features
Power management is implemented at several levels, including:
•Advanced Configuration and Power Interface (ACPI)
•Hardware support:
―Power connectors
―Fan headers
―+5 V standby power indicator LED
―LAN Wake capabilities
―Wake from USB
―Wake from PS/2 keyboard/mouse
―PME# wakeup support

Desktop Board Features
19
ACPI
ACPI gives the operating system direct control over the power management and Plug
and Play functions of a computer. The use of ACPI with the Desktop Board requires an
operating system that provides full ACPI support.
Hardware Support
Power Connectors
The Desktop Board has two power connectors. See Figure 13 on page 36 for the
location of the power connectors.
Fan Headers
The Desktop Board has a 3-pin processor fan header and a 3-pin chassis fan header.
See Figure 12 on page 35 for the location of the chassis fan header.
+5 V Standby Power Indicator LED
CAUTION
If the AC power has been switched off and the standby power indicator is still lit,
disconnect the power cord before installing or removing any devices connected to the
board. Failure to do so could damage the board and any attached devices.
The Desktop Board’s standby power indicator, shown in Figure 4, is lit when there is
standby power to the system. This includes the DIMM socket and the PCI bus
connector, even though the computer appears to be off.

Intel Desktop Board D201GLY2 Product Guide
20
Figure 4. Location of the Standby Power Indicator
Related Links:
For more information on standby current requirements for the Desktop Board, refer to
the Technical Product Specification by going to the following link, finding the product,
and selecting Product Documentation from the left-hand menu:
http://support.intel.com/support/motherboards/desktop/
LAN Wake Capabilities
CAUTION
For LAN wake capabilities, the 5 V standby line for the power supply must be capable
of delivering adequate +5 V standby current. Failure to provide adequate standby
current when using this feature can damage the power supply.
LAN wakeup capabilities enable remote wake-up of the computer through a network.
The LAN subsystem monitors network traffic and upon detecting a Magic Packet*
frame, it asserts a wake-up signal that powers up the computer.
