Intel Q77M vPro Guide

Guide
Intel® Centrino® with vPro™ Technology
Intel® Core™2 Processor with vPro™ Technology
Intel® vPro™ and Intel®
Centrino® Pro
Processor
Technology Quick
Start Guide
Based on Intel® Active Management Technology and HP Out-of-
Band Manager v 4.0
Version 0.3
April 2009

Intel® vPro™ and Intel® Centrino® Pro Processor Technology Quick Start Guide
2
Contents
Preface.................................................................................................................................3
Intended Audience....................................................................................................................................................................................3
What This Document Contains ...........................................................................................................................................................3
Process Overview..............................................................................................................4
Section 3 – Deploying Intel® vPro Using Enterprise Standard Mode
Provisioning........................................................................................................................5
Process Flowchart ....................................................................................................................................................................................5
Intel vPro Enterprise Setup and Configuration Flow ..............................................................................................................6
Step 1: Configure Existing IT Infrastructure..............................................................................................................................7
Step 2: Verify Intel vPro Client Windows Drivers....................................................................................................................8
Step 3: Install Intel SCS and HP OOBM Management Console...........................................................................................9
Step 4: Configure Intel vPro Client Authentication Settings ..........................................................................................10
Step 5: Discover Intel vPro Clients through the Management Console ....................................................................15
Step 6: Test Intel vPro Client Functionality in HP OOBMC...............................................................................................16
Step 7: Post Configuration...............................................................................................................................................................17
Appendix A: Troubleshooting...................................................................................... 19
Appendix B: Glossary of Terms used in this guide................................................. 20

Intel® vPro™ and Intel® Centrino® Pro Processor Technology Quick Start Guide
3
Preface
This document provides the high level steps required to deploy desktop and notebook PCs with Intel®
vPro™ technology. It does not provide step-by-step procedures for completing those high level steps,
but instead provides links to more detailed information where such step-by-step procedures may be
found.
Note: Hewlett Packard* Out of Band Management (HP OOBM) software only supports Intel vPro
Enterprise mode provisioning. HP OOBM supports both the standard and advanced modes of Enterprise
mode provisioning. To get users started quickly, this guide will focus on Enterprise standard mode only.
For the TLS advanced configuration, please refer to the HP OOBM manual.
Intended Audience
This Quick Start Guide is intended for Information Technology (IT) professionals, system integrators,
and other technical specialists with experience deploying computer systems and networking
technologies in an Information Technology environment. It is not intended for general audiences.
What This Document Contains
Section Description
Process Overview Provides a brief overview of the overall deployment process; lists high
level steps, including decisions to be made, which are explained in
more detail in subsequent sections.
Deploying Intel vPro Using Enterprise
Standard Mode Provisioning Provides the overall steps to deploy Intel vPro based systems into your IT environment using Enterprise Standard mode provisioning.
Appendix A: Troubleshooting Provides information on correcting problems that may arise during
deployment.
Appendix B: Glossary Provides a list of terms used in this document and their definitions.

Intel® vPro™ and Intel® Centrino® Pro Processor Technology Quick Start Guide
4
Process Overview
Intel®Active Management Technology1(Intel®AMT) provides significant flexibility in order to meet the
needs of various customer environments. This flexibility requires that customers make a number of
decisions when planning and implementing their deployment of Intel AMT enabled systems.
The overall deployment process is shown below:
•Install or validate infrastructure components (DNS, DHCP, SQL Server, etc.).
•Ensure required Windows* drivers (for SOL and IDE-R) are installed on Intel vPro clients.
•Install Intel®SCS and HP OOBM software.
•Intel SCS and Intel vPro Setup: provides steps for setting up and configuring the SCS
Provisioning Server and the Intel vPro device.
•OOB Management Console Installation: specifies system requirements and tells you how to
install, configure, and start the OOB Management Console.
•Configure your management console to manage Intel vPro clients.
•Discover Intel vPro clients in your management console.
•Test Intel vPro client management functionality in your management console.
•Perform post configuration steps (IT support process changes, maintenance procedures, etc.).
1. Intel® Active Management Technology (Intel® AMT) is a hardware-based technology that facilitates remote out-of-band
management of computers by use of a small secondary processor located on the motherboard.
This out of band (OOB) controller has embedded firmware that runs on the Intel® Management Engine (Intel® ME), a separate
small ARC architecture processor built into either the North Bridge or NIC of the motherboard. The Intel AMT firmware is stored in
the same SPI flash memory component used to store the BIOS and is generally updated along with the BIOS.

Intel® vPro™ and Intel® Centrino® Pro Processor Technology Quick Start Guide
5
Section 3 – Deploying Intel® vPro Using Enterprise Standard Mode Provisioning
Process Flowchart
The following picture shows the overall process flow for provisioning Intel vPro client systems in
Enterprise (Standard and Advanced) mode. The steps for Enterprise Standard mode are described in
further detail in this section.

Intel® vPro™ and Intel® Centrino® Pro Processor Technology Quick Start Guide
6
Intel vPro Enterprise Setup and Configuration Flow
Prior to executing the steps for configuring the Intel vPro components (Intel AMT and Intel ME) in
Enterprise standard mode, it is first important to understand the overall flow of the Enterprise mode
configuration process
In Enterprise mode, an Intel vPro machine receives its configuration settings over the network, once it
has been prepared with some initial setup information. The following diagram shows the modes or
states that an Intel vPro device passes through before it becomes operational.
Intel vPro Configuration States:
1. Factory State
– AMT disabled
– No network configuration
– No security credentials
2. Setup State
– AMT enabled
– Basic network configured
– Admin credentials loaded
3. Configured State
– AMT fully configured (e.g power policies)
– Security credentials fully loaded
– Ready for remote management
SETUP
SETUP
(Pre
(Pre- -Provisioning Provisioning) )
CONFIGURATION
CONFIGURATION
(Provisioning)
(Provisioning)
Factory State: An Intel vPro machine comes from the OEM in Factory State. In this state Intel AMT is
un-configured and not available for use by management applications. When an operator enters
information via the Intel Management Engine BIOS extension (Intel MEBX) manually or with the aid of a
USB storage device, the Intel vPro machine makes the transition into the setup state. See Step 3 –
Configure AMT Client BIOS for instructions on how to prepare an Intel vPro machine to receive its
configuration settings from a Setup and Configuration Server (SCS) which is part of HP OOBM
distribution.
Setup State: When an Intel vPro machine enters Setup State it waits for delivery of its configuration
settings from the SCS. After it enters setup mode, the Intel vPro machine periodically sends messages
to the SCS. When the SCS receives messages from the Intel vPro machine, it responds by delivering the
configuration settings and placing the device in Operational State.
Operational State: The Intel vPro machine enters Operational State once its configuration settings
have been supplied and committed. At this point the Intel vPro machine is ready to interact with HP
OOBM management applications.

Intel® vPro™ and Intel® Centrino® Pro Processor Technology Quick Start Guide
7
Step 1: Configure Existing IT Infrastructure
In order for an Intel vPro machine to be manageable, it must become known to the management
console. The process by which this occurs is called “provisioning”. Enterprise setup (pre-provisioning)
requires a series of steps that are performed on both the Intel vPro clients and the SCS in order to
prepare the client for provisioning over the network by the SCS (which acts as the provisioning server
for the Intel vPro clients).
Intel vPro Integration Points with IT Infrastructure Components
The following diagram shows the interaction with the different network elements. Each will be
discussed briefly in order to understand the integration requirement.
Management
Console
Intel®vPro™
Clients
DHCP
Core Server
Configuration Server
CA Server
SQL DB
DNS
Registers
Updates
Requests
Manages Manages
DHCP Server: When an Intel vPro machine enters setup state, the default IP addressing scheme is
DHCP (that is, use DHCP to obtain an IP address). The Intel® Management Engine (Intel® ME) also
uses the DHCP server to help dynamically update the DNS server with its network address information.
The DHCP server must support Option 81 to register network address information into the DNS server
on behalf of the Intel ME. Option 15 should also be enabled in the DHCP Scope Options to allow the
DNS to resolve host queries after IP address changes.
DNS Server: The DNS Server is used by network devices such as Management Consoles to locate
address information for Intel vPro clients in order to contact them and manage them. The Intel vPro
clients may also use the DNS server during the provisioning configuration phase to locate the provision
server and request their configuration information, as explained below.
Once configured to the setup state, Intel AMT makes a DNS request for the name "ProvisionServer"
(unless you choose to configure the client’s BIOS manually). If the requested name cannot be resolved
by the DNS server, then a second request is made for "ProvisionServer.DomainName." Intel AMT
expects to either find the IP address of the provision server in this way, or by having it set explicitly in
the Intel MEBX configuration process (Step 4: Configure Intel vPro Client Authentication Settings, page
10). The Intel Management Engine BIOS Extension (Intel MEBX) is an option ROM module extension to
the system BIOS, provided to the OEM by Intel. The Intel MEBX allows you to configure settings that

Intel® vPro™ and Intel® Centrino® Pro Processor Technology Quick Start Guide
8
control the operation of the Management Engine which runs on the Intel AMT client. For more
information on Intel MEBX, see the Intel Management Engine BIOS Extension User’s Guide.
Step 1a: Manually register the “provision server” entry into the DNS server.
Manually resister the “provision server” entry into the DNS server.
Step 1b: Set Firewall/Router Ports Open for Management Traffic
Intel AMT requires certain ports to be “open” in order to allow management traffic through them. The
Intel AMT ports are 16992 (non-TLS), 16994 (non-TLS redirection),– these are IANA-assigned ports
which Intel purchased. They cannot be changed. Port 9971 is used in Enterprise mode to listen for
“Hello” packets. This port is configurable in the SCS console.
Step 1c: Database Server Integration:
Intel vPro machines will have information about them (inventory) stored in a repository used by the
management console. With HP Software management products, Microsoft SQL 2005 is the primary
choice.
Step 2: Verify Intel vPro Client Windows Drivers
The following Intel AMT drivers, which are digitally signed by Intel and compatible with Microsoft
Windows* operating systems (including Windows 2000, Windows XP, and Windows Vista*), are required
on the Intel vPro client platform. Obtain these drivers from your client system manufacturer’s driver
and download support pages (most client drivers and Intel MEBX updates are contained on the same
support web page by the OEM).
•Intel Management Engine Interface (Intel MEI) driver -- Provides a secure local
communications interface between the host operating system and the Intel ME via the Intel MEI.
•Serial-over-LAN (SoL) driver -- Enables a COM port for VT100 or ANSI remote sessions prior
to graphic interface when the operating system loads. You can view and send commands to a
remote client prior to the operating system loading, including entering into the BIOS, viewing
POST, etc.
•Local Management Service (LMS) driver –Provides an interface enabling local management
software agents to communicate with the Intel Management Engine using the same high-level
protocols as those used for remote management (e.g. XML, SOAP). When first loaded, the driver
will cause a pop-up to occur to confirm that Intel AMT is running. The pop-up can be disabled. As
the Intel AMT firmware is updated, this driver is most likely to require a coordinated update as
new features are enabled. The driver also checks for consistency of the Intel AMT hostname and
the operating system host name.

Intel® vPro™ and Intel® Centrino® Pro Processor Technology Quick Start Guide
9
It is recommended that the HP OOBMC client agent also be installed, although it is not required. This
agent will communicate with the Intel AMT watchdog timer on the client local system in order to provide
the agent present functionality. The agent software “oobmclocalagent.msi” is located in LocalAgent sub-
directory in the HP OOBM software distribution. A manual installation is recommended for a small
number of test systems. There are other ways to install this agent software automatically, which are
described in the HP OOBM Console Guide (OVCOutOFBandMgtConsoleGuide.pdf) under Chapter 2,
“Installing the Local Agent”.
Step 3: Install Intel SCS and HP OOBM Management Console
The following two software packages need to be installed:
•Setup and Configuration Server (SCS): includes the installation executables ATMConfServer.exe
for the server portion and AMTConsole.exe for the console. For details on the SCS installation,
please refer to “Intel_AMT_SCS_Installation_Guide.pdf” Part 9-10. Note that the SCS software is
available in the HP OOBMC distribution under the SetupConfService folder.
•HP Out-of-Band Management Console (HP OOBMC): Please refer to the HP OOBMC guide
(OVCOutOFBandMgtConsoleGuide.pdf) Chapter 3 “Installing the OOBM Management Console” for
details on installing the HP OOBM software.
After the SCS and OOBMC are installed, a vPro profile needs to be created. A profile allows configuration
of multiple Intel AMT platforms with certain configuration properties. A profile defines the security
settings of the communication with the platform, the network environment, and more. For a quick start,
a basic profile is created with minimum settings. For the detail and screen shots, please refer to
“Intel_AMT_SCS_Console_Guide.pdf” Part 4 “Creating and Changing Profiles”.
1. In the Console tree, right-click the Profiles element and choose Add Profile. Alternatively, in the
Welcome window, click Create a Profile. The Profile Creator wizard opens.
2. Click Next. The New SCS Profile Wizard opens, displaying the Before You Begin section, which
contains information on creating profiles.
3. In the Basic Settings section, click General and enter Profile Name and Description area.
4. Checked ACL in the Profile Components section, the wizard displays the Access Control List
(ACL) settings.
a. To add a new user, Click Add. The ACL Details window opens.
b. To create a digest users, Select Digest User in the User Type section. Enter the user
name and password, and confirm the password. Then, select PT_administration right to
this user and Apply the setting.
During the Intel vPro system provision stage, the Intel vPro systems need to be connected through a
wired network. For Intel Centrino vPro systems, the WiFi option needs to be added so that the wireless
systems can be managed after being provisioned. Please refer to Intel_AMT_SCS_Console_Guide
“Configuring WiFi” section for the detail.

Intel® vPro™ and Intel® Centrino® Pro Processor Technology Quick Start Guide
10
Step 4: Configure Intel vPro Client Authentication Settings
In Enterprise mode, configuring the authentication settings on the Intel vPro clients can be performed in
either of the following three ways:
•Remote Configuration (Intel AMT 3.0 or higher) – Step 4A below
•OEM pre-configuration – Step 4B below
•One-touch configuration (using a USB thumb drive or manual entry) – Step 4C below
Step 4A: Remote Configuration (Intel AMT 3.0 or higher) – Factory State to Configured
State
Remote Configuration uses matching certificate hashes on the Intel vPro clients and the provisioning
server to authenticate interaction between the clients and the server. Once the client and server
authenticate each other (i.e., the certificate hashes match), the provisioning server automatically
begins provisioning the client.
With Remote Configuration, you have two choices:
•Use your own root certificate, if you already have one
•Use one of the certificate hashes provided with Intel vPro (i.e., already on the client systems)
Using your own root certificate: If you already have a root certificate on your SCS server, then you
need to do one of the following:
•instruct your Intel vPro client manufacturer (OEM) to place a matching certificate hash on each
Intel vPro client during manufacture
•manually enter the matching certificate hash using the Intel MEBX on each Intel vPro client
before deployment
If you instruct your OEM to load the certificate hashes onto your Intel vPro clients, the clients will
already have a certificate hash that matches the existing root certificate on your provisioning server
when they arrive. This will allow Intel vPro clients to establish a secure communication channel to
exchange the certificate information to ensure the authenticity of the Intel vPro clients. But the
provisioning process still depends on the Intel vPro Technology Activator to initiate the process.
The Intel® vPro™ Technology Activator Utility is the next generation of the Remote Configuration tool.
A Windows executable that runs locally on an Intel AMT enabled platform, the Activator does the
following:
•Simplify the process of configuring the Intel vPro systems via Intel SCS
•Facilitate initial Intel AMT configuration or policy change
•Address the following scenarios:
oIntel vPro failure to find the Setup and Configuration server in the network
oExpiration of Intel vPro 'hello' messages
•The configuration server must get the parameters necessary to start the Intel vPro configuration
process

Intel® vPro™ and Intel® Centrino® Pro Processor Technology Quick Start Guide
11
oIntel vPro system becomes unreachable if OS/AMT host names go out of sync
oSome Intel vPro systems are shipped with management mode disabled. Remote
Configuration must be enabled by a local software tool
For more information about the Activator, see the Intel® vPro™ Technology Activator Utility user guide,
which is available at http://software.intel.com/en-us/articles/intel-vpro-technology-activator-utility/.
Skip to Step 5: Discover Intel vPro Clients through the Management Console, on page 15.
Using one of the certificates provided with Intel vPro: If you want to use one of the certificates
provided with Intel vPro, you will need to purchase a matching root certificate, and load it onto your
SCS server. Once a matching root certificate is present on the provisioning server, the Intel vPro clients
will automatically authenticate themselves with the provisioning server at power on, and will then
automatically be provisioned by the provisioning server.
The certificates are purchased from one of the approved Certificate Authority (CA) vendors, such as
VeriSign, Comodo, Go Daddy, and Starfield. Check with your OEM to see which of these CA vendors
they support. The detail steps to purchase the certificate is available at
http://communities.intel.com/docs/DOC-1916.
Once the pending certificate request has been completed with the .CER file provided, the target website
used for this process has been assigned the issued certificate. In addition, a backup copy of the
certificate is recommended.
In SCS 5.0, which is part of the HP OOBMC 4.0 distribution, the loadcert.exe is no longer needed.
Therefore it is not necessary to run the last step “Run LoadCert.exe to Complete the Certificate Process”
of the certificate import procedure described in the http://communities.intel.com/docs/DOC-1916.
For more about how remote configuration works, please refer to Intel_AMT_SCS_Console_Guide.pdf,
Appendix A.
If you want to use one of the certificates provided with Intel vPro, the clients will already have a
certificate hash that matches the purchased root certificate on your provisioning server. This will allow
Intel vPro clients to establish a secure communication channel to exchange the certificate information to
ensure the authenticity of the Intel vPro clients. But the provisioning process still depends on the Intel
vPro Technology Activator to initiate the process, which is described in the previous section “Using
your own root certificate”. For more information about the Activator, see the Intel® vPro™
Technology Activator Utility user guide, which is available at the following website:
http://software.intel.com/en-us/articles/intel-vpro-technology-activator-utility/.
Skip to Step 5: Discover Intel vPro Clients through the Management Console, on page 15.

Intel® vPro™ and Intel® Centrino® Pro Processor Technology Quick Start Guide
12
Step 4B: OEM Pre-configuration – Factory State to Configured State
Most OEMs are willing to provide the service of changing the Intel vPro client from factory state to setup
state by entering the password and client authentication information into the Intel MEBX on each client
system for you. This often requires an additional fee to the OEM. This method is most useful when an
Intel vPro client machines are to be delivered directly to the end user from the manufacturer.
The authentication information (security keys) can be provided to the OEM for loading into the client
system’s BIOS (via the Intel MEBX), or the OEM could provide you with a list of keys they generated.
The keys must match between the Intel vPro machines and the management console. The
management consoles have an option to import and export keys to facilitate this transaction.
If you ordered your Intel vPro client systems pre-configured with Intel MEBX password and client
authentication information already loaded by the OEM, then they are already in a Setup state. When
you connect the client systems to the network and power them on they will automatically authenticate
themselves with the provisioning server and provisioning will occur (assuming you performed Steps 1-3
above). Then they will be in a Configured state, ready to be discovered and managed by the
management console.
Skip to Step 5: Discover Intel vPro Clients through the Management Console, on page 15.
Step 4C: One-Touch Configuration of Intel vPro Client - Factory State to Setup State
The Intel vPro clients need authentication information configured on them so that they can authenticate
themselves to the provisioning server; otherwise the server won’t provision them. This authentication
information is made up of a Provisioning ID (PID) and a Provisioning Pass-phrase (PPS). Together they
are referred to as a PID-PPS pair. The server maintains a list of valid PID-PPS pairs, which is matched
against any incoming PID-PPS pair from a client requesting provisioning. If the client’s PID-PPS
matches one of the entries in the server’s list, that client is provisioned.
Step 4C-1: Confirm Latest BIOS Version: It is important that you use the latest BIOS and firmware
version from the Original Equipment Manufacturer (OEM). Please visit their website to determine the
latest versions. If an update is needed, follow the instructions provided by the OEM to implement the
update.
Examples of OEM BIOS updates
•HP:
http://h20000.www2.hp.com/bizsupport/TechSupport/SoftwareIndex.jsp?lang=en&cc=us&prodN
ameId=3232116&prodTypeId=12454&prodSeriesId=3232030&swLang=13&taskId=135&swEnv
OID=1093
•Lenovo: http://www-307.ibm.com/pc/support/site.wss/MIGR-67881.html
•Dell:
http://support.dell.com/support/downloads/driverslist.aspx?c=us&l=en&s=gen&ServiceTag=&Sy
stemID=PLX_PNT_P4_745C&os=WW1&osl=en&catid=&impid=

Intel® vPro™ and Intel® Centrino® Pro Processor Technology Quick Start Guide
13
Step 4C-2: Create PID-PPS security keys in SCS. Before you can configure the PID-PPS
information on the Intel vPro clients, you need to generate that information in the SCS console.
To create TLS-PSK security keys in SCS, do the following:
1. In the Advanced element, right-click TLS-PSK Configuration Keys and choose Add Security
Keys. The Security Key Settings window opens.
2. Specify the following information where applicable:
oNumber of keys to store: The number of keys that you want to create (up to 1024 keys)
oManufacturing default MEBx password: the MEBx password that was entered in the
firmware by the manufacturer.
oNew MEBx Password: Choose the type of new MEBx password:
Fixed Password: To use the same password with all the keys, choose this and
enter the password that you want to use.
3. Click OK. The Intel SCS creates a list of Security Keys. See the MEBx Settings pane to
configure the number of keys generated. Each record consists of an 8 byte PID, a 32 byte PPS
and the administrator’s password.
Step 4C-3: Configure Intel vPro Clients Using a USB Thumb Drive: In this method, the new
password and the PID/PPS keys are exported from the management console onto a USB thumb drive.
To export the list of keys to a USB drive:
1. Attach a USB drive to a USB port on the server on which the Console is running.
2. In the Advanced element, right-click TLS-PSK Configuration Keys and choose Export Keys to
USB Drive.
3. In the USB Drive list, choose the drive to which you want to export the keys.
4. To export existing keys, select the Export option. Then specify the number of keys that you
want to store on the drive (up to 1024 keys). Click Next to export the keys and finish this
procedure.
Note: You can only use the USB key to transfer the PID/PPS information to the Intel MEBX one time
per client system. A bit is set on the client once the transfer has been made and the client will not
allow an additional transfer to occur unless the bit is reset. To reset this bit, you would need to clear
the client Intel Management Engine by performing a Full Un-Provision in the Intel MEBX (reset to factory
defaults).

Intel® vPro™ and Intel® Centrino® Pro Processor Technology Quick Start Guide
14
USB Thumb Drive Notes: You should use a USB 2.0 thumb drive and 2 GB or less. Format the USB
drive in FAT 16 through any Windows client. This must be in FAT 16, not FAT 32. The file (setup.bin)
that is created by the export function noted above MUST be the first file on the drive, to function
properly. Once this file is on the drive, other files can then be added as needed.
You may need to try several USB drives to find one that works, and you may need to try both the front
and back USB ports on the client system. Refer to the USB Provisioning Matrix for a list of tested
drives: http://communities.intel.com/docs/DOC-1247#USB2
Once you have configured your clients using the USB thumb drive, skip to Step 5: Discover Intel vPro
Clients through the Management Console, on page 24.
Step 4C-3a: Manual Configuration of the Intel vPro Clients (alternative to USB drive
method): Use this method to manually enter the password and PID-PPS credentials for each Intel vPro
client machine.
A minimal amount of information is required to change the Intel vPro client from Factory Mode to Setup
Mode. The information required includes:
•Change Intel MEBX password (change from factory default). The default password is “admin.”
The new ME password must meet “strong” password criteria which include:
•Be between 8 and 32 characters long
•Contain both upper and lower case Latin characters
•Have at least one numeric character
•Have at least one ASCII non-alphanumeric character (!, @, #, $, %, ^, &, *)
•Provisioning ID (PID) and Provisioning Pass-Phrase (PPS). These are used to perform the
necessary steps of authenticating a new client and initiating the provisioning process. This uses
Transport Layer Security (TLS) Pre-shared Key (PSK) for authentication.
To manually update the Intel vPro clients with new Intel MEBX passwords and valid PID-PPS security
keys, do the following on each client system:
1. Start the client system, then press Ctrl-P during startup to enter the Intel MEBX.
2. Change the Intel MEBX password to a “strong” password (use the same password for each
client system).
3. Select Intel AMT Configuration, then Setup and Configuration, then TLS-PSK, then Set
PID and PPS.
4. Enter one of the PID-PPS combinations from the list of PID-PPS pairs you generated in SCS
console (Step 4C-2 above).
5. Exit the Intel MEBX and reboot the client system to the Windows OS.
6. Repeat for each Intel vPro client.
Note: Once the client boots to Windows, it will automatically authenticate itself with the provisioning
server and provisioning will occur.

Intel® vPro™ and Intel® Centrino® Pro Processor Technology Quick Start Guide
15
See the Intel Management Engine BIOS Extension (Intel MEBX) User’s Guide for detailed information
about configuring the Intel ME and Intel AMT using the Intel MEBX.
Skip to Step 5: Discover Intel vPro Clients through the Management Console, on page 15.
Step 5: Discover Intel vPro Clients through the Management Console
After provisioning the vPro device in one of ways described in the previous section, you can view it in
the vPro SCS console.
1. Open the vPro SCS Console.
2. Expand the Intel AMT Systems branch and select the target vPro device. The target vPro
device is displayed with its provisioning status.
3. Depending on the provisioning approach, there are two different provisioning status associated
with vPro systems.
a. If the Intel vPro system is provisioned with the remote configuration method described in
the 4A, the system status will transition from unprovisioned to provision state
automatically using a PKI key.
b. If the Intel vPro system is provisioned with the other methods, there are several steps to
complete the provision process.
i. Select an unprovisioned Intel vPro client using a Pre-Shared Key (PSK). Enter the
Intel AMT machine’s Fully Qualified Domain Name (FQDN) in the relevant fields. If
there are multiple systems shown at the same time, administrator needs to
manually find out which UUID matches to which FQDN.
ii. From the Profile list, choose the profile that you want to use to configure the Intel
AMT system
iii. Click OK to save the setting. Then, the status of the Intel vPro system will change
from unprovisioned state to provisioned state. Since the handshaking between the
Intel vPro system and Intel SCS takes time, the state transition can take a few
minutes to complete.

Intel® vPro™ and Intel® Centrino® Pro Processor Technology Quick Start Guide
16
Step 6: Test Intel vPro Client Functionality in HP OOBMC
After the device has been discovered and added to the management database, it is a good idea to test
the functionality of the Intel vPro machine. To do that, you must login to the HP OOBM console as an
administrator (see HP OOBM Console User Guide OVCOutOfBandMgtConsoleGuide.pdf Chapter 3
“Starting the OOB Management Console” section and Chapter 5 “Getting Started Managing OOB
Devices” for detail). Once you have logged in to the HP OOBM console as an administrator, perform the
following steps to test the Intel AMT client functionality.
Step 6a: Test Intel vPro Client Functionality From HP Software
At a minimum, look at the following Intel vPro Options to test that the Intel AMT configuration has
been successfully completed:
odiscover the Hardware Assets on all of the provisioned OOB devices on your network.
Remote Boot Manager – Power On/Off
oRemote Boot Manager using Console Redirection (Serial over LAN /SOL) and IDE
Redirection
For further information on testing these features, refer to OVCOutOfBandMgtConsoleGuide.pdf
Chapter 6 “OOB Management Use Case Scenarios”.
Step 6b: Test Intel AMT Client Functionality Using Intel AMT Web Console
1. On the management console system, login as an administrator created in Step 3 with user
rights.
2. Open a web browser and enter the IP address and assigned port number (16992 for non-TLS)
in the browser address bar (example, http://192.168.0.1:16992).
The following web browsers are supported:
oInternet Explorer* 6.0 SP1 or later
oNetscape* 7.2 for Windows and Linux
oMozilla Firefox* 1.0 for Windows and Linux
oMozilla 1.7 for Windows and Linux
3. Once the Intel AMT Configuration Web Page is displayed, login using the Intel MEBX username
and password. You can then view the following client management information:
oSystem Status
oHardware Information
oEvent Log
oRemote Control
oNetwork Settings
oUser Accounts

Intel® vPro™ and Intel® Centrino® Pro Processor Technology Quick Start Guide
17
Step 7: Post Configuration
Once you’ve deployed and configured your Intel vPro client machines, there are still some additional
actions you should consider.
Adding New Devices:
As new Intel vPro clients are added to the network you will need to perform the deployment process
described above to activate Intel AMT on the new devices, discover the new devices, and then add them
to your management database. This procedure should be added to your standard maintenance
procedures.
Updating Procedures to Include Intel AMT Features:
Work with your management console to determine how best to utilize the new capabilities available to
you through your Intel vPro devices. Further, it is a good idea to update your procedures to utilize Intel
vPro features, such as those procedures your help desk staff follow when helping users. For example,
you will want to update the process to re-image a PC that has blue screened at a remote site using the
new Intel AMT features now available in your management console.
Using Agent Presence (AP):
Agent Presence (AP) monitors for the existence of agents. The HP Software client agents must be
installed on the client PC in order to use AP. The detailed procedures are described in the HP OOBM
Console User Guide (OVCOutOfBandMgtConsoleGuide.pdf) Chapter 6 “Monitoring Security Software”
section.
System Defense (SD):
System Defense (SD) does not require any agents to be installed on the Intel AMT client machine.
System Defense policies may be configured on a per-machine basis.
There are four pre-defined SD policies:
•An FTP access policy which will trigger SD if an FTP access is made either to or from the Intel
AMT client machine.
•A UDP flood policy which will trigger SD if Intel AMT sees at least 20,000 UDP packets per second
and will monitor for a Denial-of-service attack.
•An SYN flood policy which will trigger SD if Intel AMT sees at least 20,000 IP packets per second
and will monitor for a Denial-of-service attack.

Intel® vPro™ and Intel® Centrino® Pro Processor Technology Quick Start Guide
18
•A Kill All NICs policy which will stop all network traffic except for HP Software management, Intel
AMT, DNS, and DHCP traffic, thus isolating the client system from the network except for system
management functions.
Once SD triggers an alert, the alert is displayed in the OOBM log. OOBM and Intel AMT limit network
access by replacing the current client policy with the Kill All NICs policy when SD is triggered. Once the
machine is remediated, the Kill All NICs policy is removed and the previous policy is re-applied. The
administrator must manually perform the actual remediation of removing the virus or spyware, or fixing
whatever caused the SD to be triggered. The detail procedures are described in the HP OOBM Console
User Guide (OVCOutOfBandMgtConsoleGuide.pdf) Chapter 6 “Virus Infection Detection and Recovery”
section.
Congratulations! You are now on your way to more productively managing a powerful computer
system. This can improve your productivity and provide a valuable return on your investment.

Intel® vPro™ and Intel® Centrino® Pro Processor Technology Quick Start Guide
19
Appendix A: Troubleshooting
The SCS service and the SOAP API issue error messages and information messages that are displayed
in the console log. The messages actually displayed will be based on the filter selection on the Log page.
There is a table lists the possible messages, causes, and a suggested action to remedy the situation, in
case of an error. The detail information is available in the “Intel_AMT_SCS_Troubleshooting_Guide.pdf”.
The troubleshooting guide also describes various issues and suggests solutions or debugging
procedures.

Intel® vPro™ and Intel® Centrino® Pro Processor Technology Quick Start Guide
20
Appendix B: Glossary of Terms used in this guide
BIOS: Basic Input Output System
DHCP: Dynamic Host Configuration Protocol
DNS: Domain Name Service.
Enterprise Mode: Provisioning model used
for larger organizations
Intel® AMT: Intel® Active Management
Technology allows Web Service calls to Intel
desktops and notebook clients for out-of-band
management and services.
Intel® Centrino® Pro processor
technology: Intel processor technology that
provides a higher level of security and
management to mobile computers.
Intel® ME: Intel® Management Engine
Intel® MEBX: Intel® Management Engine
BIOS Extension
Intel® vPro™ Processor Technology: Intel
processor technology that provides a higher
level of security and management to desktop
computers.
ISV: Independent Software Vendor
LMS: Local Management Service driver.
Provides an interface enabling local
management software agents to communicate
with the Intel Management Engine using the
same high-level protocols as those used for
remote management (e.g. XML, SOAP).
OEM: Original Equipment Manufacturer.
Notation used to designate the PC
manufacturer.
PID: Provisioning ID. First portion of security
key used in provisioning Intel vPro machines.
PKI: Public Key Infrastructure
PKI CH: Public Key Infrastructure –
Certification Hash
PPS: Provisioning Pass phrase. Pre-shared
key used in provisioning Intel vPro machines.
PSK: Pre-shared key
SMB Mode: Small (and Medium) Business
model used for provisioning an Intel vPro
machine
TLS: Transport Layer Security
