Intel S2600CW Configuration guide

Intel® Server Board S2600CW
Family
Technical Product Specification
Revision 2.4
March, 2017
Intel®Server Boards and Systems

Revision History Intel® Server Board S2600CW Family TPS
Revision 2.4
ii
Revision History
Date
Revision
Number
Modifications
September, 2014
1.0
Initial release
November, 2014
1.10
Include information for S2600CW2S, S2600CWT and S2600CWTS
February, 2015
1.11
Updated chapter 3.4.1, 3.4.7 and 7.5
July, 2015
1.12
Updated chapter 5.3 Sensor Monitoring.
August, 2015
1.2
Updated Post Progress Codes and MRC Progress Codes
September, 2015
1.3
Updated Memory support Table3~4
January, 2016
2.0
Updated to Refresh SKU
February, 2016
2.1
Support for Intel® Xeon® E5-2600 v4 included
May, 2016
2.2
Updated Index and Appendix A with DIMM installation information
October, 2016
2.3
Updated Tables 3 and 4 regarding DIMM support on the motherboard
March, 2017
2.4
Errata: Removed “ED2 - 4: CATERR due to CPU 3-strike timeout” from
CATERR Sensor Section

Intel® Server Board S2600CW Family TPS Disclaimers
Revision 2.4
iii
Disclaimers
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL PRODUCTS. NO LICENSE,
EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY
THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS,
INTEL ASSUMES NO LIABILITY WHATSOEVER AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY,
RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO
FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR
OTHER INTELLECTUAL PROPERTY RIGHT.
A "Mission Critical Application" is any application in which failure of the Intel Product could result, directly or
indirectly, in personal injury or death. SHOULD YOU PURCHASE OR USE INTEL'S PRODUCTS FOR ANY SUCH
MISSION CRITICAL APPLICATION, YOU SHALL INDEMNIFY AND HOLD INTEL AND ITS SUBSIDIARIES,
SUBCONTRACTORS AND AFFILIATES, AND THE DIRECTORS, OFFICERS, AND EMPLOYEES OF EACH, HARMLESS
AGAINST ALL CLAIMS COSTS, DAMAGES, AND EXPENSES AND REASONABLE ATTORNEYS' FEES ARISING OUT OF,
DIRECTLY OR INDIRECTLY, ANY CLAIM OF PRODUCT LIABILITY, PERSONAL INJURY, OR DEATH ARISING IN ANY
WAY OUT OF SUCH MISSION CRITICAL APPLICATION, WHETHER OR NOT INTEL OR ITS SUBCONTRACTOR WAS
NEGLIGENT IN THE DESIGN, MANUFACTURE, OR WARNING OF THE INTEL PRODUCT OR ANY OF ITS PARTS.
Intel may make changes to specifications and product descriptions at any time, without notice. Designers must not
rely on the absence or characteristics of any features or instructions marked "reserved" or "undefined". Intel
reserves these for future definition and shall have no responsibility whatsoever for conflicts or incompatibilities
arising from future changes to them. The information here is subject to change without notice. Do not finalize a
design with this information.
The products described in this document may contain design defects or errors known as errata which may cause
the product to deviate from published specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your
product order.
Copies of documents which have an order number and are referenced in this document, or other Intel literature,
may be obtained by calling 1-800-548-4725, or go to: http://www.intel.com/design/literature.htm
Intel is a registered trademark of Intel Corporation.
*Other names and brands are the property of their respective owners.
Copyright (C) 2013~2016 Intel Corporation.

Table of Contents Intel® Server Board S2600CW Family TPS
Revision 2.4
iv
Table of Contents
1. Introduction........................................................................................................................................1
1.1 Chapter Outline....................................................................................................................................1
1.2 Server Board Use Disclaimer..........................................................................................................2
2. Intel® Server Board S2600CW Overview ......................................................................................3
2.1 Intel® Server Board S2600CW Feature Set ..............................................................................3
2.2 Server Board Layout ..........................................................................................................................5
2.2.1 Server Board Connector and Component Layout.................................................................7
2.2.2 Server Board Mechanical Drawings.............................................................................................8
2.2.3 Server Board Rear I/O Layout ..................................................................................................... 14
3. Intel® Server Board S2600CW Functional Architecture......................................................... 15
3.1 Processor Support........................................................................................................................... 16
3.1.1 Processor Socket Assembly ........................................................................................................ 16
3.1.2 Processor Population Rules......................................................................................................... 17
3.2 Processor Functions Overview................................................................................................... 20
3.2.1 Intel® Virtualization Technology (Intel® VT) for Intel® 64 and IA-32 Intel®
Architecture (Intel® VT-x)................................................................................................................................. 21
3.2.2 Intel® Virtualization Technology for Directed I/O (Intel® VT-d) .................................... 21
3.2.3 Intel® Trusted Execution Technology for Servers (Intel® TXT)...................................... 22
3.2.4 Execute Disable................................................................................................................................. 22
3.2.5 Advanced Encryption Standard (AES)..................................................................................... 22
3.2.6 Intel® Hyper-Threading Technology ........................................................................................ 22
3.2.7 Intel® Turbo Boost Technology.................................................................................................. 22
3.2.8 Enhanced Intel SpeedStep® Technology ............................................................................... 23
3.2.9 Intel® Advanced Vector Extensions 2 (Intel® AVX2)........................................................... 23
3.2.10 Intel® Node Manager 3.0 ............................................................................................................... 23
3.2.11 Intel® Secure Key .............................................................................................................................. 24
3.2.12 Intel® OS Guard ................................................................................................................................. 24
3.2.13 Trusted Platform Module (TPM) ................................................................................................ 24
3.3 Integrated Memory Controller (IMC) and Memory Subsystem..................................... 24
3.3.1 Supported Memory ......................................................................................................................... 25
3.3.2 Memory Population Rules ............................................................................................................ 26
3.3.3 Effects of Memory Configuration on Memory Sizing........................................................ 28
3.3.4 Publishing System Memory......................................................................................................... 29
3.3.5 RAS Features...................................................................................................................................... 29
3.3.6 Memory Initialization...................................................................................................................... 30

Intel® Server Board S2600CW Family TPS Table of Contents
Revision 2.4
v
3.4 System IO ............................................................................................................................................ 34
3.4.1 PCI Express* Support...................................................................................................................... 34
3.4.2 PCIe Enumeration and Allocation ............................................................................................. 35
3.4.3 PCIe Non-Transparent Bridge (NTB)........................................................................................ 36
3.4.4 PCIe SSD Support ............................................................................................................................ 37
3.4.5 Serial ATA (SATA) Support........................................................................................................... 38
3.4.6 SATADOM Support.......................................................................................................................... 38
3.4.7 M.2/NGFF Support........................................................................................................................... 39
3.4.8 Embedded SATA RAID Support................................................................................................. 40
3.4.9 Serial Attached SCSI (SAS) Support......................................................................................... 43
3.4.10 Integrated MegaRAID Support.................................................................................................... 44
3.4.11 USB Support....................................................................................................................................... 45
3.4.12 Graphics Controller and Video Support................................................................................. 46
3.4.13 Trusted Platform Module ............................................................................................................. 51
3.4.14 Network Support.............................................................................................................................. 51
4. System Security .............................................................................................................................. 54
4.1 BIOS Setup Utility Security Option Configuration.............................................................. 54
4.2 BIOS Password Protection ........................................................................................................... 55
4.3 Trusted Platform Module (TPM) Support .............................................................................. 57
4.3.1 TPM Security BIOS........................................................................................................................... 57
4.3.2Physical Presence ............................................................................................................................ 58
4.3.3 TPM Security Setup Options ....................................................................................................... 58
4.4 Intel® Trusted Execution Technology ...................................................................................... 58
5. Intel® Server Board S2600CW Platform Management ........................................................... 60
5.1 Management Feature Set Overview ......................................................................................... 60
5.1.1 IPMI 2.0 Features Overview ......................................................................................................... 60
5.1.2 Non-IPMI Features Overview....................................................................................................... 61
5.2 Platform Management Features and Functions.................................................................. 63
5.2.1 Power Subsystem ............................................................................................................................ 63
5.2.2 Advanced Configuration and Power Interface (ACPI) ....................................................... 63
5.2.3 System Initialization........................................................................................................................ 64
5.2.4 Watchdog Timer............................................................................................................................... 65
5.2.5 System Event Log (SEL)................................................................................................................. 65
5.3 Sensor Monitoring ........................................................................................................................... 65
5.3.1 Sensor Scanning............................................................................................................................... 65
5.3.2 Sensor Rearm Behavior ................................................................................................................. 66
5.3.3 BIOS Event-Only Sensors ............................................................................................................. 67

Table of Contents Intel® Server Board S2600CW Family TPS
Revision 2.4
vi
5.3.4 Margin Sensors.................................................................................................................................. 67
5.3.5 IPMI Watchdog Sensor .................................................................................................................. 67
5.3.6 BMC Watchdog Sensor.................................................................................................................. 67
5.3.7 BMC System Management Health Monitoring..................................................................... 67
5.3.8 VR Watchdog Timer........................................................................................................................ 67
5.3.9System Airflow Monitoring........................................................................................................... 68
5.3.10 Thermal Monitoring ........................................................................................................................ 68
5.3.11 Processor Sensors ........................................................................................................................... 71
5.3.12 Voltage Monitoring.......................................................................................................................... 74
5.3.13 Fan Monitoring.................................................................................................................................. 75
5.3.14 Standard Fan Management.......................................................................................................... 77
5.3.15 Power Management Bus (PMBus*)............................................................................................ 83
5.3.16 Power Supply Dynamic Redundancy Sensor ....................................................................... 84
5.3.17 Component Fault LED Control ................................................................................................... 84
5.3.18 NMI (Diagnostic Interrupt) Sensor............................................................................................. 85
5.3.19 LAN Leash Event Monitoring....................................................................................................... 85
5.3.20 Add-in Module Presence Sensor............................................................................................... 86
5.3.21 CMOS Battery Monitoring............................................................................................................. 86
5.4 Embedded Web Server.................................................................................................................. 86
5.5 Advanced Management Feature Support (RMM4 Lite).................................................... 88
5.5.1 Keyboard, Video, Mouse (KVM) Redirection ......................................................................... 90
5.5.2 Remote Console ............................................................................................................................... 91
5.5.3 Performance....................................................................................................................................... 91
5.5.4 Security................................................................................................................................................. 92
5.5.5 Availability........................................................................................................................................... 92
5.5.6 Usage..................................................................................................................................................... 92
5.5.7 Force-enter BIOS Setup ................................................................................................................ 92
5.5.8 Media Redirection ............................................................................................................................ 92
6. Intel® Intelligent Power Node Manager (NM) Support Overview ........................................ 95
6.1 Hardware Requirements ............................................................................................................... 95
6.2Features................................................................................................................................................ 95
6.3 ME System Management Bus (SMBus*) Interface............................................................... 96
6.4 PECI 3.0 ................................................................................................................................................ 96
6.5 NM “Discovery” OEM SDR............................................................................................................. 96
6.6 SmaRT/CLST ...................................................................................................................................... 96
6.6.1 Dependencies on PMBus*-compliant Power Supply Support...................................... 97
7. Intel® Server Board S2600CW Connector/Header Locations and Pin-outs ...................... 98

Intel® Server Board S2600CW Family TPS Table of Contents
Revision 2.4
vii
7.1 Power Connectors ........................................................................................................................... 98
7.1.1 Main Power Connector .................................................................................................................. 98
7.1.2 CPU Power Connectors ................................................................................................................. 98
7.2Front Panel Header and Connectors ....................................................................................... 99
7.2.1 Front Panel Header ......................................................................................................................... 99
7.2.2 Front Panel USB Connector......................................................................................................... 99
7.3 On-board Storage Connectors................................................................................................ 100
7.3.1 SATA 6Gbps Connectors ........................................................................................................... 100
7.3.2 SAS Connectors............................................................................................................................. 101
7.3.3 HSBP I2C Header............................................................................................................................ 101
7.3.4 HDD LED Header ........................................................................................................................... 101
7.3.5 Internal Type-A USB Connector ............................................................................................. 102
7.3.6 Internal eUSB SSD Header ........................................................................................................ 102
7.3.7 M.2/NGFF Header.......................................................................................................................... 102
7.4 Management and Security Connectors................................................................................ 103
7.4.1 RMM4 Lite Connector.................................................................................................................. 103
7.4.2 TPM Connector .............................................................................................................................. 104
7.4.3 PMBus* Connector........................................................................................................................ 104
7.4.4 Chassis Intrusion Header ........................................................................................................... 104
7.4.5 IPMB Connector............................................................................................................................. 105
7.5 FAN Connectors............................................................................................................................. 105
7.5.1 System FAN Connectors ............................................................................................................ 105
7.5.2 CPU FAN Connector..................................................................................................................... 105
7.6 Serial Port and Video Connectors.......................................................................................... 106
7.6.1 Serial Port Connector.................................................................................................................. 106
7.6.2 Video Connector............................................................................................................................ 106
7.7 PCIe Riser Slot ................................................................................................................................ 107
8. Intel®Server Board S2600CW Jumper Blocks........................................................................ 111
8.1 BIOS Default and Password Reset Usage Procedure..................................................... 112
8.1.1 Set BIOS to Default (Clearing the CMOS)............................................................................ 112
8.1.2 Clearing the Password ................................................................................................................ 112
8.2 Integrated BMC Force Update Procedure........................................................................... 113
8.3 ME Force Update Jumper.......................................................................................................... 114
8.4 BIOS Recovery Jumper............................................................................................................... 115
9. Intel®Light Guided Diagnostics ................................................................................................. 116
9.15-volt Stand-by LED..................................................................................................................... 116
9.2 Fan Fault LEDs................................................................................................................................ 117

Table of Contents Intel® Server Board S2600CW Family TPS
Revision 2.4
viii
9.3 DIMM Fault LEDs ........................................................................................................................... 118
9.4 System ID LED, System Status LED, and POST Code Diagnostic LEDs .................. 119
9.4.1 System ID LED ................................................................................................................................ 119
9.4.2 System Status LED........................................................................................................................ 120
9.4.3 POST Code Diagnostic LEDs .................................................................................................... 121
10. Power Supply Specification Guidelines .................................................................................. 122
10.1 Power System Options Overview........................................................................................... 122
10.2 750-W Power Supply .................................................................................................................. 122
10.2.1 Mechanical Overview................................................................................................................... 122
10.2.2 AC Input Requirements............................................................................................................... 125
10.2.3 Efficiency........................................................................................................................................... 127
10.2.4 DC Output Specification............................................................................................................. 127
10.2.5 Protection Circuits ........................................................................................................................ 131
10.2.6 Control and Indicator Functions............................................................................................. 132
10.2.7 Thermal CLST ................................................................................................................................. 135
10.2.8 Power Supply Diagnostic “Black Box” .................................................................................. 135
10.2.9 Firmware Uploader....................................................................................................................... 135
10.3 Higer Power Common Redundant Power Distribution Board (PDB) ....................... 136
10.3.1 Mechanical Overview................................................................................................................... 136
10.3.2 DC Output Specification............................................................................................................. 137
10.3.3 Protection Circuits ........................................................................................................................ 147
10.3.4 PWOK (Power OK) Signal........................................................................................................... 148
10.3.5 PSON Signal .................................................................................................................................... 148
10.3.6 PMBus* .............................................................................................................................................. 148
11. Design and Environmental Specifications.............................................................................. 149
11.1 Intel®Server Board S2600CW Design Specifications..................................................... 149
11.2 MTBF................................................................................................................................................... 150
Appendix A: Integration and Usage Tips........................................................................................ 151
Appendix B: Compatible Intel®Server Chassis.............................................................................. 152
Appendix C: BMC Sensor Tables ...................................................................................................... 153
Appendix D: Platform Specific BMC Appendix.............................................................................. 171
Appendix E: POST Code Diagnostic LED Decoder........................................................................ 176
Appendix F: POST Error Code........................................................................................................... 184
Appendix G: Statement of Volatility................................................................................................ 191
Glossary ................................................................................................................................................. 193
Reference Documents......................................................................................................................... 196

Intel® Server Board S2600CW Family TPS Table of Contents
Revision 2.4
ix

List of Figures Intel® Server Board S2600CW Family TPS
Revision 2.4
x
List of Figures
Figure 1. Intel®Server Board S2600CW2SR and S2600CWTSR.................................................................5
Figure 2. Intel®Server Board S2600CW2R and S2600CWTR......................................................................6
Figure 3. Connector and Component Layout.....................................................................................................7
Figure 4. Mounting Hole Locations (1 of 2) .........................................................................................................8
Figure 5. Mounting Hole Locations (2 of 2) .........................................................................................................9
Figure 6. Major Connector Pin-1 Locations (1 of 2)...................................................................................... 10
Figure 7. Major Connector Pin-1 Locations (2 of 2)...................................................................................... 11
Figure 8. Primary Side Card-Side Keep-out Zone ......................................................................................... 12
Figure 9. Second Side Keep-out Zone................................................................................................................ 13
Figure 10. Rear I/O Layout of Intel®Server Board S2600CW.................................................................... 14
Figure 11. Intel®Server Board S2600CW2R/S2600CWTR Functional Block Diagram................... 15
Figure 12. Intel®Server Board S2600CW2SR/S2600CWTSR Functional Block Diagram............. 16
Figure 13. Processor Socket Assembly.............................................................................................................. 17
Figure 14. Memory Subsystem for Intel®Server Board S2600CW......................................................... 24
Figure 15. Intel®Server Board S2600CW DIMM Slot Layout..................................................................... 27
Figure 16. BIOS Setup Utility – Video Configuration Options .................................................................. 49
Figure 17. TPM Module............................................................................................................................................. 51
Figure 18. High-level Fan Speed Control Process......................................................................................... 80
Figure 19. Intel®RMM4 Lite Activation Key Location.................................................................................... 89
Figure 20. Video Connector Pin-out ................................................................................................................ 107
Figure 21. Jumper Blocks ..................................................................................................................................... 111
Figure 22. 5-volt Stand-by Status LED Location......................................................................................... 116
Figure 23. Fan Fault LED’s Location ................................................................................................................. 117
Figure 24. DIMM Fault LED’s Location............................................................................................................. 118
Figure 25. Location of System Status, System ID, and POST Code Diagnostic LEDs.................. 119
Figure 26. 750-W Power Supply Outline Drawing ..................................................................................... 122
Figure 27. Differential Noise Test Setup......................................................................................................... 130
Figure 28. Turn On/Off Timing (Power Supply Signals)........................................................................... 131
Figure 29. PSON# Required Signal Characteristic...................................................................................... 133
Figure 30. Outline Drawing .................................................................................................................................. 136
Figure 31. Airflow Diagram................................................................................................................................... 137
Figure 32. Differential Noise Test Setup......................................................................................................... 146
Figure 33. POST Code Diagnostic LED Decoder ......................................................................................... 176

Intel® Server Board S2600CW Family TPS List of Tables
Revision 2.4
xi
List of Tables
Table 1. Intel® Server Board S2600CW Feature Set........................................................................................3
Table 2. Mixed Processor Configurations ......................................................................................................... 18
Table 3. RDIMM Support.......................................................................................................................................... 25
Table 4. LRDIMM Support........................................................................................................................................ 26
Table 5. Intel®Server Board S2600CW DIMM Nomenclature................................................................... 27
Table 6. Video Modes................................................................................................................................................ 46
Table 7. External RJ45 NIC Port LED Definition............................................................................................. 53
Table 8. Setup Utility – Security Configuration Screen Fields.................................................................. 55
Table 9. ACPI Power States..................................................................................................................................... 63
Table 10. Processor Sensors.................................................................................................................................. 72
Table 11. Processor Status Sensor Implementation.................................................................................... 72
Table 12. Component Fault LEDs......................................................................................................................... 85
Table 13. Basic and Advanced Server Management Features Overview............................................. 88
Table 14. Main Power Connector Pin-out......................................................................................................... 98
Table 15. CPU_1 Power Connector Pin-out..................................................................................................... 98
Table 16. CPU_2 Power Connector Pin-out..................................................................................................... 98
Table 17. Front Panel Header Pin-out................................................................................................................ 99
Table 18. Front Panel USB 3.0 Connector Pin-out .................................................................................... 100
Table 19. SATA 6Gbps Connector Pin-out.................................................................................................... 100
Table 20. Mini-SAS HD Connectors for SATA 6Gbps Pin-out............................................................... 100
Table 21. Mini-SAS HD Connectors for SAS 12Gbps Pin-out ............................................................... 101
Table 22. HSBP I2C Header Pin-out.................................................................................................................. 101
Table 23. HDD LED Header Pin-out.................................................................................................................. 102
Table 24. Type-A USB Connector Pin-out..................................................................................................... 102
Table 25. eUSB SSD Header Pin-out ............................................................................................................... 102
Table 26. M.2/NGFF Header Pin-out................................................................................................................ 102
Table 27. RMM4 Lite Connector Pin-out........................................................................................................ 104
Table 28. TPM Connector Pin-out .................................................................................................................... 104
Table 29. PMBus* Connector Pin-out.............................................................................................................. 104
Table 30. Chassis Intrusion Header Pin-out ................................................................................................. 104
Table 31. IPMB Connector Pin-out................................................................................................................... 105
Table 32. 6-pin System FAN Connector Pin-out ........................................................................................ 105
Table 33. 4-pin System FAN Connector Pin-out ........................................................................................ 105
Table 34. CPU FAN Connector Pin-out........................................................................................................... 106
Table 35. Serial Port B Connector Pin-out .................................................................................................... 106

List of Tables Intel® Server Board S2600CW Family TPS
Revision 2.4
xii
Table 36. Video Connector Pin-out.................................................................................................................. 106
Table 37. Server Board Jumpers....................................................................................................................... 111
Table 38. System Status LED .............................................................................................................................. 120
Table 39. POST Code Diagnostic LEDs........................................................................................................... 121
Table 40. DC Output Connector ........................................................................................................................ 123
Table 41. LED Characteristics ............................................................................................................................. 124
Table 42. Power Supply LED Functionality................................................................................................... 124
Table 43. Environmental Requirements......................................................................................................... 124
Table 44. Power Factor Requirements for Computer Servers.............................................................. 125
Table 45. AC Input Voltage Range .................................................................................................................... 125
Table 46. AC Line Holdup Time ......................................................................................................................... 126
Table 47. AC Line Sag Transient Performance ............................................................................................ 126
Table 48. AC Line Surge Transient Performance........................................................................................ 127
Table 49. Silver Efficiency Requirement......................................................................................................... 127
Table 50. Minimum Load Ratings...................................................................................................................... 127
Table 51. Voltage Regulation Limits ................................................................................................................ 128
Table 52. Transient Load Requirements........................................................................................................ 128
Table 53. Capacitive Loading Conditions....................................................................................................... 128
Table 54. Ripples and Noise................................................................................................................................ 130
Table 55. Timing Requirements......................................................................................................................... 130
Table 56. Over Current Protection.................................................................................................................... 132
Table 57. Over Voltage Protection (OVP) Limits......................................................................................... 132
Table 58. PSON# Signal Characteristic........................................................................................................... 133
Table 59. PWOK Signal Characteristics .......................................................................................................... 134
Table 60. SMBAlert# Signal Characteristics.................................................................................................. 134
Table 61. Thermal Requirements...................................................................................................................... 137
Table 62. Input Connector and Pin Assignment ......................................................................................... 138
Table 63. PDB Cable Length................................................................................................................................ 138
Table 64. P1 Baseboard Power Connector ................................................................................................... 139
Table 65. P0 Processor Power Connector..................................................................................................... 140
Table 66. P1 Processor Power Connector..................................................................................................... 140
Table 67. Power Signal Connector ................................................................................................................... 140
Table 68. P12 12V Connectors .......................................................................................................................... 141
Table 69. P13-P16 12V Connectors ................................................................................................................ 141
Table 70. P8, P9 Legacy Peripheral Power Connectors........................................................................... 141
Table 71. P7, P10, P11 Legacy Peripheral Power Connectors.............................................................. 141
Table 72. SATA Peripheral Power Connectors............................................................................................ 141

Intel® Server Board S2600CW Family TPS List of Tables
Revision 2.4
xiii
Table 73. Remote Sense Connection Points ................................................................................................ 142
Table 74. Remote Sense Requirements ......................................................................................................... 142
Table 75. 12V Rail Distribution........................................................................................................................... 142
Table 76. Hard Drive 12V Rail Configuration Options.............................................................................. 143
Table 77. DC/DC Converters Load Ratings.................................................................................................... 143
Table 78. 5VSB Loading ........................................................................................................................................ 144
Table 79. Voltage Regulation Limits ................................................................................................................ 144
Table 80. Transient Load Requirements........................................................................................................ 144
Table 81. Capacitive Loading Conditions....................................................................................................... 145
Table 82. Ripple and Noise .................................................................................................................................. 145
Table 83. Output Voltage Timing...................................................................................................................... 146
Table 84. PDB Over Current Protection Limits/240VA Protection ..................................................... 147
Table 85. Over Voltage Protection (OVP) Limits......................................................................................... 147
Table 86. System PWOK Requirements ......................................................................................................... 148
Table 87. PDB Addressing.................................................................................................................................... 148
Table 88．Server Board Design Specifications........................................................................................... 149
Table 89. MTBF Estimate ...................................................................................................................................... 150
Table 90. Compatible Intel®Server Chassis .................................................................................................. 152
Table 91. Integrated BMC Core Sensors ........................................................................................................ 155
Table 92. POST Progress Code LED Example.............................................................................................. 177
Table 93. POST Progress Codes........................................................................................................................ 177
Table 94. MRC Progress Codes .......................................................................................................................... 182
Table 95. MRC Fatal Error Codes....................................................................................................................... 183
Table 96. POST Error Codes and Messages.................................................................................................. 184
Table 97. POST Error Beep Codes.................................................................................................................... 189
Table 98. Integrated BMC Beep Codes ........................................................................................................... 189

List of Tables Intel® Server Board S2600CW Family TPS
Revision 2.4
xiv
< This page intentionally left blank. >

Intel® Server Board S2600CW Family TPS Introduction
Revision 2.4
1
1. Introduction
This Technical Product Specification (TPS) provides information on the Intel®Server Board
S2600CW including architecture, features, and functionality.
In addition, you can obtain design-level information for a given subsystem by ordering the
External Product Specifications (EPS) for the specific subsystem. EPS documents are not
publicly available and you must order them through your local Intel representative.
1.1 Chapter Outline
This document is divided into the following chapters:
Chapter 1 – Introduction
Chapter 2 – Intel® Server Board S2600CW Overview
Chapter 3 – Intel® Server Board S2600CW Functional Architecture
Chapter 4 – System Security
Chapter 5 – Intel® Server Board S2600CW Platform Management
Chapter 6 – Intel® Intelligent Power Node Manager (NM) Support Overview
Chapter 7 – Intel® Server Board S2600CW Connector/Header Locations and Pin-outs
Chapter 8 – Intel® Server Board S2600CW Jumper Blocks
Chapter 9 – Intel® Light Guided Diagnostics
Chapter 10 – Power Supply Specification Guidelines
Chapter 11 – Design and Environmental Specifications
Appendix A: Integration and Usage Tips
Appendix B: Compatible Intel®Server Chassis
Appendix C: BMC Sensor Tables
Appendix D: Platform Specific BMC Appendix
Appendix E: POST Code Diagnostic LED Decoder
Appendix F: POST Error Code
Glossary
Reference Documents

Introduction Intel® Server Board S2600CW Family TPS
2 Revision 2.4
1.2 Server Board Use Disclaimer
Intel® Server Boards contain a number of high-density VLSI (Very Large Scale Integration) and
power delivery components that require adequate airflow for cooling. Intel ensures through its
own chassis development and testing that when Intel server building blocks are used
together, the fully integrated system meets the intended thermal requirements of these
components. It is the responsibility of the system integrator who chooses not to use Intel
developed server building blocks to consult vendor datasheets and operating parameters to
determine the amount of airflow required for their specific application and environmental
conditions. Intel Corporation cannot be held responsible if components fail or the server
board does not operate correctly when used outside any of the published operating or non-
operating limits.

Intel® Server Board S2600CW Family TPS Intel® Server Board S2600CW Overview
Revision 2.4
3
2. Intel® Server Board S2600CW Overview
The Intel® Server Board S2600CW is a monolithic printed circuit board (PCB) with features
designed to support the pedestal server markets. This server board is designed to support the
Intel® Xeon® processor E5-2600 v3 and Intel® Xeon® processor E5-2600 v4 product families.
Previous generation Intel® Xeon® processors are not supported.
The Intel® Server Board S2600CW family includes different board configurations:
Intel® Server Board S2600CW2R: dual 1GbE NIC ports (I350)
Intel® Server Board S2600CW2SR: dual 1GbE NIC ports (I350) and onboard SAS
controller
Intel® Server Board S2600CWTR: dual 10GbE NIC ports (X540)
Intel® Server Board S2600CWTSR: dual 10GbE NIC ports (X540) and onboard SAS
controller
2.1 Intel® Server Board S2600CW Feature Set
Table 1. Intel® Server Board S2600CW Feature Set
Feature
Description
Processors
Two LGA2011-3 (Socket R3) processor sockets
Support for one or two Intel® Xeon® E5-2600 v3 or V4 processors product family
Maximum supported Thermal Design Power (TDP) of up to 145 W
Memory

Eight memory channels (four channels for each processor socket)
Two DIMM slots for each channel
Registered DDR4 (RDIMM), Load Reduced DDR4 (LRDIMM)
DDR4 Memory data transfer rates: 1333, 1600, 1866, and 2133 MT/s
Chipset
Intel® C612 chipset
Cooling Fan Support

Two processor fans (4-pin headers)
Six front system fans (6-pin headers)
One rear system fan (4-pin header)
Add-in Card Slots

Support up to six expansion slots
From PCH:
-Slot 1: PCIe Gen II x4
From the first processor:
-Slot 5: PCIe Gen III x16 connector. Electrical x16 for S2600CW2R or
S2600CWTR, electrical x8 for S2600CW2SR or S2600CWTSR
-Slot 6 PCIe Gen III x16 electrical with x16 physical connector
From the second processor:
-Slot 2: PCIe Gen III x16 electrical with x16 physical connector
-Slot 3: PCIe Gen III x8 electrical with x8 physical connector
-Slot 4: PCIe Gen III x16 electrical with x16 physical connector

Intel® Server Board S2600CW Overview Intel® Server Board S2600CW Family TPS
4 Revision 2.4
Feature
Description
RAID Support

PCH SATA 6G
-ESRT2 RAID 0/1/10
-Optional RAID 5 is supported through the ESRT2 RAID5 upgrade key
LSI* SAS3008 SAS 12G
-Integrated RAID 0/1/1E/10
-Integrated MegaRaid 0/1/10/5/50 upgrade is supported through the
upgrade key AXXRPFKHY5
External back panel I/O
Connectors

One DB-15 video connector
Two NIC ports (I350 for 1GbE or X540 for 10GbE)
One NIC port dedicated to server management (DMN)
Two USB 3.0 ports and two USB 2.0 ports
Internal I/O
Connectors/Headers

Two 7-pin SATA 6G ports
Two mini-SAS HD connectors supporting eight SATA 6Gbps transfer rate
Two mini-SAS HD connectors supporting eight SAS 12Gbps transfer rate
(S2600CW2SR and S2600CWTSR only)
One 2x10-pin connector providing front panel support for two USB 3.0 ports
One internal Type-A USB 2.0 port
One internal USB port to support low profile eUSB SSD
One DH-10 Serial Port B connector
One 24-pin SSI-EEB compliant front panel header
One TPM connector
One M.2/NGFF connector
One RMM4 LITE connector
Video Support

Integrated 2D Video Controller
16 MB DDR3 Memory
Server Management

Support for Intel® Remote Management Module 4 solutions
Intel® Light-Guided Diagnostics on field replaceable units
Support for Intel® System Management Software
Support for Intel® Intelligent Power Node Manager (PMBus*-compliant power
supply needed)
Security
Intel® TPM – AXXTPME5 (Accessory Option)
Form Factor
SSI EEB (12”x13”)
Compatible Intel®Server
Chassis
Intel® Server Chassis P4304XXMFEN2 and P4304XXMUXX

Intel® Server Board S2600CW Family TPS Intel® Server Board S2600CW Overview
Revision 2.4
5
2.2 Server Board Layout
The following diagram shows the board layout for S2600CW2SR and S2600CWTSR with
on-board SAS controller.
Figure 1. Intel® Server Board S2600CW2SR and S2600CWTSR

Intel® Server Board S2600CW Overview Intel® Server Board S2600CW Family TPS
6 Revision 2.4
The following diagram shows the board layout for S2600CW2R and S2600CWTR without
on-board SAS controller.
Figure 2. Intel® Server Board S2600CW2R and S2600CWTR
