Intel SBCEFCSW Owner's manual

Intel®Server Switch Module SBCEFCSW
and FC Expansion Card SBFCM:
Hardware Maintenance Manual and
Troubleshooting Guide
A Guide for Technically Qualified Assemblers of Intel® Identified Subassemblies &
Products
Order Number: C46558-002

ii SBCEFCSW/SBFCM: HMM and Troubleshooting Guide
Disclaimer
Information in this document is provided in connection with Intel. products. No license, express or implied, by estoppel or otherwise, to
any intellectual property rights is granted by this document. Except as provided in Intel's Terms and Conditions of Sale for such
products.
Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of Intel products
including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright or
other intellectual property right.
Intel products are not designed, intended or authorized for use in any medical, life saving, or life sustaining applications or for any
other application in which the failure of the Intel product could create a situation where personal injury or death may occur. Intel may
make changes to specifications and product descriptions at any time, without notice.
Intel, Pentium, Itanium and Intel Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United
States and other countries.
* Other names and brands may be claimed as the property of others.
© Copyright 2003, Intel Corporation. All Rights Reserved.

iii
Contents
Safety and regulatory information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
General Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Electrical Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
Regulatory specifications and disclaimers devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
1 General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Related publications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Notices used in this book. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2 Intel® Server Switch Module SBCEFCSW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Command line interface (CLI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Logging on to a switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Command syntax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Using the SAN Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
SAN Utility user interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Using the Topology window. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Using the Faceplate window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Managing fabrics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Managing switch modules. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Managing ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Switch management utility functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
LED diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Port testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Fibre Channel switch module monitoring using SNMP. . . . . . . . . . . . . . . . . . . . . . . 121
Restoring Fibre Channel switch module configuration . . . . . . . . . . . . . . . . . . . . . . . 123
Using the Fabric View application. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Mapping port locations and software numbering. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Port mapping. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
3 Fibre Channel Expansion Card SBFCM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Features and specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Inventory checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Notices and statements used in this book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Major components of the Expansion Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Installing the Expansion Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
Installation guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
Installing the Expansion Card in the blade server. . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Using Fast!UTIL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Starting Fast!UTIL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Configuration Settings menu options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
4 Diagnostic information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
General Fibre Channel configuration diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
General Checkout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145

iv SBCEFCSW/SBFCM: HMM and Troubleshooting Guide
5 Symptom-to-FRU index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
Fast!UTIL utility status codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
Switch error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
Expansion card error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Management module error messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
Switch diagnostic information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
LED error codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
I2C diagnostic register definitions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
Undetermined problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
Problem determination tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
6 Parts listing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Intel® Server Switch Module SBCEFCSW. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Fibre Channel Expansion Card SBFCM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158
A Getting help and technical assistance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
Before you call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
Using the documentation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
Hardware/Software service and support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159

v
Safety and regulatory information
✏ NOTE
The service procedures are designed to help you isolate problems. They are written with the
assumption that you have model-specific training on all computers, or that you are familiar
with the computers, functions, terminology, and service information provided in this manual.

vi SBCEFCSW/SBFCM: HMM and Troubleshooting Guide
General Safety
Follow these rules to ensure general safety:
•Observe good housekeeping in the area of the machines during and after maintenance.
•Do not perform any action that causes hazards to the customer, or makes the equipment unsafe.
•Keep your tool case away from walk areas so that other people will not trip over it.
•Do not wear loose clothing that can be trapped in the moving parts of a machine. Ensure that
your sleeves are fastened or rolled up above your elbows. If your hair is long, fasten it.
•Insert the ends of your necktie or scarf inside clothing, or fasten it with a nonconductive clip,
approximately 8 centimeters (3 inches) from the end.
•Do not wear jewelry, chains, metal-frame eyeglasses, or metal fasteners for your clothing.
Remember: Metal objects are good electrical conductors.
•Wear safety glasses when you are: hammering, drilling soldering, cutting wire, attaching
springs, using solvents, or working in any other conditions that might be hazardous to your eyes.
•After service, reinstall all safety shields, guards, labels, and ground wires. Replace any safety
device that is worn or defective.
•Reinstall all covers correctly before returning the machine to the customer.
Electrical Safety
xxCAUTION:
Electrical current from power, telephone, and communication cables can be hazardous. To
avoid personal injury or equipment damage, disconnect the server system power cords,
telecommunication systems, networks, and modems before you open the server covers, unless
instructed otherwise in the installation and configuration procedures.
✏ Important: Disconnect all power before performing a mechanical
inspection. Observe the following rules when working on electrical
equipment.
•Before you start to work on the machine, unplug the power cord or power-off at the wall box that
supplies power to the machine and to lock the wall box in the off position.
•Before you start to work on the machine, unplug the power cord. If you cannot unplug it, ask the
customer to power-off the wall box (that supplies power to the machine) and to lock the wall box
in the off position.
•Regularly inspect and maintain your electrical hand tools for safe operational condition.
•Do not use worn or broken tools and testers.
•Never assume that power has been disconnected from a circuit. First, check that it has been
powered-off.
•Always look carefully for possible hazards in your work area. Examples of these hazards are
moist floors, nongrounded power extension cables, power surges, and missing safety grounds.

Safety and regulatory information vii
•Do not touch live electrical circuits with the reflective surface of a plastic dental inspection
mirror. The surface is conductive; such touching can cause personal injury and machine damage.
Handling electrostatic discharge-sensitive devices
Any computer part containing transistors or integrated circuits (IC) should be considered sensitive to
electrostatic discharge (ESD). ESD damage can occur when there is a difference in charge between
objects. Protect against ESD damage by equalizing the charge so that the server, the part, the work
mat, and the person handling the part are all at the same charge.
✏ NOTE
Use product-specific ESD procedures when they exceed the requirements noted here.
Make sure that the ESD-protective devices you use have been certified (ISO 9000) as fully
effective.
When handling ESD-sensitive parts:
•Keep the parts in protective packages until they are inserted into the product.
•Avoid contact with other people.
•Wear a grounded wrist strap against your skin to eliminate static on your body.
•Prevent the part from touching your clothing. Most clothing insulates and retains a charge even
when you are wearing a wrist strap.
•Use the black side of a grounded work mat to provide a static-free work surface. The mat is
especially useful when handling ESD-sensitive devices.
•Select a grounding system, such as those in the following list, to provide protection that meets
the specific service requirement.
✏ NOTE
The use of a grounding system is desirable but not required to protect against ESD damage.
Attach the ESD ground clip to any frame ground, ground braid, or green-wire ground.
Use an ESD common ground or reference point when working on a double-insulated or
battery-operated system. You can use coax or connector-outside shells on these systems.
Use the round ground-prong of the AC plug on AC-operated computers.

viii SBCEFCSW/SBFCM: HMM and Troubleshooting Guide
DANGER
Electrical current from power, telephone and communication cables is hazardous.
To avoid a shock hazard:
•Do not connect or disconnect any cables or perform installation, maintenance, or
reconfiguration of this product during an electrical storm.
•Connect all power cords to a properly wired and grounded electrical outlet.
•Connect to properly wired outlets any equipment that will be attached to this product.
•When possible, use one hand only to connect or disconnect signal cables.
•Never turn on any equipment when there is evidence of fire, water, or structural damage.
•Disconnect the attached power cords, telecommunications systems, networks, and
modems before you open the device covers, unless instructed otherwise in the
installation and configuration procedures.
•Connect and disconnect cables as described in the following table when installing,
moving, or opening covers on this product or attached devices.
To Connect To Disconnect
1. Turn everything OFF.
2. First, attach all cables to devices.
3. Attach signal cables to connectors.
4. Attach power cords to outlet.
5. Turn device ON.
1. Turn everything OFF.
2. First, remove power cords from outlet.
3. Remove signal cables from connectors.
4. Remove all cables from devices.

Safety and regulatory information ix
xxCAUTION:
If your system has a module containing a lithium battery, replace it only with the same or an
equivalent type battery recommended by the manufacturer. If your system has a module containing
a lithium battery, replace it only with the same module type made by the same manufacturer. The
battery contains lithium and can explode if not properly used, handled, or disposed of.
Do not:
•Throw or immerse into water
•Heat to more than 100°C (212°F)
•Repair or disassemble
Dispose of the battery as required by local ordinances or regulations.
xxCAUTION:
When laser products (such as CD-ROMs, DVD-ROM drives, fiber optic devices, or transmitters)
are installed, note the following:
•Do not remove the covers. Removing the covers of the laser product could result in
exposure to hazardous laser radiation. There are no serviceable parts inside the device.
•Use of controls or adjustments or performance of procedures other than those specified
herein might result in hazardous radiation exposure.
✏ DANGER
✏ Some laser products contain an embedded Class 3A or Class 3B laser diode. Note the
following:
Laser radiation when open. Do not stare into the beam, do not view directly with optical
instruments, and avoid direct exposure to the beam.
xxCAUTION:
Hazardous energy is present when the blade is connected to the power source. Always replace the
blade cover before installing the blade.

xSBCEFCSW/SBFCM: HMM and Troubleshooting Guide
Regulatory specifications and disclaimers
Safety compliance:
USA: UL 60950 - 3rd Edition/CSA 22.2. No. 60950
Canada: cUL certified - 3rd Edition/CSA 22.2. No. 60950- for Canada (product bears the single
cUL mark for U.S. and Canada)
Europe: Low Voltage Directive, 73/23/EEC
TUV/GS to EN60950 2nd Edition with Amendments, A1 = A2+A3+A4
International: UL/CB to IEC 60950 3rd Edition
UL/CB - EN60 950 3rd Edition
UL/CB - EMKO-TSE (74-SEC) 207/94
Australia/New
Zealand: CB Report to IEC 60950, 3rd Edition plus international deviations

Safety and regulatory information xi
Electromagnetic compatibility notices (USA):
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses and can radiate radio frequency energy and if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his/her own expense.
✏ NOTE
Class A device definition: If a Class A device is installed within the is system, then the system
is to be considered a Class A system. In this configuration, operation of this equipment in a
residential area is likely to cause harmful interference.
Electromagnetic compatibility (EMC):
USA: FCC CFR 47 Part 2 and 15, Verified Class A Limit
Canada: IC ICES-003 Class A Limit
Europe: EMC Directive, 89/336/EEC
EN55022, Class A Limit, Radiated & Conducted Emissions
EN55024 ITE Specific Immunity Standard
EN61000-4-2 ESD Immunity (Level 2 Contact Discharge, Level 3 Air Discharge)
EN61000-4-3 Radiated Immunity (Level 2)
EN61000-4-4 Electrical Fast Transient (Level 2)
EN61000-4-5 AC Surge
EN61000-4-6 Conducted RF
EN61000-4-8 Power Frequency Magnetic Fields
EN61000-4-11 Voltage Dips and Interrupts
Japan: VCCI Class A ITE (CISPR 22, Class A Limit)
Australia/New
Zealand: AS/NZS 3548, Class A Limit
Taiwan: BSMI Approval
Korea: RRL Approval
Russia: GOST Approval
International: CISPR 22, Class A Limit

xii SBCEFCSW/SBFCM: HMM and Troubleshooting Guide
Electromagnetic compatibility notices (International):
Europe (CE Declaration of Conformity): This product has been tested in accordance to, and
complies with the Low Voltage Directive (73/23/EEC) and EMC Directive (89/336/EEC). The
product has been marked with the CE Mark to illustrate its compliance.
Japan EMC Compatibility:
English translation of the notice above: This is a Class A product based on the standard of the
Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this
equipment is used in a domestic environment, radio disturbance may arise. When such trouble
occurs, the user may be required to take corrective actions.
ICES-003 (Canada): Cet appareil numérique respecte les limites bruits radioélectriques
applicables aux appareils numériques de Classe A prescrites dans la norme sur le matériel brouilleur:
"Appareils Numériques", NMB-003 édictée par le Ministre Canadian des Communications.
English translation of the notice above: This digital apparatus does not exceed the Class A limits
for radio noise emissions from digital apparatus set out in the interference-causing equipment
standard entitled "Digital Apparatus," ICES-003 of the Canadian Department of Communications.
BSMI (Taiwan): The BSMI Certification number and the following warning is located on the
product safety label which is located visibly on the external chassis.

Safety and regulatory information xiii
RRL Korea:
English translation of the notice above: If this device is certified by MIC-RRL (Korea EMC
requirement), the following user’s information shall be put on the conspicuous location of the front
page of user’s manual.
Device User’s Information
Class A device This device complies with RRL EMC and is operated
in commercial environment so that distributors or
users pay attention to this point.
If the product is sold or purchased improperly, please
exchange this product to what can be used at home.
Class B device This device complies with RRL EMC and is operated
in a residential area so that it can be used at all other
location as well as residential area.
Remarks: Class A device - operated in a commercial area. Class B device - operated in a residential area.

xiv SBCEFCSW/SBFCM: HMM and Troubleshooting Guide
<This page intentionally left blank>

1
1 General information
Fibre Channel technology is outlined in the SCSI-3 Fibre Channel Protocol (SCSI-FCP) standard.
Fibre Channel is a high-speed data transport technology used for mass storage and networking.
By adding Fibre Channel Expansion Cards to the blade servers and Fibre Channel switch modules to
the SBCE unit, you can attach the blade server to an external storage area network (SAN) through
the external 2 Gbps (gigabits per second) optical ports on the switch modules. The Fibre Channel
Expansion Card supports data-transfer rates up to 200 MB per second half-duplex and 400 MB per
second full-duplex.
Related publications
This Hardware Maintenance Manual and Troubleshooting Guide contains information to help you
solve problems yourself or to provide helpful information to a service technician.
In addition to this Hardware Maintenance Manual and Troubleshooting Guide, the following related
documentation is provided with your switch module:
•Intel® Server Switch Module SBCEFCSW Management and User’s Guide
This publication describes how to use the Intel® Fibre Channel Manager Module Utility, also
known as SAN utility. In addition, it describes how to start the Telnet CLI and lists the CLI
commands and their usage.
The Intel® Fibre Channel Manager Module Utility will be referred to throughout this book as
the SAN Utility.
•Intel® Server Switch Module SBCEFCSW Installation Guide
This publication contains detailed installation instructions for the switch module. This
publication also provides general information about your switch module, including information
about features, how to install and set up your switch module, how to install the SAN Utility
application, and how to get help.
•Intel® Server FC Expansion Card SBFCM Installation and User’s Guide
This publication contains instructions for installing your Fibre Channel Expansion Card in an
blade server and information about:
—Configuring the Expansion Card
—Updating the BIOS code and device drivers of the Expansion card
•Intel® SAN Solutions Guide
This publication is provided in PDF on the Resource CD. It provides a user-oriented discussion
of how Fibre Channel options are used to provide different SAN storage solutions for various
application requirements. This document also provides an overview and description for backup
and restore, business continuance and high availability, and storage consolidation and data
sharing solutions.
•Intel® Switch Interoperability Guide
This publication is provided in PDF on the Resource CD. It provides detailed Fibre Channel
switch module configuration data and step-by-step configuration procedures for integrating the

2 SBCEFCSW/SBFCM: HMM and Troubleshooting Guide
SBCE unit into other vendor switch fabrics. Each vendor configuration includes an initial
integration checklist, configuration limitations, supported switch and firmware versions, specific
management application operations, and a successful-integration checklist.
•Safety Information
This multilingual publication is provided in PDF on the Resource CD. It contains translated
versions of the caution and danger statements that appear in the documentation. Each caution
and danger statement has a number, which you can use to locate the corresponding statement in
your language.
Depending on your blade server model, additional publications might be included on the Resource
CD.
Notices used in this book
The following notices are used in this book:
•Notes: These notices provide important tips, guidance, or advice.
•Important: These notices provide information or advice that might help you avoid inconvenient
or problem situations.
•Attention: These notices indicate potential damage to programs, devices, or data. An attention
notice is placed just before the instruction or situation in which damage could occur.

3
2Intel
®Server Switch Module SBCEFCSW
You can manage and configure your Fibre Channel Switch Module through a Telnet connection to
the embedded command line interface (CLI) or by using the SAN Utility application. The SAN
Utility provides an intuitive graphical user interface (GUI) that you can use to configure multiple
Fibre Channel switch modules through other connected SAN devices from a single interface. The
SAN Utility application is referred to throughout this publication as the SAN Utility. The Fibre
Channel Switch Module is referred to throughout this publication as the switch module.
This Guide provides instructions to:
•Configure your switch module
•Manage fabrics, ports, and switch modules
•Use Telnet and the CLI to configure switch module parameters
You can manage the SBCE fabric through an Ethernet network using the SAN Utility or the CLI.
The SAN Utility is installed on a Microsoft®Windows®2003, Red Hat Linux®Advanced Server
Version 2.1 or Red Hat Linux Version 9.0.
The switch module has an embedded Telnet server through which a Telnet client can connect and
manage the switch module using the CLI. See “Command line interface (CLI)” for more
information about Telnet and CLI commands.
SNMP provides monitoring and trap functions for the fabric. The switch module firmware supports
SNMP Versions 1, 2, and 3; the Fibre Alliance Management Information Base (FA-MIB) version
4.0; and the Fabric Element Management Information Base (FE-MIB) RFC 2837. Traps are
formatted using SNMP version 2.
If you are an experienced user, you can use the Telnet CLI to perform the following tasks:
•Manage the switch module from the SBCE management module interface to the Telnet client
•Perform single switch management
•Use advanced control commands
If you are a new user or if you need to manage multiple switch modules from a single interface, you
can use the SAN Utility GUI to perform the following tasks:
•Manage your switch module from a remote client or network management workstation
•Manage your multiswitch fabric
For information about installing the switch module and the SAN Utility, see the Switch Module
Installation Guide that comes with the switch module.
Command line interface (CLI)
Your switch module contains an embedded Telnet server. This server enables a Telnet client to
establish a Telnet session with the switch module to retrieve information or to configure parameters
using the CLI. You can use the CLI to perform a variety of fabric and switch management tasks
through an Ethernet connection to your SBCE unit.
You can access the Telnet interface in two ways:

4 SBCEFCSW/SBFCM: HMM and Troubleshooting Guide
•In the SBCE management module Web interface
•In a command-line window on a connected network management workstation
Important: Before you configure your switch module, be sure that the management modules in
your SBCE unit are properly configured. In addition, to access and manage your switch module
from an external environment, you might need to enable certain features, such as the external ports
and external management over all ports. See the applicable SBCE Installation and User’s Guide
publications on the Resource CD for more information. For more detailed information about
configuring your switch module, see the Fibre Channel Switch Module Installation Guide on the
Resource CD.
Logging on to a switch
To log on to a switch using Telnet, complete the following steps:
1. Open a command-line window on the network management workstation, type one of the
following commands, and press Enter.
For I/O module bay 3:
telnet 192.168.70.129
For I/O module bay 4:
telnet 192.168.70.130
A command prompt window opens.
2. At the Login prompt, type the initial default user ID, USERID. At the Password prompt, type
the initial default password, PASSW0RD (the sixth character is a zero, not the letter O). The user
ID and password are case sensitive.
This user account provides full access to the switch and its configuration. After planning your fabric
management needs and creating your own user accounts, consider changing the password for this
account. See “Commands” on page 5 for more information about authority levels. See the “User
command” on page 57 for information about creating user accounts.
✏ NOTE
The switch module supports a combined maximum of 15 logins. This includes the SAN
Utility in-band and out-of-band logins, Telnet out-of-band logins, and SNMP out-of-band
logins. A maximum of 10 SAN Utility logins are accepted. Additional logins will be refused.
Command syntax
The command syntax is as follows:
command
keyword
keyword [value]
keyword [value1] [value2]
The command is followed by one or more keywords. Consider the following rules and conventions:
•Commands and keywords are lowercase and case sensitive.
•Required keyword values are shown in standard font: [value]. Optional values are shown in
italics: [value].

Intel® Server Switch Module SBCEFCSW 5
•The underlined portion of each keyword indicates the abbreviated form that can be used. For
example the Delete keyword can be abbreviated Del.
Commands
The command set provides for User and Admin authority levels.
•User authority grants viewing access to the fabric and switches using the Show command and
other read-only commands.
•Admin authority includes the User authority and grants permission to use the Admin command.
The Admin Start command opens an admin session, which provides access to the commands
that change switch and fabric configurations. See the “Admin command” on page 7.
✏ NOTE
Admin authority is enforced only if fabric security is enabled on the switch. By default,
fabric security is disabled. See the keywords of the “Set Setup command” on page 34 for
information about setting fabric security.
The commands and their page numbers are listed by authority level in Table 1 on page 6 The
following Admin session commands have some keywords that are available with User authority:
Alias
Config
Date
Set
User
Zone
Zoneset
Zoning

6 SBCEFCSW/SBFCM: HMM and Troubleshooting Guide
Table 1. Commands listed by authority level
User authority commands Admin authority command
Help “Help command” on page 14.
History “History command” on page 15.
Ps “Ps command” on page 18.
Quit “Quit command” on page 19.
Show “Show command” on page 38.
Show Config “Show Config command” on page
45.
Show Log “Show Log command” on page 48.
Show Perf “Show Perf command” on page 50.
Show Setup “Show Setup command” on page
52.
Uptime “Uptime command” on page 56.
Whoami “Whoami command” on page 58
.
.
Admin “Admin command” on page 7
Admin session commands
Alias “Alias command” on page 8.
Config “Config command” on page 10.
Date “Date command” on page 12.
Fallback “Fallback command” on page 13.
Image “Image command” on page 16.
Lip “Lip command (for external ports
only)” on page 16.
Passwd “Passwd command” on page 17.
Reset “Reset command” on page 19.
Set “Set command” on page 23.
Set Config “Set Config command” on page 24.
Set Log “Set Log command” on page 30.
Set Port “Set Port command” on page 33.
Set Setup “Set Setup command” on page 34.
Shutdown “Shutdown command” on page 54.
Test “Test command” on page 54.
User “User command” on page 57.
Zone “Zone command” on page 59.
Zoneset “Zoneset command” on page 62.
Zoning “Zoning command” on page 64
.
