Intel Platform Panel PC Operating instructions

Intel®Platform Panel PC
USER’S MANAUL
Version 1.4

PanelPC USER’SMANUAL
Intel Platform, High Performance PPC 1
Content
FCC Statement................................................................................................................. 6
Copyright Notice............................................................................................................... 6
Trademark Acknowledgement........................................................................................ 6
Disclaimer.......................................................................................................................... 6
Safety Precautions........................................................................................................... 7
Packing List....................................................................................................................... 7
Winmate Customer Service............................................................................................ 7
Safety and Warranty........................................................................................................ 8
Chapter 1 General Information.................................................................................... 9
1.1 Product Overview ........................................................................................ 10
1.2 Features........................................................................................................ 10
1.3 System Specification...................................................................................... 11
1.4 LCD Specification ........................................................................................ 12
1.5 Mechanical Drawing.................................................................................... 14
1.6 Input / Output Devices ................................................................................ 15
Chapter 2 Hardware Installation ............................................................................... 17
2.1 DVD ROM Installation................................................................................. 17
2.2 HDD Installation........................................................................................... 18
Chapter 3 Settings Jumpers and Connectors......................................................... 21
3.1 Jumpers and Connectors........................................................................... 21
3.1.1 Jumper and Connector Layout.................................................................... 21
3.1.2 Jumpers and Connectors............................................................................. 22
3.2 Setting Jumpers........................................................................................... 24
3.2.1 CPU Host Clock(JP1)..................................................................................... 24
3.2.2 Power Mode Setting(JP2).............................................................................. 24
3.2.3 LVDS Power Setting(JP3).............................................................................. 24
3.2.4 1394 Controller EEPROM Write Protect(JP4)............................................ 24
3.2.5 RS232/422/485 (COM2) Selection(JP6, JP7, JP8)................................... 25
3.2.6 COM2 RS232 Pin9 Setting(JP9).................................................................. 25
3.2.7 COM1 RS232 Pin9 Setting(JP10)................................................................ 25
3.2.8 Clear CMOS Contents(JP11)........................................................................ 26
3.2.9 Compact Flash Mode Setting(JP13)............................................................ 26
3.2.10 Intel® 82541GI Gigabit LAN Enable/Disable(J13) .................................. 26
3.3 Connector Definitions.................................................................................. 27
3.3.1 DC Jack for DC Adaptor (CN1)...................................................................... 27
3.3.2 PS/2 Keyboard and PS/2 Mouse Connectors (CN2)................................. 27

PanelPC USER’SMANUAL
Intel Platform, High Performance PPC 2
3.3.3 DVI-I Connector (CN3)................................................................................... 27
3.3.4 Parallel Port Connector (CN4)...................................................................... 28
3.3.5 RJ45 and 2 USB Ports (CN6)....................................................................... 28
3.3.6 COM1 and COM2 Serial Ports (CN7).......................................................... 28
3.3.7 HDD Power Connector (J2) .......................................................................... 29
3.3.8 Internal DC-In Power Connector (J3).......................................................... 29
3.3.9 LCD Backlight Setting (J5)............................................................................ 29
3.3.10 Panel Connectors (1st channel, 2nd channel) (J6, J8) ............................ 29
3.3.11 IrDA Connector (J7)........................................................................................ 30
3.3.12 Digital I/O (J10)............................................................................................... 30
3.3.13 USB Port Pin Header (J11, J12) .................................................................. 30
3.3.14 HDD Power Pin Header (J16)...................................................................... 30
3.3.15 Mini PCI Socket (J17).................................................................................... 30
3.3.16 Primary and Secondary IDE Connectors (J18, J19)................................. 31
3.3.17 Secondary IDE Connector (J19).................................................................. 31
3.3.18 CD-In Pin Header (J20)................................................................................. 32
3.3.19 External Audio Connector (J21)................................................................... 32
3.3.20 System Function Connector (J22)............................................................... 32
3.3.21 Wake On LAN Connector (J23).................................................................... 33
3.3.22 Compact Flash Socket (J24) ........................................................................ 34
3.3.23 VGA CRT Connector (J25)............................................................................ 34
3.3.24 CPU Fan Power Connector (FAN1)............................................................. 34
3.3.25 System Fan Power Connector (FAN2)........................................................ 34
Chapter 4 AWARD BIOS Setup.................................................................... 36
4.1 Starting Setup............................................................................................... 36
4.2 Using Setup.................................................................................................. 37
4.2.1 Navigating Through The Menu Bar................................................................. 37
4.2.2 To Display a Sub Menu..................................................................................... 37
4.3 Getting Help.................................................................................................. 38
4.4 In Case of Problems.................................................................................... 38
4.5 Main Menu.................................................................................................... 38
4.5.1 Standard CMOS Features................................................................................ 39
4.5.1.1 Main Manu Selection...................................................................................... 40
4.5.1.2 IDE Adapters ................................................................................................... 41
4.5.2 Advanced BIOS Features................................................................................. 42
4.5.2.1 CPU Feature.................................................................................................... 42
4.5.2.2 Virus Warning.................................................................................................. 42
4.5.2.3 CPU L1 and L2 Cache / CPU L3 Cache..................................................... 42
4.5.2.4 Quick Power On Self Test ............................................................................. 43

PanelPC USER’SMANUAL
Intel Platform, High Performance PPC 3
4.5.2.5 First/Second/Third Boot Device.................................................................. 43
4.5.2.6 Boot Other Device........................................................................................ 43
4.5.2.7 Swap Floppy Drive ....................................................................................... 43
4.5.2.8 Boot Up Floppy Seek................................................................................... 43
4.5.2.9 Boot Up NumLock Status............................................................................ 43
4.5.2.10 Gate A20 Option........................................................................................... 43
4.5.2.11 Typematic Rate Setting................................................................................ 43
4.5.2.12 Typematic Rate (Chars/Sec) ...................................................................... 43
4.5.2.13 Typematic Delay (Msec).............................................................................. 44
4.5.2.14 Security Option............................................................................................. 44
4.5.2.15 APIC Mode.................................................................................................... 44
4.5.2.16 MPS Version Control for OS....................................................................... 44
4.5.2.17 OS Select for DRAM > 64MB..................................................................... 44
4.5.2.18 Report No FDD For WIN 95 ....................................................................... 44
4.5.2.19 Small Logo (EPA) Show.............................................................................. 44
4.5.3 Advanced Chipset Features............................................................................. 45
4.5.3.1 DRAM Timing Selectable .............................................................................. 45
4.5.3.2 CAS Latency Time.......................................................................................... 45
4.5.3.3 Active to Precharge Delay ............................................................................ 45
4.5.3.4 DRAM RAS# to CAS# Delay........................................................................ 45
4.5.3.5 DRAM RAS# Precharge................................................................................ 46
4.5.3.6 DRAM Data Integrity Mode........................................................................... 46
4.5.3.7 MGM Core Frequency................................................................................... 46
4.5.3.8 System BIOS Cacheable .............................................................................. 46
4.5.3.9 Video BIOS Cacheable.................................................................................. 46
4.5.3.10 Memory Hole At 15M-16M.......................................................................... 46
4.5.3.11 Delayed Transaction.................................................................................... 46
4.5.3.12 Delay Prior to Thermal................................................................................. 46
4.5.3.13 AGPAperture Size....................................................................................... 47
4.5.3.14 On-Chip VGA................................................................................................ 47
4.5.3.15 On-Chip Frame Buffer Size........................................................................ 47
4.5.3.16 Boot Display.................................................................................................. 47
4.5.3.17 TV Standard.................................................................................................. 47
4.5.3.18 Video Connector........................................................................................... 47
4.5.3.19 TV Format...................................................................................................... 47
4.5.3.20 Panel Scaling................................................................................................ 47
4.5.3.21 Panel Number............................................................................................... 47
4.5.3.22 Panel Protocol .............................................................................................. 48
4.5.4 Integrated Peripherals....................................................................................... 48
4.5.4.1 OnChip Primary/Secondary PCI IDE........................................................... 49

PanelPC USER’SMANUAL
Intel Platform, High Performance PPC 4
4.5.4.2 IDE Primary/Secondary Master/Slave PIO................................................. 49
4.5.4.3 IDE Primary/Secondary Master/Slave UDMA............................................ 49
4.5.4.4 IDE HDD Block Mode.................................................................................... 50
4.5.4.5 USB Controller................................................................................................ 50
4.5.4.6 USB 2.0 Controller......................................................................................... 50
4.5.4.7 USB Keyboard Support................................................................................. 50
4.5.4.8 USB Mouse Support...................................................................................... 50
4.5.4.9 AC97 Audio ..................................................................................................... 50
4.5.4.10 Init Display First............................................................................................ 50
4.5.4.11 Power OnAfter Fail...................................................................................... 50
4.5.4.12 Onboard FDC Controller............................................................................. 50
4.5.4.13 Onboard Serial/Parallel Port....................................................................... 51
4.5.4.14 UART Mode Select ...................................................................................... 51
4.5.4.15 Parallel Port Mode........................................................................................ 51
4.5.5 Power Management Setup............................................................................... 51
4.5.5.1 Power Supply Type........................................................................................ 52
4.5.5.2 ACPI Function................................................................................................. 52
4.5.5.3 Power Management....................................................................................... 52
4.5.5.4 Video Off Method........................................................................................... 52
4.5.5.5 Video Off In Suspend.................................................................................... 53
4.5.5.6 Suspend Type................................................................................................ 53
4.5.5.7 Modem Use IRQ............................................................................................ 53
4.5.5.8 Suspend Mode............................................................................................... 53
4.5.5.9 HDD Power Down......................................................................................... 53
4.5.5.10 Soft-Off by PWRBTN.................................................................................. 53
4.5.5.11 CPU THRM-Throttling................................................................................. 53
4.5.5.12 Wake up by PCI Card................................................................................. 53
4.5.7.1 CPU Warning Temperature.......................................................................... 55
4.5.7.2 Temperatures/Voltages................................................................................. 55
4.5.7.3 Shutdown Temperature ................................................................................ 55
4.5.7.4 Smart Fan Temperature ............................................................................... 55
4.5.8 Frequency/Voltage Control.............................................................................. 56
4.5.8.1 Auto Detect PCI Clk...................................................................................... 56
4.5.8.2 Spread Spectrum Modulated....................................................................... 56
4.5.9 Load Fail-Safe Defaults................................................................................... 56
4.5.10 Load Optimized Defaults............................................................................... 56
4.5.11 Set Supervisor Password.............................................................................. 56
4.5.12 Save & Exit Setup .......................................................................................... 57
4.5.13 Exit Without Saving........................................................................................ 57

PanelPC USER’SMANUAL
Intel Platform, High Performance PPC 5
Chapter 5 Driver Installation...................................................................................... 59
5.1 Intel Chipset Software Installation Utility.................................................. 59
5.2 VGA Drivers Installation.............................................................................. 61
5.3 AC97 Codec Audio Driver Installation...................................................... 62
5.4 Intel PRO LAN Drivers Installation............................................................ 63
Chapter 6 Touch Screen ............................................................................................ 64
6.1 Introduction................................................................................................... 65
6.2 The Elo AccuTouch Driver Installation...................................................... 65
6.2.1 Configuration Utility.......................................................................................... 66
6.3 The Premier Touch Driver Installation...................................................... 68
6.3.1 Configuration Utility.......................................................................................... 69

PanelPC USER’SMANUAL
Intel Platform, High Performance PPC 6
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION
IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED PERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE
LIMITS FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE
FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE
PROTECTION AGAINTST HARMFUL INTERFERENCE WHEN THE
EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. THIS
EQUIPMENT GENERATES, USES, AND CAN RADIATE RADIO FREQUENCY
ENERGY AND, IF NOT INSTATLLED AND USED IN ACCORDANCE WITH THE
INSTRUCTION MANUAL, MAY CAUSE HARMFUL INTERFERENCE TO RADIO
COMMUNICATIONS. OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL
AREAIS LIKELY TO CAUSE HARMFULINTERFERENCE IN WHICH CASE THE
USER WILL BE REQUIRED TO CORRECT THE INTERFERENCE AT HIS OWN
EXPENSE.
Copyright Notice
Copyright © 2006 Winmate Technology Inc., ALL RIGHTS RESERVED.
No part of this document may be reproduced, copied, translated, or transmitted in
any form or by any means, electronic or mechanical, for any purpose, without the
prior written permission of the original manufacturer.
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their
respective owners.
Disclaimer
Winmate Communication Inc. reserves the right to make changes, without notice,
to any product, including circuits and/or software described or contained in this
manual in order to improve design and/or performance. Winmate Communication
assumes no responsibility or liability for the use of the described product(s),
conveys no license or title under any patent, copyright, or masks work rights to
these products, and makes no representations or warranties that these products
are free from patent, copyright, or mask work right infringement, unless otherwise
specified. Applications that are described in this manual are for illustration
purposes only. Winmate Communication Inc. makes no representation or
warranty that such application will be suitable for the specified use without further
testing or modification.

PanelPC USER’SMANUAL
Intel Platform, High Performance PPC 7
Safety Precautions
◆Warning! Always completely disconnect the power cord from your chassis
whenever you work with the hardware. Do not make connections
while the power is on. Sensitive electronic components can be
damaged by sudden power surges. Only experienced electronics
personnel should open the PC chassis.
◆Caution!
Always ground yourself to remove any static charge before touching
the CPU card. Modern electronic devices are very sensitive to static
electric charges. As a safety precaution, use a grounding wrist strap
at all times.
Place all electronic components in a static-dissipative surface or
static-shielded bag when they are not in the chassis.
Packing List
Before using this Panel PC, please make sure that all the items listed below are
present in your package：
Panel PC
User's manual
Power adapter
Power cord
Driver CD-ROM disc
If any of these items are missing or damaged, contact your distributor or sales
representative immediately.
Winmate Customer Service
Winmate provide service guide for any problem as follow steps：First, visit the
Winmate web site at www.winmate.com to find the update information about the
product. Second, contact with your distributor, sales representative, or Winmate's
customer service center for technical support if you need additional assistance.
You may have the following information ready before you call :
Product serial number
Peripheral attachments
Software (OS, version, application software, etc.)
Description of complete problem
The exact wording of any error messages
In addition, free technical support is available from Winmate’s engineers every
business day. We are always ready to give advice on application requirements or
specific information on the installation and operation of any of our products.
Please do not hesitate to call or e-mail us.

PanelPC USER’SMANUAL
Intel Platform, High Performance PPC 8
Safety and Warranty
1. Please read these safety instructions carefully.
2. Keep this user's manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Do not use
liquid or spray detergents for cleaning. Use a damp cloth.
4. For pluggable equipment, the power outlet must be installed near the
equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall could cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power
source to avoid damage by transient over-voltage.
12. Never pour any liquid into an opening. This could cause fire or electrical
shock.
13. Never open the equipment. For safety reasons, only qualified service
personnel should open the equipment.
14. If any of the following situations arises, get the equipment checked by service
personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work according to the
users manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED
ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS BELOW -20° C
(-4°F) OR ABOVE 60° C (140° F). IT MAY DAMAGE THE EQUIPMENT.

PanelPC USER’SMANUAL
Intel Platform, High Performance PPC 9
General Information
This chapter gives background information to the Panel PC.
Sections include:
zProduct Overview
zFeatures
zSystem Specification
zLCD Specification
zMechanical Dimensions
zInput / Output Devices
1
C A P T E R

PanelPC USER’SMANUAL
Intel Platform, High Performance PPC 10
The product is a high performance Panel PC with Intel 855GME chipset
motherboard and combine with a TFT LCD Panel. It is a compact design to meet
the demanding performance requirements of today’s business and industrial
applications.
1.1 Product Overview
Panel PC combines a motherboard, LCD Display within a compact chassis, with
an option to add on HDD, FDD, CD-ROM, and touch screen as a matter of
preference.
1.2 Features
CPU Onboard:
The PPC is designed for Intel® Pentium® / Celeron® M CPU onboard, which is
equipped with a high performance and low power processor, an advanced
multi-I/O, provides all the performance, reliability, and quality.
LCD Display:
The PPC is equipped with a TFT LCD size from 8.4” to 42”.
Power Management：
The PPC supports DC input power supply with a power adapter. Supports AC97,
LAN wake up and modem ring-in functions. I/O peripheral devices support power
saving and doze/standby/suspend modes.
DVD / HDD Solution：
The Panel PC also provides one Standard Slim DVD ROM/Combo/Dual (Optional)
for choice.
Figure 1.1 Product Overview

PanelPC USER’SMANUAL
Intel Platform, High Performance PPC 11
1.3 System Specification
Table 1.1 System Specification
Form Factor Mini-ITX
CPU Socket Socket 479 or CPU on board
CPU Intel Pentium M/Celeron M up to 2.0GHz
Front Side Bus 400 MHz
Chipset Intel 855 GME/852 GM ICH4
Memory One 184-pin DDR DIMM Max.1GB
BIOS Award 4Mbit
VGA Controller Intel 855GME integrated
VGA Memory Shared memory Max. 64MB
LCD Support 24-bit LVDS (dual channel)
Ethernet Intel ICH4 integrated + PHY 82565EZ
Intel 82541 GI Gigabit Ethernet
Audio Built-in audio+AC97 codec
IDE 2 U DMA33/66/100
SATA N/A
Super I/O Chipset W83627HF
Parallel 1 SPP/EPP/ECP port
Serial 2 RS232
Fire Wire 2 1394
USB 2 port on board Pin header for 4 ports(USB 2.0)
KB / Mouse Connector PS/2
DVD（Optional）Standard Slim DVD ROM/Combo/Dual
(15” to 19”)
Watchdog Timer 256 Ievels
Expansion Slots Mini PCI , Internal/socket
Power Adapter DC In 12V or 19V
Operation temperature 0~45(°C)
IP65 Optional

PanelPC USER’SMANUAL
Intel Platform, High Performance PPC 12
1.4 LCD Specification
Table 1.2 LCD Specification
Item Size Resolution Display Colors
R08B89T- XXM1 640x480 262144
(6bit / colors)
R08B89T- XXU1 800x600 262144
(6bit / colors)
R08B89T- XXT1 800x600 262144
(6bit / colors)
R10B89T- XXP1 800x600 262144
(6bit / colors)
R10B89T- XXP3 640x480 260K
R10B89T- XXU1 800x600 262144
(6bit / colors)
R10B89T- XXH1 1024x768 262144
(6bit / colors)
R10B89T- XXM2 800x600 16.7M
(8bitS/color)
R12B89T- XXL1 800x600 262144
(6bit / colors)
R12B89T- XXL2 800x600 262,144
(6bit/colors)
R12B89T- XXM1 800x600 262144
(6bit / colors)
R12B89T- XXM2 1024x768 262,144
(6bit/colors)
W12L100- XXM4 1280x800 262,144
(6bit/colors)
R15B89T- XXC3 1024x768 16.2M
(6bit+FRC)
R15B89T- XXC5 1024x768 16.2M
(6bit+FRC)

PanelPC USER’SMANUAL
Intel Platform, High Performance PPC 13
R15B89T- XXA1 1024x768 262,144
(6bit/colors)
W15B89T- XXM2 1280x800 262,144
(6bit/colors)
W15B89T- XXM3 1280x800 262,144
(6bit/colors)
W17B89T- XXA1 1280x768 16.2M
(6bit+FRC)
R17B89T- XXA3 1280x1024 16.2M
(8bit/colors)
R17B89T- XXM1 1280x1024 16.2M
(8bit/colors)
R19B89T- XXM1 1280x1024 16.7M
(8bit/colors)
R19B89T- XXA1 1280x1024 16.2M
(6bit+FRC)
R20B89T- XXA2 1600x1200 260K
W20B89T- XXA3 1366x768 16.2M
(6bit+FRC)
W23B89T- XXQ1 1280x768 16.7M
(8bit/colors)
W26B89T- XXA2 1280x768 16.7M
(8bit/colors)
W32B89T- XXA1 1366x768 16.7M
(8bit/colors)
W37B89T- XXA2 1366x768 16.7M
(8bit/colors)
W42B89T- XXL1 1366x768 16.7M
(8bit/colors)

PanelPC USER’SMANUAL
Intel Platform, High Performance PPC 14
1.5 Mechanical Drawing
Figure 1.2 Dimensions of the R15B89T-IPC3

PanelPC USER’SMANUAL
Intel Platform, High Performance PPC 15
1.6 Input / Output Devices
The following figure shows the I/O arrangement of the Panel PC. The backside of
the chassis contains most of the connectors.
1 Power On/Off
&Reset
Put on/off and reset the power on your computer. The
Power hot key is located in the right of upward view in the
Panel PC.
2 COM port 9-pin male Serial Port connector that can attach a serial
mouse or other serial devices directly to the port.
3 USB port USB-compatible devices can be plugged directly into the
USB 2.0 port.
4 RJ-45 port Connect a network cable to the standard RJ-45 port and
get connection to the Local Area Network (LAN).
5 IEEE1394 6-pin IEEE1394 connector that can attach some digital
electronic instruments as DV, DSC to the port.
6 LPT port 25-pin female parallel port that connect to printer.
7 DVI port A DVI port that connect PPC to other LCD monitor.
8 PS/2 port Connect Keyboard to the PS/2 port.
9 PS/2 port Connect Mouse to the PS/2 port.
10 DC-in jack Connect the power cord to the AC outlet, and connect the
power to the monitor through the AC/DC adapter.
1 Power On/Off
&Reset
10 DC-in
9PS/2 Mouse
8PS/2 Keyboard
4RJ-45 port
6LPT port
7DVI output
5IEEE1394
2COM port
3USB port

PanelPC USER’SMANUAL
Intel Platform, High Performance PPC 16
Hardware Installation
This chapter gives hardware installation details to the Panel PC.
Sections include:
zHDD Installation
zDVD ROM Installation
C A P T E R
2

PanelPC USER’SMANUAL
Intel Platform, High Performance PPC 17
Chapter 2 Hardware Installation
The PPC is a PC-based industrial computer that is housed in aluminum alloy front
panel and heavy-duty steel chassis. And the following section will show the HDD
and DVD-ROM installation process.
2.1 DVD ROM Installation
The PPC has a Standard Slim DVD ROM/Combo/Dual for choice (15” to 19”).
When installing the DVD ROM, please follow the steps below:
Step 1. Take out the screws and remove the PPC back cover.
Step 2. Fasten the DVD ROM to the drives shelf by 4 screws.
Step 3. Fasten screws on the side cover of the PPC.
DVD ROM 3.5” 1.44MB
+ Card Reader
Figure 2.1 DVD ROM position of the R15B89T-IPC3

PanelPC USER’SMANUAL
Intel Platform, High Performance PPC 18
2.2 HDD Installation
The PPC has a IDE connector for 3.5” HDD, the user can install 3.5”HDD easily by
removing the side cover of HDD drive bay.
If the user intends to install DVD ROM and HDD, follow the steps below：
Step 1. Take out the screws and remove the PPC back cover.
Step 2~4. Fasten DVD with shelf by 4 screws. Fix DVD ROM within the Panel PC
with 4 screws. Connect IDE cable to the DVD IDE pin connector. Match pin
1 of the DVD and the pin 1 of the cable.
Step 5~6. Fasten the HDD to the drives shelf by 4 screws.
Step 7. Fix HDD within the Panel PC above the DVD ROM. Fasten the HDD drive
shelf inside with 4 screws.
Step8. Use the IDE cable to connect the HDD to the IDE pin connector. Match pin 1
of the HDD and the pin 1 of the cable. Connect HDD power connector as
the picture showed below.
Step 9. Fasten screws on the side cover of the PPC.
1 2
3 4

PanelPC USER’SMANUAL
Intel Platform, High Performance PPC 19
5 6
7 8
Figure 2.2 HDD Installation of the R15B89T-IPC3
