INSTALLATION GUIDE
Corvette Digital Dash Panel
Part Number: DP2002
Year Series: 1978 - 1982
* Always disconnect the battery before attempting any electrical work on your vehicle.*
KIT COMPONENTS
◊ Three (3) Digital Circuit Boards (speedometer, tachometer and 5-gauge cluster)
◊ Two (2) Smoked Acrylic Lenses (including horseshoe.)
* Peel off protective covering from both sides
◊ Two (2) Temperature Sending units (S8013)
◊ One (1) Oil Pressure Sending units (S8434)
◊ One (1) Universal Speedometer Sensor (S9013)
◊ One (1) Mounting Kit
* 6 6/32” screws, 6 nylon spacers, 6 c-brackets, and 6 flat nylon washers
INSTRUMENT INSTALLATION:
Tools needed:
Phillips (cross-head) screwdrivers
Tiny jewelers/electronics flat screwdrivers
Allen key drivers
Small sockets
Nylon spud wedges (small pry bar)
Miscellaneous: wire, wire nut/splices, and nylon zip ties

2 –DP2002 Intellitronix (rev.10/2017) www.intellitronix.com
Summary:
You will be reusing the original factory (OEM) bezels and fasteners, so work carefully and keep
track of the parts upon disassembly. There are 2 phases to this installation: the main instrument
bezel (Speedo and Tach) and the center console ancillary gauges. In each phase you will remove
the factory housings, pull out and set aside the current existing gauges (whether OEM or
aftermarket) and replace them with your new Intellitronix digital gauge boards. Finally, you will
reassemble the bezel/housing back into the dash/console. If you are not comfortable performing
auto electric work, seek professional installation. If you have done this or a similar procedure
previously, you may want to advance to the WIRING INSTRUCTIONS on page 4.
Be Advised: This process can take several hours the first time, depending upon your ability and
experience.
Main Bezel
Removal:
Remove 5 Phillips screws from the Speedo panel to release the clear plastic lens. You may need
nylon spuds for this. Repeat for Tach panel.
Remove 6 Allen head screws to release inner black frame.
Remove 3 Nut-head screws to unfasten the Speedo, and another 3 to unfasten the Tach.
Remove 3 Phillips screws to release the small kick panel beneath the steering column to ease under-
dash access.
Remove the center section of the heater ducting by jiggling carefully, allowing for easier access.
Reach up behind the dash and depress the retaining clip on the Speedo cable while pulling the
cable away from the gauge to release the Speedo.
Reach up behind the dash and pinch the Tach coupler, then pull away from the gauge to release the
Tach.
Reach up behind the dash and twist out the factory bulbs behind the Speedo and Tach, but leave the
bulbs in the center column for the turn signals and other warning lights.
Installation:
Install the new Speedo board by passing the wires through the
empty cable hole, and press the board’s tabs into the housing
depressions, and fasten with OEM nut head screws. Prepare the
Tach board for installation by fastening the included horseshoe
adapter (you can peel off the protective film) to the outer edge
of the board using the included Phillips screws and locking nuts.
Install the Tach board by clipping the black, red, and green
alligator clips to the left, top, and bottom terminals respectively,
as in figure 1, and pass the remaining leads through an empty
bulb hole. Fasten the board with OEM nut head screws.
(figure 1)
Reach up behind the dash and re-attach the Tach coupler to the housing. It needs to be plugged in,
to provide power to the Tach and the turn signal indicators and other warning lights.
Remove the protective film from both sides of the new smoke tinted acrylic lens, and mate it to the
OEM black plastic housing such that the tabs align with the slots. (You may want to clear away any
dust.)
Install the new smoked lens and OEM housing over the gauge boards and fasten with 6 OEM Allen
head screws.
Re-Install the OEM clear plastic lens using the OEM Phillips screws.

3 –DP2002 Intellitronix (rev.10/2017) www.intellitronix.com
Center Console
Console Removal:
Remove the car radio from the console. Procedure will vary depending on what unit has been
installed.
Remove 4 Phillips screws from the black plastic console faceplate to release it.
Pull the entire vertical section out, jiggling around the upper dash edge, being careful not to
damage the heater control switches.
Reach behind and pinch the ancillary gauge coupler to disconnect.
Disconnect the upper accent light coupler.
Remove this upper console from the car and take it to your workbench.
Gauge Removal:
You will be removing each of the gauges from the metal housing a/k/a “bucket”, and then
reassembling the bucket with the new digital board and smoked acrylic cover inserted.
Remove the bulbs for the old OEM gauges, but not for the 4 warning lights.
Use a tiny jewelers flathead to unscrew the (eyeglasses size) retaining screw in the center of the
clock knob, and put it somewhere safe like a magnetic parts tray or piece of tape.
Unscrew the plastic clock knob until it comes off.
Remove the nut-head screws from the back of the panel to release the metal bucket from the black
plastic console.
Remove the 3 nuts from the back of each of the 5 gauges in turn, using deep sockets, nut drivers, or
pliers.
Set aside the OEM gauges.
Digital Panel Installation:
Center the new digital dash panel board into the bucket, and gently but firmly press it in.
Route the new panel wires out through a hole the back of the bucket.
Align the smoked acrylic over the digital board, and the OEM clear plastic over that.
Make sure the colored warning light covers are still in place in the black bezel.
Flip everything over and secure it to the back of the black plastic console bezel with the 4 OEM
screws.
Make sure the flexible circuit is still attached to the back of the bezel to power the 4 warning lights.
Make sure the 4 warning light bulbs are still in place.
The center console is now ready to re-install.
Console Re-installation:
Plug in the upper accent light coupler.
Plug in the ancillary gauge coupler to power the warning lights.
Work the console back into its original position, being careful of the heater control switches.
Secure the front bezel to the dash with the 4 OEM Phillips screws that came out.
Do not reinstall the car radio yet, until you have completed the wiring connections to the sensors.
Congratulations, you are done with this part!
Running wires
Wires need to be run between the digital dash panel boards and the supplied sensors, to send a
signal to each gauge, plus power and ground. Power should be a good clean, switched 12V source,
and ground should be solid bare metal such as engine block or unpainted frame members. How and
where you run these wires will vary depending on your preferences, and how your car is set up. A
good practice is to poke through into the engine bay via an existing grommet, and it is often easiest
to fish the wires though in a staggered manner if the grommet is tight. Tuck in the wire runs behind
existing components to achieve a clean look. Secure the wires with zip ties at intervals. Make sure
the new wiring doesn’t interfere with gas or brake pedals. The rest is up to you.

4 –DP2002 Intellitronix (rev.10/2017) www.intellitronix.com
WIRING INSTRUCTIONS
Note: Automotive circuit connectors are the preferred method of connecting wires. However, you
may solder if you wish.
Note: If doing an LS engine swap, pick up the tach signal wire from the ECM/ECU and then set
the tach switch to 4-cylinders. You may also need to order the Intellitronix LS Engine Swap
Adapter Kit –for Series 1, 2 and 3 engines. The part number is 8014LS. If you are getting the tach
signal from the ECU, the resistor in the adapter kit will help pull a stronger signal for the
tachometer. If your engine is a 4 cylinder, please call Tech Support at Intellitronix, as you may
need to send the gauge back to us to be reconfigured. There is no charge for this additional
service.
Ground –Black This is the main ground for the display system. A wire should be run from this
board to the vehicle’s engine block ground. Use 18 AWG or larger wire to ensure sufficient
grounding. Proper vehicle grounding is extremely important for any gauges (or electronics) to
operate correctly. The engine block should have heavy ground cables to the battery, frame, and
firewall. Failure to properly ground the engine block, senders, or digital dash panels can cause
incorrect or erratic operation.
Power –Red Connect the power terminal to accessory +12V power from the fuse panel or vehicle
wiring harness. This terminal should have power when the key is on or in accessory position. Use 18
AWG wire to ensure the system receives a sufficient power feed.
Speedometer –White If your vehicle has a mechanical speedometer cable from the transmission,
disconnect it and thread the new electronic sensor onto the transmission. This unit comes with a 3-
wire sensor. If you are using this sensor, the white wire is the speed signal; connect this to the
speed signal wire on your gauge. The red and black wires in the cable are switched power
(12VDC) and ground, respectively. Twisting the ground and signal wires around each other will
provide an additional level of interference protection. The speed signal wire should not be routed
alongside the tachometer, ignition, or any other high-current or high-voltage wires. For vehicles
which have a vehicle speed signal from a transmission -- one wire goes to the speedometer, and the
other to the ground -- or ECM. Tap into the VSS wire (consult a vehicle service manual or wiring
diagram to determine the correct wire color) and connect it to the white speed sending wire on the
digital dash.
--OR --
Speedometer –White If your vehicle has an electronic vehicle speed signal from a transmission --
one wire goes to the speedometer, and the other to the ground -- or ECM. Tap into the VSS wire
(consult a vehicle service manual or wiring diagram to determine the correct wire color) and
connect it to the white speed sending wire on the digital dash. The speed signal wire should not be
routed alongside the tachometer, ignition, or any other high-current or high-voltage wires. Twisting
the ground and signal wires around each other will provide an additional level of interference
protection
Note: If your vehicle is equipped with an electronic transmission, your electronic vehicle sender will
have either two or three wires.
Trip/Cal Recall Button –Grey There are two long grey wires connected to a push-button on the
speedometer board. Mount the button in a convenient location such as under the steering column so
that you may easily reset your trip odometer or other speedometer functions. Alternatively, your
speedometer may have a small pushbutton which will accomplish these same settings.
To ensure that the ignition system does not interfere with any other dashboard functions, do not

5 –DP2002 Intellitronix (rev.10/2017) www.intellitronix.com
run the tachometer wire alongside any other sender or input wires. Do not use solid core spark plug
wires with this dashboard system. Solid core ignition wires cause a large amount of electromagnetic
and radio frequency interference which can disrupt the system’s operation.
Tachometer (memory capable) –Green
If your vehicle has a separate ignition coil, connect the green wire to the negative (-) side of the
coil –the wire that goes to the points or electronic ignition module.
If your vehicle has a GM HEI ignition, connect to the terminal marked ‘TACH’, or, on some systems,
a single white wire with a spade terminal.
If your vehicle has an after-market ignition –some systems will connect to the TACH output
terminal.
If your vehicle has a computer controlled ignition system, consult the service manual for the wire
color and location.
If your vehicle has a magneto system, connect the tach signal wire to the negative side of the coil.
Do not connect the tach terminal to the positive (+ or high voltage) side of the ignition coil.
Note: The default setting for this dash is for an 8-cylinder engine. If the engine you are using is
smaller, the dash unit will have to be returned to us to be re-set.
To recall the highest RPM achieved, simply press and release the button near the tach readout. To
reset the peak RPM value, press and hold the button until the RPM displayed value is zero.
Dimmer –Purple Connect to the parking lights to dim the LEDs 50% when the headlights are on.
However, do not connect to the headlight rheostat control wire, or the dimming feature will not work
properly.
Fuel - Yellow The fuel gauge sending unit is not normally supplied because the display system
can use the existing fuel level sending unit in the tank in most cases. If your wiring harness already
has a single wire routed through the vehicle for the fuel sender then it may be used. If using a wire
from an external harness, make sure that the wire does not have power. Fuel senders reference their
ground from the sender mounting plate. Connect the yellow wire to the factory sending unit.
Oil Pressure –Orange Replace the existing oil pressure sending unit with the unit included. Do
not use Teflon tape or other sealer on the new sending unit’s threads. This will avoid inaccurate
ground connections as the sending units get their ground from the threads. The oil sender gets its
ground from the threading into the engine block, thus proper grounding is crucial. Connect to the
sending unit.
Water –Blue This gauge is incompatible with other sending units, so you must replace the
existing water temperature sending unit with the included sender. Do not use Teflon tape or other
sealer on the new sending unit’s threads to avoid inaccurate readings. Connect the blue wire to the
sending unit.
Volt –Pink Connect the alternator wire from the engine to the pink wire on the dash panel.
Oil Temp –Orange/White Replace the existing oil temperature sending unit with the unit
included. Do not use Teflon tape or other sealer on the new sending unit’s threads, to avoid
inaccurate readings. Connect the orange/white wire to the sending unit.

6 –DP2002 Intellitronix (rev.10/2017) www.intellitronix.com
DIGITAL PERFORMANCE SPEEDOMETER
Your Intellitronix dash panel is equipped with our Digital Performance Speedometer. This electronic
speedometer displays speed and includes an odometer, trip meter, high speed recall, 0 - 60 time,
and quarter-mile elapsed time. It can be calibrated with the push-button to adjust the speedometer
for different tire sizes, wheel sizes, and gear ratios. The single push-button is used by a quick tap to
toggle between odometer and trip meter. The microprocessor distinguishes between a quick tap
and a press and hold which will reset the trip meter in trip mode or display performance data in
odometer mode.
CALIBRATION
Note: If you are using the Intellitronix GPS Sending Unit, (S9020 –not included) the speedometer does not
need to be calibrated.
The speedometer leaves the factory with a pre-set industry standard setting of 8,000 pulses per
mile. Chances are that you may not need to recalibrate your speedometer, unless you have changed
the original tire size or the rear end gear ratio.
Note: Do not attempt to recalibrate your speedometer until after it is working properly and you have determined
that the speed is incorrect. The calibration procedure will NOT correct a faulty installation or improper wiring. If
you attempt to recalibrate your speedometer without making sure the speedometer is receiving pulses from the
sending unit, the speedometer will display ‘Err’ and default back to the factory settings.
To calibrate:
1. Locate a measured mile where you can safely start and stop your vehicle. By running the
vehicle over this measured distance, the speedometer will learn the number of pulses
outputted by the speedometer sensor during a specific measured distance. It will then use
this acquired data to calibrate itself for accurate reading. There is a small recall push-button
in the center of the panel used to calibrate and read all of the data stored in the speedometer.
After installing your speedometer according to the wiring instructions, when the ignition is on
it should immediately display the default screen of 0 MPH, if the vehicle is not moving.
NOTE: You will then need to drive your vehicle to the predetermined measured mile. During this
trip, the speedometer should read something other than 0 MPH. If it does not change, return and
locate the problem before continuing. Otherwise, proceed with the calibration.
2. Stop at the beginning of the measured mile with your vehicle running and in odometer mode
(NOT trip mode), press and hold the push-button until the odometer displays ‘HI-SP’. On its
own, the gauge will then cycle through the recorded performance in the following order: ‘0 –
60’, ‘1/4’, ‘ODO’, and ‘CAL’.
3. While ’CAL’ is displayed, quickly tap the push-button once. This will put the speedometer in
Program Mode. If you did not tap while ‘CAL’ is displayed, the pulses per mile will be
displayed on the odometer and the display will go back to MPH mode. Otherwise, you will
now see ‘CAL’ displayed along with the number ‘0’. This indicates that the microprocessor is
now ready for calibration.
4. When you are ready, begin driving on the metered mile. You will notice that the reading will
start counting up. The odometer will begin to display the incoming pulse count. Drive the
vehicle through the measured mile (speed is not important, only the distance traveled).
5. At the end of the mile, stop and press the push-button again. The odometer will now display
the new number of speedometer pulses that were registered over the distance. The odometer
will continue to display the pulse reading for a few seconds. Once it reverts to the default
mode, you have successfully calibrated your speedometer.

7 –DP2002 Intellitronix (rev.10/2017) www.intellitronix.com
Warning: If, while in ‘CAL’ mode, you do not move the vehicle and press the button again, the
microprocessor will NOT have received any data and the unit will display ‘Err’ and will revert
to the factory settings. At a minimum, drive some distance and return to the start if necessary. If
you miss stopping the display at ‘CAL’, simply repeat the steps.
Trip Distance
A single tap of the recall button will activate the trip meter in the odometer display. A decimal point
will appear which will indicate that you are in trip meter mode. Holding the recall button will clear
out the trip distance. To return to the default odometer display, tap the recall button again. The
decimal point will disappear, indicating that you are back in the default odometer display.
Setting the Odometer
While scrolling through ‘CAL’ mode you will see ‘ODO’ appear. This will allow you to enter the
vehicle’s actual mileage. Press the trip button again at this point and you will enter the odometer set
up mode. Press quickly to change the number of the digit on the right. Press and hold to advance to
the next digit. Do this for all 5 digits. For Example: To enter the mileage reading 23456 into the
odometer, at the ‘ODO’ prompt, tap the small black button (quickly) two times, until the number 2is
displayed. Then press and hold the button until the numbers 20 are displayed. Tap the button 3
times until 23 is displayed. Press and hold the button until 230 is displayed, and continue in this
manner until 23456 is displayed. The speedometer will advance to the home screen, five seconds
after the last number is entered.
Recording and Viewing Performance Data
Follow these steps to record and recall Performance Data (high speed, ¼mile ET, and 0-60 time):
1. Before each run, your car must be at a complete stop at the starting position. Press and hold
the push-button as it cycles through the performance data. At the end, the odometer will
reset and all performance data will be cleared. This will not affect your stored calibration
value or the odometer reading.
2. Press the push-button until ‘HI-SP’ is displayed. The gauge will automatically cycle through
the performance data.
3. Start the run, pass, session, etc., as mentioned above.
4. When finished, repeat Step 2 to view the data gathered from the run. While stopped, you can
view this data as often as you wish. However, once it finishes scrolling one time, the memory
is ready to record new data and will begin recording again once the vehicle starts to move.
The highest speed measured over multiple runs will be retained in memory.
# # #

Made in America Lifetime Guarantee
Technical Support
Monday –Friday
9am to 5 pm EST
[phone]
[e-mail]
This product carries a limited Lifetime Warranty.
This warranty is limited to replacement or repair of the unit at the discretion of Intellitronix.
