Intellitronix S9020 User manual

1 - S9020 Intellitronix (rev.02/2017) www.intellitronix.com
Made in America Lifetime Guarantee
Thank you for purchasing this instrument from Intellitronix. We value our customers!
INSTALLATION GUIDE
Programmable GPS Speedometer Sending Unit
With High Speed Memory Recall
Part Number: S9020
This Unit MUST have a clear view of the sky in order to function properly!
* Always disconnect the battery before attempting any electrical work on your vehicle.*
Note: Pushbutton for high speed memory recall not included
WIRING INSTRUCTIONS
Note: Automotive circuit connectors are the preferred method of connecting wires. However,
you may also solder if you wish.
Ground - Black Connect the ground wire directly to the engine block. Be sure to
thoroughly clean the contact areas to ensure a good connection.
Power - Red Connect to a switched +12V source (such as the ignition circuit).
Speedometer - White Connect to the speedometer gauge. If using an Intellitronix gauge,
the wire will be white on the gauge.
Recall - Grey (Optional) Connect to a pushbutton switch with the other terminal connected
to a ground source.
CONFIGURATION
There are two DIP switches on the circuit board, which allow you to configure the number
of pulses per mile that the sending unit will generate. These settings are:
S1
S2
Ppm
OFF
OFF
16,000
ON
OFF
8,000
OFF
ON
16,000
ON
ON
4,000
Note: There are two (2) separate settings for 16,000 pulses. Both work correctly.
Note: The first time the GPS receiver is turned on it might take up to 15 minutes to detect its location
and start communicating with the circuit. There will not be any delay once the unit is wired. The
following LED indicators are designed for easy status detection:
Red - Power On; Yellow - Data Link with Satellite; Green –Unit is Receiving Data.

Made in America Lifetime Guarantee
Technical Support
Monday –Friday
9am to 5 pm EST
[phone]
[e-mail]
This product carries a limited Lifetime Warranty.
This warranty is limited to replacement or repair of the unit at the discretion of Intellitronix.
