Inter-m PP-100 User manual

Operation Manual
Pre Amplifier
PP-100
PP_100_E 2009.1.30 9:47 AM 페이지 2

PRE AMPLIFIER
Welcome
Welcome
A personal welcome to you from the management and employees of Inter-M
All of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value,
and we are delighted you have purchased one of our products.
We sincerely trust this product will provide years of satisfactory service, but if anything is not to your complete
satisfaction, we will endeavor to make things right.
Welcome to Inter-M, and thank you for becoming part of our worldwide extended family!
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING
To prevent fire or shock hazard, do not
expose the unit to rain or moisture.
*WARNING FOR YOUR PROTECTION PLEASE READ THE FOLLOWING-WATER AND MOISTURE: Unit should not be used near water(e.g.
near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, etc). Care should be taken so than objects do
not fall and liquids are not spilled into the enclosure through openings.
*Do not install this equipment in a confined space such as a book case or similar unit.
*This apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such vases, shall be placed on the apparatus.
*This apparatus shall be connected to a mains socket outlet with a protective earthing connection.
*
It has heed to be easy to disconnect the device. To disconnect the device from power, separate AC input cable from inlet or unplug the AC Cord.
CAUTION
*These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any servicing
other than that contained in the operating instructions unless you are qualified to do so.
NOTE
*This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will
be required to correct the interference at his own expense.
This symbol is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
This symbol is intended to alert the user to the
presence of important operation and maintenance
(servicing) instructions in the literature accompanying
the appliance.
Caution: To prevent electric shock do not use this (polarized) plug with
an extension cord, receptacle or other outlet unless the blades
can be fully inserted to prevent blade exposure.
Attentions: Pour prévenir les chocs électriques ne pas utiliser cette
fiche polarisée avec un prolongateur, une prise de courant
on une autre sortie de courant, sauf si les lames peuvent
étre insérées à fond sans en laisser aucune partie à
découvert.
PP_100_E 2009.1.30 9:47 AM 페이지 3

PRE AMPLIFIER
1
PP-100
Contents
Contents
Unpacking.......................................................................................................................................2
Installation
Environment....................................................................................................................................2
Important Safety Instructions.............................................................................................................2
Features............................................................................................................................................3
Operation........................................................................................................................................3
Precautions when setting up your utilization environment.....................................................3
Front Panel ......................................................................................................................................4
Rear Panel.......................................................................................................................................5
Applications ....................................................................................................................................7
Fabricate The Cables .....................................................................................................................8
RJ45 Data Protecting Connector (Ethercon)...............................................................................8
Block Diagram................................................................................................................................9
Specifications................................................................................................................................10
Service
Procedures....................................................................................................................................11
Schematic.....................................................................................................................................11
Parts List .......................................................................................................................................11
Variations and Options...............................................................................................................11
Warranty .......................................................................................................................................11
PP_100_E 2009.1.30 9:47 AM 페이지 4

PRE AMPLIFIER
Unpacking
2PP-100
Unpacking
Although your PP-100 is neither complicated nor difficult to operate, we recommend you take a few minutes to
read this brief manual and familiarize yourself with the important information regarding product features, setup
and operation.
As with most electronic devices, we strongly recommend you retain the original packaging. In the unlikely event
the product must be returned for servicing, the original packaging (or reasonable equivalent) is required.
Installation
Installation
Environment
Never place this product in an environment which could alter its performance or reduce its service life. Such
environments usually include high levels of heat, dust, moisture, and vibration.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and
the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped. S3125A
S3125A
PP_100_E 2009.1.30 9:47 AM 페이지 5

PRE AMPLIFIER
3
PP-100
FeaturesFeatures
Operation
Precautions when setting up your utilization environment
Features
- IPC SYSTEM INTERLOCKING
It interlocks with SI-100 and is available to connect ANALOG/DIGITAL amplifier in the output terminal
according to a purpose.
- 6 channel pre-amplifier
It is possible to conduct six broadcastings with the single CAT5 line.
- Remote control using work
Available to automatically allocate an amplifier ID and recognize.
- Self broadcasting function using a local input
- Make available to be interfaced with other devices using an output interface.
- Make available to control each of the output volumes for 6 channels.
Operation
This pre-amplifier offers an expansion of output to IPC system, a remote control of the system through
CAT5 cable, and a support of local input to XLR/PHONE jack.
And it has 4 output interfaces and 6 input interfaces, which is utilized to the grand output amplified in
the rear part.
Precautions when setting up your utilization environment
Environment setting up menu of SP-100 is commonly utilized then.
PP_100_E 2009.1.30 9:47 AM 페이지 6

PRE AMPLIFIER
4PP-100
Front Panel
Front Panel
1. POWER LED
It becomes stand-by that Red LED lights when power is supplied to the device.
And it becomes Operational State that Green LED lights when the power supply is switched ON by pressing
the Power Switch in the rear part.
2. LCD DISPLAY
It displays a communicating status with the set and a channel volume level.
3. SIGNAL OUTPUT INDICATING LED
It indicates Pre-out levels in each of the channels and lights Green LED for a signal output exceeding a pre
set level.
4. FAULT INDICATING LED
It indicates an operating status of the communication line and lights Red LED when it happens an abnormality
in communication.
PP_100_E 2009.1.30 9:47 AM 페이지 7

PRE AMPLIFIER
5
PP-100
Rear Panel
Rear Panel
1. LOCAL INPUT
It is the Line Input Jack and MIC Input Jack. According to a local input volume, XLR input is to -60dBV~-
16dBV and Phone input is to -43dBV~0dBV.
Caution) If high level signal is inputted to MIC Jack, AMP or SPEAKER in the rear part can be damaged due
to signal clipping.
2. LOCAL INPUT VOLUME
The volume adjusts levels of XLR and PHONE input signals.
3. CONTROL OUTPUT
The interface sets up 4 operations of the Control output in Setup Mode of SI-100. ( It is set up in SI-100.)
Setting up operation specification that Control output is on, when one signal of EM,BGM,RM,LOCAL,SCHED,ALL is
inputted to CH1 ~CH6. Control output can be set up to 4.
12 3 45 6
111098 12
7
PP_100_E 2009.1.30 9:47 AM 페이지 8

PRE AMPLIFIER
6PP-100
4. CONTROL INPUT
The interface sets up 6 operations of the input interface in Setup Mode of SI-100. ( It is set up in SI-100.)
5. ID SETTING SWITCH
It selects manual Mode or Auto Mode and sets up ID.
1) When SW 8 is up-wards : Manual Mode.
Assign ID up to 1~128 AMP in manual by combining SW 1~7.
2) When SW 8 is down-wards : It assign ID automatically.
6. CHANNEL VOLUME
The volume adjusts pre-out level of each channels up to CH1~CH6.
( MIN : Output mute , MAX : 0dB , Vol 60: -5dB , Vol 70 : 0dB)
7. POWER SWITCH
It turns ON/ OFF(stand-by) of PP-100 power.
8. NETWORK INPUT JACK ( LINK IN )
It is the input terminal for digital signals and control signals coming from SI-100.
9. NETWORK OUTPUT JACK ( LINK OUT )
It is the output terminal that makes by pass digital audio signals and control signals coming from SI-100.
10. PRE-OUT JACK
It is the jack that transmits Pre-out outputs to CH1 ~CH6.
11. AC INPUT
It is the AC power input terminal.
It is available to input a power of 100 ~240V, 50/60Hz free voltage.
12. DC INPUT
It is an emergency power input terminal of 24V.
It will be automatically converted to the DC power supply terminal when it happens a fault in the AC power
supply.
Control output is as follow:
1) If interface is off, connect C with NC.
2) If interface is on, connect of C and NC is OFF, and connect
NO with NC.
NO
NC C
CH1~CH6 of local input to
any output channel to set
about the 6 Control inputs.
PP_100_E 2009.1.30 9:47 AM 페이지 9

PRE AMPLIFIER
7
PP-100
Applications
Applications
※The shape of outlets can be different according to country requirements.
PP_100_E 2009.1.30 9:47 AM 페이지 10

PRE AMPLIFIER
8PP-100
Fabricate The Cables
RJ45 Data Protecting Connector (Ethercon)
Fabricate The Cables
SI-100 and PP-100 device are wired with CAT5 cable.
* Caution : Please fabricate CAT5 CABLE for Direct.
RJ45 Data Protecting Connector (Ethercon)
*Caution :[Relating to fabrication of protecting connectors]
Connector between SI-100 and PP-100 :NE8ME Protecting Connectors are applied in both of the UTP
cable ends that are assembled together.
PP_100_E 2009.1.30 9:47 AM 페이지 11

PRE AMPLIFIER
9
PP-100
Block Diagram
Block Diagram
MIC
1
2
3
LINE
HEAD AMP A/D
DECODER
RX
TX
EXT IN
6CH
MICOM
DSP D/A XLR JACK
6CH
LPF
LEVEL LED DRIVE
LCD DISPLAY LED DISPLAY
BALANCE OUT
EXT OUT
4CH
VOLUME
6CH
SMPS
LINK
BUFFER
LINK INLINK OUT
PP_100_E 2009.1.30 9:47 AM 페이지 12

PRE AMPLIFIER
10 PP-100
Specifications
Specifications
PP-100
NNEETTWWOORRKK IINNTTEERRFFAACCEE
CONTROL RS-422
CONNECTORS RJ-45 JACK
CABLE TYPE UTP CAT-5
CABLE LENGTH 100m Less than
AAUUDDIIOO IINNPPUUTT
DDIIGGIITTAALL IINNPPUUTT((RRJJ--4455 IINNPPUUTT))
OUTPUT LEVEL 0dBV
INPUT SENSITIVITY(at 0dBV output) 0dBV
S/N (20kHz LPF,A-weight filter) 85dB Better than
T.H.D (at 0dBV output,20kHz LPF) 0.1% Less than
LLooccaall IInnppuutt ((XXLLRR iinnppuutt))
INPUT SENSITIVITY(at 0dBV output) -60dBV
S/N (20kHz LPF,A-weight filter) 60dB Better than
T.H.D (at 0dBV output,20kHz LPF) 0.1% Less than
FREQUENCY RESPONSE 100Hz ~ 20kHz (±3dB)
LLooccaall IInnppuutt ((PPHHOONNEE iinnppuutt))
INPUT SENSITIVITY(at 0dBV output) 0dBV
S/N (20kHz LPF,A-weight filter) 75dB Better than
T.H.D (at 0dBV output,20kHz LPF) 0.1% Less than
FREQUENCY RESPONSE 100Hz ~ 20kHz (±3dB)
Operation Temperature -10℃ ~ 40℃
Power Source AC: 100-240V, 50/60Hz , DC 24V
Power Consumption 15W
Weight (SET) 6.5kg / 14.33Ib
Dimensions (SET) 440(W)x88(H)x388(D)mm / 17.3(W)x3.46(H)x15.27(D)in
※ The specifications and performances may be under modification without a prior notification
according to our circumstances.
PP_100_E 2009.1.30 9:47 AM 페이지 13

PRE AMPLIFIER
11
PP-100
Service
Service
Procedures
Take steps to insure the problem is not related to operator error or other products within the system. Information
provided in the troubleshooting portion of this manual may help with this process. Once it is certain that the
problem is related to the product contact your warranty provider as described in the warranty section of this
manual.
Schematic
A Schematic is available by contacting your warranty provider.
Parts List
A Parts List is available by contacting your warranty provider.
Warranty
Warranty
Warranty terms and conditions vary by country and may not be the same for all products. Terms and conditions
of warranty for a given product may be determined first by locating the appropriate country which the product
was purchased in, then by locating the product type.
To obtain specific warranty information and available service locations contact Inter-M directly or the
authorized Inter-M Distributor for your specific country or region.
Variations and Options
Variations and Options
Variations
Variations of this product exist to reflect the variations in AC power requirements throughout the world. Product
supplied through local sources are compatible with local AC power requirements.
Options
No optional items are available for this product.
PP_100_E 2009.1.30 9:47 AM 페이지 14

PRE AMPLIFIER
PP_100_E 2009.1.30 9:47 AM 페이지 15

3
PP-100
PP_100_E 2009.1.30 9:47 AM 페이지 16

MADE IN KOREA
2009 124086
Inter-M, Ltd. (Korea) began operations in 1983.
Since then, Inter-M has grown to become one of the largest manufacturers
of professional audio and commercial sound electronics equipment in the world.
Inter-M has gained worldwide recognition for its own branded products,
as well as private label manufacturing of electronics sold under other names (OEM).
The company is no longer just a Korean company, but rather a global company
that is truly international in scope, with factories and offices in Korea and China,
and sales and marketing operations located in Japan, Europe, and the U.S.A.
With more than 850 employees around the globe,
Inter-M is well-poised for further growth and expansion.
Inter-M Americas, Inc.
13875 Artesia Blvd. Cerritos, CA 90703 USA
TEL : [phone], FAX : [phone]
Home Page : http://www.inter-m.net, E-mail : [email protected]
Inter-M Corporation
Seoul OFFICE:653-5 BANGHAK-DONG, DOBONG-KU, SEOUL, KOREA
TEL : [phone]~8, FAX : [phone]
Home Page : http://www.inter-m.com, E-mail : [email protected]
PP_100_E 2009.1.30 9:47 AM 페이지 1
